Philips BT6000C User manual

www.philips.com/support
User manual
Always there to help you
Register your product and get support at
BT6000C
Question?
Contact
Philips

1EN
Contents
1 Important 2
2 Your Bluetooth speaker 3
Introduction 3
What's in the box 3
Overview of the speaker 4
3 Get started 5
Power supply 5
Turn on/off 5
Adjust volume 6
Use the pouch 6
4 Use Bluetooth devices 7
Connect a device 7
Play from Bluetooth device 8
Control your phone call 8
Disconnect a device 8
Reconnect a device 8
5 Listen to an external device 9
6 Product information 10
Specications 10
7 Troubleshooting 11
General 11
About Bluetooth device 11
8 Notice 12
Care of the environment 12
Trademark notice 12

2EN
1 Important
Warning
• Never remove the casing of this speaker.
• Never place this speaker on other electrical equipment.
• Keep this speaker away from direct sunlight, naked
amesorheat.
• Make sure that there is enough free space
around the speaker for ventilation.
• After use under humid circumstance,
immediately clean the product with a soft
dry cloth.
• The battery shall not be exposed to
excessiveheatsuchassunshine,reorthe
like.

3EN
2 Your Bluetooth
speaker
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
This speaker has passed splash-proof test
(IPX4) and can be used near water.
With this speaker, you can enjoy audio from
Bluetooth-enabled devices or other external
devices.
What's in the box
Check and identify the contents of your
package:
• Speaker
• USB cable for charging
• Pouch for carrying
• Quick start guide
Quick Start Guide
www.philips.com/support
Always there to help you
Registeryour product and get support at
Question?
Contact
Philips

4EN
Overview of the speaker
a PAIRING
• Enter Bluetooth pairing mode.
• Disconnect Bluetooth connection.
• Answer or reject an incoming call.
• End the current phone call.
• Transfer the call to your mobile device.
b NFC
• Connect a NFC compatible device
through Bluetooth.
c
• Charge the built-in battery.
d AUDIO IN
• Connect an external audio device.
e Volume knob ( )
• Adjust volume.
• Turn the speaker on or off.
a
c
b
d
e

5EN
3 Get started
Always follow the instructions in this chapter in
sequence.
Power supply
Either AC power or battery can be used as
power supply of this product.
Note
• Rechargeable battery has a limited number of charge
cycles. Battery life and number of charge cycles vary by
use and settings.
• It takes approximately three hours to fully charge the
battery.
• TheredLEDindicatorasheswhenthebatteryislow.
To recharge the built-in battery:
• Connect the USB cable between
• the socket on the speaker, and
• a USB socket on a computer.
LED indicator Battery status
Solid red Under charging
Off Fully charged
Turn on/off
• To turn the speaker on or off, rotate the
knob clockwise or anticlockwise until you
hear a click.
» When the speaker is turned on, the
blueLEDindicatorashes.
» When the speaker is turned off, the
blue LED indicator lights off, and the
and the icons are towards the same
direction.
Note
• Ifthebatterylevelislow,theredLEDindicatorashes.
OFF
ON

6EN
Switch to standby mode
The speaker switches to standby mode in the
following situations:
• The connection with Bluetooth device or
other device is invalid for 15 minutes; or
• Music playback is stopped for 15 minutes.
Adjust volume
During play, rotate the knob to increase or
decrease volume.
Use the pouch
A pouch makes the speaker convenient for
carrying. Use the supplied pouch as illustrated.

7EN
4 Use Bluetooth
devices
With this speaker, you can listen to audio from
Bluetooth-enabled devices and control the
incoming call through Bluetooth.
Connect a device
Note
• The speaker can memorize a maximum of four paired
devices.Thefthpaireddevicewillreplacetherstone.
• Make sure that Bluetooth function is enabled on your
device, and your device is set as visible to all other
Bluetooth devices.
• Any obstacle between this speaker and a Bluetooth
device can reduce the operational range.
• Keep away from any other electronic device that may
cause interference.
• Make sure that no audio input cable is connected to
the AUDIO IN socket.
Option 1: Connect a device through
NFC
Near Field Communication (NFC) is a
technology that enables short-range wireless
communication between various NFC
compatible devices, such as mobile phones and
IC tags.
If your Bluetooth device supports NFC, you can
connect it with this speaker easily.
1 Enable NFC on your Bluetooth device
(refer to its user manual).
2 Turn on the speaker.
» TheblueLEDindicatorashes.
3 Tap the NFC tag on the top of the speaker
with the NFC area of your Bluetooth
device.
4 Follow the on-screen instructions to
complete the pairing and connection.
» After successful connection, the
speaker beeps twice, and the LED
indicator turns solid blue.
Option 2: Connect a device manually
Note
• The operational range between this speaker and a
Bluetoothdeviceisapproximately10meters(30feet).
1 On your Bluetooth device, enable
Bluetooth and search for Bluetooth devices
that can be paired (see the user manual of
the device).
2 Turn on the speaker.
» TheblueLEDindicatorashes.

