Philips NN-P994 NN-T994SF User manual

Service Manual
TOP NEXT
ORDER NO.SIMMC 0401005A1
E1
Microwave Oven
 NN-P994 NN-T994SF
 NN-T984SF NN-T964SF
NN-H964 NN-H944
NN-H934 NN-H924
NN-H914 NN-S954
NN-S944 NN-S934
NN-S924 NN-S914
APH(USA)
CPH(CANADA)
Please file and use this specified manual together with the service manual for Model NN-S560BF/WF
(ORDER NO. SIMMC0001002C3).
Page
1
of
4
1/5/2009

© 2004 Shanghai Matsushita Microwave Oven Co., Ltd.
All rights reserved. Unauthorized copying and distribution is a violation of law.
Page
2
of
4
1/5/2009

Page
3
of
4
1/5/2009

TOP
NEXT
Page
4
of
4
1/5/2009

Page
1
of
1
1/5/2009

4.2 PARTS LIST
TOP PREVIOUS NEXT
NOTE:
1. When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
2. Important safety notice:
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacture’s specified parts.
NOTE:
“A” parts are supplied by MOD (Japan)
“F” parts are supplied by SIMMC (China)
Ref.
No.
Part No. Part Name & Description Pcs/Set Remarks
1F00064W70AP CAUTION LABEL 1 P994 APH, T9*4SF APH
1 F00069660AP CAUTION LABEL 1 H9*4 APH, S9*4 APH
1 F00067600CP CAUTION LABEL 1 CPH
2F00076G30BAP NAME PLATE 1 H964BF APH
2 F00076G30HAP NAME PLATE 1 H964WF APH
2 F00076G60BAP NAME PLATE 1 H944BF APH
2 F00076G60HAP NAME PLATE 1 H944WF APH
2 F00076G80BAP NAME PLATE 1 H944BFW APH
2 F00076G80HAP NAME PLATE 1 H944WFW APH
2 F00076G40BAP NAME PLATE 1 S954BF APH
2 F00076G40HAP NAME PLATE 1 S954WF APH
2 F00076G70BAP NAME PLATE 1 S944BF APH
2 F00076G70HAP NAME PLATE 1 S944WF APH
2 F00076G90BAP NAME PLATE 1 S944BFW APH
2 F00076G90HAP NAME PLATE 1 S944WFW APH
2 F00076H20BAP NAME PLATE 1 H924BF APH
2 F00076H20HAP NAME PLATE 1 H924WF APH
2 F00076H40BAP NAME PLATE 1 H914BF APH
2 F00076H40HAP NAME PLATE 1 H914WF APH
2 F00076H00BAP NAME PLATE 1 H934BF APH
2 F00076H00HAP NAME PLATE 1 H934WF APH
2 F00076Q10BAP NAME PLATE 1 H924BFW APH
2 F00076Q10HAP NAME PLATE 1 H924WFW APH
Page
1
of
4
1/5/2009

2 F00076H30BAP NAME PLATE 1 S924BF APH
2 F00076H30HAP NAME PLATE 1 S924WF APH
2 F00076H50BAP NAME PLATE 1 S914BF APH
2 F00076H50HAP NAME PLATE 1 S914WF APH
2 F00076H10BAP NAME PLATE 1 S934BF APH
2 F00076H10HAP NAME PLATE 1 S934WF APH
2 F00076Q20BAP NAME PLATE 1 S924BFW APH
2 F00076Q20HAP NAME PLATE 1 S924WFW APH
3F00334W00AP FUSE LABEL 1
4F10016G10AP BASE 1
5F10084T00AP RUBBER FOOT 4
6F110D5W00SAP CABINET BODY 1 P994SF, T9*4SF APH
6 F110D5W20BAP CABINET BODY 1 P994BF, H9*4BF(W), S9*4BF(W)
6 F110D5W20HAP CABINET BODY 1 P994WF, H9*4WF(W), S9*4WF(W)
7 F200A5W20AP OVEN 1 P994 APH/CPH, T9*4SF APH, H9*4 APH/CPH
7 F200A5W30AP OVEN 1 S9*4 APH
8F20555K00AP COVER 1
9F21315Y00AP PULLY SHAFT 1
10 F2177-F80 WASHER 1
11 F290D9330AP ROLLER RING (U) 1
12 F3020-1200 DOOR HOOK 1
14 F3136-1200 HOOK LEVER A 1
15 F31374650AP HOOK LEVER B 1
16 F31384650AP HOOK LEVER C 1
17 F400A5Y00AP FAN MOTOR 1 AC120V, SINGLE PHASE, 60Hz
18 F40084T00AP FAN BLADE 1
19 F40254W00AP AIR GUIDE A 1
21 F41445W00AP ORIFICE 1
22 F64508660AP SENSOR COVER B 1 P994 APH/CPH, T9*4SF APH, H9*4 APH/CPH
24 F65434W00AP SENSOR COVER C 1 P994 APH/CPH, T9*4SF APH, H9*4 APH/CPH
25 A607S4M00AP STEAM SENSOR 1 P994 APH/CPH, T9*4SF APH, H9*4 APH/CPH
26 F612E4W00AP INCANDESCENT LAMP (U) 1 125V, 60Hz, 20W
27 J61424T00AP MICRO SWITCH 1 (PRIMARY LATCH SWITCH) (V-15G-3C25)
28 J61414T00AP MICRO SWITCH 1 (SECONDARY LATCH SWITCH) (D3V-16G-3C25)
29 F61455L00CP THERMAL CUTOUT 1 105°C
30 F66264W00AP THERMAL CUTOUT INSULATION
BRACKET
1
Page
2
of
4
1/5/2009

