Philips
Eco Smart LED TV with
Pixel Plus HD
117 cm (46")
Full HD 1080p DVB-T/C
46PFL6806H
Designed with the future in mind
Energy class A++
Awarded as the European Green TV 2011-2012 by EISA, the Philips Econova 46PFL6806
ECO Smart LED TV has clear, vivid Full HD pictures and authentic sound. With Smart
TV, you can easily surf the internet and download movies.
Your entertainment in brilliant detail
• Full HD TV with Pixel Plus HD for better details and clarity
• Brilliant LED images with incredible contrast
• 400Hz Perfect Motion Rate (PMR) for superb motion sharpness
Enjoy the online world with Smart TV
• A wealth of online apps, videos to rent and catch-up TV
• Control the TV with your smart phone, tablet or keyboard
• With SimplyShare, enjoy photos, music and movies on your TV
• Find, schedule, record* & pause TV
• Wi-Fi Ready to use Net TV Apps and SimplyShare wirelessly
Greener every day
• Zero watt power switch
• 2-in-1 stand for easy use on table and a wallmount
• Solar rechargeable remote means never replace batteries
• Energy Class A++

46PFL6806H/12
Highlights
Eco Smart LED TV with Pixel Plus HD
117 cm (46") Full HD 1080p DVB-T/C
Pixel Plus HD
Pixel Plus HD offers the unique combination of
ultimate sharpness, natural detail, vivid colors,
and smooth natural motion. Artifacts and noise
in any sources from multimedia to standard
definition TV and also in highly compressed
HD are detected and reduced, ensuring that
the picture is clear and razor-sharp.
Full HD LED TV
The most advanced LED lighting technology in
this Full HD LED TV combines an eye-catching
minimalistic design with stunning image quality
as well as the lowest power consumption in its
category. On top of that, LED lighting
technology does not contain any hazardous
materials. Thus, with LED backlight you can
enjoy low power consumption, high
brightness, incredible contrast, sharpness and
vibrant colors.
400Hz Perfect Motion Rate
400Hz Perfect Motion Rate (PMR) creates
extreme motion sharpness for clear and
vibrant images in fast action movies. The new
Philips PMR standard shows the combined
visible effect of the fastest panel refresh rate,
HD Natural Motion and unique processing
formula, for unprecedented motion sharpness.
Zero Watt power switch
Zero power consumption at a flick of the 0
Watt hard switch
2-in-1 stand
This TV comes with a revolutionary table top
stand that can also be use to wall-mount your
television. There is no need to buy additional
wall-mount brackets. The environment
benefits even more because an unnecessary
soure of waste is eliminated as you do not
need to discard any parts.
Solar powered remote control
With this Solar powered rechargeable remote
you never need to replace or dispose of
batteries again. Designed for maximum
sustainability the solar cell will recharge the
remote from freely available source of energy:
daylight. And even in darker winter times there
is no need to worry. The built in accumulator
has a significant energy reserve to keep the RC
going, and keep you in control!
100% recyclable packaging
100% recyclable packaging for lowest
environmental impact. A lot of detail and
breakthrough innovation went in the design of
this packaging. By eliminating polystyrene
buffers, this TV makes yet another
contribution to a more sustainable
environment . In a highly innovative
development for this size of TV it uses only
paper and cardboard, so the complete
packaging can easily be recycled.
Smart TV
Smart TV for an easier TV experience in 4
areas. Net TV lets you rent movies, watch
catch-up TV and enjoy social media.
Control your TV with your Smartphone
or tablet. Use SimplyShare to enjoy
multimedia content from your computer,
phone & tablet on your TV. Record your
TV programs easily without additional
bulky devices.
