Philips 150X3M User manual

15" TFT LCD Colour Monitor
Horizontal frequencies
30 - 61 kHz
Published by BCUMonitor Printed inTaiwan Copyright reserved Subjectto modification June,30. 2002
©
DDC/Power saving/Auto Picture Adjustment
REFER TO BACK COVER FOR IMPORTANTSAFETY GUIDELINES
CAUTION: USE A SEPARATE ISOLATION TRANSFORMER FOR THIS UNIT WHEN SERVICING.
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
SAFETY NOTICE
3138 106 10211
150X3M/00C
(LG PANEL)
TABLE OF CONTENTS
Description Description
Page Page
Important Safety Notice..................................2
Technical Data & Power Management.............3~4
Connection To PC..........................................5
Installation ...................................................6
Description Of Controls..................................7
Advanced Control Of OSD..............................8
Clock & Phase Adjustments............................9
OSD Menu Control Level Structure ................10~11
OSD Attention Signal....................................12
Trouble shooting...........................................13
Failure Mode Of LCD Panel...........................14
Flat Panel Adjust ( FP Adjust ).......................15
Definition Of Pixel Defects............................16
Wiring Diagram............................................17
Mechanical Instructions ...............................18~19
Electrical Instructions ...................................20
Factory Adjustment.......................................21
Safety Test Requirements .............................22
DDC Instructions...........................................23~27
DDC Data.......................................................28~29
Serial Number Modification- EEPROM ( OSD ).30~31
Repair Flow Chart...........................................32~33
Colour Adjustment..........................................34~40
Repair Tips.....................................................41
Block Diagram and control pannel(C.B.A)........42
Scaler board C.B.A.........................................43
Connector Diagram........................................44
Input DVI & D-SUB Diagram............................45
MCU Diagram................................................46
Scaler Diagram..............................................47
Inverter Diagram ( Ambit )and Recommend parts
List................................................................48
Explode View ...............................................49
Recommended Parts List.................................50
Spare Parts List.............................................. 51~52
General Product Specification .........................53~73
General Trouble Shooting Guide ......................74~89

FOR PRODUCTS CONTAINING LASER :
DANGER- Invisible laser radiation when open.
AVOID DIRECT EXPOSURE TO BEAM.
CAUTION- Use of controls or adjustments or
performance of procedures other than
those specified herein may result in
hazardous radiation exposure.
CAUTION- The use of optical instruments with this
product will increase eye hazard.
TO ENSURE THE CONTINUED RELIABILITY OF THIS
PRODUCT, USE ONLYORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR
PART NUMBERS IN THE PARTS LIST SECTION OF THIS
SERVICE MANUAL.
Proper service and repair is important to the safe, reliable
operation of all Philips Consumer Electronics Company**
Equipment. The service procedures recommended by
Philips and described in this service manual are effective
methods of performing service operations. Some of these
service operations require the use of tools specially designed
for the purpose. The special tools should be used when and
as recommended.
It is important to note that this manual contains various
CAUTIONS and NOTICES which should be carefully read in
order to minimize the risk of personal injury to service
personnel. The possibility exists that improper service
methods may damage the equipment. It is also important to
understand that these CAUTIONS and NOTICES ARE NOT
EXHAUSTIVE. Philips could not possibly know, evaluate and
advise the service trade of all conceivable ways in which
service might be done or of the possible hazardous
consequences of each way. Consequently, Philips has not
undertaken any such broad evaluation. Accordingly, a
servicer who uses a service procedure or tool which is not
recommended by Philips must first satisfy himself thoroughly
that neither his safety nor the safe operation of the equipment
will be jeopardized by the service method selected.
* * Hereafter throughout this manual, Philips Consumer
Electronics Company will be referred to as Philips.
WARNING
Critical components having special safety characteristics are
identified with a by the Ref. No. in the parts list and
enclosed within a broken line*
(where several critical components are grouped in one area)
along with the safety symbol on the schematics or
exploded views.
Use of substitute replacement parts which do not have the
same specified safety characteristics may create shock, fire,
or other hazards.
Under no circumstances should the original design be
modified or altered without written permission from Philips.
Philips assumes no liability, express or implied, arising out of
any unauthorized modification of design.
Servicer assumes all liability.
* Broken Line
Take care during handling the LCD module with backlight unit
- Must mount the module using mounting holes arranged in four
corners.
- Do not press on the panel, edge of the frame strongly or electric
shock as this will result in damage to the screen.
- Do not scratch or press on the panel with any sharp objects, such
as pencil or pen as this may result in damage to the panel.
- Protect the module from the ESD as it may damage the electronic
circuit (C-MOS).
- Make certain that treatment person’s body are grounded through
wrist band.
- Do not leave the module in high temperature and in areas of high
humidity for a long time.
- Avoid contact with water as it may a short circuit within the module.
- If the surface of panel become dirty, please wipe it off with a soft
material. (Cleaning with a dirty or rough cloth may damage the
panel.)
Important Safety Notice
2150X3M LCD
Go to cover page

