Philips Philishave HQ 6735 User manual

ENGLISH 4
BAHASA MELAYU 16
BAHASA INDONESIA 29
TI”NG VI◊T 42
 54
64
76
87
HQ6735
3

Warning
◗Only use the HQ600 powerplug and the
charging stand supplied to charge the shaver.
◗The powerplug transforms 100-240 volts to
12 volts
C◗Make sure the HQ600 powerplug and the
charging stand do not get wet.
C◗The shaver runs at a safe low voltage of 12
volts.It is watertight and can be cleaned
under the tap.Do not rinse with water hotter
than 80cC.
◗For the best shaving results,shaving emulsion
should be pumped up frequently.
Charge indications
C◗As soon as you start charging the empty
shaver,the green pilot light will go on.
◗The red pilot light will blink when the
batteries are almost empty.
◗The red pilot light will blink a few times after
the shaver has been switched off.
Charging
Recharge,store and use the appliance at a
temperature between 5cC and 35cC.
The powerplug is suitable for mains voltages
ranging from 100 to 240V.
1Insert the small plug into the charging
stand and put the powerplug in the wall
socket.
ENGLISH4

C2Place the shaver in the charging stand.
C3Press until you hear a 'click'.
The shaver automatically switches off while
charging.
4When charging for the first time or after a
long period of disuse:leave the shaver to
charge continuously for 24 hours.
Charging normally takes approx. 8 hour.
A fully charged shaver has a cordless shaving time
of up to approx.40 minutes.
Inserting cartridges
The cartridges with moisturising NIVEA FOR
MEN shaving emulsion are available in boxes
containing five cartridges and one small plastic
pump.Do not throw the pump away:you will
need it for all five cartridges!
Use only Philishave NIVEA FOR MEN Cool Skin
(HQ160 or HQ161) cartridges.
For hygienic reasons,we advise you to insert a
new pump when you start using a new set of five
cartridges.
ENGLISH 5

Inserting the first cartridge
C1Take one cartridge from the box.Take the
pump (supplied in the same box) out of its
bag and push it into the cartridge until it
locks into position with a click.
C2Move the release slide downwards and
open the cover of the cartridge
compartment.
C3Slide the cartridge with the pump into the
shaver.It only fits properly if the white side
of the pump is pointing upwards.Close the
cover.
4Press the yellow pump button a few times
until the NIVEA FOR MEN shaving
emulsion appears.The shaver is now ready
for use.
Do not throw the pump away when you replace
an empty cartridge.You will need it for the other
cartridges.
The NIVEA FOR MEN shaving emulsion in this
cartridge will keep when stored at temperatures
between 0cC and +40cC.
ENGLISH6
12

Shaving
1Switch the shaver on by pressing the on/off
button once.
C2Press the yellow pump button to apply
NIVEA FOR MEN shaving emulsion to
your skin.Move the shaver over your skin,
making both straight and circular
movements.
3While shaving,press the pump button
frequently to apply more NIVEA FOR
MEN shaving emulsion so that the shaver
keeps gliding smoothly over your face.
Do not press the shaver too hard against your
skin while shaving.
If you prefer,you can wet your face first.
◗When you have run out of shaving emulsion,
you can also use the shaver without it on a
dry face.
◗Your skin may need 2-3 weeks to get
accustomed to the Philishave system.
4Switch the shaver off.
C5Put the protection cap on the shaver every
time you have used it,to prevent damage.
Remove the cartridge and clean the shaver if you
are not going to use the appliance for more than
one week.Rinse the shaver after each shave.
ENGLISH 7

Trimming
The shaver has a separate trimmer for grooming
sideburns and moustache.
1Switch the shaver off.
Clean the shaver before you attach the trimmer.
C2Press the release button and pull the
shaving unit off the shaver.
C3Tilt the trimmer slightly backwards and fit
it onto the shaver.
4Remove the trimmer by pressing the
release button again.
Cleaning
Shaving unit
Rinse the shaving unit and the hair chamber with
hot water (60cC - 80cC) after every use.
1Switch the shaver off.
C2Press the release button and flip the
shaving unit open.
C3Clean the shaving unit and the hair
chamber by rinsing them under a hot tap
for some time.
Never dry the shaving unit with a towel or tissue
as this may damage the shaving heads.
ENGLISH8
2
1

