Philips MX960DHT User manual

DigitalAudio/Video Surround Receiver Package
•Integrated Dolby Digital®(AC-3) and ProLogic Surround Sound decoder
•6-Speaker Package with Subwoofer (customized acoustical speaker design!)
•350Watts Surround Power Output :
5 x 60Watts equal power per channel,and 50Watts Powered Subwoofer
•Digital Sound Processing via DUET CORE
•6 Channel Input terminal (DVDAudio and Super-Audio CD prepared)
•Virtual 3D Surround for Simulated Surround Sound without Rear Speakers
•'Hall' feature for normal stereo with rear speaker sound
•Loudness,Bass andTreble Control
•All Dolby surround Modes and Delayound Modes and DelayTimes
•Equalizer smarer smart sound modes :Personal,Speech,MusicMusic,MoMovie,Multi-MediaMulti-Media
•Night mode for Dynamic Range ComprNight mode for Dynamic Range Compression of Digital Sound
•13Audio Input connections in total
•3 Digital Inputs (2 coax,1 optical) and a Digital Outputand a Digital Output (coax) for Digital (CD)
Recordings from multiple analogue or digital sources including DVD!
•4Video Input Connections and 2 OutputsVideo Input Connections and 2 Outputs
•Easy Hook up via Color Coded Speaker Connections
•Screw terminals for Left,Right and Center speaker connections
•'Cinema Link' System Contr'Cinema Link' System Control Bus
•51-keyAudio/Video MultiBrAudio/Video MultiBrand Universal Remote Control
•MenMenu Navigator Rotary Knob for quick set-up
•HarmonizHarmonized Philips Home Cinema Components designed Philips Home Cinema Components design
DigitalAudio/Video Surround Receiver Package
• Integrated Dolby Digital® (AC-3) and ProLogic Surround Sound decoder
• 6-Speaker Package with Subwoofer (customized acoustical speaker design!)
• 350Watts Surround Power Output :
5 x 60Watts equal power per channel,and 50Watts Powered Subwoofer
• Digital Sound Processing via DUET CORE
• 6 Channel Input terminal (DVDAudio and Super-Audio CD prepared)
• Virtual 3D Surround for Simulated Surround Sound without Rear Speakers
• 'Hall' feature for normal stereo with rear speaker sound
• Loudness,Bass andTreble Control
• All Dolby surround Modes and DelayTimes
• Equalizer smart sound modes :Personal,Speech,Music,Movie,Multi-Media
• Night mode for Dynamic Range Compression of Digital Sound
• 10Audio Input connections in total
• 3 Digital Inputs (2 coax,1 optical) and a Digital Output (coax) for Digital (CD)
Recordings from multiple analogue or digital sources including DVD!
• 3Video Input Connections and 2 Outputs
• Easy Hook up via Color Coded Speaker Connections
• Screw terminals for Left,Right and Center speaker connections
• 'Cinema Link' System Control Bus
• 51-keyAudio/Video MultiBrand Universal Remote Control
• Menu Navigator Rotary Knob for quick set-up
• Harmonized Philips Home Cinema Components design
MX960D
Home CinemaAudio System
SET UP MENU
NAVIGATOR

Sound Enhancement
Dolby Digital Surround Sound - Available on DVD,
Laserdisc*, satellite broadcasts, Cable and as the standard for
HDTV, Dolby Digital® offers the ultimate experience in home
theater surround with six discrete channels of digital CD sound.
Discrete means that each channel carries its own sound and
depending on what happens on screen each speaker plays its own
unique role in providing the right sound. Front left, center and
right join two surround speakers to reproduce highs,mid and bass
frequencies in five full-range channels of surround. Bass rumble,
explosions and low frequency effects you feel are delivered
through a dedicated sixth, subwoofer channel.Also known as AC-
3 and Dolby 5.1, Dolby Digital® delivers the expanded sense of
depth, localization and overall realism which was formerly only
known from digital surround sound equipped cinemas.
6-speaker package - No less then 5 full range loudspeakers to
build your personal cinema. The five speakers are acoustically
specially designed to match the tonal characteristics of the
receiver. Front left and right and surround left and right speaker
are tri-cone systems with a 5 1/4" driver, a 2" ferro fluid tweeter
and a 6 1/2" passive radiator for improved bass performance and
reduced distortion.The center speaker is three-way; carrying 2 4"
drivers and a 2" tweeter. Front left, right and center speaker are
magnetically protected to prevent any interference with television
picture tube purity. The sixth speaker is a 50 watt powered
subwoofer.
350W surround power output - The five, 3x60W (left, right,
center) and 2x60W (rear), receiver amplifiers together with the
50W subwoofer amplifier deliver 350 Watts of home theater
power.The stereo output power of 50W per channel is specified
at 6 Ohm, 40Hz-20KHz and 0.7% total harmonic distortion
(THD).The amplifiers have been designed with special attention
to a short 'rise' and 'fall' time, so characteristic for the frequent
and sudden drastic changes in dynamics of movie sound in
general. Furthermore,the amplification reserves are designed such
that they are more than sufficient to follow sudden needs for
more sound pressure.
