Philips 107E Installation and operating instructions

electronic user's manual
file:///D|/Rita/LF3/lf3manual/english/107E/manual.html [2002/7/7 ?? 11:03:58]

Safety and Troubleshooting Information
Safety Precautions and Maintenance • Troubleshooting • Regulatory Information • Other
Related Information
Safety precautions and maintenance
WARNING: Use of controls, adjustments, or procedures other than those
specified in this documentation may result in exposure to shock, electrical
hazards, and/or mechanical hazards.
Read and follow these instructions when connecting and using your computer monitor:
Disconnect the monitor from the power supply if the monitor is not to be used for an extended period
of time.
●
Do not attempt to remove the back cover, as you will be exposed to a shock hazard. The back cover
should only be removed by qualified service personnel.
●
Do not place objects on top of the monitor cabinet, objects could fall into vents or cover them and
prevent proper cooling of the monitor's electronic devices.
●
To avoid the risk of shock or permanent damage to the set, do not expose the monitor to rain or
excessive moisture.
●
Do not use alcohol or ammonia-based liquid to clean the monitor. If necessary, clean with a slightly
damp cloth. Disconnect the monitor from the power supply before cleaning.
●
When positioning the monitor, make sure the power plug and outlet are easily accessible.●
Consult a service technician if the monitor does not operate normally when operating instructions of this
manual are followed.
RETURN TO TOP OF THE PAGE
Safety & Troubleshooting
file:///D|/Rita/LF3/lf3manual/english/107E/SAFETY/SAFETY.HTM [2002/7/7 ?? 11:04:09]

About This Electronic User's Manual
About This Guide • Other Documents You May Need • Notational Descriptions
About This Guide
This electronic user's guide is intended for anyone who uses the Philips Color Monitor. It describes the
monitor's features, setup, operation and all other information, which is the same exact information described
in our printed version.
The sections are as follows:
Safety and Troubleshooting Information provides tips and solutions for common problems, and other
related information you may need.
●
About This Electronic User's Manual gives overview of what information are included as well as
notation icon descriptions and other documentation you can refer to.
●
Product Information gives an overview of the monitor's features and as well as the technical
specifications for this monitor.
●
Installing Your Monitor describes the initial setup process and gives an overview of how to use the
monitor.
●
On Screen Display provides information on adjusting the settings on your monitor.●
Customer Care and Warranty is a list of worldwide Philips consumer information centers along with
the help desk phone numbers and information on the applicable warranty of your product..
●
Glossary provides more information for technical terms.●
Download allows users to install the entire manual on their hard drive.●
Frequently Asked Questions provides answers to commonly asked questions.●
RETURN TO TOP OF THE PAGE
Other Documents You May Need
In addition to this Electronic User's Guide, you may need to refer to the following documentation:
Philips Color Monitor Quick Start Guide which summarizes the steps for setting up the monitor. This
is included with this product.
●
RETURN TO TOP OF THE PAGE
Notational Descriptions
The following subsections describe notational conventions used in this document.
About This Electronic User's Manual
file:///D|/Rita/LF3/lf3manual/english/107E/ABOUT/ABOUT.HTM (1 of 2) [2002/7/7 ?? 11:04:10]

Notes, Cautions, and Warnings
Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic
type. These blocks are notes, cautions, and warnings, and they are used as follows:
NOTE: This icon indicates important information and tips that help you make better
use of your computer system.
CAUTION: This icon indicates information that tells you how to avoid either potential
damage to hardware or loss of data.
WARNING: This icon indicates the potential for bodily harm and tells you how to
avoid the problem.
SMART HELP: This icon indicates helpful information when adjusting the On Screen
Display of your monitor.
Some warnings may appear in alternate formats and may be unaccompanied by an icon. In such cases, the
specific presentation of the warning is mandated by regulatory authority.
RETURN TO TOP OF THE PAGE
©2002 Koninklijke Philips Electronics N.V.
All rights reserved. Reproduction, copying, usage, modifying, hiring, renting, public performance, transmission and/or broadcasting in whole or in
part is prohibited without written consent of Philips Electronics N.V.
About This Electronic User's Manual
file:///D|/Rita/LF3/lf3manual/english/107E/ABOUT/ABOUT.HTM (2 of 2) [2002/7/7 ?? 11:04:10]

Product Information
Product Features • Technical Specifications • Automatic Power Saving • Physical
Specification • Pin Assignment • Product Views
Product Features
107E40
17-inch (16.0" VIS) color monitor with excellent front of screen performance for use with MACs and
PCs
●
Autoscan covers horizontal frequencies up to 70 kHz offering a maximum resolution of 1280 x 1024
with flicker free display of 1024 x 768 at up to 88 Hz
●
Flat square High Contrast CRT with high-resolution 0.27 mm dot pitch (0.23 hdp).● Large screen display in a small footprint: World's shortest 17-inch conventional monitor with maximum
depth of only 408 mm/16.1"
●
Multimedia Base and USB Hub option● sRGB for true on screen color representation.●
FCC, CE (in selected countries only) and ISO9241, ISO14001 certified ●
107E41
17-inch (16.0" VIS) color monitor with excellent front of screen performance for use with MACs and
PCs
●
Autoscan covers horizontal frequencies up to 70 kHz offering a maximum resolution of 1280 x 1024
with flicker free display of 1024 x 768 at up to 88 Hz
●
Flat square High Contrast CRT with high-resolution 0.27 mm dot pitch (0.23 hdp).● Large screen display in a small footprint: World's shortest 17-inch conventional monitor with maximum
depth of only 408 mm/16.1"
●
Multimedia Base and USB Hub option● sRGB for true on screen color representation.●
FCC, CE (in selected countries only) and ISO9241, ISO14001 certified● RETURN TO TOP OF THE PAGE
Technical Specifications*
CRT
• Size and deflection 17 inch / 41 cm ; 90° deflection angle
• Dot pitch 0.27 mm
• Horizontal pitch 0.23 mm
• Tube type Shadow mask, flat square, high contrast, anti-glare, anti-static,
anti reflection, light transmission 47%
107E Product Information
file:///D|/Rita/LF3/lf3manual/english/107E/PRODUCT/PRODUCT.HTM (1 of 5) [2002/7/7 ?? 11:04:10]

