Colour Television Chassis
TPN14.1E
LA
Contents Page Contents Page
1. Revision List 2
2. Technical Specs, Diversity, and Connections 2
3. Precautions, Notes, and Abbreviation List 13
4. Mechanical Instructions 17
Cable dressing (22" 4100 series) 17
Cable dressing (24" 4100 series) 18
Cable dressing (32" 4100 series) 18
Cable dressing ( 40" & 47"PFx4109/88 series) 19
Cable dressing ( 40" & 47" PFx4109/12 series) 19
5. Service Modes and Fault Finding 27
6. Alignments 34
7. Circuit Descriptions 37
8. IC Data Sheets 48
9. Block Diagrams
Block diagram 4100 series 59
10. Circuit Diagrams and PWB Layouts Drawing PWB
A 715G6163 PSU 60 64-65
A 715G6297 PSU 66 68-69
BA 715G6079 SSB+PSU combination panel 70 85-86
B 715G6092 SSB 87 100-101
B 715G6094 SSB 102 119-120
J 715G5772 IR/LED Panel 121 122
EJ 715G6167 Control Board IR/LED Panel 123 124
11. Styling Sheets
4100 series 22" 125
4100 series 24" 126
4100 series 32" 127
4100 series 40" 128
4100 series 47" 129

Revision List
EN 2 TPN14.1E LA1.
2014-Feb-21 back to
div. table
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
Manual xxxx xxx xxxx.1
•Chapter 2: Updated table2.1 TechnicalSpecifications and
connection 2.7 Connections ( for 40" & 47"PFT4109/12).
•Chapter 4: Added figure 4-5 Cable dressing ( 40" & 47"
PFx4109/12 series).
•Chapter 5: Updated table 5-2 Factory mode overview.
•Chapter 6: Updated tables 6-2 White tone default settings
and 6-3 Display code overview.
•Chapter 7: Updated figure 7-1 Connector overview.
•Chapter 11: Added styling sheet 11.5 4100 series 47".
2. Technical Specs, Diversity, and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connections ( for 20"/22"/24"PxH4109/88 &
20"/24"PxH4109/60)
2.4 Connections ( for 22"/24"Pxx4109/12)
2.5 Connections ( for 32")
2.6 Connections ( for 40" & 47"PFx4109/88)
2.7 Connections ( for 40" & 47"PFT4109/12)
2.8 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in Table 2-1.
Hereisproductinformation available,aswellasgettingstarted,
user manuals, frequently asked questions and software &
drivers.
Table 2-1 Described Model Numbers and Diversity
2.2 Directions for Use
Directions for use can be downloaded from the following
websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN
24 910 11
Connection Overview
Mechanics Block Diagrams Schematics
Styling Wire Dressing Rear Cover Removal Speakers Removal SSB Removal Block Diagram Power Supply SSB + PSU combination panel SSB J (IR/LED ) EJ (control board + IR/LED panel)
20PHH4109/88 2-1 4-1 4-6 -4-7 9.1 10.2 -10.4 10.6 -11.1
