INTRODUCTION
PHILIPS G3 AUTODOMES
Since the development of integrated domed high speed pan/tilt
zoom cameras, almost a decade ago, AutoDome has been
synonymous with innovation, superior performance and
reliability.
Philips G3 AutoDome systems are designed to meet the needs
of your security application.They easily integrate with our entire
security product line, including multiplexers, recorders, and the
Allegiant matrix switchers. Our UnityTM Domes, which have the
same appearance as the G3, but contain a pre-configured fixed
camera and lens combination, are the perfect complement to
the G3 installation.
Also available is the e-domeTM, a camera that let’s you see and
record everything.....all the time.
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:42 Pagina 2

AUTODOMES
INTRODUCTION
Full integration offers you a complete, easy to install, low
maintenance CCTV system from a single vendor.
The Philips commitment to world class support begins with a
three year warranty and easy access to technical support. Our
international sales organisations are committed to meet your
product, service and training needs. More options, better
quality, more support - only from Philips.
www.philipscsi.com
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:42 Pagina 3

4
CHOOSING THE
RIGHT DOME
PHILIPS G3 AUTODOMES
CHOOSING THE RIGHT DOME
FEATURE G3B G3A ENV
CAMERA OPTIONS Color Color Color
Monochrome Monochrome
Day/Night Day/Night
25xZoom 25xZoom
FRAME INTEGRATION NO YES* YES*
IR RATING IP31 IP54 IP66
OPTICAL ZOOM 12X 18/25X (16X Mono.) 18/25X (16X Mono.)
DIGITAL ZOOM NO 12X (6X Mono.) 12X (6X Mono.)
PRIVACY MASKING NO YES* YES*
DIGITAL STABILIZATION NO 25X model only 25X model only
* Not for monochrome
CHOOSING THE BUBBLE
TYPE DETAILS
CLEAR Light sensitivity important. Dome camera visible
TINT Dome camera hidden. Restricts some lighting
BRONZE (G3A ONLY) Similar to Tinted. Blend with interior aesthetics
GOLD (G3A ONLY) Similar to Tinted. Blend with interior aesthetics
CHROME (G3A ONLY) Similar to Tinted. Blend with interior aesthetics
G3B - DUMMY For G3B domes only
CHOOSING THE CAMERA
FEATURE MONO. COLOR DAY/NIGHT 25X ZOOM
RESOLUTION Highest Good Good
SENSITIVITY Highest Good Good in day mode V.Good in
night mode
IR SENSITIVITY Good No Limited in day mode
Good in night mode
COLOR No Yes Yes in day mode
No in night mode
OPTICAL ZOOM Good Good V. Good
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:42 Pagina 4

5
PHILIPS G3 AUTODOMES
There are the 3 families of domes, with a selection of dome
covers, and a selection of cameras that Philips offers.
Choose the one best suited to your application from the table
on page 4.
Philips’ G3B AutoDomes
Philips’ G3B AutoDomes are anything but basic. They are an
affordable, yet full featured G3 AutoDome. The G3B high
resolution, color 12x optical zoom camera assembly mounts
into either the pendant mount or the in-ceiling box, and there
are even dummy versions. In common with all Philips G3
AutoDomes the G3B includes an On-screen Display (OSD) for
programming, 16 zone sectors and 99 pre-positions, each with
separate 16-character title. The auto-playback (Guard Tour)
feature allows you to store 2 separate tours totaling 15 minutes
of duration. G3B includes auto-focus and our patented
AutoPivot feature. The Philips G3B AutoDome is ideal for
routine indoor applications such as retail and office
environments.
CHOOSING THE
RIGHT DOME
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:42 Pagina 5

6
PHILIPS G3 AUTODOMES
Philips G3A AutoDomes
When the requirements get more demanding the Philips G3A
comes into its own. It has all the key features of the Philips G3
AutoDome range but now the performance is extended for
when the going gets tough. The 18x optical zoom and 12x
digital zoom high resolution camera means you can really get
close to the subject, and see all the details you need. The
sensitive color camera gives sharp bright pictures, but if the
scene can get really dark, the day/night version is ideal. The
Philips G3A AutoDome is ideal for demanding indoor
applications such as retail, casinos, banks, warehouses and car
parks.
Philips EnviroDome
The EnviroDome is the outdoor version of the G3A
AutoDome, with addtional 25x optical zoom function. It comes
complete with heater, blower and sunshield.With IP66, Nema 4,
protection the EnviroDomes can be used in virtually any
outdoor application, and are ideal for, Public area surveillance,
transport and distribution, car parks etc.
CHOOSING THE
RIGHT DOME
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:42 Pagina 6