31 J61784T00AP MICRO SWITCH 1 (SHORT SWITCH) (D3V-1G-2C25)
32 A606Y6G00AP H.V.INVERTER (U) 1
33 F65856K10AP INVERTER BRACKET 1 P994 APH, T9*4SF APH
33 F65856K50AP INVERTER BRACKET 1 P994 CPH, H9*4 APH/CPH, S9*4 APH
34 2M261-M32F MAGNETRON 1 APH
34 2M261-M32G MAGNETRON 1 CPH
35 B62308250AP FUSE 1 18A
36 F62315G10XN FUSE HOLDER 1 APH
37 J692Y4T00CPR NOISE FILTER 1 CPH
38 F63265G60AP TURNTABLE MOTOR 1
39 F900C4T60CP AC CORD W/PLUG 1 P994 APH/CPH, T9*4SF APH
39 F900C4T00AP AC CORD W/PLUG 1 H9*4 APH, S9*4 APH
39 F900C4W10CP AC CORD W/PLUG 1 CPH
40 F66626G10AP GROUNDING PLATE 1
41 XTWFA4+12T SCREW 4 FOR MAGNETRON
42 F90804W00AP CANOE CLIP 1 FOR COVER
43 XTTANE4T12A0 SCREW 5 FOR CABINET BODY
44 XTTFA4+8BFZ SCREW 2 FOR CABINET BODY SIDE (P994BF, H9*4BF(W), S9*4BF
(W))
44 XTTFA4+8BCR SCREW 2 FOR CABINET BODY SIDE
(P994SF/WF, T9*4SF, H9*4WF(W), S9*4WF(W))
45 XTWAFE4+8S SCREW 1 FOR THERMAL CUTOUT
46 F02245Y00AP CAUTION LABEL 1 P994SF APH/CPH, T9*4SF APH
47 F03346G60AP MENU LABEL 1 H944BF/WF APH
47 F03346G80AP MENU LABEL 1 H944BFW/WFW APH
47 F03346G40AP MENU LABEL 1 S954BF/WF APH
47 F03346G70AP MENU LABEL 1 S944BF/WF APH
47 F03346G90AP MENU LABEL 1 S944BFW/WFW APH
47 F03346H20AP MENU LABEL 1 H924BF/WF APH
47 F03346H40AP MENU LABEL 1 H914BF/WF APH
47 F03346H00AP MENU LABEL 1 H934BF/WF APH
47 F03346Q10AP MENU LABEL 1 H924BFW/WFW APH
47 F03346H30AP MENU LABEL 1 S924BF/WF APH
47 F03346H50AP MENU LABEL 1 S914BF/WF APH
47 F03346H10AP MENU LABEL 1 S934BF/WF APH
47 F03346Q20AP MENU LABEL 1 S924BFW/WFW APH
50 F82575W00AP DOOR OPENING BRACKET 1 P994 APH/CPH, T994SF APH, T984SF APH
50 F82574U00AP DOOR OPENING BRACKET 1 T964SF APH, H9*4 APH/CPH, S9*4 APH
Page
3
of
4
1/5/2009