20PHH4109/60 2-1 4-1 4-6 -4-7 9.1 10.2 -10.4 10.6 -11.1
22PFH4109/88 2-1 4-1 4-6 -4-7 9.1 10.2 -10.4 10.6 -11.1
22PFK4109/12 2-6 4-2 4-6 -4-7 9.1 10.2 -10.5 10.6 -11.2
22PFT4109/12 2-6 4-2 4-6 -4-7 9.1 10.2 -10.5 10.6 -11.2
24PHH4109/88 2-1 4-1 4-6 -4-7 9.1 10.2 -10.4 10.6 -11.1
24PHH4109/60 2-1 4-1 4-6 -4-7 9.1 10.2 -10.4 10.6 -11.1
24PHK4109/12 2-6 4-2 4-6 -4-7 9.1 10.2 -10.5 10.6 -11.2
24PHT4109/12 2-6 4-2 4-6 -4-7 9.1 10.2 -10.5 10.6 -11.2
32PHH4109/88 2-11 4-3 4-8 4-10 4-11 9.1 -10.3 - - 10.7 11.3
32PFH4109/88 2-11 4-3 4-8 4-10 4-11 9.1 -10.3 - - 10.7 11.3
32PFT4109/12 2-11 4-3 4-8 4-10 4-11 9.1 -10.3 - - 10.7 11.3
32PHT4109/12 2-11 4-3 4-8 4-10 4-11 9.1 -10.3 - - 10.7 11.3
32PHH4109/60 2-11 4-3 4-8 4-10 4-11 9.1 -10.3 - - 10.7 11.3
40PFH4109/88 2-16 4-4 4-12 4-10 4-15 9.1 10.1 -10.4 -10.7 11.4
40PFT4109/12 2-21 4-5 4-12 4-10 4-15 9.1 10.1 -10.5 -10.7 11.5
47PFH4109/88 2-16 4-4 4-12 4-10 4-15 9.1 10.1 -10.4 -10.7 11.4
47PFT4109/12 2-21 4-5 4-12 4-10 4-15 9.1 10.1 -10.5 -10.7 11.5

Technical Specs, Diversity, and Connections EN 3TPN14.1E LA 2.
2014-Feb-21
back to
div. table
2.3 Connections ( for 20"/22"/24"PxH4109/88 & 20"/24"PxH4109/60)
Figure 2-1 Connection overview
Note: The following connector colour abbreviations are used
(acc. to DIN/IEC 757): Bk= Black, Bu= Blue, Gn= Green,
Gy= Grey, Rd= Red, Wh= White, Ye= Yellow.
2.3.1 Side Connections
1 - Common Interface
68p-See figure 10-3-12 jk
2 - USB2 2.0
Figure 2-2 USB (type A)
1-+5V k
2 -Data (-) jk
3 -Data (+) jk
4 -Ground Gnd H
3 - Power Button
Turn on/off the TV.
2.3.2 Rear Connections
4 - Audio - In: Left / Right, VGA
Bu -Audio L/R in 0.5 VRMS / 10 kW jq
5 - PC IN:VGA
Figure 2-3 VGA connector
1 -Video Red 0.7 VPP / 75 W j
2 -Video Green 0.7 VPP / 75 W j
3 -Video Blue 0.7 VPP / 75 W j
4-n.c.
5 -Ground Gnd H
6 -Ground Red Gnd H
7 -Ground Green Gnd H
8 -Ground Blue Gnd H
9-+5V
DC +5 V j
10 -Ground Sync Gnd H
11 -Ground Red Gnd H
12 -DDC_SDA DDC data j
13 -H-sync 0 - 5 V j
14 -V-sync 0 - 5 V j
15 -DDC_SCL DDC clock j
6 - HDMI 1: Digital Video - In, Digital Audio with ARC -
In/Out
Figure 2-4 HDMI (type A) connector
1 -D2+ Data channel j
2 -Shield Gnd H
3 -D2- Data channel j
TVANTENNA
VGA / DVI
AUDIO IN
DIGITAL
AUDIO OUT
(RGB/CVBS)
(Optional)
HDMI1
ARC
SCART
SERV.U
VGA
19531_001_130923.eps
130923
1
2
3
4
65
7
8
10 9
11
Side ConnectorsRear Connectors
1 2 34
10000_022_090121.eps
090121
1
610
11
5
15
10000_002_090121.eps
090127
10000_017_090121.eps
090428
19 1
182

Technical Specs, Diversity, and Connections
EN 4 TPN14.1E LA2.
