Philips 42-inch 3D-Intelligent Display 42-3D6W02/00 User manual

42-inch 3D-Intelligent Display
42-3D6C01/00
42-3D6W01/00
42-3D6C02/00
42-3D6W02/00
User Manual
Philips 3D Solutions

Safety Instructions for 3D display
Read and follow these instructions:
1. This product must be earthed.
2. Use only an approved power cord or interconnection cable.
3. Unplug the product if you are not going to use it for a long period of time.
4. Unplug the product if you need to clean it, use a slightly damp cloth. Never use
alcohol, solvents or ammonia-based liquids.
5. Refer all servicing to qualified service personnel
6. Do not block any ventilation holes.
7. To avoid electric shock, do not expose to rain or excessive moisture.
8. Do not store or use the product in locations exposed to excessive heat, direct
sunlight, extreme cold or in dusty environments.
9. Avoid moving the product between locations with large temperature differences.
10. Choose a location within the following temperature and humidity ranges.
•Temperature: 0- 35°C
•Humidity : 20-80% RH
11. Avoid hitting or dropping during operation and transportation.
Instructions de sécurité pour l’écran 3D
Prière de lire et respecter les instructions suivantes :
1. Cet appareil doit être connecté à la terre.
2. Utilisez uniquement un cordon d’alimentation ou un câble d’interconnexion
approuvé.
3. Déconnectez l’appareil si vous ne l’utilisez pas pendant une période prolongée.
4. Déconnectez l’appareil pour le nettoyer ; utilisez un chiffon légèrement humidifié.
Ne jamais utiliser de l’alcool, des solvants ou des produits à base d’ammoniac.
5. Confiez les opérations d’entretien au personnel d’entretien qualifié.
6. Ne pas bloquer les orifices d’aération.
7. Afin d’éviter tout choc électrique, ne pas exposer l’appareil à la pluie, ni à un taux
d’humidité excessif.
8. Ne pas entreposer ni utiliser l’appareil dans des lieux poussiéreux ou exposés à
une chaleur excessive, aux rayons du soleil ou à des températures excessivement
basses.
9. Évitez de transporter l’appareil entre deux endroits entre lesquels il y a une
grande différence de température.
10. Veillez à ce que le lieu d’entreposage ou d’utilisation ait les caractéristiques de
température et de taux d’humidité suivantes :
•Température: 0-35°C
•Humidité relative : 20-80%
11. Évitez les chocs ou la chute de l’appareil pendant son utilisation ou pendant le
transport.

Warning this is a class A product. In a domestic
environment this product may cause radio interference in
which case the user may be required to take adequate
measures.

Document Information
Info Content
Title 42 inch 3D Display, User Manual (9922 159 01 73 1 080923)
Date 23 September 2008
Security The material and the information contained herein are proprietary to
Philips 3D Solutions. Copying, reproduction, adaptation, modification
or dissemination in whole or part is not permitted without the prior
written consent of Philips 3D Solutions.
Contact
address
Philips 3D Solutions
High Tech Campus 27
5656 AE Eindhoven
The Netherlands,
E-mail support: [email protected]
E-mail general: [e-mail]
Website: www.philips.com/3D

