Philips 42PF7411 User manual

Philips
widescreen flat TV with
Pixel Plus
107cm (42")
LCD HD Ready
42PF7411
Turn up your viewing experience
with Pixel Plus
Experience the superior picture quality of this excellent Flat TV with the latest LCD
technology and Pixel Plus. It's packed into a stunning design that will complement your
interior.
Breathtaking natural pictures
• HD LCD WXGA display, with a 1366 x 768p resolution
• HD Ready for the highest quality display of HD signals
• Pixel Plus for detail, depth and clarity
• Dynamic contrast enhancer delivering rich black details
• 3D combfilter separates colors for a razor-sharp image
Superb sound reproduction
• Virtual Dolby Surround for a cinema-like audio experience
Slim, stylish design to complement your interior
• Compact and slim design that fits in every room
Designed for your convenience
• Turn your TV screen into a mosaic of different channels
For advanced performance
• HDMI input for full digital HD connection in one cable

42PF7411/10
Highlights
Widescreen flat TV with Pixel Plus
107cm (42") LCD HD Ready
LCD WXGA display, 1366 x 768p
This WXGA display with state-of-the-art LCD
screen technology gives you widescreen HD
resolution of 1366 x 768p pixels. It produces
brilliant flicker-free progressive scan pictures
with optimum brightness and superb colors.
This vibrant and sharp image will provide you
with an enhanced viewing experience.
HD Ready
Enjoy the exceptional picture quality of High
Definition pictures and be fully prepared for
HD sources like HDTV settop box or Blu-ray
disc. HD Ready is a protected label that offers
picture quality beyond that of progressive scan.
It conforms to strict standards laid out by
EICTA to offer a HD screen that displays the
benefits of resolution and picture quality of a
High Definition signal. It has a universal
connection for both analog YPbPr and
uncompressed Digital connection of DVI or
HDMI, supporting HDCP. It can display 720p,
and 1080i signals at 50 and 60Hz.
Pixel Plus
Pixel Plus is a digital picture processing
technology that increases the number of lines
and the number of pixels. The result is razor
sharp pictures with incredible detail and depth,
every time from any source.
Dynamic contrast enhancer
You want the LCD flat display with the highest
contrast and most vibrant images even at wide
viewing angle. The Philips dynamic contrast
enhancer uses video processing and unique
dimming backlight technology. This delivers
deep rich black levels with increased detail.
The dimming backlight increases the contrast
up to 5 times*, and at the same time improves
the viewing angle. It gives a bright, lifelike
picture with high contrast and vibrant colors,
(* factor between 2 and 5, screen type and
picture content dependant).
3D Combfilter
The 3D comb filter separates brightness and
color signals better in 3D domain to eliminate
cross-color, cross-luminance and dot-crawl
distortion - all of which detract from your
viewing pleasure. The 3D digital comb filter
performs field-by-field comparisons of the
television image to accurately separate the
color from the black-and-white information
and remove both horizontally and vertically
hanging dots, as well as dot crawl. The result is
a razor sharp image.
Virtual Dolby Surround
Virtual Dolby Surround is a processing
technology for enhancing surround sound
effects. It will create the sensation of Dolby
Pro Logic without the necessity of additional
rear speakers. You become totally immersed
in your television experience.
Compact and slim design
This design style emphasizes a slim, compact
look that saves space and fits in anywhere.
Multiple PiP Modes
Multiple Picture-in-Picture modes allow you to
simultaneously watch two video sources either
picture-in-picture, side by side, or in a mosaic-
view with still images.
HDMI input
HDMI makes an uncompressed digital RGB
connection from the source to the screen. By
eliminating conversion to an analog signal, it
delivers an unblemished image. The non-
degraded signal reduces flicker and leads to a
clearer picture. HDMI intelligently
communicates the highest output resolution
with the source device. The HDMI input is fully
backward compatible with DVI sources but
includes digital audio. HDMI uses HDCP copy
protection.