C4Rinse the outside of the shaver.
Make sure the inside of the shaving unit and the
hair chamber have been cleaned properly.Close
the shaving unit and shake off excess water.
Charging stand
1Unplug the charging stand.
2Clean the charging stand with a moist
cloth.
Trimmer
1Clean the outside of the trimmer with the
brush supplied after every use.
C2Flip the trimmer open to clean it on the
inside.
C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
Replacing the shaving heads
Replace the shaving heads every two years for
optimal shaving results.
1Switch the shaver off.
ENGLISH 9
OIL

C2Press the release button to open the
shaving unit.
C3Turn the wheel anti-clockwise and remove
the retaining frame.
C4Remove the shaving heads and place the
new ones in the shaving unit.
C5Reassemble the shaving unit by replacing
the retaining frame.Press the wheel and
turn it clockwise.
Replace damaged or worn shaving heads with
Philishave HQ167 Cool Skin heads only.
Storing
C◗After cleaning,the wet shaver can be placed in
the charging stand.
◗The appliance and the trimmer can be stored
in the pouch or cassette supplied.Whether
you have a pouch or a cassette depends on
your shaver version.
ENGLISH10
1
1
2
1
1

Disposal of batteries
The built-in rechargeable batteries contain
substances that may pollute the environment.
Remove the batteries when you discard the
shaver. Do not throw the batteries away with the
normal household waste,but hand them in at an
official collection point.You can also take the
batteries to a Philips Service Centre,which will
dispose of them in an environmentally safe way.
Only remove the batteries if they are completely
empty.
C1Let the shaver run until it stops,undo the
screws and open the shaver.
2Remove the batteries.
Do not put the shaver back into the charging
stand after the batteries have been removed.
Tip
◗The shaver comes with cartridges containing
two different kinds of shaving emulsion:an
emulsion for a sensitive skin and a fresh gel.
This gives you the opportunity to try them
out and discover which one suits your skin
type best.
ENGLISH 11

Troubleshooting
1Shaving heads do not move smoothly over
the skin:
BCause:not enough shaving emulsion has been
applied.
◗Press the pump button a few times until a
sufficient amount of NIVEA FOR MEN shaving
emulsion has been released to allow the
shaving heads to move smoothly over your
face again.
2Reduced shaving performance:
BCause 1:the shaving heads are dirty.The shaver
has not been cleaned immediately after use
and/or has not been rinsed long enough and/or
the water used to rinse the shaver was not hot
enough.
◗Clean the shaver thoroughly before you
continue shaving (see 'Cleaning').
BCause 2:long hairs are obstructing the shaving
heads.
C◗Remove the retaining plate.
C◗Clean the cutters and guards.
Do not clean more than one cutter and guard at
a time,since they are all matching sets.If you
accidentally mix up the cutters and guards,it
ENGLISH12
1
1
2

could take several weeks before optimal shaving
performance is restored.
◗Remove the hairs.
◗Put the retaining plate back onto the shaving
unit.
BCause 3:shaving heads are damaged or worn.
◗Remove the retaining plate.
◗Remove the old shaving heads from the
shaving unit and replace them with new ones.
Damaged or worn shaving heads (cutters and
guards) must only be replaced with the original
Philishave HQ167 Cool Skin shaving heads.
◗Put the retaining plate back onto the shaving
unit.
3Shaver does not work when the on/off
button is pressed:
BCause:the batteries are empty
◗Recharge the batteries.
4Cover of the cartridge compartment
cannot be closed
BCause 1:the cartridge has not been inserted
correctly.
ENGLISH 13

◗Insert the cartridge correctly.It only fits
properly into the shaver if the white side of
the pump is pointing upwards.
BCause 2:the cartridge has not been pushed far
enough into the shaver.
◗Press the cartridge until it is properly seated.
5The NIVEA FOR MEN shaving emulsion
has changed colour or has turned watery.
BCause:the NIVEA FOR MEN shaving emulsion
has not been stored at the right temperature.
◗Take a new cartridge.
6Skin irritation occurs:
BCause 1:your skin has not yet become
accustomed to this shaving system.
◗Allow 2-3 weeks for you skin to get
accustomed to this shaving system.
BCause 2:the shaving emulsion irritates your skin.
◗Try the other type of shaving emulsion.
◗Wet your face before shaving with the shaving
emulsion.
If the irritation does not disappear after 24 hours,
we advise you to stop using the shaving emulsion
and to contact your doctor.
ENGLISH14

