Philips DivX Ultra HTS4750/93 User manual

English
DVD HOMETHEATRE SYSTEM HTS4750
User Manual 6
Փ⫼䇈ᯢк 56

2
LASER
Type Semiconductor laser
GaAIAs
Wave length 650 - 660 nm (DVD)
784 - 796 nm (CD)
Output Power 7 mW (DVD)
10 mW (VCD/CD)
Beam divergence 60 degrees ATTENTION!
For Customer Use:
Read carefully the information located at the
bottom or rear of your DVD Home Theatre
System and enter below the Serial No. Retain
this information for future reference.
Model No. HTS4750
Serial No. _______________
CAUTION
Use of controls or adjustments or performance
of procedures other than herein may result in
hazardous radiation exposure or other unsafe
operation.
‘CONSUMERS SHOULD NOTE THAT NOT ALL HIGH
DEFINITION TELEVISION SETS ARE FULLY
COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE
ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN
CASE OF 525 OR 625 PROGRESSIVE SCAN PICTURE
PROBLEMS, IT IS RECOMMENDED THAT THE USER
SWITCH THE CONNECTION TO THE ‘STANDARD
DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS
REGARDING OUR TV SET COMPATIBILITY WITH THIS
MODEL 525p AND 625p DVD PLAYER, PLEASE
CONTACT OUR CUSTOMER SERVICE CENTER.’

3
English
HDMI (High Denition Multimedia
Interface) is a digital interface that
allows pure HD digital video
transmission without the loss of image
quality. The integrated control bus
allows system control between the TV
set and connected devices like a digital
set top box.
Manufactured under license from
Dolby Laboratories, “Dolby”, “Pro
Logic” and the double-D symbol are
trademarks of Dolby Laboratories.
Manufactured under license from
Digital Theater Systems, Inc. U.S. Pat.
Noís. 5,451,942; 5,956,674; 5,974,380;
5,978,762; 6,226,616; 6,487,535 and
other U.S. and world-wide patents
issued and pending. “DTS” and “DTS
Digital Surround” are registered
trademarks of Digital Theater
Systems, Inc. Copyright 1996, 2003
Digital Inc. All Rights Reserved.
DivX Ultra Certied products: “DivX,
DivX Ultra Certied, and associated
logos are trademarks of DivX, Inc. and
are used under license.
Windows Media and the Windows logo
are trademarks, or registered
trademarks of Microsoft Corporation
in the United States and/or other
countries.

4
Language Code

5
English
Index
English ------------------------------------ 6
------------------------------ 56

6
English
Table of contents
General
General Information ........................................................................................................ 8
Setup precautions.................................................................................................................................................8
Accessories supplied ...........................................................................................................................................8
Cleaning discs ........................................................................................................................................................8
About recycling.....................................................................................................................................................8
Product Overview
Main Unit ........................................................................................................................... 9
Remote Control .........................................................................................................10-12
Using the remote control ................................................................................................................................12
Connections
Basic Connections .....................................................................................................13-18
Step 1 : Placing the speakers ...........................................................................................................................13
Step 2 : Connecting the speakers to AV subwoofer ...............................................................................14
Step 3 : Connecting the AV subwoofer to DVD system.........................................................................15
Step 4 : Connecting the FM/MW antennas.................................................................................................15
Step 5 : Connecting to TV ...............................................................................................................................16
Option 1: Using the Video (CVBS) jack (good picture quality).....................................................16
Option 2: Using the S-Video jack (excellent picture quality).........................................................16
Option 3: Connecting to a Progressive Scan TV or component video input............................17
Option 4: Connecting to a HDMI-compatible TV ............................................................................17
Step 6 : Connecting the power cord ............................................................................................................18
Optional Connections .................................................................................................... 19
Connecting audio from TV .............................................................................................................................19
Connecting audio from an audio/video device...........................................................................................19
Basic Setup
Getting Started ........................................................................................................ 20-25
Step 1: Turning on the DVD system ............................................................................................................ 20
Turning off to Eco Power standby mode............................................................................................. 20
Step 2: Finding the correct viewing channel.............................................................................................. 20
Step 3: Setting language preferences ............................................................................................................21
On-screen display (OSD) language........................................................................................................21
Audio, Subtitle and Menu language for DVD playback...............................................................21-22
Step 4: Setting the TV...................................................................................................................................... 22
Selecting the matching color system ............................................................................................. 22-23
Setting the TV Display.............................................................................................................................. 23
Step 5: Setting up Progressive Scan feature................................................................................................24
Step 6: Setting the speakers’ channels ........................................................................................................ 25
Disc Playback
Disc Operations ........................................................................................................ 26-34
Playable discs ...................................................................................................................................................... 26
Playing a disc ....................................................................................................................................................... 26
Basic playback controls.....................................................................................................................................27
Selecting various repeat/shufe functions ..................................................................................................27
Programming disc tracks................................................................................................................................. 28
Other playback features for video discs (DVD/VCD/SVCD) ............................................................. 28
Using the Disc Menu ................................................................................................................................. 28
Viewing playback information..................................................................................................................29