150X3M LCD 3
Technical Data
Go to cover page
LCD Panel
Screen type : LG Panel LS 150X03-A3
Screen dimensions : 15 inches (diagnoal)
Preset display area
Horizontal : 304.1 mm
Vertical : 228.1 mm
Pixel pitch : 0.297 x 0.297 mm
Viewing angle (CR>= 10) : Vertical 90 degree,
Horizontal 120 degree typical,
Display Colors : 6 bits interface (16M colors)
SCANNING
Horizontal scan range : 30 kHz to 61 kHz (automatic)
Vertical scan range : 56 Hz to 76 Hz (automatic)
Optimal preset resolution : 1024 x 768 at 60 Hz
Highest preset resolution : 1024 x 768 at 75 Hz
Video
Video dot rate : 79MHz
input impedance
-Video : 75 ohms
-Sync : 5 K6Ohm
Input signal levels : 700m Vpp
Synchronization input signals : Separate horizontal and vertical /
composite ;TTL level, positive or
negative, Sync On Green
Input Frequency : XGA Hsync
48-61 KHz,Vsync 60-76Hz(N.I.)
SVGA Hsync
35-50 KHz,Vsync 56-75Hz(N.I.)
VGA Hsync
31-38 KHz,Vsync 60-76Hz(N.I.)
Video interface : Dual input:Both Analog(D-Sub) and
DVI-I(Digital only) are available It
can be switching via OSD selection
,Resolution and Preset Modes
Maximum : 1024 x 768 at 75Hz
Recommended : 1024 x 768 at 60Hz
Physical Characteristics
Dimensions
Height : 343 mm
Depth : 165 mm
Width : 399 mm
Weight (monitor only) : 4. 7 kg
o
Tilt and swivel angle of pedestal : - 5 to 35
Height adjustment range : 50mm
o
Portrait display : 90 rotation counter colockwise
oo
Forward / Backward : -5 / 25
AC input voltage / frequency : 90 to 264 VAC / 50 or 60 Hz
Power consumption : 23 W (typ.)
Temperature
Operating : 5 degree C to 40C (41F to 104F)
Humidity
Operating : 20% to 80%
Technical Specifications
Pin Assignment
DVI-D connector
(Digital Visual Interface - Digital)
Pin Assignment
The digital only connector contains 24 signal contacts organized in three rows of eight
contacts. Signal pin assignments are listed in the Table:
2. The 15-pin D-sub connector (male) of the signal cable
Pin
No. Assignment Pin No. Assignment
1Red video input 9DDC+5V
2Green video input 10 Logic ground
3Blue video input 11 Identical output-
connected to pin 10
4Identical output-
connected to pin 10 12 Serial data line (SDA)
5Cable detect 13 H. Sync / H+V
6Red video ground 14 V. Sync
7Green video ground 15 Data clock line (SCL)
8Blue video ground
17
16
Pin
No.
Signal
Assignment
Pin
No.
Signal
Assignment
Pin
No.
Signal
Assignment
1T.M .D. S .
Data2 - 9T.M .D. S. Data1 - 17 T.M .D. S. Data0 -
2T.M.D.S.
Data2+ 10 T.M .D. S. Data1+ 18 T.M .D. S. Data0+
3T.M.D.S.
Data2/4 Shield 11 T.M .D. S. Data1/3 Shield 19 T.M.D.S. Data0/5 Shield
4No connect 12 No connect 20 No connect
5No conn ect 13 No connect 21 No connect
6DDC Clock 14 +5V Power 22 T.M.D.S. Clock
Shield
7DDC Data 15 Ground (for
+5V) 23 T.M.D.S. Clock+
8No connect 16 Hot Plug
Detect 24 T.M.D.S. Clock -