Issue date 2012-01-20
Version: 2.1.7
12 NC: 8670 000 24381
EAN: 87 10895 99055 4
© 2012 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
42PF7411/10
Specifications
Widescreen flat TV with Pixel Plus
107cm (42") LCD HD Ready
Picture/Display
• Aspect ratio: 16:9, Widescreen
• Brightness: 550 cd/m²
• Dynamic screen contrast: 2800:1
• Response time (typical): 8 ms
• Viewing angle (H / V): 178 / 178 degree
• Diagonal screen size: 42 inch / 107 cm
• Display screen type: LCD WXGA Active Matrix
TFT
•Panel resolution: 1366 x 768p
• Picture enhancement: Pixel Plus, 3/2 - 2/2 motion
pulldown, 3D Combfilter, Active Control,
Contrast Plus, Digital Noise Reduction, Jagged Line
Suppression, Luminance Transient Improver,
Progressive scan
• Screen enhancement: Anti-Reflection coated
screen
• Color cabinet: Black Tempered Glass Deco Front
with Black Cabinet
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75Hz
800 x 600 56, 60, 72, 75Hz
1024 x 768 60, 70, 75Hz
•Video Formats
Resolution Refresh rate
640 x 480p 2Fh
720 x 576p 2Fh
1280 x 720p 3Fh
1920 x 1080i 2Fh
Sound
• Equalizer: 5-bands
• Output power (RMS): 2 x 15W
• Sound Enhancement: Auto Volume Leveller,
Dynamic Bass Enhancement
• Sound System: Stereo, Virtual Dolby Surround
Loudspeakers
• Built-in speakers: 4
• Loudspeaker types: Dome tweeter
Convenience
• Clock: Sleep Timer, Wake up Clock
• Ease of Installation: Auto Program Naming,
Automatic Channel Install(ACI), Automatic Tuning
System (ATS), Autostore, Fine Tuning, Plug & Play,
Program Name, Sorting
• Ease of Use: Auto Volume Leveller (AVL), Program
List, Side Control, Smart Picture, Smart Sound
• Remote Control: TV, DVD, Multi-functional
• Remote control type: RCFE06FRS00
• Screen Format Adjustments: 4:3, Movie expand
14:9, Movie expand 16:9, Subtitle Zoom, Super
Zoom, Widescreen
• Teletext: 1000 page Smart Text
• Teletext enhancements: 4 favourite pages,
Program information Line
• VESA Mount: 800 x 400 mm
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: PAL B/G, PAL D/K, SECAM B/G,
SECAM D/K
• Video Playback: NTSC, SECAM, PAL
• Tuner bands: Hyperband, S-Channel, UHF, VHF
• Number of Preset Channels: 100
•TunerDisplay:PLL
Connectivity
• Ext 1 Scart: Audio L/R, CVBS in/out, RGB
• Ext 2 Scart: Audio L/R, CVBS in/out, S-video in
•NumberofScarts:2
• Ext 4: YPbPr
• Ext 5: HDMI
• Ext 6: HDMI
•Front/Sideconnections:Audio L/R in, CVBS in,
Headphone Out, S-video in
Power
• Ambient temperature: 5 °C to 40 °C
• Mains power: AC 220 - 240 V +/- 10%
• Power consumption: 220 W Normal Operation W
• Standby power consumption: < 2 W
Dimensions
• Dimensions (with base) (W x H x D):
1249 x 748 x 306 mm
• Weight incl. Packaging: 47 kg
• Product weight: 42 kg
•Boxdimensions(Wx H x D):
1328 x 989 x 330 mm
• VESA wall mount compatible: 0
Accessories
• Included accessories: Table top stand, Power cord,
Quick start guide, User Manual, Registration card,
Warranty certificate, Remote Control, Batteries
for remote control
• Optional accessories: Floor stand
•