2014-Feb-21 back to
div. table
4 -D1+ Data channel j
5-Shield Gnd H
6 -D1- Data channel j
7 -D0+ Data channel j
8-Shield Gnd H
9 -D0- Data channel j
10 -CLK+ Data channel j
11 -Shield Gnd H
12 -CLK- Data channel j
13 -Easylink/CEC Control channel jk
14 -ARC Audio Return Channel k
15 -DDC_SCL DDC clock j
16 -DDC_SDA DDC data jk
17 -Ground Gnd H
18 -+5V j
19 -HPD Hot Plug Detect j
20 -Ground Gnd H
7 - Cinch: Digital Audio - Out
BK -Coaxial 0.4 - 0.6VPP / 75 W kq
8 - Service / UART
1 -Ground Gnd H
2 -UART_TX Transmit k
3 -UART_RX Receive j
9 - Head phone (Output)
Bk -Head phone 80 - 600 / 10 mW
ot
10 - EXT1: Video RGB/YC - In, CVBS - In/Out, Audio - In/Out
Figure 2-5 SCART connector
1 -Audio R 0.5 VRMS / 1 kk
2 -Audio R 0.5 VRMS / 10 kj
3 -Audio L 0.5 VRMS / 1 kk
4 -Ground Audio Gnd H
5 -Ground Blue Gnd H
6 -Audio L 0.5 VRMS / 10 kj
7 -Video Blue/C-out 0.7 VPP / 75 jk
8 -Function Select 0 - 2 V: INT
4.5 - 7 V: EXT 16:9
9.5 - 12 V: EXT 4:3 j
9 -Ground Green Gnd H
10 -n.c.
11 -Video Green 0.7 VPP / 75 j
12 -n.c.
13 -Ground Red Gnd H
14 -Ground P50 Gnd H
15 -Video Red/C 0.7 VPP / 75 j
16 -Status/FBL 0 - 0.4 V: INT
1 - 3 V: EXT / 75 j
17 -Ground Video Gnd H
18 -Ground FBL Gnd H
19 -Video CVBS 1 VPP / 75 k
20 -Video CVBS/Y 1 VPP / 75 j
21 -Shield Gnd H
11 - TV ANTENNA - In
Signal input from an antenna, cable or satellite.
21
20
1
2
10000_001_090121.eps
090121

Technical Specs, Diversity, and Connections EN 5TPN14.1E LA 2.
2014-Feb-21
back to
div. table
2.4 Connections ( for 22"/24"Pxx4109/12)
Figure 2-6 Connection overview
Note: The following connector colour abbreviations are used
(acc. to DIN/IEC 757): Bk= Black, Bu= Blue, Gn= Green,
Gy= Grey, Rd= Red, Wh= White, Ye= Yellow.
2.4.1 Side Connections
1 - Common Interface
68p-See figure 10-3-12 jk
2 - USB2 2.0
Figure 2-7 USB (type A)
1-+5V k
2 -Data (-) jk
3 -Data (+) jk
4 -Ground Gnd H
3 - SAT - In
Signal input from an SAT.
4 - Power Button
Turn on/off the TV.
2.4.2 Rear Connections
5 - TV ANTENNA - In
Signal input from an antenna, cable or satellite.
6 - PC IN:VGA
Figure 2-8 VGA connector
1 -Video Red 0.7 VPP / 75 W j
2 -Video Green 0.7 VPP / 75 W j
3 -Video Blue 0.7 VPP / 75 W j
4-n.c.
5 -Ground Gnd H
6 -Ground Red Gnd H
7 -Ground Green Gnd H
8 -Ground Blue Gnd H
9-+5V
DC +5 V j
10 -Ground Sync Gnd H
11 -Ground Red Gnd H
12 -DDC_SDA DDC data j
13 -H-sync 0 - 5 V j
14 -V-sync 0 - 5 V j
15 -DDC_SCL DDC clock j
7 - Audio - In: Left / Right, VGA
Bu -Audio L/R in 0.5 VRMS / 10 kW jq
8 - HDMI 1: Digital Video - In, Digital Audio with ARC -
In/Out
Figure 2-9 HDMI (type A) connector
TVANTENNA
VGA / DVI
SERV.U
AUDIO IN
DIGITAL
AUDIO OUT
SCART(RGB/CVBS)
HDMI1
ARC
VGA
SAT
19590_001_140110.eps
140110
1
2
3
4
765
8
9
11
10
12
Side ConnectorsRear Connectors
1 2 34
10000_022_090121.eps
090121
1
610
11
5
15
10000_002_090121.eps
090127
10000_017_090121.eps
090428
19 1
182

Technical Specs, Diversity, and Connections
EN 6 TPN14.1E LA2.