Technical Data
4150X3M LCD
Go to cover page
Data Storage
Factory preset mode:
This monitor has 14 factory-preset modes as indicated in the
following table :
Meanwhile, it also reverse 14 sets data space available for user
storage new timings data.
Mode Resol
ution
H. freq. / V. freq Standard
1. 640 x 350 31.469Khz/70.087Hz VGA
2. 720 x 400 31.469Khz/70.087Hz VGA
3. 640 x 480 31.469Khz/59.940Hz VGA
4. 640 x 480 35.000Khz/66.667Hz Macintosh
5. 640 x 480 37.861Khz/72.809Hz VESA
6. 640 x 480 37.500Khz/75.000Hz VESA
7. 800 x 600 35.156Khz/56.250Hz VESA
8. 800 x 600 37.879Khz/60.317Hz VESA
9. 800 x 600 48.077Khz/72.188Hz VESA
10. 800 x 600 46.875Khz/75.000Hz VESA
11. 832 x 624 49.700Khz/75.000Hz Macintosh
12. 1024 x 768 48.363Khz/60.004Hz VESA
13. 1024 x 768 56.476Khz/70.069Hz VESA
14. 1024 x 768 60.023Khz/75.029Hz VESA
Power Management Definition
Active
Amber
Amber
Green
Amber
Blanked
Blanked
Blanked < 3 W 90 %
83.3 %
83.3 %
0 %
< 3 W
< 3 W
< 23 W
Suspend
ON
OFF No
No
No
No
Yes
Yes
Yes Yes
Stand-by
V-SYNC POWER
SAVING( % )
POWER
USED
LED
COLOR
H-SYNC
VIDEO
VESA's mode
This monitor is Environmental Protection Agency (EPA) Energy Star
compliant and TCO'99 power management compatible.
*Zero power consumption in OFF mode can only be achieved by
disconnecting the mains cable from the monitor.
ENERGY STAR is a U.S. registered mark. AS AN ENERGY STAR
PARTNER, PHILIPS HAS DETERMINED THAT THIS PRODUCT
MEETS THE ENERGY STAR GUIDELINES FOR ENERGY
EFFICIENCY.
R
If you have VESA's DPMS compliance display card or software
installed in your PC, the monitor can automatically reduce power
consumption when power saving function active. And if an input
from keyboard, mouse or other input devices is detected, the
monitor will automatically "wake up". The following table shows
the power consumption and signaling of this automatic power
saving feature :
Automatic Power Saving
Philips Switchable adapter for Apple Video Connectors
MAC Adaptor ( For Reference Only )

5
150X3M LCD
Connection to PC
Go to cover page
2.Connect microphone and audio cables onto the rear side of base if any
Double check all cables connection closely. Make sure they are all
connected well.
3. If you use an Apple Macintosh, you need to connect the special
Mac adapter to one end of the monitor signal cable.
4.Pull back up the monitor body.
5.Connect to PC
(1) Turn off your computer and unplug its power cable.
(2) Connect the monitor signal cable to the video connector on the back
of your computer.
(3) Plug the power cord of your computer and your monitor into a
nearby outlet.
(4) Turn on your computer and monitor. If the monitor displays an image,
installation is complete.
1.Thread power cable through the hole
at the bottom of the stand, and plug
onto monitor firmly.
1. Headphone Jack
Rear View
1. Audio in
2. Mic out
3. VGA
4. DC 12V_in
5. DVI-D
Side View