50 W powered subwoofer - Subwoofers add dynamism to
normal music and motion pictures. It sets the stage for a more
intense sensation.The 50W Philips subwoofer features a down-
firing 51/4" woofer to reflect sound waves off the floor, thereby
adding impact. In addition a 50-150Hz crossover adjustment knob
and a bass level control rotary are present.In all, the subwoofer is
sufficiently power packed to generate that cinema essential sonic
sound boom.
Digital Sound Processing via DUET CORE - Philips
Semiconductors is highly specialized in digital sound processing.
One of their crown DSP (digital sound processing) ICs is the
'DUET'.The DUET's huge processing power of 80 MIPS (million
instructions per second) assures the highest possible accuracy in
digital audio processing. Other characteristics are automatic
detection of source (AC-3, MPEG or PCM audio) and smooth
(clicking free) automatic switching between coding formats.
Furthermore DUET carries digital bass cross-over filters (for
subwoofer signal) and 3rd generation virtualizer algorithms for
highly realistic virtual Dolby. Lastly, DUET has the unique capability
of translating Dolby Digital multi-channel sound into a stereo
signal suitable for digital recording onto e.g.CD-R.
Virtual 3D Surround / Virtual Dolby® Surround - A
Dolby Surround playback system delivers amazingly rich and
convincing surround sound from only the two (or three) front
speakers. The Pro-Logic or Dolby Digital® surround channel is
processed by a 'virtualizer' DSP to add the surround effect from
just the front speakers. The Philips virtualizer algorithm on the
'DUET' DSP is the current state of the art reference for virtual
surround sound processing.
'Hall' feature - For use with non-surround sound sources in
order to create a cinema effect through normal stereo with rear
speaker sound.This 'simulated' surround provides an extra musical
('live') ambience to stereo sound.
Equalizer Smart Sound - Has 5 modes, specially designed to
match the sound of variousTV (and Audio) programs. 'Speech' is
used for news,discussions and talk show programs.'Music' is used
for music programs. 'Movie' is used for movies or TV-series or
soaps. 'Multi-Media' is used when video games are connected to
the TV. 'Personal' corresponds with the bass and treble setting
chosen by the user.
Screw terminals - For left , right and center speaker
connection ensures a loss-less flow of electrical signals from the
set to all main loudspeakers.
Convenience
Digital inputs and output - 3 digital inputs (2 coax, 1 optical)
are foreseen to connect digital sound sources (e.g. DVD player,
CD player and DigitalTV). A digital output connection (coax) is
foreseen to enable digital (CD) recordings from any of the digital
inputs. The output can provide a down-mixed (stereo) DVD
multi-channel sound signal in order to record from DVD to e.g.
CD-R.
Stereo Downmix - The digital output will automatically
provide a stereo downmix in case a multichannel signal is
detected at any of the digital input connectors. In that way digital
audio recordings can be made from movie DVD's (e.g. Live
concerts from music DVD's)
Night mode - Establishes dynamic range compression of digital
sound to reduce the volume differences between the loud and
soft passages in source material with digital surround sound
where sound level differences can be so dramatic.This feature is
especially useful at night when you don't want to disturb the
neighbors or wake up the kids!
Video Connections - 3 video input connections and 2 outputs
(incl. monitor) are foreseen to hook up video sources. As these
video inputs switch simultaneously with the audio inputs, correct
picture with correct sound is guaranteed.
6 Channel input -Six input selectors at the back of the set
allow to connect to any type of multichannel decorder. Be it DTS,
DVD Audio or Super Audio CD.The 6 Channel input makes your
system future proof!
Easy hook up - With color coded speaker connections for
quick and easy connection of all loudspeakers. By using distinct
colors for each of the speaker connection terminal on the
speaker and on the set, and using the same color for the cable,
the chance of faulty connection (and customer complaints) are
practically zero!
Cinema Link System Control Bus - When connected to a
Philips TV with 'Cinema Link' (and even better, in addition a
Philips VCR and or DVD player), the combination offers an
interesting range of extra user benefits: One Touch Cinema -
upon starting your e.g. DVD disc, the complete system will
automatically switch to the correct source and sound mode.High
Resolution OSD - the onscreen display of the television will
feature the 'receiver' menu option.This option can be used for
easier receiver set-up and receiver settings. Multiple Languages -
depending on the languages offered by theTV (likely are Spanish,
French and English) the user can operate the set via theTV menu
in his/her native language.TV as Center speaker - allows to get rid
of the separate center speaker and use all the speakers and
amplifiers in the TV to function as center speaker (most large
screen Philips TVs provide over 50W of sound pressure). One
Touch End - puts your complete home theater system into
standby after some exciting hours of cinema enjoyment.
