Philips 7000 LED series
LCD TV with Ambilight
Spectra 2 and Pixel Precise
HD
37"
Full HD 1080p digital TV
37PFL7605H
Be part of the action!
with Ambilight in an ultra-thin design
Like a painting on your wall, experience the latest in ultra thin TVs from Philips.
Combining powerful LED picture performance and the immersion of Ambilight, be
assured you are always part of the action.
Enlarge your viewing experience
• Ambilight Spectra 2 widens the viewing experience
Action captured in stunning detail
• Full HD TV with Pixel Precise HD for details in action
• Brilliant LED images with low power consumption
• 100 Hz LCD, 2 ms performance for superb motion sharpness
• HD Natural Motion for ultra-smooth motion in Full HD movies
Impressive, invisible sound
• Feel the power of 20 W RMS and Incredible Surround Sound
Connect and enjoy the online world
• Net TV for popular online services on your TV
• DLNA PC Network link to browse PC and Home network content
Greener every day
• LED is up to 40% more energy efficient than normal LCD TVs

37PFL7605H/05
Highlights
LCD TV with Ambilight Spectra 2 and Pixel Precise HD
37" Full HD 1080p digital TV
Ambilight Spectra 2
Add a new dimension to your viewing
experience with Ambilight Spectra 2. This
patented Philips technology enlarges the
screen by projecting a glow of light, on 2 sides
of the TV, from the back of the screen onto the
surrounding wall. Ambilight automatically
adjusts the colour and brightness of the light to
match the picture, creating an immersive
viewing experience. The wall adaptive function
ensures that the colour of the light always
matches the picture, no matter the colour of
your wall. With Ambilight Spectra 2, movies
truly come to life!
Pixel Precise HD
Pixel Precise HD builds on the award winning
Pixel Plus foundation. It brings the high
definition picture quality to the next level with
4 trillion colours with HD Natural Motion
making all your movies fluently moving and
razor sharp. With Super Resolution, Pixel
Precise HD now brings you the best HD TV
picture quality whether you are watching a
video from the Internet or good quality Blu-ray
movies.
LED
LED lighting technology is the most advanced
available. In this TV it combines an eye-catching
minimalistic design with stunning image quality,
as well as having the lowest power
consumption in its category. Another
environmental benefit is that LED lighting
technology does not contain hazardous
materials. With an LED backlight you can enjoy
low power consumption, high brightness,
incredible contrast and sharpness and vibrant
colours.
100 Hz LCD, 2 ms response time
100 Hz LCD creates extreme motion
sharpness. The Double Frame Rate Insertion
increases the sharpness of motion
reproduction to more than twice that of
conventional LCD, resulting in a performance
with a response time of 2 milliseconds. Now
you can enjoy clear images even with fast on-
screen motion.
HD Natural Motion
Philips invented HD Natural Motion to
minimise juddering effects that are visible with
movie-based picture content. The award
winning algorithm estimates motion in the
picture and corrects juddering movements in
both broadcast and recorded movie material
(such as DVD and Blu-ray Disc). The resulting
smooth motion reproduction and excellent
sharpness take the viewing experience to a
higher level.
20 W RMS Incredible Surround Sound
Feel the power of the music beat and the
atmosphere of the movies. The powerful 20 W
RMS (2 x 10 W RMS) amplifiers create a lifelike
soundstage. The Incredible Surround Sound
allows you to experience total surround with
greater depth and width of sound. It gives a
clear and spacious sound stage complementary
to the rich viewing experience.
Net TV
Experience a rich selection of online services
with Net TV. Enjoy movies, pictures,
infotainment and other online content directly
on your TV whenever you like. Simply connect
your home theatre directly to your home
network through the Ethernet connection, and
navigate and select what you want to watch
with the remote control. The Philips menu
gives you access to popular Net TV services
fitted for your TV screen. Additionally, with
the DLNA certified PC network you can watch
videos or access pictures stored on your
computer using your remote control.
Energy efficient LED
Up to 40% more energy efficient than
conventional flat TVs. Using the latest LED
backlight technology, LED-backlit TVs are
considered a more sustainable choice, with a
longer life and far lower energy consumption
than plasmas and conventional LCD TVs.
Unlike CCFL backlights, LEDs do not use
mercury in their manufacture. In addition,
Philips TV designs have improved generation
after generation resulting in an increase in
material efficiency and a reduction in energy
usage without compromising on safety and
wellbeing. That's good news for you today -
your children tomorrow.