Display User Manual
3D Solutions
23 September 2008
©2008 Philips Electronics Nederland B.V. 5 of 26
Table of Contents
1Introduction .............................................................................................................................................................................6
2Product features......................................................................................................................................................................7
2.1Global product features ..............................................................................................................................................7
2.2Technical aspects and details......................................................................................................................................8
2.3Cosmetic specifications ...............................................................................................................................................9
3Scope of supply, Set up and mounting .............................................................................................................................12
3.1Scope of Supply ...........................................................................................................................................................12
3.2Image retention ...........................................................................................................................................................12
3.3Installation locations...................................................................................................................................................12
3.4Mounting .......................................................................................................................................................................13
3.5Positioning the display................................................................................................................................................13
3.6Connecting the display ..............................................................................................................................................14
3.7Cleaning instructions..................................................................................................................................................15
3.8Disposal of your old product...................................................................................................................................16
4Software installation.............................................................................................................................................................17
4.1Minimum PC requirements ......................................................................................................................................17
4.2Prepare PC ...................................................................................................................................................................17
5Approbations .........................................................................................................................................................................18
5.1CE ...................................................................................................................................................................................18
5.2USA and Canada .........................................................................................................................................................18
5.3CB Certificate..............................................................................................................................................................18
6Environmental........................................................................................................................................................................19
7Interfaces.................................................................................................................................................................................20
7.1DVI-in.............................................................................................................................................................................20
7.2LED.................................................................................................................................................................................20
8Trademarks, Copyrights and disclaimer..........................................................................................................................21
9Manufacturer / Support.......................................................................................................................................................22
10Mounting bracket..................................................................................................................................................................23
11References ..............................................................................................................................................................................26

Display User Manual
3D Solutions
23 September 2008
6 of 26 ©2008 Philips Electronics Nederland B.V.
1Introduction
The 42-inch 3D display from Philips 3D Solutions offers state-of-the-art lenticular lens design creating a
variety of distinct autostereoscopic views. By this the viewer will benefit from the multi-user
experience along with a large comfort zone. The 42-inch 3D display is specifically designed for a wide
range of applications such as digital signage and information provision.
The display is featuring superior lens design and 3D rendering relying on proven, highly optimized and
accurate manufacturing processes. The lens design minimizes cross talk, creating highly distinct views.
The 42-3D6C01/00 and 42-3D6C02/00 are designed for optimal viewing comfort. The 42-3D6W01/00
and 42-3D6W02/00 are designed for maximum WOW viewing experience.
The display’s 2D-plus-depth rendering interface is open, allowing maximum flexibility. No matter what
sort of Philips 3D Solutions display is used, the content does not need regeneration. What’s more, the
rendering hardware sits inside the display, allowing for maximum optimisation of the optical system by
embedded processing.
Provided with the 42-inch 3D display are the 3DS Media Player and the Display Control Tool. The
Display Control Tool can be used to set all kinds of visualisation parameters for the 3D display;
examples are the WOW offset, the WOW range, the contrast, and the brightness. The 3DS Media
Player is used for play-out for the Philips 3D Solutions 3D displays. It takes care that the display
switches to 3D mode with the appropriate 3D visualization settings.
After registration a digital version of the 3D Display User Manual can be downloaded from our
website: www.philips.com/3Dsolutions.

Display User Manual
3D Solutions
23 September 2008
©2008 Philips Electronics Nederland B.V. 7 of 26
2Product features
2.1 Global product features
Multi-view Lenticular Display
o9 view autostereoscopic 3D display
oNon-switchable lenticular technology
oOptimal viewing distance: 3 meters (10 feet).
oWide comfort zone for 3D perception
oFull brightness, full contrast
o2D-plus-Depth or Declipse input in 3D mode 1
oProtective plate at the front side of the display
Advanced display signal processing engine
oIntegrated 3D display processing hardware
oOpen 3D data interface
o2D-plus-Depth converted to 9 different views and interwoven into a 3D image
oRendering algorithm is tuned for lenticular optical behaviour
oTwo modes:
•3D rendering mode
•2D transparent mode with picture quality improvement filter
Connectivity
oDisplay control via DDC/CI channel; no additional RS232 cable needed
oAC switch
oA LED indicates ‘power on’ and ‘standby’ mode
1For an elaborate explanation on the WOWvx display interface formats see the ‘3D Interface Specifications -
white paper’ and ‘3D Content Creation Notes’ documents. Both can be downloaded from the download section
on http://www.philips.com/3dsolutions.