51-key Audio/Video Multi Brand Universal remote
control - To operate all main receiver functions and Philips,
Magnavox or any other mainstream branded CD player, tape
deck,VCR, television and DVD player, Satellite or cable box! The
remote will operate your non-Philips/Magnavox equipment by
simply entering a code from the instruction manual in the remote
control. The remote has a clear ergonomically designed lay-out
(see picture)
30 tuner presets with station name display -The available
tuner presets can be randomly used to store AM and FM stations
(30 in total). Each of the presets can be given a user defined
name of up to 8 characters. Giving the preset a name is as easy
as 1-2-3 with the menu navigator.
Tuner sensitivity adjustment - The tuner sensitivity to pick
up radio stations can be set to high and low. In case of low, only
the 'strong' stations will be picked up during a search.When even
some of the weaker stations are of interest, the 'low' option will
pick up every station the tuner can possibly receive.
Display brightness adjustment - Conveniently adjusts the
brightness of the display in 3 steps.
2 switched mains outlets - Allows to connect another HiFi
component. Switching the receiver to standby will automatically
switch off the connected set.
Standby power <2W -To help save energy consumption, the
standby transformer of this set has been designed not to
consume more than 2Watt in standby mode.
UPC Code :0 37849 89370 8
Product Dimensions:
17.1"W x 5.3" H x 13.8" D (set)
8.6" W x 16.6" H x 7.6" D (l/r, center and rear
speakers)
17.1"W x 5.2" H x 4.8" D (center speaker)
9.3"W x 12.2" H x 14" D (subwoofer)
Product weight: 20.7 lbs.
Package Dimensions:
37.8"W x 20.7" H x 22.1" D
Total package weight :68.3 lbs
Carton contains: receiver FR965/17, remote control,
batteries, instruction for use, AM + FM antenna, quick
installation card, warrantee information, 6 loudspeakers
(incl. subwoofer), loudspeaker cable (L/R: 2x13ft, C:
1x10ft, S: 2x39ft.), subwoofer mains + connection cable,
'Cinema Link' cable,coax cable
Printed in Singapore
Date printed : Dec 1999
©1999 Royal Philips Electronics N.V.
All rights reserved.
A Division of Philips Electronics North America
Corp.
Specifications subject to change without notice.
Dolby, Dolby Digital®,Dolby ProLogic® and the
double-D symbol are trademarks of Dolby
Laboratories
Design
Harmonized Philips Home Cinema Components Design -
The design of this component follows the design language of the
Philips Harmonized Home Cinema design. Characteristics of this
design language are stylish, simple, capable, powerful and rich. All
Philips Home Cinema components and HiFi components will follow
this design (e.g.VCR, CD Changer,CD Recorder DVD, etc).
Display - Color and graphic/character size are defined such that at
visibility remains clear even at larger distances.
Connections
• Audio inputs/outputs 7 analogue input sources,
3 analogue output connections
- Phono :in
- CD :in
- CDR/Tape :in/out
- TV : in
-SAT :in
- VCR : in/out
- 6 CH/DVD :in
- DVD :see digital audio inputs/outputs
- Headphone : 6.3mm
• Digital audio in/output 3 digital input sources,
1 digital output connection
- 2 digital coax connections: :in
- 1 optical slink to connection :in
- 1 digital coax connection :out
• Video inputs/outputs 3 input sources,
2 output connections
- DVD : in
-SAT :in
- VCR : in/out
- Monitor : out
• Speaker Connections suitable for speakers ≥6 Ohm
- left,right,center :screw type connection
- rear left,right :click-fit connection
• Miscellaneous connections
- Cinema Link System control bus
- subwoofer pre-out : 1
- center pre-out :2
- mains outlet :switched 2x
- AM antenna :loop type
- FM antenna : click-fit 300 Ohm
* Dolby Digital laserdisc use requires optionalAC-3 RF demodulator
DVD
2
H
AA
TV
Ç
É
MENU OK
GUIDE
NEWS/TA
5
13
2
46
79
8
0
MUTE
TUNER CD CDR/TAPE
DVD
SAT
VCR
TV
PHONO
CABLE BOXCINEMA LINK
Home Cinema Control
Multibrand/Universal
REC CANCEL FR.D. INDEX
íë ±
CHANNEL/TRACK LOUDNESS
3D SURR.NIGHT
DISC
SURR.
SURR. MODE
SOUND
T-C
Å
+
-
+
-
REAR
CHANNEL
SUB WOOFER TEST TONE
ON/
OFF
AUDIO
As an ENERGY STAR® Partner,Philips has determined that this product meets
the ENERGY STAR® guidelines for energy efficiency.
MX960D
Home CinemaAudio System