TOP
PREVIOUS
NEXT
Page
4
of
4
1/5/2009

Page
1
of
1
1/5/2009

4.3.1 NN
-
H9*4 APH/CPH, NN
-
S9*4 APH
TOP PREVIOUS NEXT
TOP
PREVIOUS
NEXT
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
E1 F603L6G30AP D.P.CIRCUIT 1 H964BF/WF APH
E1 F603L6G60AP D.P.CIRCUIT 1 H944BF/WF/BFW/WFW APH, H924BF/WF/BFW/WFW APH
E1 F603L6G30CP D.P.CIRCUIT 1 H964BF/WF CPH
E1 F603L6G40AP D.P.CIRCUIT 1 S954BF/WF APH
E1 F603L6G70AP D.P.CIRCUIT 1 S944BF/WF/BFW/WFW APH, S924BF/WF/BFW/WFW APH
E1 F603L6H00AP D.P.CIRCUIT 1 H934BF/WF APH, H914BF/WF APH
E1 F603L6H10AP D.P.CIRCUIT 1 S934BF/WF APH, S914BF/WF APH
E3 F630Y6G30BAP MEMBRANE SWITCH (U) 1 H964BF APH
E3 F630Y6G30HAP MEMBRANE SWITCH (U) 1 H964WF APH
E3 F630Y6G60BAP MEMBRANE SWITCH (U) 1 H944BF/BFW APH
E3 F630Y6G60HAP MEMBRANE SWITCH (U) 1 H944WF/WFW APH
E3 F630Y6G30BCP MEMBRANE SWITCH (U) 1 H964BF CPH
E3 F630Y6G30HCP MEMBRANE SWITCH (U) 1 H964WF CPH
E3 F630Y6G40BAP MEMBRANE SWITCH (U) 1 S954BF APH
E3 F630Y6G40HAP MEMBRANE SWITCH (U) 1 S954WF APH
E3 F630Y6G70BAP MEMBRANE SWITCH (U) 1 S944BF/BFW APH
E3 F630Y6G70HAP MEMBRANE SWITCH (U) 1 S944WF/WFW APH
E3 F630Y6H20BAP MEMBRANE SWITCH (U) 1 H924BF/BFW APH
E3 F630Y6H20HAP MEMBRANE SWITCH (U) 1 H924WF/WFW APH
E3 F630Y6H00BAP MEMBRANE SWITCH (U) 1 H934BF APH, H914BF APH
E3 F630Y6H00HAP MEMBRANE SWITCH (U) 1 H934WF APH, H914WF APH
E3 F630Y6H30BAP MEMBRANE SWITCH (U) 1 S924BF/BFW APH
E3 F630Y6H30HAP MEMBRANE SWITCH (U) 1 S924WF/WFW APH
E3 F630Y6H10BAP MEMBRANE SWITCH (U) 1 S934BF APH, S914BF APH
E3 F630Y6H10HAP MEMBRANE SWITCH (U) 1 S934WF APH, S914WF APH
E4 F80346G40BAP ESCUTCHEON BASE 1 H9*4BF(W) APH/CPH, S9*4BF(W) APH
E4 F80346G40HAP ESCUTCHEON BASE 1 H9*4WF(W) APH/CPH, S9*4WF(W) APH
E5 F80726G40BAP DOOR OPENING BUTTON 1 H9*4BF(W) APH/CPH, S9*4BF(W) APH
E5 F80726G40HAP DOOR OPENING BUTTON 1 H9*4WF(W) APH/CPH, S9*4WF(W) APH
E6 F80375K00AP COOK BUTTON SPRING 1
E7 F82564M60AP DOOR OPENING LEVEL 1
E8 F00076G30BCP NAME PLATE 1 H964BF CPH
E8 F00076G30HCP NAME PLATE 1 H964WF CPH
Page
1
of
1
1/5/2009

