Philips CSP610/55 User manual

www.philips.com/welcome
Register your product and get support at
CSP410 CSP510
CSP6910CSP610
EN User manual

b
e
ac
d
a b
d
c
A
B

Amplifier
Right White lined White lined
Right
Left
Black
Black
Left
Car speaker
e
f g
C

English
1. Important
Safety
Read and understand all instructions before you use the apparatus.•
If damage is caused by failure to follow instructions, the warranty does
not apply.
Use only the supplied mounting hardware for a safe and secure•
installation.
Do not continuously use the speaker system beyond the peak power•
handling capacity.
Keep credit cards, watches, recorded tapes etc. with magnetic coding•
away from the speaker system to prevent damage caused by the
magnets in the speakers.
Clean the apparatus with soft, damp cloth. Never use substances such•
as alcohol, chemicals or household cleaners on the apparatus.
Notice
Environmental information
All unnecessary packaging has been omitted. We have tried to make
the packaging easy to separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.)
Your system consists of materials which can be recycled and reused if
disassembled by a specialized company. Please observe the local regulations
regarding the disposal of packaging materials, exhausted batteries and old
equipment.
Anychangesormodicationsmadetothisdevicethatarenotexpressly
approved by Philips Consumer Lifestyle may void the user’s authority to
operate the equipment.
2009 © Koninklijke Philips Electronics N.V. All rights reserved.
Specicationsaresubjecttochangewithoutnotice.Trademarksaretheproper tyofKoninklijkePhilips
Electronics N.V. or their respective owners. Philips reserves the right to change products at any time
without being obliged to adjust earlier supplies accordingly.

2.Your car stereo speakers
Congratulationsonyourpurchase,andwelcometoPhilips!Tofully
benetfromthesupportthatPhilipsoffers,registeryourproductat
www.philips.com/welcome.
Introduction
With the speakers, you can enjoy high power music with vivid sound.
What’s in the box A
Check and identify the contents of your package:
aSpeakers (x2)
bGrille net + Frame (x2)
cSpeaker wire (x2)
dScrew (x8)
eShrapnel (x8)
3. Installation
A depth of at least 46mm is required to mount the speaker. Measure the
depth of the area where you are to mount the speaker, and ensure that
the speaker does not obstruct any other components of the car.
Option 1: Mount on door (front or rear) B
You can mount the speakers on the front/rear door of your car. a

Note
•Make sure that nothing obstructs around the mounting location of the door.
A hole for mounting may already be cut out of the inner panel of the door
•
(front or rear). In this case, you need to modify the board only.
Ensure that the speaker terminals, frame or magnet do not interfere with any
•
inner parts, such as the window mechanism in the door (when you open or close
the window), etc. Also ensure that the speaker grille does not touch any inner
ttings,suchasthewindowcranks,doorhandles,armrestsetc.
1 Turnoffthecarignitionkey.
If the power is on, the click noise generated by the connection•
may damage the speakers.
2Cut out the mounting template from the packing box.
3Paste the template on the location selected for mounting the
speaker.
4Mark the cut-off hole and the 4 bolt holes. b
5Cut out the marked area and drill the bolt holes. c
6Remove the grille net. d
7 Stripthespeakerwiresandconnectthemtotheamplier. e
Black wire: connect to “-“ (negative) terminal•
Black (white lined): connect to “+“ (positive) terminal•
Note
Match the “left”, “right”, “+” and “-” terminals correctly. Revised polarity may
•
degrade sound quality.
Two4-ohmspeakers,wiredinstereo,presenta8ohmloadtoeachchannel
•
oftheamplier.Mosttwochannelampliersworkwellinthisconguration.
However, if two 4-ohm speakers, wired in parallel to a bridged two -channel
amplier,presenta2-ohmmonoloadtotheamplier.Most2-channelampliers
donotsupport2-ohmmonooperation!Amplierdamagemayresult!
8Mount on the speaker as shown below. f
9Press and insert the edges of the grille net. g

Tip
Thespeakergrillecanbemountedwithoutthegrillenet,ifyoulike.
•
Option 2: Mount on rear tray C
You can also mount the speakers into the surface of the rear tray.
Follow the steps in section “Option 1: Mount in door” to mount the
speakers into the rear tray:
4. Product information
Note
Product information is subject to change without prior notice.•
Model CSP410 CSP510
Speaker type 10cm 2-way coaxial
speaker
13cm, 2-way coaxial
speaker
RMS power (Watts) 30W 35W
Peak music power (Watts) 150W 180W
Sensitivity (dB/W/m) 88dB 89dB
Frequency response (Hz) 50-30kHz 45-30kHz
Impedance (ohms) 4 ohms 4 ohms
Magnet mass (Oz) 4.4Oz 6.4Oz
Mounting depth (mm) 46mm 47mm

Model CSP610 CSP6910
Speaker type 16.5cm, 2-way coaxial
speaker
16x24cm, 3-way triaxial
speaker
RMS power (Watts) 40W 50W
Peak music power (Watts) 210W 300W
Sensitivity (dB/W/m) 90dB 90dB
Frequency response (Hz) 40-30kHz 28-32kHz
Impedance (ohms) 4 ohms 4 ohms
Magnet mass (Oz) 7.6Oz 12.6Oz
Mounting depth (mm) 58mm 78mm
5.Troubleshooting
Tokeepthewarrantyvalid,nevertrytorepairthesystemyourself.
If you encounter problems when using this apparatus, go to the Philips
web site (www.philips.com/welcome). When you contact Philips, ensure
that the apparatus is nearby and the model number and serial number
are available.

© 2009 Koninklijke Philips Electronics N.V.
All rights reserved.
CSP410_55_UM_V2.1