Full HD
LED
Perfect Motion Rate
remote control
energy
savings

Issue date 2013-03-10
Version: 11.1.8
12 NC: 8670 000 81535
EAN: 87 12581 61938 1
© 2013 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
46PFL6806H/12
Specifications
Eco Smart LED TV with Pixel Plus HD
117 cm (46") Full HD 1080p DVB-T/C
Picture/Display
• Display: edge LED backlight
• Diagonal screen size: 46 inch / 117 cm
• Panel resolution: 1920x1080p
• Aspect ratio: 16:9
• Peak Luminance ratio: 65 %
• Dynamic screen contrast: 500,000 : 1
• Response time (typical): 2 ms
• Picture enhancement: Pixel Plus HD, HDNatural
Motion, Active Control + Light sensor, Super
Resolution, 400 Hz Perfect Motion Rate
Sound
• Output power (RMS): 28W (2 x 14W)
• Sound Enhancement: AmbiwOOx, Auto Volume
Leveller, Clear Sound, Incredible Surround, Treble
and Bass Control
Smart TV Applications
• Control: MyRemote app (iOS & Android), USB
Keyboard & Mouse support
• SimplyShare: DLNA media browser, USB media
browser
• Net TV: Catch-up TV, Online Video stores, Open
Internet browser, Online apps
• Program: Pause TV, USB recording
Connectivity
• Number of HDMI connections: 3
•HDMIfeatures:Audio Return Channel
• EasyLink (HDMI-CEC): Remote control pass-
through, System audio control, System standby,
Plug & play add to Homescreen, Auto subtitle shift
(Philips), Pixel Plus link (Philips), One touch play
• Number of component in (YPbPr): 1
•Numberofscarts(RGB/CVBS):1
• Number of USBs: 1
• Other connections: Antenna IEC75, Common
Interface Plus (CI+), Ethernet-LAN RJ-45, SD card
slot (Videostore), Digital audio out (coaxial), PC-in
VGA + Audio L/R in, Headphone out, Service
connector
• Wireless connections: Wireless LAN ready
Multimedia Applications
• Video Playback Formats: Codec support:,
Containers: AVI, MKV, H264/MPEG-4 AVC,
MPEG-1, MPEG-2, MPEG-4, WMV9/VC1
• Music Playback Formats: AAC, MP3, WMA (v2 up
to v9.2)
• Picture Playback Formats: JPEG
• Net TV: Included
Supported Display Resolution
• Computer inputs: up to 1920x1080 @ 60Hz
• Video inputs: 24, 25, 30, 50, 60 Hz, up to
1920x1080p
Convenience
• PC network link: DLNA 1.5 certified
• Electronic Program Guide: 8day Electronic
Program Guide*
• Ease of Installation: Auto detect Philips devices,
Channel installation wizard, Device connection
wizard, Network installation wizard, Settings
assistant wizard, 2-in-1 Wallmount Stand
• Ease of Use: One-stop Home button, Onscreen
Usermanual, Touch control buttons
• Screen Format Adjustments: Autofill, Autozoom,
Movie expand 16:9, Super Zoom, Unscaled,
Widescreen
• Signal strength indication
• Teletext: 1200 page Hypertext
• Firmware upgradeable: Firmware auto upgrade
wizard, Firmware upgradeable via USB, Online
firmware upgrade
Tuner/Reception/Transmission
• Digital TV: DVB-C MPEG2*, DVB-C MPEG4*,
DVB-T MPEG2*, DVB-T MPEG4*
• Video Playback: NTSC, PAL, SECAM
Power
• Mains power: 220-240V~; 50-60Hz
• Ambient temperature: 5 °C to 40 °C
• Energy Label Class: A++
• Eu Energy Label power: 45.5 W
• Annual energy consumption: 63.1 kW·h
• Standby power consumption: < 0.15 W
• Power Saving Features: 0 Watt Power-off switch,
Auto switch-off timer, Eco mode, Eco settings
menu, Light sensor, Picture mute (for radio)
• Presence of lead: Yes*
• Off mode power consumption: < 0.01 W
• Annual stby energy consumption: 1.1* kW·h
Dimensions
•Boxdimensions(Wx H x D):
1324 x 773 x 198 mm
•Setdimensions(Wx H x D):
1081 x 653 x 39.9 mm
• Set dimensions with stand (W x H x D):
1081 x 705 x 265 mm
• Product weight: 16.4 kg
• Product weight (+stand): 20 kg
• Compatible wall mount: 400 x 400mm
Accessories
• Included accessories: Power cord, Solar powered
remote control, Quick start guide, Legal and safety
brochure, Warranty Leaflet, Charging cable USB A
> Micro-B
• Optional accessories: Wireless USB adaptor
(PTA01), Philips Wall Mount SQM 6375, Philips
Wall Mount SQM 6485
Sustainability
• Energy Efficiency: Ambient light sensor, Energy
saving options, Lowest power in Ultra-thin TVs,
Solar rechargeable Remote, Low power LED
display, 60% less power vs LCD/CCFL
• Material: 2 in 1 Stand avoids waste, Minimal
component Architecture, Minimal industrial metal
waste, Minimized internal cable
• Packaging: 100% paper monomaterials, Full
cardboard cushions, Minimized dimensions
• Recycling and disposal: Designed for disassembbly,
Highest % recyclable content, packaging materials
100% paper
• Removal hazardous substances: Full Halogen &
PVC free design
• User manual: 28 languages E-user manual,
Integrated E- user manual, No paper user manual
•
* Net TV: Visit www.philips.com/smarttv to discover the services
offering in your country.
* The TV supports DVB reception for 'Free to air' broadcast. Specific
DVB operators may not be supported. An up to date list can be
found in the FAQ section of the Philips support website. For some
operators Conditional Access and subscripction are required.
Contact your operator for more information.
* Using the integrated digital TV tuner will help to save energy
* 8 days EPG, service not available in all countries
* Energy consumption in kWh per year, based on the power
consumption of the television operating 4 hours per day for 365
days. The actual energy consumption will depend on how the
television is used.
* Using the ZERO power off switch will reduce standby energy
consumption to 0
* This television contains lead only in certain parts or components
where no technology alternatives exist in accordance with existing
exemption clauses under the RoHS Directive.
REAR CONNECTORS
BOTTOM REAR CONNECTORS
SIDE CONNECTORS