Page
1
of
1
1/5/2009

4.3.2 NN
-
P994 APH/CPH, NN
-
T9*4 APH
TOP PREVIOUS NEXT
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
E10 F603L6G00AP D.P.CIRCUIT (AU) 1 P994 APH
E10 F603L6G00CP D.P.CIRCUIT (AU) 1 P994 CPH
E10 F603L6G10AP D.P.CIRCUIT (AU) 1 T994SF APH, T984SF APH
E10 F603L6Q00AP D.P.CIRCUIT (AU) 1 T964SF APH
E11 F800L4M60BCP CONTROL PANEL (AU) 1 T964SF APH
E12 F630Y6Q00SAP MEMBRANE SWITCH (U) 1 T964SF APH
E13 F82565W00AP DOOR OPENING LEVEL 1 P994 APH/CPH, T994SF APH, T984SF APH
E13 F82564M60AP DOOR OPENING LEVEL 1 T964SF APH
E14 F81274M60CP BACK PANEL 1 T964SF APH
E15 F00076G00SAP NAME PLATE 1 P994SF APH
E15 F00076G00BAP NAME PLATE 1 P994BF APH
E15 F00076G00HAP NAME PLATE 1 P994WF APH
E15 F00076G00SCP NAME PLATE 1 P994SF CPH
E15 F00076G00BCP NAME PLATE 1 P994BF CPH
E15 F00076G00HCP NAME PLATE 1 P994WF CPH
E15 F00076G10SAP NAME PLATE 1 T994SF APH
E15 F00076G20SAP NAME PLATE 1 T984SF APH
E15 F00076Q00SAP NAME PLATE 1 T964SF APH
E16 F66164W20AP FLAT CABLE 1 P994 APH/CPH, T994SF APH, T984SF APH
E17 F603Y5W00AP D.P.CIRCUIT (DU) 1 P994 APH, T994SF APH, T984SF APH
E17 F603Y5W00CP D.P.CIRCUIT (DU) 1 P994 CPH
E18 F83376G10SAP MEMBRANE SHEET 1 T994SF APH
E18 F83376G20SAP MEMBRANE SHEET 1 T984SF APH
E19 F800L6G00SAP CONTROL PANEL (AU) 1 P994SF APH
E19 F800L6G00BAP CONTROL PANEL (AU) 1 P994BF APH
E19 F800L6G00HAP CONTROL PANEL (AU) 1 P994WF APH
E19 F800L6G00SCP CONTROL PANEL (AU) 1 P994SF CPH
E19 F800L6G00BCP CONTROL PANEL (AU) 1 P994BF CPH
E19 F800L6G00HCP CONTROL PANEL (AU) 1 P994WF CPH
E19 F800L5W00BAP CONTROL PANEL (AU) 1 T994SF APH, T984SF APH
E20 F82986G00SAP BUTTON 1 P994SF APH/CPH
E20 F82986G00BAP BUTTON 1 P994BF APH/CPH
E20 F82986G00HAP BUTTON 1 P994WF APH/CPH
E20 F82985W00AP BUTTON 1 T994SF APH
E20 F82985W00BAP BUTTON 1 T984SF APH
E21 F90095X00AP GROUNDING PANEL 1 P994 APH/CPH, T994SF APH, T984SF APH
E22 F891P6G00SAP DOOR OPENING BUTTON 1 P994SF APH/CPH
Page
1
of
2
1/5/2009

TOP
PREVIOUS
NEXT
E22 F891P6G00BAP DOOR OPENING BUTTON 1 P994BF APH/CPH
E22 F891P6G00HAP DOOR OPENING BUTTON 1 P994WF APH/CPH
E22 F80724M60SCP DOOR OPENING BUTTON 1 T9*4SF APH
E23 F80375K00AP COOK BUTTON SPRING 1 P994 APH/CPH, T9*4SF APH
Page
2
of
2
1/5/2009

Page
1
of
1
1/5/2009

4.4 WIRING MATERIALS
TOP PREVIOUS NEXT
TOP
PREVIOUS
NEXT
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
W1 F030A6G30AP LEAD WIRE HARNESS 1 APH
W1 F030A6G30CP LEAD WIRE HARNESS 1 CPH
W2 F030E6G30AP H.V.LEAD WIRE 1 APH
W2 F030E6G30CP H.V.LEAD WIRE 1 CPH
Page
1
of
1
1/5/2009