6150X3M LCD Installation
Installation Locations
Avoid Heat and Extreme Cold
1. Do not store or use the LCD monitor in locations exposed to heat,
direct sunlight, or extreme cold.
2. Avoid moving the LCD monitor between locations with large
temperature differences. Choose a site falling within the following
temperature and humidity ranges.
Temperature: 5-35 C 41-95 F
Humidity: 20-80% RH
3. Do not subject the LCD monitor to severe vibration or high impact
conditions. Do not place the LCD monitor inside a car trunk.
4. Take care not to mishandle this product by either knocking or
dropping during operation or transportation.
5. Do not store or use the LCD monitor in locations exposed to high
humidity or a dusty environment. Also do not allow water or other
liquids to spill on or into the LCD monitor
Correct handling of the monitor
1. When handling the monitor, grip the bottom firmly with both hands
and ensure that the front panel faces outward before lifting. Please
refer to the diagram on the right.
2. Handling the monitor with care prevents scratching and damage. If
the monitor becomes damaged, immediately disconnect the power
from the unit and have it checked by a qualified service person
before using it again.
3. To prevent fire or electrical shock, do not drop the monitor.
4. When moving the monitor, be sure to unplug all power cords in order
to avoid injury or damage to the equipment.
Go to cover page

7
150X3M LCD
Description of Controls
Go to cover page
Front View
UP and DOWN buttons are used when adjusting the OSD of
your monitor
LEFT and RIGHT buttons, like the UP and DOWN buttons, are
also used in adjusting the OSD of your monitor.
BRIGHTNESS hotkey. When the UP and DOWN arrow buttons
are pressed, the adjustment controls for the BRIGHTNESS will
show up.
OK button which when pressed will take you to the OSD
controls.
POWER button switches your monitor on.
Automatically adjust the horizontal position,
vertical position, phase and clock setting.
Physical Function
1) Tilt
2) Height adjustment
1. Audio power on/off
2. Audio power LED and Volume adjustment
3. Built-in Microphone

8 150X3M LCD Advanced control of OSD
Go to cover page
Leave factory mode by simply power off the monitor.
ATTENTION
OSD MAIN MENU LOCKED
ATTENTION
OSD MAIN MENU UNLOCK
ATTENTION
ATTENTION SIGNAL OFF
ATTENTION
ATTENTION SIGNAL ON
SERVICE MODE
SERIAL NO.: TY 123456
HOURS OF OPERATION: 000103
Access Aging Mode
In the factory mode, once video signal removed, a full white pattern
will be display on the screen as Fig.1 in stead of power saving mode.
In other words, the power saving function will be disable in the factory
mode.
To Lock/Unlock OSD function
The OSD function can be locked by pressing button for more than
10 seconds, the screen shows following windows for 3 seconds.
Everytime when you press or button, this message appears
on the screen automatically. The & (brightness) , &
(mute) hotkey are still functional for brightness and mute expectively
while OSD locked
Locked OSD function can be released by pressing button for
more than 10 seconds. While press button for OSD unlocked
purpose, the screen will keep showing OSD MAIN MENU LOCKED
until OSD function unlocked and screen automatically shows
following window for 3 seconds.
Switch ON/OFF attention signals
All attention signals can be switched off by keep pressing button
for more than 10 seconds if there is no video signal supplied.
Recover attention signals by pressing button for more than 10
seconds without video signal input.
Access Service Mode
Operating monitor with no signals (power saving mode), keep
pressing button for more than 10 seconds. Following information
will appear on the screen. Leave service mode by either re-feed
video signal or simply turn off and on the power of monitor.
Access Factory Mode
To hold and buttons then power on the monitor. Press to
bring up OSD menu for confirmation as below:
Fig.1
AGING...
HUDSON 150P V1.56D 01-03-09
Front control panel