7
G3B SERIES
AUTODOMES
PHILIPS G3 AUTODOMES
SPECIFICATIONS
MODEL G3BS50/G3BPW50
IMAGER 1/4-inch IT CCD (752 x 596 pixels)
LENS 12X zoom (4.0mm - 48mm)
F1:1.0 to F1: 2.0
FIELD OFVIEW 3.8° to 43.6°
HORIZ. RESOLUTION 450 TVL
SENSITIVITY 10 fc/1.0 lx (5fc/0.5lx with optional clear window)
DESIGN RATING IP31 (NEMA 2)
OPERATING TEMP. -10°C to 50°C
WEIGHT 1.7 kg
CAMERA SETUP Biphase or RS-232
CONTROL
PRE-POSITIONS 99 each with 16-character titles
GUARDTOUR 2 record/playback tours totaling 15 minutes of
PTZ commands and 1 pre-position tour consisting of
xx stored scenes
ADDRESSING FastAddressTM remote addressing
SECTORS/TITLING 16 indepentent sectors with 16-character titles/sector
G3BS50
G3BPW50
• Low Profile
• High Speed
• Affordable, yet Feature Rich
• Easy to Install
• Remotely Configurable
• RS-232 Compatible
• Patented Auto Scaling Feature
• Sector and Preset Titling
Note: Specifications are for PAL on all products.
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:42 Pagina 7

8
G3A AUTODOME
PENDANT
INDOOR SYSTEMS
PHILIPS G3 AUTODOMES
• Low Profile
• Ultra High Sensitivity
• High Resolution and High Speed
• Slow Shutter control (Frame integration) (except Monochrome)
LTC 0725
LTC 0825
LTC 0925
LTC 0935
SPECIFICATIONS
MODEL LTC0725 LTC0825
Monochrome Color
IMAGER 1/3-inch IT CCD 1/4-inch IT CCD
(752 x 596 pixels) (752 x 582 pixels)
LENS 16 X Optical 18 X Optical
(4.5mm to 72mm) (4.1mm to 74mm)
F1:1.2 to F1:2.7 F1:1.4 to F1:3.0
FIELD OFVIEW 3.4° to 57° 2.7° to 48°
GAIN CONTROL Off/Auto Off/Auto/Fixed
DIGITAL ZOOM None 12X
HORIZ. RESOLUTION 550 TVL 460 TVL
SENSITIVITY
w/frame integration off 0.008 fc/0.08 lx 0.05 fc/0.5 lx
w/frame integration on N/A 0.0031fc/0.031 lx
DESIGN RATING IP54 (NEMA 3) IP54 (NEMA 3)
OPERATING TEMP. -10°C to 50°C -10°C to 50°C
WEIGHT 3.6 kg 3.6 kg
PRE-POSITIONS 99 99
GUARDTOUR 2 record/playback tours totaling 15 minutes of PTZ commands
and 1 pre-position tour consisting of xx stored scenes.
ADDRESSING 4 Digit Thumbwheel or FastAddress
SECTORS/TITLING 16 indepentent sectors with 16-character titles/sector
PRIVACY MASKING N/A N/A
Note: Specifications are for PAL on all products.
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:42 Pagina 8

9
PHILIPS G3 AUTODOMES
LTC0925 LTC0935
Day/Night Day/Night/Extended Zoom
1/4-inch IT CCD 1/6-inch IT CCD
(752 x 582 pixels) (752 x 582 pixels)
18 X Optical 25 X Optical
(4.1mm to 74mm) (2.4mm to 60mm)
F1:1.4 to F1:3.0 F1:1.6 to F1:2.7
2.7° to 48° 2.0° to 45°
Off/Auto/Fixed Off/Auto/Fixed
12X 12X
460 TVL 460 TVL
0.025 fc/0.25 lx (day) 0.2 fc/2.0 lx (day)
0.0031 fc/0.03 1lx (nt) 0.02 fc/0.25 lx (nt)
0.0016 fc/0.016 lx (day) 0.013 fc/0.13 lx (day)
0.00023 fc/0.002 lx (nt) 0.0013 fc/0.013 lx (nt)
IP54 (NEMA 3) IP54 (NEMA 3)
-10°C to 50°C -10°C to 50°C
3.6 kg 3.6 kg
99 99
2 record/playback tours totaling 15 minutes of PTZ commands
and 1 pre-position tour consisting of xx stored scenes.
4 Digit Thumbwheel or FastAddress
16 indepentent sectors with 16-character titles/sector
N/A Up to 6 individual masks
• 18x or 25x optical Zoom (except Monochrome)
• 160-mm (6.3-in) Dome
• Remotely Configurable
• Available in Day/Night and extended zoom
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:42 Pagina 9

