Philips BDL4681XU User manual

Philips
LCD monitor
46"
multimedia HD Ready
BDL4681XU
Impress and capture your audience
with an Ultra slim bezel 46" LCD
Deliver your message with a stylish seamless video wall. Whether it's used in a 5 x 5
square matrix or in a 1 x 3 portrait setup, your audience will be astonished.
Optimised for public viewing
• Wide format WXGA 1366 x 768 resolution for sharper display
• Slim bezel design for a stylish look
• Advanced in factory colour calibration
• Projects a high brightness picture even in daylight
Operational flexibility for different applications
• Smart insert in the back cover to place a small PC
• Enhanced zoom feature supports tiled matrix applications
Lower total cost of ownership
• SmartPower for energy saving
• Brightness automatically adjusts with ambient conditions
• Advanced anti-image sticking function
Sustainable and safe
• Temperature sensor measures the health condition

BDL4681XU/00
Highlights
LCD monitor
46" multimedia HD Ready
Slim bezel
A slim bezel design adds a stylish look to a
public display to blend in nicely in most
environments. Furthermore, this design is ideal
for tiled matrix video walls.
Advanced colour calibration
Whether installing a video wall in a 3 x 3, 2 x 4
or 5 x 5 set up, you want the colour
performance of each image to be consistent in
each display used. Therefore, each display is
specially calibrated in the factory to meet the
highest standard of advanced video walls.
High brightness
Allows daylight viewing even in large public
environments with high ambient light
conditions.
Smart insert
Professional PCs are part of most public
signage installations. Quite often they add
additional depth to the public display and a lot
of cable clutter. This public display contains a
Smart insert in the back cover that will fit many
professional small form factor PCs. In addition,
it offers provisions for efficient cable
management.
SmartPower
The backlight intensity can be controlled and
pre-set by the system to reduce the power
consumption by up to 50%, which saves
substantially on energy costs.
Automatic brightness control
The adjustment of display settings to
correspond with ambient light without user
intervention.
Temperature sensor
This public display contains a temperature
sensor to monitor the internal health
condition. If the internal temperature exceeds
the pre-set threshold, two internal fans will be
automatically activated to cool down the
display to normal conditions.
Advanced anti-image sticking
Static images left on-screen for extended
periods of time may leave a "ghost image" or
image sticking effect on LCD displays.
Although image sticking on LCD displays is not
permanent, you want to prevent this
happening, especially in locations where
content is shown 24/7.
Zoom function for tiled matrix
The internal zoom function enables easy
implementation of a video wall matrix, without
the need for expensive external equipment.
Capable of a vidiwall of 25 displays by dividing
up to 5 displays each horizontally and
vertically.
VIDIWALL
SMARTPOWER
P
O
R
T
R
A
I
T

Issue date 2010-08-03
Version: 4.1.3
12 NC: 8670 000 65013
EAN: 87 12581 55151 3
© 2010 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
BDL4681XU/00
Specifications
LCD monitor
46" multimedia HD Ready
Picture/Display
• Diagonal screen size: 46 inch / 117 cm
• Panel resolution: 1366 x 768p
• Optimum resolution: 1360 x 768 @ 60 Hz
• Brightness: 700 cd/m²
• Contrast ratio (typical): 3000:1
• Response time (typical): 8 ms
• Aspect ratio: 16:9
• Viewing Angle (H / V): 178 / 178 degree
• Pixel pitch: 0.7455 x 0.7455
• Display colours: 16.7 million colours
• Picture enhancement: 3/2 - 2/2 motion pull down,
3D Combfilter, Motion compens. deinterlacing,
Progressive scan, 3D MA deinterlacing, Dynamic
contrast enhancement
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75 Hz
800 x 600 56, 60, 72, 75 Hz
1024 x 768 60 Hz
1280 x 768 60 Hz
1280 x 800 60 Hz
1280 x 1024 60 Hz
1360 x 768 60 Hz
1366 x 768 60 Hz
1440 x 900 60 Hz
1600 x 1200 60 Hz
1920 x 1080 60 Hz
1920 x 1200 60 Hz
•Video formats
Resolution Refresh rate
480i 60 Hz
480p 60 Hz
576p 50 Hz
576i 50 Hz
720p 50, 60 Hz
1080i 50, 60 Hz
1080p 50, 60 Hz
Connectivity
• PC: VGA-in D-Sub 15HD, VGA-out D-Sub 15HD,
DVI-D x 1, RS232 D-Sub9, RS232 D-sub9 output,
3.5 mm PC audio input x 1
• AV input: HDMI x 1, Component (BNC) x 1,
Composite (RCA) x 1, Composite (BNC) x 1, S-
video x 1, Audio (L/R) x 2
• AV output: Composite (BNC) x 1, Audio (L/R) x 1
• Other connections: External loudspeaker
connector
Convenience
• Placement: Portrait, Landscape
• Tiled Matrix: 5 x 5
• Picture in picture:: PBP, PIP, POP
• Screen-saving functions: Pixel shift, Low bright
• Signal Loop Through:: RS232, VGA
• Keyboard control:: Hidden, Lockable
• Remote control signal:: Lockable
•Ease of installation: Carrying Handles,Smart Insert
• Energy-saving functions:: Ambient light sensor,
Smart Power
• Safety control functions:: Heat Control,
Temperature Sensor
• Picture performance: Advanced colour control
• Packaging:: Reusable box
• Network controllable: RS232
Dimensions
• Bezel thickness: 2.4 mm bottom/right, 4.3 mm top/
left
• Smart insert (WxHxD): 200 x 280 x 55 mm
• Smart insert in inch (WxHxD): 7.9 x 11.0 x 2.17
inches
•Setdimensions(Wx H x D):
1026 x 578 x 133 mm
• Set dimensions in inch (W x H x D):
40.4 x 22.8 x 5.2 inch
• Product weight: 27.5 kg
• Product weight (lb): 60.6
• VESA Mount: 400 x 200 mm (Set), 100 x 100 mm
(Smart insert)
Operating conditions
• Temperature range (operation): 0 - 40 °C
• Relative humidity: 5 - 90 %
• MTBF: 50,000 hour(s)
Power
• Mains power: 90-264 VAC, 50/60 Hz
• Consumption (On mode): Typ. 238 W
• Standby power consumption: < 1 W
Sound
• Built-in speakers: 2 x 12 W (8 ohm)
Accessories
• Included accessories: Remote Control, Batteries
for remote control, AC Power Cord, VGA cable,
User manual on CD-ROM, Quick start guide
• Optional accessories: Fixed wall mount, Flexible
wall mount, Ceiling mount, Tabletop stand
Miscellaneous
• Bezel: metallic anthracite
• Warranty: Europe/North America: 3 years
• On-Screen Display Languages: English, French,
German, Italian, Polish, Turkish, Russian, Simplified
Chinese
• Regulatory approvals: CE, FCC, Class B, CCC,
RoHS
•