Display User Manual
3D Solutions
23 September 2008
8 of 26 ©2008 Philips Electronics Nederland B.V.
2.2 Technical aspects and details
Group Item 42-3D #
LCD
panel
Type TFT LCD
Resolution 1920 x RGB x 1080
Pixel pitch 0.4845 mm x 0.4845 mm
Effective viewing area 930.24 mm x 523.26 mm
Size 42’’
Contrast Ratio 1500:1
Aspect Ratio 16:9
Brightness 500 cd/m2
Response time 8 ms (gray-to-gray)
Refresh rate 60 fps
Display colors 16.7 M (8 bits RGB)
White chromaticity Wx: 0.280 Wy: 0.285 (at 10500°K)
Physical Weight (including table
stand) 42-3D6C #: 32 kg
42-3D6W #: 35 kg
Dimensions (WxHxD) 1017 x 610 x 128 mm
Package dimensions
(WxHxD) 1176 x 791 x 318 mm
Installation Table stand (included) wall, or ceiling mounting
bracket or free-standing (optional)
Power Consumption 230 W
Power Consumption
standby
2.5 W
Operating temperature
0 - 35 °C
Relative humidity 20 % to 80 %
System MTBF 50K hrs
Installation angle
0 - 10°from vertical
Interface Connector DVI-D single link
Voltage 110 – 230 V, 50 – 60 Hz

Display User Manual
3D Solutions
23 September 2008
©2008 Philips Electronics Nederland B.V. 9 of 26
2.3 Cosmetic specifications
2.3.1 Description
This specification standard is applicable to:
3D-displays supplied by Philips 3D Solutions.
2.3.2 Environmental conditions of inspection
The environmental conditions and visual inspection shall be conducted as below.
Ambient temperature in the range 15-25 [oC].
Humidity in the range 25-75 [%RH].
The functional inspection distance of the monitor (measured between the monitor and the inspector’s
sight) should be at least 3.0 [m].
The maximal viewing angle relative from the normal direction of the module/monitor is specified
according to ±Y degree to the front surface of the display in vertical direction, and ±X degree to the
front surface of the display in horizontal direction. The values below are the following: X = 15, Y = 45.
Ambient illumination:
External appearance inspection in the range 400-600 [Lux].
Light on inspection in the range 100-200 [Lux].
2.3.3 Classification of defects
The defects are classified as major and minor defects. The definition of defects is described as follows:
Major defect:
The defect may cause functional failure, or reduce the usability of the product for its purpose. For
example: electrical failure, deformation, etc.
Minor defect:
The defect does not reduce the usability of the product for its purpose. For example: dot defect, etc.
The judgement of the major and minor defects shall be according to the table with classification of
defects below.
Inspection item Description Defect type
Vertical line Abnormal line appears in vertical direction. Major
Horizontal line Abnormal line appears in horizontal
direction.
Major
Cross line Abnormal cross line appears in display. Major
No display No signal output in display. Major
Irregular display Abnormal signal outputs in display. Major
Dot defect Bright dot, dark dot or dot adjacent appear
in display.
Minor
Foreign material Foreign material appears in display Minor