10
G3A AUTODOME
CEILING
INDOOR SYSTEMS
PHILIPS G3 AUTODOMES
• Low Profile
• Ultra High Sensitivity
• High Resolution and High Speed
• 160-mm (6.3-in) Dome
• Slow Shutter control (Frame integration)*
LTC 0729
LTC 0829
LTC 0929
LTC 0939
Note: Specifications are for PAL on all products.
* Color and Day/Night Models only
SPECIFICATIONS
MODEL LTC0729 LTC0829
Monochrome Color
IMAGER 1/3-inch IT CCD 1/4-inch IT CCD
(752 x 596 pixels) (752 x 582 pixels)
LENS 16 X Optical 18 X Optical
(4.5mm to 72mm) (4.1mm to 74mm)
F1:1.2 to F1:2.7 F1:1.4 to F1:3.0
FIELD OFVIEW 3.4° to 57° 2.7° to 48°
GAIN CONTROL Off/Auto Off/Auto/Fixed
DIGITAL ZOOM None 12X
HORIZ. RESOLUTION 550 TVL 460 TVL
SENSITIVITY
w/frame integration off 0.008 fc/0.08 lx 0.05 fc/0.5 lx
w/frame integration on N/A 0.0031 fc/0.031 lx
DESIGN RATING IP54 (NEMA 3) IP54 (NEMA 3)
OPERATING TEMP. -10°C to 50°C -10°C to 50°C
WEIGHT 3.6 kg 3.6 kg
PRE-POSITIONS 99 99
GUARDTOUR 2 record/playback tours totaling 15 minutes of PTZ commands
and 1 pre-position tour consisting of xx stored scenes.
ADDRESSING 4 Digit Thumbwheel or FastAddress
SECTORS/TITLING 16 indepentent sectors with 16-character titles/sector
PRIVACY MASKING N/A N/A
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:42 Pagina 10

11
PHILIPS G3 AUTODOMES
• 18X or 25X optical Zoom*
• Remotely Configurable
• Color/Monochrome Day/Night Models
• Multi Lingual Displays
LTC0929 LTC0939
Day/Night Day/Night/Extended Zoom
1/4-inch IT CCD 1/6-inch IT CCD
(752 x 582 pixels) (752 x 582 pixels)
18 X Optical 25 X Optical
(4.1mm to 74mm) (2.4mm to 60mm)
F1:1.4 to F1:3.0 F1:1.6 to F1:2.7
2.7° to 48° 2.0° to 45°
Off/Auto/Fixed Off/Auto/Fixed
12X 12X
460 TVL 460 TVL
0.025 fc/0.25 lx (day) 0.2 fc/2.0 lx (day)
0.0031 fc/0.031 lx (nt) 0.02 fc/0.25 lx (nt)
0.0016 fc/0.0163 lx (day) 0.013 fc/0.13 lx (day)
0.0002 fc/0.002 lx (nt) 0.0013 fc/0.013 lx (nt)
IP54 (NEMA 3) IP54 (NEMA 3)
-10°C to 50°C -10°C to 50°C
3.6 kg 3.6 kg
99 99
2 record/playback tours totaling 15 minutes of PTZ commands
and 1 pre-position tour consisting of xx stored scenes.
4 Digit Thumbwheel or FastAddress
16 indepentent sectors with 16-character titles/sector
N/A Up to 6 individual masks
Note: Specifications are for PAL on all products.
* Color and Day/Night Models only
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:42 Pagina 11