7In case of other problems:
◗See 'Information & service'
Accessories
The following accessories are available:
- HQ167 Philishave Cool Skin shaving heads.
- HQ160 NIVEA FOR MEN Cool Skin
(moisturizing shaving emulsion).
- HQ161 NIVEA FOR MEN Cool Skin
(moisturizing fresh shaving gel).
- HQ8000 powerplug.
- HQ100 Philishave Action Clean (shaving head
cleaner).
- HQ101 Philishave Action Clean refill (shaving
head cleaning liquid).
- HQ110 Philishave shaving head cleaner (shaving
head cleaning spray).
Information & service
If you need information or if you have a problem,
please visit the PhilipsWeb site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet).If there is no Customer Care Centre in
your country,turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
◗Keep these instructions for use for future
reference.
ENGLISH 15

Amaran
◗Guna hanya plag kuasa HQ600 dan penegak
cas yang dibekalkan untuk mengecas alat
pencukur.
◗Plag kuasa akan menukarkan 100-240 volt
kepada 12 volt.
C◗Pastikan plag kuasa HQ600 dan penegak cas
tidak basah.
C◗Alat pencukur ini beroperasi pada voltan 12V
yang rendah dan selamat.La juga kedap air dan
boleh dibersihkan di bawah paip air.Jangan
bilas menggunakan air yang lebih panas dari
80cC.
◗Untuk kesan cukuran yang terbaik,hendaklah
sentiasa pamkan emulsi pencukur.
Penunjuk cas
C◗SecepatAnda mula mengecas pencukur yang
kosong itu,lampu hijau dihidupkan.
◗Lampu panduan merah akan berkelip apabila
kuasa bateri hampir kehabisan.
◗Lampu panduan merah akan berkelip beberapa
kali selepas suis alat pencukur dimatikan.
Mengecas
Cas semula dan simpan alat pada suhu antara 5cC
dan 35cC.
Palam kuasa adalah sesuai bagi voltan kuasa antara
100 dan 240V.
1Masukkan plag kecil ke penegak cas dan
letakkan plag kuasa di soket dinding.
BAHASA MELAYU16

C2Letakkan alat pencukur di penegak cas.
C3Tekan sehingga anda terdengar bunyi 'klik'.
Alat pencukur akan secara automatik dipadamkan
semasa mengecas.
4Apabila mengecas untuk kali pertama atau
selepas jangka masa lama tidak digunakan:
biarkan alat pencukur dicaskan berterusan
selama 24 jam.
Masa mengecas biasanya lebih kurang 8 jam.
Alat pencukur yang telah dicas penuh tanpa wayar
mempunyai masa cukuran hingga lebih kurang 40
minit.
Memasukkan kartrij
Kartrij dengan pelembapan emulsi cukuran NIVEA
FOR MEN untuk Lelaki terdapat dalam kotak
mengandungi lima kartrij dan satu pam plastik
kecil.Jangan buangkan pam:anda akan
memerlukannya untuk kesemua lima kartrij!
Guna hanya Philishave NIVEA FOR MEN untuk
kartrij Sejukan Kulit Lelaki (HQ160 atau HQ161).
Untuk tujuan kesihatan,kami nasihatkan anda
untuk masukkan pam baru apabila mula
mengunakan lima set kartrij yang baru.
BAHASA MELAYU 17

Masukkan kartrij yang pertama
C1Ambil satu kartrij dari dalam kotak.Ambil
pam (yang dibekalkan di dalam kotak)
keluarkan dari dalam beg dan tolakkannya
ke dalam kartrij sehingga ia dalam
kedudukan terkunci dengan klik.
C2Alih dan lepaskan luncuran ke bawah dan
buka penutup bekas kartrij.
C3Luncurkan kartrij dengan pam ke dalam
alat pencukur.Ia akan benar-benar muat
jika bahagian putih pam mengarah ke atas.
Tutup dengan penutupnya.
4Tekan butang kuning pam beberapa kali
sehingga ternampak emulsi cukuran NIVEA
FOR MEN untuk Lelaki.Alat pencukur kini
sedia untuk digunakan.
Jangan buangkan pam apabila anda menggantikan
kartrij kosong.Anda akan memerlukannya untuk
kartrij yang lain.
Emulsi cukuran NIVEA FOR MEN untuk Lelaki di
dalam kartrij ini akan terjaga apabila disimpan
pada suhu antara 0cC dan +40cC.
BAHASA MELAYU18
12

