Philips 10BDL4551T User manual

Professional
Display Solutions
T line
10BDL4551T
Quick
Start
Please check out the website below for more product information.
www.philips.com/signagesolutions-support
Q41G10M181304A
© 2020 Koninklijke Philips N.V. All rights reserved.
Philips and the Philips Shield Emblem are registered
trademarks of Koninklijke Philips N.V. and are used under
license from Koninklijke Philips N.V.
Specications are subject to change without notice.
Version: V1.00 2020-07-23

Menu
Wall Mount
Screw Hole
VESA mount
(Screw spec: M4)
Speaker
Micro USB
Landscape
* Simply screw the supplied table stand onto the stand screw hole.
Portrait
Reserved Expansion Port
For SW upgrade only
Reset Button
Stand screw
hole
Colour Monitor Quick Start Guide USB Cable
HDMI Cable
DC Power Adapter Power Plug
(Provided by regions)
for US for EU for UK
Volume
Silicon Foot Stand Bar
- Replacement of a battery with an incorrect type that can be defeat a safeguard;
- Disposal of a battery into re or a hot oven, or mechanically crushing or cutting of a
battery, that can result in an explosion;
- Leaving a battery in an extremely high temperature surrounding environment that
can result in an explosion or the leakage of ammable liquid or gas;
- A battery subjected to extremely low air pressure that may result in an explosion or
the leakage of ammable liquid or gas.
* Installation height: <2 m
* Mounting and installation
Mounting Option 1: [VESA mount]
Supporting VESA standard:
VESA MIS-D75 (75*75mm)
Supporting screw: M4*4mm
(exclude the mounting plate thickness)
Mounting Option 2: [Using back cover]
Supporting screw: Self-tapping screw *3pcs
(exclude the mounting plate thickness)
* Dierences according to regions.
Display design and accessories may dier from those illustrated above.
Use a screwdriver to loosen
the screw on the left side of
the back cover.
Use a screwdriver to
detach the back cover.
To mount the back cover to the wall, ip
over the back cover, the “PHILIPS” logo
should face the wall. Use a screwdriver to
insert nails (x3) into the holes of back
cover, then x the back cover to the wall.
Plug the power cable to the
“DC12V” port, then connect
the network cable to “LAN”
port of the signboard.
Insert the signboard carefully
into the back cover which is
already mounted on the wall.
Remove the back cover
from the signboard.
Stick the silicon gaskets
(provided) on the back
cover .
Mounting
Installing the stand
Rear view Top view
1 2 3
5 6 7
4
NOTE: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the Radio Equipment
Directive (2014/53/EU). The following test methods have been applied in order to
prove presumption of conformity with the essential requirements of the Radio
Equipment Directive This equipment is compliant with Class A of EN55032. In a
residential environment this equipment may cause radio interference.
The suitable temperature for the Colour Monitor and sccessories is 0°C-45°C.
Adaptor with ferrite must be used with this equipment to ensure compliance with the
Class A FCC limits.
Power Adapter information:
Model No.: ADS-26SGP-12 12024E
INPUT: 100-240V~50/60Hz
OUTPUT: 12 2.0A
Correct Disposal of this product. This marking indicates that this product
should not be disposed with other household wastes throughout the EU. To
prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device, please use the
return and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
“FCC & CE RF Radiation Exposure Statement Caution: To maintain compliance with
the FCC & CE’s RF exposure guidelines, place the product at least 20cm from near by
persons.”
WARNING: Changes or modications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
CAUTION
Risk of explosion if the battery is replaced by an incorrect type
Wait one-half hour after switching o before handling parts
CARE AND WARNING