12
PHILIPS G3 AUTODOMES
G3 ENVIRODOME
COLOR AND
MONOCHROME
OUTDOOR
SYSTEMS
SPECIFICATIONS
MODEL ENVM ENVC
Monochrome Color
IMAGER 1/3-inch IT CCD 1/4-inch IT CCD
(752 x 596 pixels) (752 x 582 pixels)
LENS 16 X Optical 18 X zoom
(4.5mm to 72 mm) (4.1mm - 74mm)
F1:1.2 to F1:2.7 F1:1.4 to F1:.3.0
FIELD OFVIEW 3.4° to 57° 2.7° to 48°
GAIN CONTROL Off/Auto Off/Auto/Fixed
DIGITAL ZOOM None 12 X
HORIZ. RESOLUTION 550 TVL 460 TVL
SENSITIVITY 0.008 fc/0.08 lx 0.025 fc/0.25 lx day mode w/ frame integration off
0.0031 fc/0.031 lx night mode w/ frame integration off
0.0016 fc/0.016 lx day mode w/ frame integration on
0.0002 fc/0.002 lx night mode w/ frame integration on
DESIGN RATING IP66 (NEMA 4)
OPERATING TEMP. -40°C to 50°C
WEIGHT 5.9 kg
PRE-POSITIONS 99 each with 16-character titles
GUARDTOUR 2 tours totaling 15 minutes duration.
All camera functions stored in memory
ADDRESSING FastAddressTM remote addressing or
4 digit “thumbwheel” type
SECTORS/TITLING 16 indepentent sectors with 16-character titles/sector
• Available in Color and B/W
• Ultra High Sensitivity
• High Resolution
• High Speed
• Remotely Configurable
• RS-232 Compatible
ENVC
ENVM
Note: Specifications are for PAL on all products.
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:43 Pagina 12

13
PHILIPS G3 AUTODOMES
G3 ENVIRODOME
DAY/NIGHT
OUTDOOR
SYSTEMS
18X & 25X ZOOM
SPECIFICATIONS
MODEL ENVD ENVT
IMAGER 1/4-inch IT CCD 1/6-inch It CCD
(752 x 582 pixels) (752 x 582 pixels)
LENS 18X zoom 25X zoom
(4.1mm - 74mm) (2.4mm - 60mm)
F1:1.4 to F1:.3.0 F1:1.6 TO F1:2.7
FIELD OFVIEW 2.7° to 48° 2.0° to 45°
GAIN CONTROL Off/Auto/Fixed
DIGITAL ZOOM 12 X
HORIZ. RESOLUTION 460 TVL
SENSITIVITY 0.2 fc/2.0 lx day mode w/ frame integration off
0.02 fc/0.2 lx night mode w/ frame integration off
0.013 fc/0.13 lx day mode w/ frame integration on
0.0013 fc/0.013 lx night mode w/ frame integration on
DESIGN RATING IP66 (NEMA 4)
OPERATING TEMP. -40°C to 50°C
WEIGHT 5.9 kg
PRE-POSITIONS 99 each with 16-character titles
GUARDTOUR 2 tours totaling 15 minutes duration.
All camera functions stored in memory
ADDRESSING FastAddressTM remote addressing or
4 digit “thumbwheel” type
SECTORS/TITLING 16 indepentent sectors with 16-character titles/sector
• Ultra High Sensitivity
• High Resolution
• High Speed
• Remotely Configurable
• RS-232 Compatible
• Patented AutoPivot,Auto Scaling Features
• Privacy Masking
• Digital Stabilization
• 25X Optical Zoom
ENVD
ENVT
Note: Specifications are for PAL on all products.
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:43 Pagina 13

INDOOR
G3B G3A
COLOR MONO COLOR DAY/NIGHT
Imager 1/4-inch 1/3-inch 1/4-inch 1/4-inch
Optical Zoom x12 (4 - 48 mm) x16 (4,5 - 72 mm) x18 (4,1 - 74 mm) x18 (4,1 - 73.8 mm)
Field ofView 3,8° to 43,6° 3,4° to 57° 2.7° to 48° 2.7° to 48°
Digital Zoom No No x 12 x 12
Auto Iris Yes Yes Ye s Ye s
Auto Focus Yes Yes Ye s Ye s
Horizontal Resolution 450 lines 550 lines 460 lines 460 lines
Sensitivity 2 Lux (with tinted bubble) 0,08 Lux 0,5 Lux 0,5/0,03 Lux (Day/Nt)
Frame Integration No No Yes Yes
Sensitivity (Frame Integration) NA NA 0.03 Lux 0,03/0,004 Lux (Day/Nt)
Environmental Protection IP 31 (pendant) IP 54 (pendant) IP 54 (pendant) IP 54 (pendant)
Operating temperature - 10°C to 50°C - 10°C to 50°C - 10°C to 50°C - 10°C to 50°C
Heater / Blower No No No No
Variable speed 120°/s 120°/s 120°/s 120°/s
Speed between prepos. 360°/s 360°/s 360°/s 360°/s
Remote Control Biphase or RS232 Biphase or RS232 Biphase or RS232 Biphase or RS232
Addressing Remotely Remotely / Switch Remotely / Switch Remotely / Switch
Number of prepositions 99 99 99 99
Guard tour 2 [total 15 min] 2 [total 15 min] 2 [total 15 min] 2 [total 15 min]
Zone masking 16 16 16 16
In-Ceiling version Yes Ye s Yes Yes
Pendant version Ye s Ye s Yes Yes
Optional Fiber OpticsTrans. Ye s Yes Yes Yes
Privacy Masking No No No No
14
PHILIPS G3 AUTODOMES
G3 AUTODOME
COMPARISON
CHART
Note: Specifications are for PAL on all products.
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:43 Pagina 14