7
English
Resuming playback from the last stopped point ................................................................................29
Zooming in....................................................................................................................................................29
Changing subtitle language (DVD only)................................................................................................29
Changing sound track language.............................................................................................................. 30
Playback Control (VCD only)................................................................................................................. 30
Preview function (VCD/SVCD only).................................................................................................... 30
Playing an MP3/ JPEG/Window Media Audio disc ...................................................................................31
Playing a JPEG image le (slide show) ..........................................................................................................32
Preview function..........................................................................................................................................32
Zoom picture ..............................................................................................................................................32
Rotating/ipping the picture ....................................................................................................................32
Playing MP3 music and JPEG pictures simultaneously .............................................................................33
Playing a DivX disc .............................................................................................................................................33
Playing a Karaoke disc...................................................................................................................................... 34
Microphone setting .................................................................................................................................. 34
USB / MP3 Direct
USB Operations..............................................................................................................35
Playing from USB ash drive or USB memory card reader .................................................................. 35
MP3 Direct Operations..................................................................................................36
Playing from a portable audio or HDD player.......................................................................................... 36
Setup Options
DVD Setup Menu Options....................................................................................... 37-44
Accessing the DVD setup menu.....................................................................................................................37
General Setup Page........................................................................................................................................... 38
Audio Setup Page.........................................................................................................................................39-40
Video Setup Page......................................................................................................................................... 41-42
Preference Setup Page ...............................................................................................................................43-44
Radio Tuning
Tuner Operations ..................................................................................................... 45-46
Tuning to radio stations................................................................................................................................... 45
Presetting radio stations ................................................................................................................................. 45
Using auto install ........................................................................................................................................ 45
Using automatic preset............................................................................................................................. 46
Using manual preset .................................................................................................................................. 46
Selecting a preset radio station..................................................................................................................... 46
Deleting a preset radio station...................................................................................................................... 46
Changing tuning grid......................................................................................................................................... 46
Others
Sound and Volume Controls ......................................................................................... 47
Selecting surround sound.................................................................................................................................47
Selecting digital sound effects.........................................................................................................................47
Volume control ...................................................................................................................................................47
Other Features ...............................................................................................................48
Software upgrades ............................................................................................................................................ 48
Troubleshooting.........................................................................................................49-51
Glossary ..................................................................................................................... 52-53
Specications ..................................................................................................................54
Frequently Asked Questions (USB) ............................................................................55
Table of contents

8
English
General Information
CAUTION!
The machine does not contain any
user-serviceable parts. Please leave
all maintenance work to qualied
personnel.
Setup precautions
Finding a suitable location
– Place the set on a at, hard and stable
surface. Do not place the set on a carpet.
– Do not position the set on top of
other equipment that might heat it up
(e.g., receiver or amplier).
– Do not put anything under the set
(e.g., CDs, magazines).
– Install this unit near the AC outlet
where the AC power plug can be easily
reached.
Space for ventilation
– Place the apparatus in a location with
adequate ventilation to prevent internal
heat build up. Allow at least 10 cm (4”)
clearance from the rear and the top of
the set and 5cm (2”) from the left and
right to prevent overheating.
Avoid high temperatures, moisture,
water and dust
– Apparatus must not be exposed to
dripping or splashing.
– Do not place any sources of danger
on the apparatus (e.g., liquid lled
objects, lighted candles).
Accessories supplied
– 1 AV subwoofer
– 2 front speakers with speaker stands
– 2 rear speakers with speaker stands
– 1 center speaker
– 1 remote control with batteries
– 1 inter-connect cable (for connecting
between the AV subwoofer and the
DVD system)
– 1 composite video cable (yellow)
– 1 FM wire antenna
– 1 MW loop antenna
– 1 MP3 direct white cable (for
connecting portable audio player)
– 2 power cables
– Quick Start Guide
Cleaning discs
To clean a disc, use a micro ber cleaning
cloth and wipe the disc from the center
to the edge in a straight line.
CAUTION!
Do not use solvents such as benzene,
thinner, commercially available cleaners,
or anti-static sprays intended for discs.
About recycling
These operating instructions have been
printed on non-polluting paper. The
electronic equipment contains a large
number of materials that can be recycled.
If you are disposing of an old machine,
please take it to a recycling center.
Please observe the local regulations
regarding disposal of packaging materials,
exhausted batteries and old equipment.