2014-Feb-21 back to
div. table
1 -D2+ Data channel j
2-Shield Gnd H
3 -D2- Data channel j
4 -D1+ Data channel j
5-Shield Gnd H
6 -D1- Data channel j
7 -D0+ Data channel j
8-Shield Gnd H
9 -D0- Data channel j
10 -CLK+ Data channel j
11 -Shield Gnd H
12 -CLK- Data channel j
13 -Easylink/CEC Control channel jk
14 -ARC Audio Return Channel k
15 -DDC_SCL DDC clock j
16 -DDC_SDA DDC data jk
17 -Ground Gnd H
18 -+5V j
19 -HPD Hot Plug Detect j
20 -Ground Gnd H
9 - Cinch: Digital Audio - Out
BK -Coaxial 0.4 - 0.6VPP / 75 W kq
10 - Head phone (Output)
Bk -Head phone 80 - 600 / 10 mW
ot
11 - Service / UART
1 -Ground Gnd H
2 -UART_TX Transmit k
3 -UART_RX Receive j
12 - EXT1: Video RGB/YC - In, CVBS - In/Out, Audio - In/Out
Figure 2-10 SCART connector
1 -Audio R 0.5 VRMS / 1 kk
2 -Audio R 0.5 VRMS / 10 kj
3 -Audio L 0.5 VRMS / 1 kk
4 -Ground Audio Gnd H
5 -Ground Blue Gnd H
6 -Audio L 0.5 VRMS / 10 kj
7 -Video Blue/C-out 0.7 VPP / 75 jk
8 -Function Select 0 - 2 V: INT
4.5 - 7 V: EXT 16:9
9.5 - 12 V: EXT 4:3 j
9 -Ground Green Gnd H
10 -n.c.
11 -Video Green 0.7 VPP / 75 j
12 -n.c.
13 -Ground Red Gnd H
14 -Ground P50 Gnd H
15 -Video Red/C 0.7 VPP / 75 j
16 -Status/FBL 0 - 0.4 V: INT
1 - 3 V: EXT / 75 j
17 -Ground Video Gnd H
18 -Ground FBL Gnd H
19 -Video CVBS 1 VPP / 75 k
20 -Video CVBS/Y 1 VPP / 75 j
21 -Shield Gnd H
21
20
1
2
10000_001_090121.eps
090121

Technical Specs, Diversity, and Connections EN 7TPN14.1E LA 2.
2014-Feb-21
back to
div. table
2.5 Connections ( for 32")
Figure 2-11 Connection overview
Note: The following connector colour abbreviations are used
(acc. to DIN/IEC 757): Bk= Black, Bu= Blue, Gn= Green,
Gy= Grey, Rd= Red, Wh= White, Ye= Yellow.
2.5.1 Side Connections
1 - Common Interface
68p-See figure 10-3-12 jk
5 - USB2 2.0
Figure 2-12 USB (type A)
1-+5V k
2 -Data (-) jk
3 -Data (+) jk
4 -Ground Gnd H
6 - HDMI 1: Digital Video - In, Digital Audio with ARC -
In/Out
Figure 2-13 HDMI (type A) connector
1 -D2+ Data channel j
2-Shield Gnd H
3 -D2- Data channel j
4 -D1+ Data channel j
5-Shield Gnd H
6 -D1- Data channel j
7 -D0+ Data channel j
8 -Shield Gnd H
9 -D0- Data channel j
10 -CLK+ Data channel j
11 -Shield Gnd H
12 -CLK- Data channel j
13 -Easylink/CEC Control channel jk
14 -ARC Audio Return Channel k
15 -DDC_SCL DDC clock j
16 -DDC_SDA DDC data jk
17 -Ground Gnd H
18 -+5V j
19 -HPD Hot Plug Detect j
20 -Ground Gnd H
7 - Cinch: Digital Audio - Out
BK -Coaxial 0.4 - 0.6VPP / 75 kq
2.5.2 Rear Connections
2 - TV ANTENNA - In
Signal input from an antenna, cable or satellite.