INDOOR OUTDOOR
G3A ENVIRO ENVIRO DAY/NT
DAY/NIGHT/ MONO COLOR MONO/COLOR MONO/COLOR/
EXTENDED ZOOM EXTENDED ZOOM
1/6-inch 1/3-inch 1/4-inch 1/4-inch 1/6-inch
x25 (2.4 - 60 mm) x16 (4,5 - 72 mm) x18 (4,1 - 74 mm) x18 (4,1 - 74 mm) x25 (2,4 - 60 mm)
2.0° to 45° 3,4° x 57° 2,7° x 48° 2,7° x 48° 2,0° x 45°
x 12 No x 12 x 12 x 12
Yes Yes Yes Yes Ye s
Yes Ye s Yes Yes Yes
460 lines 550 lines 460 lines 460 lines 460 lines
0,2/0,02 Lux (Day/Nt) 0,08 Lux 0,5 Lux 0,5/0,03 Lux (Day/Nt) 0,2/0,02 Lux (Day/Nt)
Yes N o Yes Yes Ye s
0,013/0,0013 Lux (Day/Nt) NA 0,03 Lux 0,03/0,004 Lux (Day/Nt) 0,013/0,0013 Lux (Day/Nt)
IP 66 (pendant) IP 66 IP 66 IP 66 IP 66
- 10°C to 50°C - 40°C to 50°C - 40°C to 50°C - 40°C to 50°C - 40°C to 50°C
No Ye s Yes Yes Ye s
120°/s 120°/s 120°/s 120°/s 120°/s
360°/s 360°/s 360°/s 360°/s 360°/s
Biphase or RS232 Biphase or RS232 Biphase or RS232 Biphase or RS232 Biphase or RS232
Remotely / Switch Remotely Remotely / Switch Remotely / Switch Remotely / Switch
99 99 99 99 99
2 [total 15 min] 2 [total 15 min] 2 [total 15 min] 2 [total 15 min] 2 [total 15 min]
16 16 16 16 16
Yes N o No No No
Yes Ye s Yes Yes Yes
Yes Ye s Yes Yes Yes
Yes N o No No Yes
15
PHILIPS G3 AUTODOMES
G3 AUTODOME
COMPARISON
CHART
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:43 Pagina 15

16
UNITYDOME™
FIXED CAMERA
UNITS
PHILIPS G3 AUTODOMES
• Integrated Fixed Camera/Lens Module
• Innovative 3-pivot Camera Adjustment System for a Full 180° of Movement
• Prewired for Quick and Easy Installation
• Variety of Options Available
• Concealed Camera w/ Minimal f-stop Loss
LTC 9349
LTC 9449
LTC 9450
Note: Specifications are for PAL on all products.
SPECIFICATION IN-CEILING
COLOR COLOR MONOCHROME COLOR
STANDARD RES HI RES STANDARD RES
MODELS LTC 9349/x0CS LTC 9349/20CH LTC 9349/x0MS LTC 9449/x0CS
RESOLUTION 330 TVL 480 TVL 380 TVL 330 TVL
IMAGER 1/3” 1/3” 1/3”
MIN. LUX 1.8 2.8 .5 1.8
CAMERA Backlight Backlight Backlight Backlight
Compensation Compensation, Compensation Compensation
AGC,AWB, Gamma
LENS 3.5-8mm/5-50mm 2.6-6mm 3.5-8mm/5-50mm 3.5-8mm/5-50mm
FRANGE 1.4-200 1.6-200 1.4-200 1.4-200
LENS FORMAT 1/3” 1/3” 1/3” 1/3”
POWER 3W 3W 3W 3W
MOUNTING ------ ------ -------- Wall, pipe, pole,
parapet
WEIGHT 3.8lb 3.8lb 3.8lb 4.4lb
HEATER No No No No
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:43 Pagina 16