9
150X3M LCD
CLOCK & PHASE Adjustments Go to cover page
Step 5 : Select VIDEO NOISE by press button.
Step 6 : Press for bring up it’s submenu.
The 150X3M has build-in a auto adjustment hotkey on the front panel,
you may obtained a optimal video display by simply press the button
and save the settings. CLOCK, PHASE, Vertical position, and Horizontal
position are adjusted automatically.
Step 1 : Click on the Start button (Win95, Win98 or Win NT)
and choose " Shut Down...". as shown in Fig.1
Step 2 : The menu of " Shut Down Windows " is as shown in Fig. 2
Step 3 : Remaining Shut Down Window on the screen , follow
The CLOCK and PHASE adjustment instructions for the
optimal video display.
Fig.1
Fig. 2
PHASE phenomenon
Due to the different quality of video signal generated from graphics
cards. It is necessary to adjust CLOCK and PHASE functions for the
optimal video display of LCD monitor. Following steps will guide you to
make correct adjustment of CLOCK and PHASE.
However, CLOCK and PHASE functions are only available while analog
video signal is supplied. Operating unit under digital signal state, the
video clock information can be obtained from graphics cards directly.
Therefor, it is unnecessary to adjust these functions
Manual adjustment
If the quality of display still poor or flicker, you may also improve it by
manual adjust CLOCK and PHASE functions to eliminate the flicker.
Step 4 : Press the button to bring up OSD menu.
Step 7 : Press or to adjust PHASE. The picture will be jitter as
following figure, adjust PHASE and check the picture, stop at the
point that without any vertical jitter bar remaining on the screen.
Step 8 : Press or to adjust CLOCK. The picture will be jitter as
following figure, adjust CLOCK to fine-ture the video until
optimal display is obtained.
Step 9 : Quit OSD menu by press button to save the settings.
CLOCK Phenomenon
Auto adjustment hotkey

10 150X3M LCD OSD Control Structure for Analog
Go to cover page
The OSD Tree for analog video signal
Below is an overall view of the structure of the On-Screen Display. You can use this as reference when you want to later on work your way around the
different adjustments.
First Level Second Level
OSD Menu (Analog)

11
150X3M LCD
OSD Control Structure for Digital
The OSD Tree for digital video signal (DVI-D or DVI-I)
This OSD structure is different from analog menu, there are three functions will be disable on digital OSD menu: Contrast, Video Noise, and Adjust
Color.
Go to cover page
First Level Second Level
OSD Menu (Digital)

12 150X3M LCD OSD Attention signals
NO VIDEO INPUT
This screen appears if there is no video signal input. Please check
that the signal cable is properly connected to the video card of PC
and make sure PC is on.
ENTERING SLEEP MODE
This screen appears when the monitor is about to enter the sleep
mode. Please press any key on the keyboard or click the mouse to
wake up the monitor and computer.
USE 1024 X 768 FOR BEST RESULT
This message appears at the top of the OSD window when the video
mode input is not the recommended 1024x768. Other modes may
result in some picture distortion. Please adjust the video mode to
1024x768 at 60Hz for best display quality.
The monitor will detect various display situation automatically. When
the monitor detects the problems, the screen will show the different
warning signals to remind you what is happen to your monitor.
WAIT FOR AUTOMATIC ADJUSTMENT
This screen appears when you touch the button. It will
disappear when the monitor is properly adjusted.
SECOND VIDEO IS NOT AVAILABLE
When you select video input between Analog or Digital signal via
INPUT SELECTION function of OSD menu, if the one you are
selecting is not available, following message will appear on the
screen then switching back to the previous setting automatically.
ATTENTION
NO VIDEO INPUT
ATTENTION
ATTENTION
ENTERING SLEEP MODE
USE 1024x768 FOR BEST RESULT
WAITING FOR AUTOMATIC ADJUSTMENT
Go to cover page