Display User Manual
3D Solutions
23 September 2008
10 of 26 ©2008 Philips Electronics Nederland B.V.
2.3.4 Inspection Criteria
Definition of dot defect:
If the size of a dot defect is larger than 0.5 times a single pixel, it can be regarded as one dot defect
Bright dot: Dot appears bright and the size is fixed in a black pattern.
Dark dot: Dot appears dark and the size is fixed in pure red, green and blue pattern.
2.3.4.1 Display defects
The size of a circular area is defined by the average of the size along the horizontal axis (=a) and the
vertical axis (=b), i.e. D=(a+b)/2. The size of a lint/scratch is defined by its with (=W) and its length
(=L).
Item 3D-display Maximum tolerance
Bright dot Random N ≤3
2 dots adjacent N ≤1
3 dots adjacent or more N ≤0
Dark dot Random N ≤12
2 dots adjacent N ≤2
3 dots adjacent or more N ≤1
Minimum distance between dark dots L ≥15 [mm]
Total bright and dark dots N ≤12
Backlight Break down Not permitted
Connector Oxidized/rusty connector not acceptable
Item protective plate Maximum tolerance
Protective plate scratches 0.15 < W ≤0.25 [mm], 0.3 < L ≤10.0 [mm], N ≤7
Item 3D-display Maximum tolerance
LED function See paragraph 7.2 Failure not acceptable
Cosmetic
profiles
Scratches 0.05 < W ≤0.15 [mm], 0.3 < L ≤2.0
[mm], N ≤7
Sharp edges Not allowable.
Outside and
connectors
Cracks and Rust Not acceptable under any
circumstances.
Disclaimer will be printed on bag sticker and included in this manual
Please be aware that the protective plate in front of this display is sensitive for
scratching during cleaning. This is caused by hard particles (like sand) that might be
present in the cloth used and/or the cleaning fluid.
Small backlight intensity variations can occur in dark backgrounds
Discoloration of the active area circumference can occur and should be treated as
normal and will not change the functional performance of the 3D intelligent display.
Philips 3D Solutions is not responsible for a poor performance due to a not optimal
signal input according to display timing recommendation below

Display User Manual
3D Solutions
23 September 2008
©2008 Philips Electronics Nederland B.V. 11 of 26
Advanced Timin
g
Horizontal
pixels
Front porch 152 Sync width 48
Back porch 48 Scan rate 67.02 kHz
Sync polarity +
A
ctive lines 1920
Vertical
lines
Front porch 5 Sync width 5
Back porch 26 Refresh rate 60.054 Hz
Sync polarity +
A
ctive pixels 1080
Pixel cloc
k
145.30 MHz
Signals must comply with the
following DVI standard:Digital Visual
Interface DVI
Digital Display Working Group
Revision 1.0; April 02, 1999

Display User Manual
3D Solutions
23 September 2008
12 of 26 ©2008 Philips Electronics Nederland B.V.
3Scope of supply, Set up and mounting
3.1 Scope of Supply
The contents of the box:
oDisplay 42-3D #
oTable stand
o3 Mains cords (USA, EU and UK)
oDVI cable
oCD ROM with:
Display Control Tool
3DS Media Player
User manuals
3D Sample content 2
oPrinted version of the Display user manual (this manual)
oCardboard box with cushions
The following items can be purchased separately:
oMounting bracket (Article code: 42-WM)
3.2 Image retention
IMPORTANT: Always display alternating content with your application. If a still image in high contrast
remains on the screen for an extended period of time, it may leave an 'after-image' or 'ghost image' on
the front of the screen. This is a well-known phenomenon, caused by the shortcomings inherent in the
LCD technology. Please note that the after-image symptom cannot be repaired and is not covered
under warranty.
3.3 Installation locations
oAvoid exposure to excessive heat and extreme cold.
oDo not store or use the product in locations exposed to excessive heat, direct sunlight or
extreme cold.
oAvoid moving the product between locations with large temperature differences. Choose a
site that falls within the following temperature and humidity ranges.
•Temperature: 0-35°C
•Humidity: 20-80% RH
oDo not subject the product to severe vibration or high impact conditions. Do not place the
product e.g. inside a car, car boot or trunk.
oTake care not to mistreat this product by either hitting it or dropping it during operation or
transportation.
oDo not store or use the product in locations where there is a high level of humidity or in
dusty environments. Do not allow water or other liquids to spill on or into the product.
2More sample content can be downloaded from http://www.wowvx.com, http://www.philips.com/3D or the
Extranet at http://www.philips.com/3dsolutions (registration required).