8EN
3 Select [Philips BT6000] displayed on your
deviceforpairing.Ifnecessary,input“0000”
as the pairing password.
» After successful connection, the
speaker beeps twice, and the LED
indicator turns solid blue.
• Ifyoufailtond[Philips BT6000] on
your device for pairing, press and hold
PAIRING until you hear beep sound,
and then try again.
LED indicator Description
Flashing blue Connecting;
Waiting for pairing
Solid blue Connected
Play from Bluetooth device
Note
• If there is an incoming call on the connected mobile
phone, music play pauses.
After successful Bluetooth connection, play
audio on the Bluetooth device.
» Audio streams from your Bluetooth
device to the speaker.
Control your phone call
After Bluetooth connection, you can control an
incoming call with this speaker.
Button Function
Press to answer an incoming call.
Press and hold for three seconds to
reject an incoming call.
During a call, press to end the current
call.
During a call, press and hold for three
seconds to transfer the call to your
mobile device.
Disconnect a device
• Press and hold PAIRING for three seconds
when there is no incoming call;
• Disable Bluetooth on your device; or
• Move the device beyond the
communication range.
» The speaker beeps twice, and the blue
LEDindicatorashes.
Note
• Before connecting another Bluetooth device, disconnect
thecurrentdevicerst.
Reconnect a device
When you turn on the speaker, it will reconnect
the last connected device automatically; If not,
select [Philips BT6000] on your Bluetooth
device to start connection.

9EN
5 Listen to an
external device
With this speaker, you can also listen to an
external audio device such as an MP3 player.
Note
• Make sure that music playback through Bluetooth is
stopped.
1 Open the protective cover on the left of
the speaker.
2 Connect an audio input cable (not
supplied) with a 3.5 mm connector on
both ends to
• the AUDIO IN socket on this speaker,
and
• the headphone socket on the external
device.
3 Play audio on the external device (refer to
its user manual).

10 EN
6 Product
information
Note
• Product information is subject to change without prior
notice.
Specications
Amplier
Rated Output Power 2 X 5W RMS
Frequency Response 40-20000Hz,±3dB
Signal to Noise Ratio > 65 dBA
Audio In 600mV(RMS),22kohm
Speaker
Speaker Impedance 8 ohm
Speaker Driver 1.5 inch full range
Sensitivity >85dB/m/W±
2dB/m/W
Bluetooth
BluetoothVersion V4.0
SupportedProles HFP,A2DP,AVRCP
Range 10m(Freespace)
General information
Built-in Battery Li-ionbattery(3.7V,
4400mAh)
Standby Power
Consumption
<1 W
Eco Standby Power
Consumption
<0.5W
Dimensions - Main
Unit(WxHxD) 188x70x71mm
Weight - Main Unit 0.5kg

11EN
7 Troubleshooting
Warning
• Never remove the casing of this device.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page (www.
philips.com/support).When you contact Philips,
make sure that the device is nearby and the
model number and serial number are available.
General
No power
•Recharge your speaker.
No sound
•Adjust volume on this product.
•Adjust volume on the connected device.
•Make sure that your Bluetooth device is
within the effective operational range.
No response from the speaker
•Recharge the speaker.
The LED indicator is solid red, and the
speaker has no response when pressing any
key.
•The speaker is in DEMO mode. Press and
hold PAIRING for 15 seconds to exit this
mode.
About Bluetooth device
The audio quality is poor after connection
with a Bluetooth-enabled device.
•The Bluetooth reception is poor. Move the
device closer to this product or remove
any obstacle between them.
Fail to nd [Philips BT6000] on your device
for pairing.
•Press and hold PAIRING for three seconds,
and then try again.
Cannot connect with the device.
•The Bluetooth function of the device is not
enabled. Refer to the user manual of the
device for how to enable the function.
•This product is already connected with
another Bluetooth-enabled device.
Disconnect that device and then try again.
The paired device connects and disconnects
constantly.
•The Bluetooth reception is poor. Move the
device closer to this product or remove
any obstacle between them.
•For some devices, Bluetooth connection
may be deactivated automatically as a
power-saving feature.This does not indicate
any malfunction of this product.

12 EN
8 Notice
Anychangesormodicationsmadetothis
device that are not expressly approved by
Gibson Innovations may void the user’s
authority to operate the equipment.
This product is designed to be waterproof in
compliancewithIEC60529IPX4.
Care of the environment
Disposal of your old product
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
Do not throw away the product with the
normal household waste at the end of its life,
buthanditinatanofcialcollectionpointor
recycling. By doing this, you help to preserve the
environment.
Caution
• Removal of the built-in battery invalidates the warranty
and may destroy the product.
Always bring your product to a professional to
remove the built-in battery.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
Trademark notice
The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Gibson
Innovations Limited is under license. Other
trademarks and trade names are those of their
respective owners.
The N Mark is a trademark or registered
trademark of NFC Forum, Inc. in the United
States and in other countries.

13

Specications are subject to change without notice.
2016 © Gibson Innovations Limited.All rights reserved.
This product has been manufactured by, and is sold under the responsibility of Gibson
Innovations Ltd., and Gibson Innovations Ltd. is the warrantor in relation to this product.
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.
and are used under license from Koninklijke Philips N.V.
BT6000C_77_UM_V1.0