9
English
Main Unit
aSTANDBY ON 2
– Turns on the system or turns off to Eco
Power standby mode.
bPLAY PAUSE u
– DISC: starts/pauses playback.
– TUNER: starts auto tuner installation for
rst time setup.
STOP Ç
– Exits an operation.
– DISC: stops playback.
– TUNER: press and hold this button to
erase the current preset radio station.
PREV ./ NEXT >
– DISC: selects a track or press and hold
this button to search backward/forward.
– TUNER: selects a preset radio station.
cSOURCE
– Selects the relevant active source mode:
DISC, MP3 DIRECT, TUNER (FM/MW),
TV or AUX/DI.
dEJECT ç
– Ejects the disc from the disc slot.
eVOLUME
– Adjusts the volume level.
fSURROUND
– Selects multi-channel surround or
stereo mode.
gMIC LEVEL
– Activates microphone level mode and use
the VOLUME control to set the
microphone volume level.
hUSB port
– Input for USB ash drive or USB memory
card reader.
iMP3 Direct
– Phono input for connecting to the
headphone out jack on your portable
audio or HDD player.
jMIC
– For connecting the microphone jack.
kDisc slot
13 42 5 6 7
8
9
11 10
Top view
Front view

10
English
Remote Control
2
3
4
5
6
7
8
9
10
11
12
1
a2
– Turns off to Eco Power standby mode.
bSource buttons
– DISC/USB: switches to DISC or USB
mode.
TUNER: toggles between FM and MW
band.
TV: switches to TV mode. The sound
from the TV will output through the
connected speakers system.
AUX/DI: toggles between AUX and
DIGITAL IN external source mode.
cZOOM
– Enlarges a picture on the TV.
dAUDIO
– Selects an audio language (DVD) or an
audio channel (CD.)
eSETUP
– Enters or exits the system setup menu.
fDISPLAY
– Displays the current status or disc
information.
gPLAY É
– DISC: starts playback.
hSTOP Ç
– Exits an operation.
– DISC: stops playback.
– DISC: press and hold this button to eject
the disc.
– TUNER: press and hold this button to
erase the current preset radio station.
iTV VOL +-
– Adjusts TV volume (Philips TV only.)
jNumeric keypad (0-9)
– Enters a track/title number of the disc.
– Enters a number of a preset radio station.
kREPEAT
– Selects various repeat modes; turns off
repeat mode.
lVOCAL
– Toggles between various audio mode
options.
KARAOKE
– Enters microphone setup menu.

11
English
Remote Control (continued)
13
14
15
16
17
18
20
21
22
23
24
25
19
mMP3-DIRECT
– Switches to MP3 mode for the source
connected through the MP3 Direct jack
at the front panel.
nSUBTITLE
– Selects a DVD subtitle language.
oDISC MENU
– For DVD, enter or exit disc contents
menu.
– For VCD/SVCD, enter digest menu.
pWXST
– DISC: selects movement direction in the
menu.
– TUNER: press up or down to tune the
radio frequency up/down.
– TUNER: press left or right to start auto
search.
qOK
– Conrms a selection.
rRETURN/TITLE
– For DVD, go back to the previous menu.
– For VCD version 2.0 only;
During playback, display the disc title
menu or return to the main menu.
s.>
– DISC: press and hold this button for fast
forward and backward search.
– TUNER: selects a preset radio station.
tPAUSE Å
– DISC: pauses playback.
uVOL +-
– Adjusts the volume level.
vMUTE
– Mutes or restores the volume.
wPROGRAM
– DISC: starts programming.
– TUNER: press and hold this button to
start automatic/ manual preset
programming.
xSURR.
– Selects multi-channel surround or
stereo mode.
ySOUND
– Selects a predened sound effect.

12
English
Remote Control (continued)
Using the remote control
AOpen the battery compartment.
BInsert two batteries type R03 or AAA,
following the indications (+-) inside
the compartment.
CClose the cover.
DPoint the remote control directly at the
remote sensor (iR) on the front panel.
ESelect the source you wish to control by
pressing the DISC, TUNER, TV, AUX/DI
or MP3 DIRECT button on the remote
control.
FThen select the desired function (for
example ., >).
CAUTION!
– Remove batteries if they are
exhausted or if the remote control
is not to be used for a long time.
– Do not mix batteries (old and new
or carbon and alkaline, etc.).
– Batteries contain chemical
substances, so they should be
disposed of properly.