• Phosphor P22
• Recommended display area 12.0" x 9.0" / 306 x 230 mm
• Maximum display area 12.9" x 9.7" / 327 x 245 mm
SCANNING
• Horizontal scanning 30 - 70 KHz
• Vertical scanning 50 - 160 Hz
VIDEO
• Video dot rate 108 MHz
• Input impedance
- Video 75 ohm
- Sync 2.2 kOhm
• Input signal levels 0.7 Vpp
• Sync input signal Separate sync
Composite sync
• Sync polarities Positive and negative
WHITE COLOR TEMPERATURE
Chromaticity CIE coordinates:
• at 9300 degrees K x = 0.283 / y = 0.297
• at 6500 degrees K x = 0.313 / y = 0.329
sRGB
sRGB is a standard for ensuring correct exchange of colors between different devices (e.g. digital
cameras, monitors, printers, scanners, etc.)
Using a standard unified color space, sRGB will help represent pictures taken by an sRGB compatible
device correctly on your sRGB enabled Philips monitors. In that way, the colors are calibrated and you
can rely on the correctness of the colors shown on your screen.
Important with the use of sRGB is that the brightness and contrast of your monitor is fixed to a
predefined setting as well as the color gamut. Therefore it is important to select the sRGB setting in the
monitor's OSD.
To do so, open the OSD by pressing the OK button on the front of your monitor. Use the down button to
go to Color temperature and press OK again. Then move the down button to go to sRGB and press OK
again.
Exit this OSD.
After this, please don't change the brightness or contrast setting of your monitor. If you change either of
these, the monitor will exit the sRGB mode and go to a color temperature setting of 6500K.
107E Product Information
file:///D|/Rita/LF3/lf3manual/english/107E/PRODUCT/PRODUCT.HTM (2 of 5) [2002/7/7 ?? 11:04:10]

For more information on sRGB, please visit: www.srgb.com
* These information are subject to change without notice.
RETURN TO TOP OF THE PAGE
Automatic Power Saving
If you have VESA's DPMS compliance display card or software installed in your PC, the monitor can
automatically reduce its power consumption when not in use. And if an input from a keyboard, mouse or
other input device is detected, the monitor will automatically "wake up". The following table shows the power
consumption and signaling of this automatic power saving features:
Power Management Definition
VESA's
Mode Video H-sync V-sync Power Used Power
Saving
(%) LED color
ON Active Yes Yes Typical 64W 0 % Green
OFF Blanked No No
<2W 96% Yellow
This monitor is ENERGY STAR®compliant. As an ENERGY STAR®Partner, PHILIPS has
determined that this product meets the ENERGY STAR®guidelines for energy efficiency.
RETURN TO TOP OF THE PAGE
Physical Specifications
• Dimensions 15.7" x 16.1" x 16.1" / 399 x 410 x 408 mm (including base)
15.7" x 14.7" x 16.1" / 399 x 373 x 408 mm (excluding base)
• Weight 15.0 kg
• Power supply 90 - 264 VAC, 50/60Hz
• Temperature (operating) 0° to 40°C / 32° to 104°F
• Temperature (storage) -25° to +65°C / -13° to +149°F
107E Product Information
file:///D|/Rita/LF3/lf3manual/english/107E/PRODUCT/PRODUCT.HTM (3 of 5) [2002/7/7 ?? 11:04:10]

• Relative humidity(storage) 5% to 95%
* Resolution 1280 x 1024, standard size, contrast max., brightness 50%, 9300°, full white pattern.
* These information are subject to change without notice.
RETURN TO TOP OF THE PAGE
Pin Assignment
The 15-pin D-sub connector (male) of the signal cable (IBM systems):
Pin
No. Assignment
Pin
No. Assignment
1 Red video input 9 No pin
2 Green video input 10 Logic ground
3 Blue video input 11 Identical output - connected
to pin 10
4Identical output - connected
to pin 10 12 Serial data line (SDA)
5 Ground 13 H. Sync / H+V
6 Red video ground 14 V. Sync (VCLK for DDC)
7 Green video ground 15 Data clock line (SCL)
8 Blue video ground
RETURN TO TOP OF THE PAGE
Views
Follow the links to see various views of the monitor and its components.
Front View
107E Product Information
file:///D|/Rita/LF3/lf3manual/english/107E/PRODUCT/PRODUCT.HTM (4 of 5) [2002/7/7 ?? 11:04:10]

Rear View
RETURN TO TOP OF THE PAGE
107E Product Information
file:///D|/Rita/LF3/lf3manual/english/107E/PRODUCT/PRODUCT.HTM (5 of 5) [2002/7/7 ?? 11:04:10]

Installing your Monitor
Front View • Rear View • 6G3B11 Multimedia Base (option) • PCUH411 USB Hub (option)
Front View
Power button switches your monitor on.
OK button which when pressed will take you to the OSD controls
Contrast hotkey. When the UP arrow is pressed, the adjustment controls
for the CONTRAST will show up.