17
PHILIPS G3 AUTODOMES
These preconfigured fixed camera and lens combinations blend seamlessly
into an application with G3 AutoDomes and even use the same mounts and
wiring for maximum flexibility.
UNITYDOME™
FIXED CAMERA
UNITS
INDOOR PENDANT OUTDOOR PENDANT
COLOR MONOCHROME COLOR COLOR MONOCHROME
HI RES. STANDARD RES STANDARD RES HI RES STANDARD RES
LTC 9449/x0CH LTC 9449/x0MS LTC 9450/x0CS LTC 9450/x0CH LTC 9450/x0MS
480 TVL 380TVL 330 TVL 480 TVL 380TVL
1/3” 1/3” 1.3”
2.8 0.5 1.8 2.8 0.5
Backlight Backlight Backlight Backlight Backlight
Compensation, Compensation Compensation Compensation, Compensation
AGC,AWB, Gamma AGC,AWB, Gamma
2.6-6mm 3.5-8mm/5-50mm 3.5-8mm/5-50mm 2.6-6mm 3.5-8mm/5-50mm
1.6-200 1.4-200 1.4-200 1.6-200 1.4-200
1/3” 1/3” 1/3” 1/3” 1/3”
3W 3W 35W 35W 35W
Wall, pipe, pole, Wall, pipe, pole, Wall, pipe, pole, Wall, pipe, pole, Wall, pipe, pole,
parapet parapet parapet parapet parapet
4.4lb 4.4lb 5.0lb 5.0lb 5.0lb
No No Yes Yes Yes
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:43 Pagina 17

18
WALL MOUNTS
PHILIPS G3 AUTODOMES
All of the mounts are
compatible with all
mentioned domes:
• G3A
• G3B
• ENVIRO
ORDERING CODES
MOUNT WHITE
PENDANT ARM ONLY LTC 9540/00
WALL MOUNT 120 VAC * LTC 9540/60
WALL MOUNT 240 VAC* LTC 9540/50
*Contains Wall Arm w/integrated power supply and wall mount plate
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:43 Pagina 18

19
PHILIPS G3 AUTODOMES
G3 AUTODOME
FIBER OPTIC
MOUNTS
SPECIFICATIONS
MODEL LTC 954*/**F
DESIGN RATING IP65 (NEMA 4)
OPERATING TEMP. –40°C to 50°C ( –40° F to 122° F)
OPTICAL FIBER 50/125 nm, 62.5/125 nm, low loss multimode glass fiber,
COMPATIBILITY rated for a minimum system bandwidth of 20 MHz
(video 850 nm/control 1300 nm)
MAX DISTANCE 4 km (2.5 miles)
POWER G3 Indoor – 25 W Max
EnviroDome – 50 W Max
COMPATIBLE LTC 4629/50, LTC 4629/60, LTC 4629/00
RECEIVERS
• Integrated Fiber Optic Transceiver for G3 AutoDomes
• Single Fiber Optic Connection forVideo and Control
• Simple Field Installation
• Environmentally Sound NEMA 4/IP65 Rated Enclosure
• Available in a Variety of Mounting Options
Note: Specifications are for PAL on all products.
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:43 Pagina 19

20
AUTODOME
ORDERING GUIDE
* NOTE:
No transformer included.
Customer must supply 24 VAC,
50 VA transformer
(LTC 5401 or equivalent).
Not available with fiber optic option.
** Each fiber kit requires an LTC 4629
at the system.
***Roof mount mounts to vertical
parapet. For flat roof installations,
you must also order the
LTC 9230/01 Flat Roof Adapter Plate.
* NOTE:
No transformer included.
Customer must supply 24 VAC,
50 VA transformer
(LTC 5401 or equivalent).
Not available with fiber optic option.
** Wall and pipe mount kits
only apply to pendant models.
* NOTE:
No transformer included.
Customer must supply
24 VAC, 15 W (min.) transformer
(LTC 5401 or equivalent).
** Wall and pipe mount kits
only apply to pendant models.
Monocrome models are ordered as
LTC 0725 Series (pendent) and LTC 0729
Series (in-ceiling).
See your local sales representarive for
specific model numbers.
Ordering Information:
Use the following chart to create your order numbers based on the example below.
G3 ENVIRODOME ORDERING GUIDE
G3 BASIC ORDERING GUIDE
G3 AUTODOME ORDERING GUIDE
PHILIPS G3 AUTODOMES
CCTV_AutoD_RefG_46814_ENG 29-05-2002 16:43 Pagina 20