Display User Manual
3D Solutions
23 September 2008
©2008 Philips Electronics Nederland B.V. 13 of 26
3.4 Mounting
The display can be placed on a table stand or wall-mounted. The table stand is supplied as standard;
the mounting bracket can be purchased separately. This bracket can also be used as an adapter in
combination with universal wall supports, ceiling supports or universal floor stands (e.g. Vogel’s
Professional).
3.4.1 Fitting the table stand
Only use the stand supplied with the set, making sure that the fasteners are properly tightened. Never
use a makeshift stand, or legs fixed using woods crews.
3.4.2 Using the mounting bracket
The standard VESA mount holes on the mounting bracket allow the user to install the Philips 3D
display on any VESA MIS-E compatible wall support, ceiling support or floor stand.
Important: Use a VESA MIS-E compatible support suitable for the weight of this 3D Display.
Always secure the mounting bracket to the display using 4 screws. This helps avoid potentially
dangerous situations when lifting the display out of the mounting bracket.
3.5 Positioning the display
For the best results, choose a place where there is no direct light shining onto the screen, and which is
some distance away from radiators or other sources of heat. Leave a space of at least 10 cm all around
the display for ventilation, making sure that curtains, cupboards etc. cannot obstruct the airflow
through the ventilation apertures. The display is intended for use in a public places only and should
never be operated or stored in excessively hot or humid conditions.

Display User Manual
3D Solutions
23 September 2008
14 of 26 ©2008 Philips Electronics Nederland B.V.
1
3.6 Connecting the display
NEVER (dis)connect DVI when your PC or Display is on.
PC DVI cable
Power cord
DVI cable
2D monitor
(optional)
3D Display
A second 2D display may be connected to the PC. Only use a DVI cable and graphics card that is
compliant with the DVI standard (see reference to DVI standard in Error! Reference source not
found.)
The picture below show the DVI-connector and power connector on the back of the display
Make sure the PC and Display are switched off!
1. Connect the PC via the DVI cable to the DVI connecter.
2. Connect the power cord.
2

Display User Manual
3D Solutions
23 September 2008
©2008 Philips Electronics Nederland B.V. 15 of 26
3.7 Cleaning instructions
Before cleaning the display, disconnect the power cord and DVI cable.
It is preferable to clean the front of the display with the cleaning products listed in the table below.
To clean we recommend:
cleaning materials e.g. soft cotton cloth
window leather
Aqueous solution, neutral and weakly
alkaline window cleaner without
additives of abrasive substances:
Permitted portion of ammonia < 5
Vol-%, as well as water soluble
organic solvents < 5 Vol-%.
e.g. Flux
Ajax
Do not use for cleaning:
alkaline lyes e.g. durd soap, certain textile detergents
lyes e.g. toilet cleaner
acids e.g. hydrochloric acid, vinegar, lemon
decalcification agent e.g. citric acid
degreasing agent e.g. acetone, methylene chloride,
trichloroethylene, petrol
Strong ammonia detergents e.g. Toilet cleaner
chlorine or Hypochloride detergents e.g. Chavel water, Domestos
solvents e.g. Ethyl alcohol, Isopropyl alcohol,
alcohol, acetone, trichloroethylene,
benzene, hexane, petrol
coarse millinery e.g. abrasive, steel wool, sponge with
abrasives, blades cloth with thread
made of steel, hard cloth or paper
tissue
Other Electrolube ASC, REF ASC250ml
As an alternative, clean the front of the display with a solution of soft soap (e.g. liquid hand soap) and
tepid water, using a soft cloth or sponge.
The rest of the display can be cleaned with a dry cloth.

Display User Manual
3D Solutions
23 September 2008
16 of 26 ©2008 Philips Electronics Nederland B.V.
3.8 Disposal of your old product
Your product is designed and manufactured with high quality materials and components, which can be
recycled and reused.
When this crossed-out wheeled bin symbol is attached to a product it means the
product is covered by the European Directive 2002/96/EC
Please inform yourself about the local separate collection system for electrical and
electronic products.
Please act according to your local rules and do not dispose of your old products with normal
household waste. The correct disposal of your old product will help prevent potential negative
consequences for the environment and human health.