13
150X3M LCD
Trouble Shooting
Go to cover page
Make sure the Power cable is plugged to the
wall and back of the monitor.
Make sure the DC power cord has been
attached to the DC jack.
First, power button in front of the monitor
should be in the OFF position, then press it to
ON position again.
Make sure the computer is turned on.
Make sure the signal cable is properly
connected to your computer.
Check to see if the monitor cable has bent pins.
The Energy Saving Feature may be activated.
Make sure the monitor cable is properly
connected to your computer.
Check to see if the monitor cable has bent pins.
Make sure the computer is turned on.
The Auto Function is designed for
use on standard Macintosh or
IBM-compatible PC running Microsoft Windows.
It may not work properly if using
non-standard PCs or video card.
Push the AUTO button.
Adjust the image position using the Horizontal
Position & / or Vertical Position in the Second
Window.
Check that the signal cable is properly
connected to the graphics board or PC.
Push the Auto button.
Eliminate the horizontal bars using the Phase
Adjustment in the First Window.
Adjust the contrast and brightness using the
First Window.
(The backlight of the LCD monitor has a fixed
life span. When the screen becomes dark or
begins to flicker,please contact your dealer.)
If an image remains in the screen for an
extended period of time,it may be imprinted in
the screen and leave an after-image. This
usually disappears after a few hours.
This is characteristic of liquid crystal and is
not caused by a malfunction or deterioration
of the liquid crystal. The after-image will
disappear after a set amount of time.
The remaining dots are normal
charactericstic of the liquid crystal used in
today's technology.
No Picture
(Power LED not lit)
No Picture
(Power LED is
Amber or Yellow in
color)
Screen says
AUTO button not
working
properly
Imaging
Problems
Display position
is incorrect
Image vibrates
on the screen
Horizontal flicker
appears
The screen is too
bright or too dark
An after-image
appears
An after-image
remains after the
power has been
turned off
Green, red,
blue, dark and
white dots
remain on the
screen
TROUBLE SHOOTING
This page presents problems that can be corrected by the user. If the
problem still exists after these possible solutions, a further action has
to be take by authorized technicians.
Vertical flicker
appears
Push the AUTO button.
Eliminate the vertical bars using the Clock
Adjustment in the FIRST Window.

14 150X3M LCD Failure Mode of LCD panel
Quick reference for failure mode of LCD panel
This page presents problems that could be made by LCD panel. It is
not necessary to repair circuit board. Simply follow the Mechanical
instruction on this manual to eliminate failure by replace LCD panel
or backlight tubes.
Failure description Phenomenon
Vertical dim lines
Vertical block defect
Vertical lines defect
(Always bright or dark)
Horizontal block defect
Horizontal dim lines
Horizontal lines defect
(Always bright or dark)
Has bright or dark pixel
.
...
.
.
.
...
.
.
Bright pixel
Dark pixel
..
....
Polarizer has bubbles
Polarizer has bubbles
Foreign material inside
polarizer. It shows linear or
dot shape.
....
Concentric circle formed
Bottom back light of LCD is
brighter than normal
Backlight un-uniformity
Backlight has foreign
material. Black or white
color, linear or circular type
Go to cover page

15
Flat Panel Adjust (FP Adjust)
Go to cover page
Fpadjust program
The Flat Panel Adjust (FPadjust) software helps you to find the best
setting for your Philips LCD monitor. It allows you to adjust the image
performance of LCD monitor, such as RESOLUTION,
AUTO ADJUSTMENT, POSITION, CONTRAST, VIDEO CLOCK and
VIDEO PHASE.
Note: Video clock and phase functions are only available for analog
video signals.
Install and Run FPadjust
In "MS Windows 95/98" environment : For example
1. Insert CD-DFU to your CD-ROM driver.
2. Run "F:\PC\FPADJUST\FP_SETUP01.EXE" as Fig. 1.
3. Then follow the instructions to install the FPadjust program.
When finish, double click FPadjust icon " ", then the
description (can be moved by mouse) and background pattern
come on the screen for image adjustment.
FPadjust program is working as a pattern generator to provide the
pattern display on the screen for the adjustment of CONTRAST,
CLOCK, PHASE ...etc. Please follow the steps below to adjust your
PHILIPS Flat Panel Monitor for best display quality.
FPadjust.lnk
Fig. 1
150X3M LCD