3 - HDMI2 : Digital Video - In, Digital Audio - In/Out
Figure 2-14 HDMI (type A) connector
1 -D2+ Data channel j
2 -Shield Gnd H
3 -D2- Data channel j
4 -D1+ Data channel j
TV ANTENNA
SERV.U
HDMI 2
SCART (RGB/CVBS)
CI
HDMI 1
ARC
SPDIF OUT
USB
19530_001_130730.eps
130730
1
2
3
4
6
7
5
8
Side ConnectorsSide ConnectorsRear Connectors
1 2 34
10000_022_090121.eps
090121
10000_017_090121.eps
090428
19 1
182
10000_017_090121.eps
090428
19 1
182

Technical Specs, Diversity, and Connections
EN 8 TPN14.1E LA2.
2014-Feb-21 back to
div. table
5-Shield Gnd H
6 -D1- Data channel j
7 -D0+ Data channel j
8-Shield Gnd H
9 -D0- Data channel j
10 -CLK+ Data channel j
11 -Shield Gnd H
12 -CLK- Data channel j
13 -Easylink/CEC Control channel jk
14 -n.c.
15 -DDC_SCL DDC clock j
16 -DDC_SDA DDC data jk
17 -Ground Gnd H
18 -+5V j
19 -HPD Hot Plug Detect j
20 -Ground Gnd H
4 - Service / UART
1 -Ground Gnd H
2 -UART_TX Transmit k
3 -UART_RX Receive j
8 - EXT1: Video RGB/YC - In, CVBS - In/Out, Audio - In/Out
Figure 2-15 SCART connector
1 -Audio R 0.5 VRMS / 1 kk
2 -Audio R 0.5 VRMS / 10 kj
3 -Audio L 0.5 VRMS / 1 kk
4 -Ground Audio Gnd H
5 -Ground Blue Gnd H
6 -Audio L 0.5 VRMS / 10 kj
7 -Video Blue/C-out 0.7 VPP / 75 jk
8 -Function Select 0 - 2 V: INT
4.5 - 7 V: EXT 16:9
9.5 - 12 V: EXT 4:3 j
9 -Ground Green Gnd H
10 -n.c.
11 -Video Green 0.7 VPP / 75 j
12 -n.c.
13 -Ground Red Gnd H
14 -Ground P50 Gnd H
15 -Video Red/C 0.7 VPP / 75 j
16 -Status/FBL 0 - 0.4 V: INT
1 - 3 V: EXT / 75 j
17 -Ground Video Gnd H
18 -Ground FBL Gnd H
19 -Video CVBS 1 VPP / 75 k
20 -Video CVBS/Y 1 VPP / 75 j
21 -Shield Gnd H
21
20
1
2
10000_001_090121.eps
090121

Technical Specs, Diversity, and Connections EN 9TPN14.1E LA 2.
2014-Feb-21
back to
div. table
2.6 Connections ( for 40" & 47"PFx4109/88)
Figure 2-16 Connection overview
Note: The following connector colour abbreviations are used
(acc. to DIN/IEC 757): Bk= Black, Bu= Blue, Gn= Green,
Gy= Grey, Rd= Red, Wh= White, Ye= Yellow.