Page
1
of
1
1/5/2009

4.5 PACKING AND ACCESSORIES
TOP PREVIOUS NEXT
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
P1 F00036J00AP INSTRUCTION MANUAL 1 P994SF/BF/WF APH, T9*4SF APH, H964BF/WF APH
P1 F00036J00CP INSTRUCTION MANUAL 1 P994SF/BF/WF CPH, H964BF/WF CPH
P1 F00036J30AP INSTRUCTION MANUAL 1 S954BF/WF APH
P1 F00036J50AP INSTRUCTION MANUAL 1 H944BF/WF/BFW/WFW APH, H934BF/WF APH,
H924BF/WF/BFW/WFW APH, H914BF/WF APH
P1 F00036J60AP INSTRUCTION MANUAL 1 S944BF/WF/BFW/WFW APH, S934BF/WF APH,
S924BF/WF/BFW/WFW APH, S914BF/WF APH
P2 F01026G00SAP PACKING CASE, PAPER 1 P994SF APH
P2 F01026G00BAP PACKING CASE, PAPER 1 P994BF APH
P2 F01026G00HAP PACKING CASE, PAPER 1 P994WF APH
P2 F01026G00SCP PACKING CASE, PAPER 1 P994SF CPH
P2 F01026G00BCP PACKING CASE, PAPER 1 P994BF CPH
P2 F01026G00HCP PACKING CASE, PAPER 1 P994WF CPH
P2 F01026G10SAP PACKING CASE, PAPER 1 T994SF APH
P2 F01026G20SAP PACKING CASE, PAPER 1 T984SF APH
P2 F01026Q00SAP PACKING CASE, PAPER 1 T964SF APH
P2 F01026G30BAP PACKING CASE, PAPER 1 H964BF APH
P2 F01026G30HAP PACKING CASE, PAPER 1 H964WF APH
P2 F01026G60BAP PACKING CASE, PAPER 1 H944BF APH
P2 F01026G60HAP PACKING CASE, PAPER 1 H944WF APH
P2 F01026G80BAP PACKING CASE, PAPER 1 H944BFW APH
P2 F01026G80HAP PACKING CASE, PAPER 1 H944WFW APH
P2 F01026G30BCP PACKING CASE, PAPER 1 H964BF CPH
P2 F01026G30HCP PACKING CASE, PAPER 1 H964WF CPH
P2 F01026G40BAP PACKING CASE, PAPER 1 S954BF APH
P2 F01026G40HAP PACKING CASE, PAPER 1 S954WF APH
P2 F01026G70BAP PACKING CASE, PAPER 1 S944BF APH
P2 F01026G70HAP PACKING CASE, PAPER 1 S944WF APH
P2 F01026G90BAP PACKING CASE, PAPER 1 S944BFW APH
P2 F01026G90HAP PACKING CASE, PAPER 1 S944WFW APH
P2 F01026H20BAP PACKING CASE, PAPER 1 H924BF APH
P2 F01026H20HAP PACKING CASE, PAPER 1 H924WF APH
P2 F01026H40BAP PACKING CASE, PAPER 1 H914BF APH
P2 F01026H40HAP PACKING CASE, PAPER 1 H914WF APH
P2 F01026H00BAP PACKING CASE, PAPER 1 H934BF APH
P2 F01026H00HAP PACKING CASE, PAPER 1 H934WF APH
P2 F01026Q10BAP PACKING CASE, PAPER 1 H924BFW APH
P2 F01026Q10HAP PACKING CASE, PAPER 1 H924WFW APH
P2 F01026H30BAP PACKING CASE, PAPER 1 S924BF APH
P2 F01026H30HAP PACKING CASE, PAPER 1 S924WF APH
Page
1
of
2
1/5/2009

TOP
PREVIOUS
NEXT
P2 F01026H50BAP PACKING CASE, PAPER 1 S914BF APH
P2 F01026H50HAP PACKING CASE, PAPER 1 S914WF APH
P2 F01026H10BAP PACKING CASE, PAPER 1 S934BF APH
P2 F01026H10HAP PACKING CASE, PAPER 1 S934WF APH
P2 F01026Q20BAP PACKING CASE, PAPER 1 S924BFW APH
P2 F01026Q20HAP PACKING CASE, PAPER 1 S924WFW APH
P3 F01044W00AP UPPER FILLER 1 P994 APH/CPH, T9*4SF APH
P3 F01045J00AP UPPER FILLER 1 H9*4 APH/CPH, S9*4 APH/CPH
P4 F01054W00AP LOWER FILLER 1 P994 APH/CPH, T9*4SF APH
P4 F01055J00AP LOWER FILLER 1 H9*4 APH/CPH, S9*4 APH/CPH
P5 F01064W00AP P.E.BAG 1
P6 F01074U00AP DOOR SHEET 1
P7 F06014M00AP COOKING TRAY 1
P8 F01084M00AP TRAY PACKING 1
P9 F01924U00AP SHEET 1 P994BF APH/CPH, H9*4BF(W) APH/CPH, S9*4BF(W) APH
P10 F00065G40AP CAUTION LABEL 1 APH
P11 F04456G00SCP OVERLAY 1 P994SF CPH
P11 F04456G00BCP OVERLAY 1 P994BF CPH
P11 F04456G00HCP OVERLAY 1 P994WF CPH
P11 F04456G30BCP OVERLAY 1 H964BF CPH
P11 F04456G30HCP OVERLAY 1 H964WF CPH
Page
2
of
2
1/5/2009

Page
1
of
1
1/5/2009