Display User Manual
3D Solutions
23 September 2008
©2008 Philips Electronics Nederland B.V. 17 of 26
4Software installation
This chapter contains the prerequisites for the PC hardware and the operating system for the
software. First, check whether your PC complies with the requirements that are given in the next
sections. Then follow the installation instructions, where you will be guided step by step through the
software installation procedure.
4.1 Minimum PC requirements
The PC must comply with the following requirements:
oPentium 4, ≥3 GHz or Dual core ≥1.7 GHz
o≥512 MB internal memory for Windows XP, ≥1024 MB internal memory for Windows Vista
o7200 rpm hard disk with 8 Mbyte cache (minimal sustained throughput 10 MB/s)
oDVD ROM player
oGraphics card:
obased on NVIDIA for example 7600 or 8600 chipsets,
oor based on NVIDIA Quadro for example FX1400 (windows XP only),
oor based on ATI for example X1650 (Windows XP only).
oWindows XP SP2 or Windows Vista (see above for restrictions concerning graphics cards)
4.2 Prepare PC
Make sure that the following software is installed on the PC before connecting the 3D Display to the
PC: oWindows XP (upgraded to Service Pack 2) or Windows Vista
oNVIDIA Display driver or ATI Driver (Windows XP only)

Display User Manual
3D Solutions
23 September 2008
18 of 26 ©2008 Philips Electronics Nederland B.V.
5Approbations
5.1 CE
EN 60950-1:2001
EN 55022: 1998-09; cor 1: 1999-08; A1: 2000-10; A2: 2003-01; cor 2: 2003-07
EN 55024: 1998-09; A1: 2001-10; A2: 2003-01
EN 61000-3-2: 2000-12
EN 61000-3-3: 1995-01; A1: 2001-06
5.2 USA and Canada
cETLus listing
UL 60950
Can/CSA 60950
FCC part 15B: 2004-10 Class A
ANSI C63.4: 2001; 2003
5.3 CB Certificate
IEC 60950-1: 2001 (1st edition)
IEC 61000-3-2: 2000-08; A1: 2001-08; A2: 2004-10
IEC 61000-3-3: 1994-12; A1: 2001-01

Display User Manual
3D Solutions
23 September 2008
©2008 Philips Electronics Nederland B.V. 19 of 26
6Environmental
Condition Operating Shipping / storage
Temperature 0 °C to 35 °C -20 °C to 60 °C
Humidity 20 % - 80 %
No condensation
0% - 95 %
No condensation
Air pressure 600 – 1100 mBar 300 – 1100 mBar
The display is only used indoor.

Display User Manual
3D Solutions
23 September 2008
20 of 26 ©2008 Philips Electronics Nederland B.V.
7Interfaces
7.1 DVI-in
Pin Signal Pi
n
Signal Pi
n
Signal
1 T.M.D.S.
Data2-
9 T.M.D.S.
Data1-
17 T.M.D.S.
Data0-
2 T.M.D.S.
Data2+
10 T.M.D.S.
Data1+
18 T.M.D.S.
Data0+
3 T.M.D.S.
Data2/4
Shield
11 T.M.D.S.
Data1/3
Shield
19 T.M .D.S. Da t
a0/5 Shield
4 No
connect
12 No
connect
20 No connect
5 No
connect
13 No
connect
21 No connect
6 DDC
Clock
14 +5V
Power
22 T.M.D.S.
Clock Shield
7 DDC Data 15 Ground
(for +5V)
23 T.M.D.S.
Clock+
8 No
connect
16 Hot Plug
Detect
24 T.M.D.S.
Clock-
The DDC Clock and the DDC data are used by the Display Control Tool to control depth and colour
settings in the display.
7.2 LED
LED Color Status
Red Display is in standby mode. No DVI clock is present.
Green Display on
