Philips MCD297/12 User manual

USB/
USB/
MCD297
Quick Start Guide
What’s in the Box?
You should find these items upon opening the box.
1
Quick Start Guide
Quick Start Guide
Composite Video Cable Remote control with
battery
MW antenna FM antenna
2
User Manual
User Manual
Remove the plastic
protective sheet
MCD297 QUG_Eng 2008.6.24, 10:37 AM1

SPEAKER 4Ω
R L
FM aerial
75 Ω
LINE OUT
VIDEO OUT
VIDEO S-VIDEO
COAXIAL
SUB WOOFER
OUT
R L
MW aerial
+
–
AC power cord
FM wire
antenna
MW loop
antenna
Speaker
(right)
Speaker
(left)
Tip
See the User Manual for other TV
connection options.
Setting up the TV
1
2
4
3
Connect the speaker cables.
Connect the FM and MW antennas.
Connect the composite video cable to a TV.
Connect the power cords of the system and TV.
1
2
Press SOURCE (DISC on the remote) to select disc source.
Turn on the TV and set it to the correct Video In channel.
USB/USB/
AUDIO OUT
L
R
B
ATo listen to the sound of this DVD Player
through your TV, use the audio cables (white/
red-not supplied) to connect LINE OUT
(L/R) jacks of the DVD Player to the
corresponding AUDIO IN jacks on the TV.
B To listen to the sound of your TV through
this DVD player, use a cinch cable (not
supplied) to connect AUX-IN on the front
panel of the DVD player to the
corresponding AUDIO OUT jacks on the TV.
A
MCD297 QUG_Eng 2008.6.24, 10:37 AM2

Setting the clock
1
2
3
4
In standby mode, press and hold CLOCK on the system.
When the hour digits flash, turn the VOLUME -/+ control on the front panel or press
VOL +/- on the remote to set the hours.
Press CLOCK again and the minute digits flash.Then turn the VOLUME -/+ control on
the front panel or press VOL +/- on the remote to set the minutes.
Press CLOCK again to confirm the time setting.
Setting system menu options
Tip
See chapters "Preparations" and "System Menu Options" in the User
Manual for detailed descriptions.
USB/
LATIN
DIVX(R) VODDIVX(R) VOD
Important!
– To set clock in the Eco Power mode, press and hold ECO POWER/STANDBY ON on the set for 3 seconds
or more to switch to normal standby mode first before proceeding with the procedures below.
Before using the remote control
1 Pull out the plastic protective sheet.
2 Select the source you wish to control by pressing one of the source
select keys on the remote control (for example CD,TUNER).
3 Then select the desired function (for example ÉÅ , à, á)
Remove the plastic protective sheet
MCD297 QUG_Eng 2008.6.24, 10:37 AM3

Playing a disc
Programming and tuning to radio stations
1
2
3
Press SOURCE (TUNER on the remote) to select tuner source.
Press PROG/ANGLE for more than two seconds to program all available stations in
order of waveband.
Press PRESETí/ëuntil the desired preset station is displayed.
1
2
3
Press OPEN•CLOSE 0to open the disc tray and load in a disc, then press the same
button again to close the disc tray.
➜Make sure the label side of the disc is facing up.
Playback will start automatically. If not pressÉÅ.
To stop playback, press 9.
1
2
3
Insert the USB device’s USB plug into the socket on the front panel of the main set.
Press SOURCE (or USB/AUX on the remote control) once or more to select USB.
Playing a USB mass storage device
With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),
USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to
work with this Hi-Fi system).
Play the USB’s audio files as you do with the albums/tracks on a CD.
Tip
Detailed playback features and additional functions are described in the
accompany owner's manual.
PDCC-J.W.Wang 0746
CRoyal Philips Electronics N.V. 2007
All rights reserved.
http://www.philips.com
MCD297 QUG_Eng 2008.6.24, 10:37 AM4