13
English
Basic Connections
Step 1: Placing the speakers
The Philips Home Theater System is
simple to install. However, proper
system placement is critical to ensure an
optimum sound experience.
APlace the front left and right speakers at
equal distances from the TV and at an
angle of approximately 45 degrees from
the listening position.
BPlace the center speaker above the TV or
the DVD system so that the center
channel’s sound is localized.
CPlace the rear speakers at normal
listening ear level facing each other.
DPlace the subwoofer at the corner of the
room. Keep at least one meter away
from the TV.
Helpful Hints:
– The placement diagram shown here is only
a guideline that will provide great system
performance. You may nd other placement
choices that are more suitable for your room
layout and provide the sound experience you
enjoy.
– To avoid magnetic interference, do not
position the front speakers too close to your
TV.
– The rear speakers are labelled as REAR
LEFT or REAR RIGHT.
– The front speakers are labelled as
FRONT LEFT or FRONT RIGHT.

14
English
Step 2: Connecting the
speakers to AV subwoofer

Connect all the speakers to the speaker
jacks at the rear of the AV subwoofer.
Make sure that the colors of the plugs
and jacks are matched.
Basic Connections (continued)
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
FRONT
LEFT
REAR
LEFT
CENTER
REAR
RIGHT
FRONT
RIGHT

15
English
Step 3: Connecting the AV
subwoofer to DVD system
AUse the supplied inter-connect cable to
connect TO AV SUBWOOFER jack at
the rear of the DVD system to the TO
DVD SYSTEM jack at the rear of the
AV subwoofer.
BTighten the screws beside the inter-
connect cable to secure the connection.
Basic Connections (continued)
Step 4: Connecting the FM/
MW antennas
AConnect the supplied MW loop antenna
to the MW jack. Place the MW loop
antenna on a shelf, or attach it to a stand
or wall.
BConnect the supplied FM antenna to the
FM jack. Extend the FM antenna and x
its ends to the wall.
For better FM stereo reception, connect
an external FM antenna (not supplied).
Helpful Hints:
– Adjust the position of the antennas for
optimal reception.
– Position the antennas as far away as
possible from your TV, VCR or other
radiation source to prevent any unwanted
interference.
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
FM 75
MW
FM/MW ANTENNA
~
MAINS
R
L
1
2
x the claw
into the slot
FM antenna
MW
antenna
FM 75
MW
FM/MW ANTENNA
TO AV SUBWOOFER
HDMI OUT
~
MAINS
R
L

16
English
Step 5: Connecting to TV
This connection enables you to view the
playback from this DVD system. You only
need to choose one of the options
below to make the video connection.
– For a standard TV, follow option 1 or
2.
– For a progressive scan TV, follow
option 3.
– For a HDMI TV, follow option 4.
IMPORTANT!
Connect the DVD system directly
to the TV.
Helpful Hint:
– To hear the TV channels through this DVD
system, connect the AUDIO IN - TV IN jacks
to the corresponding AUDIO output jacks on
the TV using an audio cable. Press TV on
the remote control when watching the TV
programs.
Option 1: Using the Video (CVBS)
jack (good picture quality)
Use the supplied composite video cable
(yellow) to connect the CVBS jack on
the DVD system to the video input jack
(or labelled as A/V In, Video In,
Composite or Baseband) on the TV.
Option 2: Using the S-Video jack
(excellent picture quality)
Use an S-video cable (not supplied) to
connect the S-VIDEO (Y/C) jack on the
DVD system to the S-Video input jack
(or labelled as Y/C or S-VHS) on the TV.
FM 75
MW
FM/MW ANTENNA
TO AV SUBWOOFER
HDMI OUT
~
MAINS
R
L
Option 1 Option 2
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
Basic Connections (continued)

