Philips MCD109/55 User manual

1
4
7
2
5
8
0
3
6
9
ANGLEPROG
AUDIO MUTE
GOTO
VOL
+
ZOOM
DSC
DBB
OK
SYSTEM MENU
SUBTITLE REPEAT A-B SHUFFLE
SLOWDISPLAY
OSD
DISC MENU
DISC AUX
CR2025
MCD109
Quick Start Guide
What’s in the Box?
You should find these items upon opening the box.
1
Quick Start Guide
Quick start guide
2
User Manual
Remote control with one
CR2025 battery loaded
DIN cable
User manual
Composite video cable
AC power cord
Remove the insulation plastic tab
before use
MCD109_55 QSG_Eng 24/8/06, 15:181

Important!
–This set can only be operated after the
supplied DIN cable has been connected.
–Before connecting the AC power cord
to the wall socket, make sure that the
VOLTAGE SELECTOR (located on the rear
of the left speaker) is adjusted to match
the local power voltage.
Tips
–See the User Manual for otherTV
connection options.
–For connecting to a Progressive Scan
TV, refer to the user manual for proper
connections and detailed setup.
1
2
3
4
Connect the speaker wires of the right speaker to the left speaker.
Connect the left speaker and the DVD player by using the supplied
DIN cable.
Connect the DVD player to your TV by using the supplied composite
video cable.
Connect the supplied power cord to the left speaker and the wall socket.
3
4
AC power cord
Voltage selector
DVD player
Right speaker Left speaker
DIN cable
Video cable
Speaker wires
TV
1
2
MCD109_55 QSG_Eng 24/8/06, 15:182

Press SOURCE (DISC on the remote) to select disc source.
Turn on the TV and set it to the correct Video In channel.
Setting DVD menu options
IMPORTANT!
If the progressive scan feature is activated but the connected TV does not support
progressive signals or the video cables are not connected accordingly, see the user
manual for proper progressive scan setup or deactivate the progressive scan
feature as below:
1) Turn off your TV progressive scan mode or turn on to interlaced mode.
2) Select “OFF” in PROGRESSIVE menu of the system setup menu to turn off
progressive scan, then press SYSTEM MENU on the remote to exit the system
menu.
Tip
See chapters "Getting Started" and "DVD menu operations" in the
User Manual for detailed descriptions.
SETUP MENU
Picture Setup
Sound Setup
Language Setup
Feature Setup
OFF
OFF
NIGHT MODE
GOTO SOUND SETUP PAGE
TEST TONE
ENGLISH
ENGLISH
ENGLISH
GOTO LANGUAGE SETUP PAGE
AUDIO
SUBTITLE
DISC MENU
8 ADULT
CHANGE
ENGLISH
RESET
GOTO FEATURE SETUP PAGE
OSD LANG
WIDE
MULTI
OFF
ON
GOTO PICTURE SETUP PAGE
TV DISPLAY
TV TYPE
PROGRESSIVE
SCREEN SAVER
Setting up the TV
1
4
7
2
5
8
0
3
6
9
ANGLEPROG
AUDIO MUTE
GOTO
VOL
+
ZOOM
DSC
DBB
OK
SYSTEM MENU
SUBTITLE REPEAT A-B SHUFFLE
SLOWDISPLAY
OSD
DISC MENU
DISC AUX
1
4
7
2
5
8
0
3
6
9
ANGLEPROG
AUDIO MUTE
GOTO
VOL
+
ZOOM
DSC
DBB
OK
SYSTEM MENU
SUBTITLE REPEAT A-B SHUFFLE
SLOWDISPLAY
OSD
DISC MENU
DISC AUX
SYSTEM MENU
1
2
MCD109_55 QSG_Eng 24/8/06, 15:183

Playing a disc
1
2
3
4
Push OPEN /CLOSEçto open the disc door.
Load in a disc with the label side facing up, then close the disc door.
Playback will start automatically. If not, pressÉÅ.
To stop playback, press 9.
PDCC-JH-0634
2006 CKoninklijie Philips Electronics
N.V. All rights reserved.
http://www.philips.com
Tip
Detailed playback features and
additional functions are described in the
accompanied user manual.
Notes for the remote control:
– First, select the source you wish to
control by pressing one of the source select
keys on the remote control (DISC or AUX,
for example).
–Then select the desired function ( 2; ,
í , ë for example).