16 150X3M LCD Definition of Pixel Defects
Go to cover page
0. General
This section explainsthe different types of pixel defects and
defines acceptable defectlevels of each type. In order to qualify
for repair orreplacement under warranty, the number of pixel
defects on aTFT LCD panel must exceed these acceptable levels.
1. Definition of Pixels and Subpixels
A pixel,or picture element , is composed of three subpixels in the
primary colors ofred, green and blue. Many pixels together from
an image. Whenall subpixels of a pixel are lit, the three colored
subpixels together appearas a single white pixel. When all are
dark, the threecolored subpixels together appear as a single black
pixel. Other combinationsof lit and dark subpixels appear as
single pixels ofother colors.
2. Types of Pixel Defects
Pixel and subpixeldefects appear on the screen in different ways.
Bright dot defects
Bright dot defectsappear as pixels or subpixels that are always lit
or "On". Theseare the types of bright dot defects:.
One lit red, green or blue subpixel
Two adjacentlit subpixels:
- Red +Blue = Purple
- Red +Green = Yellow
- Green +Blue = Cyan (Light Blue)
Three adjacent litsubpixels
(One white pixel)
Black dot defects
Black dot defectsappear as pixels or subpixels that are always
dark or "Off". These are the types ofblack dot defects:
One dark subpixel
Two orthree adjacent dark subpixels
3. Pixel DefectTolerances
In order toqualify for repair or replacement due to pixel defects
during the warrantyperiod, a TFTLCD panel ina PHILIPS flat
panel monitor musthave pixel or subpixel defects exceeding the
tolerances listed inthe following tables.
Pixel
Subpixel Subpixel
Subpixel
BRIGHT DOT
DEFECTS ACCEPTABLE LEVEL
MODEL 150X3M
1 lit subpixel None
2 adjacent lit subpixels None
3 adjacent lit subpixels
(one white pixel) None
Distance between two
bright dot defects* None
Bright dot defects within
20 mm circle None
Total bright dot defects
of all types None
BLACK DOT DEFECTS ACCEPTABLE LEVEL
MODEL 150X3M
1 dark subpixel 4 or fewer
2 adjacent dark
subpixels 1 or fewer
3 adjacent dark
subpixels None
Distance between two
black dot defects*
15 mm or
more
Black dot defects within
20 mm circle* 3 or fewer
Total black dot defects of
all types 4 or fewer
TOTAL DOT DEFECTS ACCEPTABLE LEVEL
MODEL 150X3M
Total bright or black dot
defects of all types 4 or fewer
Note: 1 or 2 adjacent subpixel defects = 1 dot defect

150X3M LCD 17
Go to cover page
Wiring Diagram
C D
A B C D
A B
123456 123
DATE
NAME
CHECK
SUPERS . A3
456
MODEL : X2-PCB-SCALER-HUDSON2 DRAWING : 8639-000-12116-SH132
8639 000 12116
110 132-1
TY 19-Apr-02 C PHILIPS ELECTRONICS INDUSTRIES (TAIWAN) LTD - CED
FPC CABLE
TO SCALER PC.BOARD
TO PANEL
TO FPC CABLE
TO FPC CABLE
DC12V
DVI CABLE
VGA CABLE
1502
1503
1601
1203 1201
LCD 15"
TFT LCD 15" MONITOR TYPE : XH2-150X3M/00C BRAND ; PHILIPS
19-APR-02
W.Y.LIN
1712
SCALE 0.500

18 150X3M LCD Mechanical instructions
Go to cover page
Fig. 6
Removal 8 screws as Fig. 6
Fig. 4
Fig. 2
Release one screw as Fig. 2
Fig. 1
To be able to perform measurements and repairs on the circuit
board, spread a soft mat underneath to avoid damaging the LCD
surface.
Fig. 5
Removal two covers as Fig. 5.
Fig. 3
Back cover removal as Fig. 3

150X3M LCD 19
Go to cover page
Mechnical instructions
Remove 10 screw( two sides. ) Cover removal. As fig. 7
Removal 4 screws.
Removal connectors.As Fig. 8.
Pull out LCDmodule. Bezel and control board. As Fig.10
Fig. 7
Fig. 8
Fig. 9
Removal connector then pull out shield. As Fig. 9
Fig. 10

