Philips MCM169/61 User manual

MCM169
You should nd these items upon opening the box.
Quick Start Guide
Remote Control
Quick Start Guide User Manual
1 x MP3 link cable
MCM169_61_QSG_0914_Eng.indd 1 1/18/2010 3:44:54 PM

6
5
4
3
2
1
2
Connect the speaker cables.
Speaker
(right)
Speaker
(left)
FM antenna
AC power
Tip
See the User Manual for how to
connect other equipment to this
system.
MP3 LINKUSB
MODE
USB RECORD USB DELETE
TIMER TIMER
Set clock
1
Connect the AC power cable to the main
unit and the wall socket.
7
Press and hold CLOCK/DISPLAY to activate the clock setting mode.
The 12 hour or 24 hour format is displayed..
➜
Press PROG repeatedly to select 12 hour or 24 hour format.
Press CLOCK/DISPLAY to conrm.
The hour digits are displayed and begin to blink.
➜
Press / to set the hour.
Press CLOCK/DISPLAY to conrm.
The minute digits are displayed and begin to blink.
➜
Press / to set the minute.
Press CLOCK/DISPLAY to conrm.
MCM169_61_QSG_0914_Eng.indd 2 1/18/2010 3:44:55 PM

4
3
2
1
Play disc
Press SOURCE (or DISC on the remote control) to select the disc source.
Lift the disc compartment door on the top panel to open the disc
compartment.
Insert a disc with the printed side facing up, then close the disc
compartment.
If the disc doesn’t play, press 2;.
To stop play, press 9.
5
1
2
3
Plug the USB device into the socket of this unit.
Press SOURCE once or more (or USB on the remote control) to select the USB source.
Play the USB’s audio les as you do with the albums/tracks on a CD.
Play form USB
With the Hi-Fi system, you can use USB ash memory (USB 2.0 or USB1.1),
USB ash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to
work with this Hi-Fi system).
MCM169_61_QSG_0914_Eng.indd 3 1/18/2010 3:44:56 PM

1
2
3
Press SOURCE (or TUN on the remote control) repeatedly to select FM or MW.
Press PROG for more than two seconds to program all available stations in order of
waveband.
In tuner mode, press PRESET/ALBUM +/- (or ALB/PRESET +/- on the remote control) to
select a preset number.
Listen to radio
MCM169_61_QSG_V1.0
Tip
Detailed playback features and additional functions are described in the
accompany owner's manual.
MP3 LINKUSB
MODE
USB RECORD USB DELETE
TIMER TIMER
© 2010 Koninklijke Philips Electronics N.V.
All rights reserved.