Issue date 2010-09-06
Version: 2.1.6
12 NC: 8670 000 60036
EAN: 87 12581 52601 6
© 2010 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
37PFL7605H/05
Specifications
LCD TV with Ambilight Spectra 2 and Pixel Precise HD
37" Full HD 1080p digital TV
Picture/Display
• Peak Luminance ratio: 65 %
• Aspect ratio: Widescreen
• Brightness: 450 cd/m²
• Dynamic screen contrast: 500,000:1
• Response time (typical): 2 ms
• Viewing angle: 176º (H)/176º (V)
• Diagonal screen size: 37 inch / 94 cm
• Display: LCD Full HD, edge LED backlight
• Panel resolution: 1920 x 1080p
• Picture enhancement: 100 Hz, 2 ms, Pixel precise
HD, Active Control + Light sensor, 100 Hz Clear
LCD, Digital Noise Reduction, Dynamic contrast
enhancement, Luminance Transient Improver,
MPEG artefact reduction, HD Natural Motion,
Super Resolution, Colour booster
• Screen enhancement: Anti-Reflection coated
screen
• Colour processing: 4 trillion colours (14-bit RGB)
Ambilight
• Ambilight Version: 2 sided
• Ambilight Features: Ambilight Spectra 2, Lounge
light mode
• Dimming Function: Manual and via Light Sensor
• Ambilight light system: LED-wide colour
Supported Display Resolution
• Computer inputs: up to 1920 x 1080 @ 60 Hz
• Video inputs: up to 1920 x 1080p, 24, 25, 30, 50, 60
Hz
Sound
• Output power (RMS): 2 x 10 W, Invisible Sound
• Sound Enhancement: Auto Volume Leveller,
Dynamic Bass Enhancement, Incredible Surround,
Treble and Bass Control, Clear Sound
• Sound System: Mono, Nicam Stereo, Stereo
Convenience
• Child Protection: Child Lock+Parental Control
• Clock: Sleep Timer
• Ease of Installation: Channel installation wizard,
Network installation wizard, Settings assistant
wizard, Device connection wizard, Auto detect
Philips devices, Auto Programme Naming,
Autoinstall, Programme Name, Sorting
• Ease of Use: Smart Picture, Smart Sound, On-
screen User manual, EasyLink, Favourite
programme selection, Mozaïc channel grid, One-
stop experience button, One-stop Home button
• Electronic Programme Guide: Now + Next EPG,
8-day Electronic Programme Guide*
• Screen Format Adjustments: Auto Format, Super
Zoom, Movie expand 16:9, Widescreen, unscaled
(1080p dot by dot)
• Teletext: 1200-page Hypertext
• Firmware upgradeable: Firmware auto upgrade
wizard, Firmware upgradeable via USB, Online
firmware upgrade
• Multimedia: DLNA media Browser, Net TV
services, USB media browser
Multimedia Applications
• Net TV: Included
• Picture Playback Formats: JPEG
• Music Playback Formats: MP3, WMA (v2 up to
v9.2), AAC
•Video Playback Formats: Codec support:, H264/
MPEG-4 AVC, MPEG-1, MPEG-2, MPEG-4,
WMV9/VC1, Containers: AVI, MKV
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: DVB COFDM 2K/8K
• Video Playback: NTSC, SECAM, PAL
• Digital TV: DVB Terrestrial*, DVB-T MPEG4*,
DVB-C MPEG4*
•Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• Summary: 4 x HDMI, 1 x USB, 2 x SCART, 1 x
Ethernet, Wi-Fi ready
• Ext 1 Scart: Audio L/R, CVBS in, RGB
• Ext 2 Scart: Audio L/R, CVBS in, RGB
• Ext 3: YPbPr, Audio L/R in
• VGA-in: PC input, D-sub 15
•HDMI1:HDMIv1.4(AudioReturn Ch.)
•HDMI2:HDMIv1.3
•HDMI3:HDMIv1.3
• HDMI Side: HDMI v1.3
• Front/Side connections: USB, Common Interface
Slot (CI-CI+), SD-card (Videostore)
• Other connections: Headphone out, PC Audio in,
Ethernet-LAN RJ-45
• EasyLink (HDMI-CEC): One touch play, EasyLink,
Pixel Plus link, Remote control pass-through,
System audio control, System standby
• Audio Output - Digital: Coaxial (cinch)
• PC network link: DLNA 1.5 certified
Power
• Off mode power consumption: < 0.01 W
• Green label: ECO label certified
• Presence of lead: Yes*
• Annual energy consumption: 106.58 kW·h
• Ambient temperature: 5°C to 40°C
• Mains power: 220 - 240 V, 50/60 Hz
• Power consumption (typical): 73 W
• Standby power consumption: < 0.15 W
• Power Saving Features: 0 Watt Power-off switch,
Light sensor, Eco mode, Picture mute (for radio),
Auto switch-off timer
Dimensions
•Setdimensions(Wx H x D): 898 x 554 x 42 mm
• Set dimensions with stand (W x H x D):
898 x 602 x 242 mm
• Weight incl. Packaging: 17.2 kg
• Product weight: 12 kg
• Product weight (+stand): 15 kg
•Boxdimensions(Wx H x D):
1078 x 642 x 158 mm
• Colour cabinet: Silver-brushed deco-front with
black cabinet
• Compatible wall mount: 200 x 200 mm
Accessories
• Included accessories: Tabletop swivel stand, Quick
start guide, Registration card, Warranty Leaflet,
Remote Control, 2 x AAA Batteries, Safety/legal
instructions, Software declaration
• Optional accessories: Wireless USB adapter
(PTA01)
•
* 8 days EPG, service not available in all countries
* Typical on-mode power consumption measured according to
IEC62087 Ed 2.
* Net TV: Visit www.philips.com/tv to discover the services offered in
your country.
* Annual energy consumption is calculated using the typical power
consumption 4 hours per day, 365 days per year.
* The TV supports DVB reception for 'Free to air' broadcast. Specific
DVB operators may not be supported. An up to date list can be
found in the FAQ section of the Philips support website. For some
operators Conditional Access and subscription are required.
Contact your operator for more information.
* This television contains lead only in certain parts or components
where no technology alternatives exist in accordance with existing
exemption clauses under the RoHS Directive.
REAR CONNECTORS
BOTTOM REAR CONNECTORS
SIDE CONNECTORS