150X3M LCD
20
Go to cover page
Electrical instructions
0. General
When carry-out the electrical settings in many cases a video
signal must be applied to the monitor.A computer with :
- ATI VGA 1024 V6-1.04/PH BETA4 interface card
- PGA 1024 (4822 212 30916), Mach 8.
- PGA 1280 (4822 212 30917), Mach 32.
- ATI GPT-1600 (4822 397 10065), Mach 64 (up to 107kHz)
are used as the video signal source. The signal patterns are
selected from the "service test software" package, see user
guide 4822 727
19896 (ATI1024), or 4822 727 20273 (PGA1280), or
4822 727 21046 (GPT-1600).
0.1 With normal VGA card:
If not using theATI card during repair or alignment, The service
engineer also can use this service test software adapting with
normal standard VGA adaptor and using standard VGAmode
640 x 480, 31.5 kHz/60 Hz (only) as signal source.
0.2 AC/DC Measurement:
The measurements for AC waveform and DC figure is based on
1024 x 768 48kHz/60 Hz resolution mode with test pattern "32
gray scale".
Power input: 110V AC
1.General points
1.1 During the test and measuring, supply a distortion free AC mains
voltage to the apparatus via an isolated transformer with low
internal resistance.
1.2 All measurements mentioned hereafter are carried out at a
normal mains voltage (90 - 132 VAC for USA version, 195 -264
VAC for EUROPEAN version, or 90 - 264 VAC for the model with
full range power supply, unless otherwise stated.)
1.3 All voltages are to be measurement or applied with respect to
ground, unless otherwise stated. Note: don't use heat-sink as
ground.
1.4 The test has to be done on a complete set including LCD panel in
a room with temperature of 25 +/- 5 degree C.
1.5 All values mentioned in these test instruction are only applicable
of a well aligned apparatus, with correct signal.
1.6 The letters symbols (B) and (S) placed behind the test instruction
denotes
(B): carried out 100% inspection at assembly line
(S): carried out test by sampling
1.7 The white balance (color temperature), has to be tested in
subdued lighted room.
1.8 Repetitive power on/off cycle are allowed except it should be
avoided within 6 sec.
2. Input signal
2.1 Signal type
Video : 0.7 Vp-p linear, positive polarity
Sync. : TTL level, separate, positive ornegative polarity
Signal source: patterngenerator format as attachment.
(table 1 to14) Reference generator : CHROMA2200 or 2250
2.2 Input signalmode
Pre-set 14 modes
PRESET VIDEO RESOLUTION
4. Display Adjustment
4.1Input signals check
In factory mode, use 64 gray level and set the R,G,B sub gain to
100%.
4.2 Display quality test
Use timing mode as described in 2.2, and use the POPO (pixel on
pixel off) pattern to adjust the clock until no stripe and adjust the
phase until clear picture. Check all pre-setting 14 modes.
4.3 Check of WHITE-D (B)
Apply a 48kHz/60Hz signal with white pattern, set brightness
control at 100%, and contrast control at 50%. Adjust the R, G, B
sub_gain, for the screen center, the 1931 CIE chromaticity (X, Y)
co-ordinates shall be;
Factory preset video resolution
9300 K 6500 K
x (center) 0.281 0.005 0.312
y (center) 0.311 0.338
0.005 0.005
0.005
Dot rate (MHz) H.freq (KHz) Mode Resolution V.freq (Hz)
25.175 31.469 IBM VGA 10h 640 * 350 70.087
28.322 31.469 IBM VGA 3h 720 * 400 70.087
25.175 31.469 IBM VGA 12h 640 * 480 59.940
30.240 35.000 MACINTOSH 640 * 480 66.667
31.500 37.861 VESA 640 * 480 72.809
31.500 37.500 VESA 640 * 480 75.000
36.000 35.156 VESA 800 * 600 56.250
40.000 37.879 VESA 800 * 600 60.317
50.000 48.077 VESA 800 * 600 72.188
49.500 46.875 VESA 800 * 600 75.000
57.300 49.700 MACINTOSH 832 * 624 75.000
65.000 48.363 VESA 1024 * 768 60.004
75.000 56.476 VESA 1024 * 768 70.069
78.750 60.023 VESA 1024 * 768 75.029
Use Minolta CA-110 for color coordinates and luminance check.
Luminance; 250 Nits (LG panel) in the center of the screen.
4.4 Check the digital interface
Set the delay time tobe 6 nsec.
Check the 64 gray level color poor & noise condition.
3. AC Adaptor
3.1Setup theAC I/P at 90VAC, and OutputDC loading at 3.8 Amp,
The DC output voltage is12+- 0.6 VDC
3.2Adjustment is nothingto do