17
English
Option 3: Connecting to a
Progressive ScanTV or component
video input
The progressive scan video quality is only
available when using Y Pb Pr connection
and a progressive scan TV is required. It
provides superior picture quality when
watching DVD movies.
AFollow option 1 to make the basic video
connection.
BUse the component video cables (red/
blue/green - not supplied) to connect the
Y PBPRjacks on the DVD system to the
corresponding component video input
jacks (or labelled as Y Pb/Cb Pr/Cr or
YUV) on the TV.
CIf your TV accepts progressive signals,
proceed to ‘Getting Started - Step 5:
Setting up Progressive Scan feature’ for
detailed progressive feature setup.
Option 4: Connecting to a HDMI-
compatible TV
HDMI (High Denition Multimedia
Interface) is a digital interface that allows
pure digital video transmission without
the loss of image quality.
AUse an HDMI cable (not supplied) to
connect the HDMI OUT on this DVD
system to the HDMI IN on a HDMI-
compatible device (e.g. HDMI TV, HDCP
compliant DVI TV).
BWhen you have completed the necessary
connections, installation and set-up, see
‘Audio Setup Page and Video Setup Page’
for optimum HDMI audio and video
settings.
Helpful Hints:
– The HDMI is backward compatible with
some DVI devices using an appropriate
adaptor plug.
– If a DVI device is connected, an additional
audio cable is required for audio transmission.
– Most of the older DVI enable devices are
not HDCP compliant and playback is not
possible.
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.
FM 75
MW
FM/MW ANTENNA
~
MAINS
R
L
Option 3
Basic Connections (continued)
TO AV SUBWOOFER
HDMI OUT
R
L
Option 4

18
English
Step 6: Connecting the
power cord
After everything is connected
properly, plug the AC power cord
into the power outlet.
The Eco Power LED on the DVD system
and the AV subwoofer will light up.
Never make or change any connections
with the power turned on.
Helpful Hints:
– Refer to the type plate at the rear or
bottom of the product for identication and
supply ratings.
FM 75
MW
FM/MW ANTENNA
TO AV SUBWOOFER
HDMI OUT
~
MAINS
R
L
Basic Connections (continued)
TIPS: Before making or changing any connections, make sure that all the devices are disconnected
from the power outlet.

19
English
Optional Connections
Connecting audio from TV
When connecting the audio output from
your TV to this Home Theater Audio
System, you will have the sound of the
TV output on all the speakers. It will
enable you to enjoy the multi-channel
surround sound capabilities.
Use an audio cable (red/white - not
supplied) to connect the TV IN jacks on
this DVD system to the AUDIO OUT
jacks on the TV.
To listen to the sound, press TV on the
remote control as the sound source that
you want to play.
Connecting audio from an
audio/video device
This DVD system provides analog and
digital audio connection. You can connect
the audio output from an audio/video
device (e.g. VCR, Cable/Satellite Box) to
this Home Theater Audio System in
order to enjoy the multi-channel
surround sound capabilities.
Use an audio cable (red/white - not
supplied) to connect the AUX IN jacks
on this DVD system to the AUDIO OUT
jacks on the connected device.
To listen to the sound, press AUX/DI to
select “AUX” as the sound source that
you want to play.
Or
Use a coaxial cable (not supplied) to
connect the DIGITAL IN jack on this
DVD system to the DIGITAL OUT jack
on the connected device.
To listen to the sound, press AUX/DI to
select “DI” as the sound source that you
want to play.
FM 75
MW
FM/MW ANTENNA
TO AV SUBWOOFER
HDMI OUT
~
MAINS
R
L
DIGITAL OUT
TIPS: Refer to the respective connected device’s user manual for other possible connections.
OR

20
English
Step 1: Turning on the DVD
system

Press the SOURCE button on the front
panel repeatedly to select :
DISC ¤MP3 DIRECT ¤FM ¤MW ¤
TV ¤AUX ¤DI ¤DISC ....
Or

Press DISC/USB, TUNER, TV,
AUX/DI or MP3 DIRECT on the
remote control.
If the USB is detected, pressing the
DISC/USB will toggle between DISC
and USB mode.
Press TUNER to toggle between FM
and MW band.
Press AUX/DI to toggle between
analog audio input and digital audio input.
Press MP3 DIRECT to playback the
audio tracks from your portable audio/
HDD player which is connected to this
DVD system.
Turning off to Eco Power standby
mode
Press STANDBY ON (2).
The display screen will turn off.
Getting Started
Step 2: Finding the correct
viewing channel
Before you start ...
Make sure you have completed all the
necessary connections before proceeding.
APress SOURCE button until “DISC”
appears on the display panel.
BTurn on the TV and set it to the correct
video-in channel. You should see the
blue DVD background screen on the TV.
You may go to Channel 1 on your TV,
then press the Channel Down button on
your TV’s remote control until you see
the Video In channel.
You may press °button repeatedly
on your TV’s remote control.
Usually this channel is between the
lowest and highest channels and may be
called FRONT, A/V IN, VIDEO. See your
TV manual for more details.