Cukur
1Hidupkan alat pencukur dengan menekan
butang suis hidup/matikan 'on/off'.
C2Tekan pam kuning untuk menggunakan
emulsi cukuran NIVEA FOR MEN untuk
Lelaki kepada kulit anda.Alihkan alat
pencukur ke atas kulit anda,untuk
membuat kedua-dua pergerakan lurus dan
bulatan.
3Semasa bercukur,tekan butang pam kerap-
kali untuk menggunakan banyak emulsi
cukuran NIVEA FOR MEN untuk Lelaki
supaya alat pencukur akan meluncur rata di
muka anda.
Jangan tekan alat pencukur kuat kepada kulit anda
semasa bercukur.
Jika anda mahu,anda boleh basahkan dahulu muka
anda.
◗Apabila emulsi cukuran anda telah habis,anda
juga boleh menggunakan alat pencukur
tanpanya di atas muka yang kering.
◗KulitAnda dapat memerlukan 2-3 minggu
untuk menbiasakan diri dengan sistem
Philishave ini.
4Mematikan alat pencukur.
C5Tutupkan pencukur dengan tudung
perlindungan setiap kali selepas anda
gunakannya untuk mengelakkan kerosakan.
BAHASA MELAYU 19

Alihkan kartrij dan bersihkan alat pencukur jika
anda tidak mahu menggunakan peralatan lebih
daripada seminggu. Bilaskan alat pencukur setiap
kali selepas bercukur.
Perapian
Alat pencukur ini ada perapi berasingan untuk
membersihkan misai dan jambang.
1Mematikan alat pencukur.
Bersihkan alat pencukur sebelum anda pasangkan
perapi.
C2Tekan butang pelepas dan tarik unit
pencukur keluar dari alat pencukur.
C3Miringkan perapi kebelakang sedikit dan
muatkan ke dalam alat pencukur.
4Alihkan perapi dengan menekan butang
pelepas sekali lagi.
Pembersihan
Unit cukur
Bilas unit pencukur dan bekas rambut dengan air
panas (60cC -80cC) selepas digunakan.
1Mematikan alat pencukur.
C2Tekan butang pelepas dan petikkan unit
pencukur supaya terbuka.
BAHASA MELAYU20
2
1

C3Bersihkan unit pencukur dan ruang rambut
dengan membasuhnya seketika dengan air
panas.
Jangan keringkan unit pencukur dengan tuala atau
tisu,kerana ini akan merosakkan kepala alat
pencukur.
C4Bilas bahagian luar alat pencukur.
Pastikan bahagian dalam unit alat pencukur dan
bekas rambut telah dibersihkan dengan betul
Tutup bahagian cukuran dan goncangkan air yang
berlebihan.
Penegak cas
1Tanggalkan penegak cas
2Bersihkan penegak cas dengan kain yang
lembab.
Pemotong
1Bersihkan bahagian luar perapi dengan
berus yang dibekalkan selepas setiap kali
digunakan.
C2Petik keluar perapi untuk membersihkan
bahagian dalam.
BAHASA MELAYU 21

C3Lincirkan gigi perapi setiap enam bulan
dengan setitik minyak mesin jahit.
Menggantikan kepala pencukur
Gantikan kepala pencukur setiap 2 tahun sekali
untuk mendapatkan hasil pencukuran yang terbaik.
1Mematikan alat pencukur.
C2Tekan butang pelepas untuk membuka unit
pencukur.
C3Putarkan roda mengikut arah lawan jam
dan alihkan rangka penahan.
C4Alihkan kepala pencukur dan gantikan
dengan yang baru di unit pencukur.
C5Pasang semula unit pencukur dengan
memasang semula rangka penahan.Tekan
roda dan putarkan ia mengikut arah jam.
Gantikan kerosakan atau kepala pencukur yang
tumpul dengan kepala Penyejuk Kulit Philishave
HQ167 sahaja.
BAHASA MELAYU22
OIL
1
1
2
1
1