2.6.1 Side Connections
1 - Common Interface
68p-See figure 10-3-12 jk
2 - USB2 2.0
Figure 2-17 USB (type A)
1-+5V k
2 -Data (-) jk
3 -Data (+) jk
4 -Ground Gnd H
2.6.2 Rear Connections
3 - Audio - In: Left / Right, VGA
Bu -Audio L/R in 0.5 VRMS / 10 kW jq
4 - HDMI2 : Digital Video - In, Digital Audio - In/Out
Figure 2-18 HDMI (type A) connector
1 -D2+ Data channel j
2 -Shield Gnd H
3 -D2- Data channel j
4 -D1+ Data channel j
5 -Shield Gnd H
6 -D1- Data channel j
7 -D0+ Data channel j
8 -Shield Gnd H
9 -D0- Data channel j
10 -CLK+ Data channel j
11 -Shield Gnd H
12 -CLK- Data channel j
13 -Easylink/CEC Control channel jk
14 -n.c.
15 -DDC_SCL DDC clock j
16 -DDC_SDA DDC data jk
17 -Ground Gnd H
18 -+5V j
19 -HPD Hot Plug Detect j
20 -Ground Gnd H
5 - HDMI 1: Digital Video - In, Digital Audio with ARC -
In/Out
Figure 2-19 HDMI (type A) connector
1 -D2+ Data channel j
2 -Shield Gnd H
3 -D2- Data channel j
4 -D1+ Data channel j
5 -Shield Gnd H
6 -D1- Data channel j
7 -D0+ Data channel j
CI
USB
TV ANTENNA
SERV.U
HDMI 2
HDMI 1
ARC
SCART (RGB/CVBS)
DIGITAL
AUDIO OUT AUDIO IN
DVI
19530_002_130719.eps
130719
1
2
3
5 4
6
7
8
9
10
Side ConnectorsRear Connectors
1 2 34
10000_022_090121.eps
090121
10000_017_090121.eps
090428
19 1
182
10000_017_090121.eps
090428
19 1
182

Technical Specs, Diversity, and Connections
EN 10 TPN14.1E LA2.
2014-Feb-21 back to
div. table
8-Shield Gnd H
9 -D0- Data channel j
10 -CLK+ Data channel j
11 -Shield Gnd H
12 -CLK- Data channel j
13 -Easylink/CEC Control channel jk
14 -ARC Audio Return Channel k
15 -DDC_SCL DDC clock j
16 -DDC_SDA DDC data jk
17 -Ground Gnd H
18 -+5V j
19 -HPD Hot Plug Detect j
20 -Ground Gnd H
6 - Cinch: Digital Audio - Out
BK -Coaxial 0.4 - 0.6VPP / 75 W kq
7 - Service / UART
1 -Ground Gnd H
2 -UART_TX Transmit k
3 -UART_RX Receive j
8 - Head phone (Output)
Bk -Head phone 80 - 600 / 10 mW
ot
9 - EXT1: Video RGB/YC - In, CVBS - In/Out, Audio - In/Out
Figure 2-20 SCART connector
1 -Audio R 0.5 VRMS / 1 kk
2 -Audio R 0.5 VRMS / 10 kj
3 -Audio L 0.5 VRMS / 1 kk
4 -Ground Audio Gnd H
5 -Ground Blue Gnd H
6 -Audio L 0.5 VRMS / 10 kj
7 -Video Blue/C-out 0.7 VPP / 75 jk
8 -Function Select 0 - 2 V: INT
4.5 - 7 V: EXT 16:9
9.5 - 12 V: EXT 4:3 j
9 -Ground Green Gnd H
10 -n.c.
11 -Video Green 0.7 VPP / 75 j
12 -n.c.
13 -Ground Red Gnd H
14 -Ground P50 Gnd H
15 -Video Red/C 0.7 VPP / 75 j
16 -Status/FBL 0 - 0.4 V: INT
1 - 3 V: EXT / 75 j
17 -Ground Video Gnd H
18 -Ground FBL Gnd H
19 -Video CVBS 1 VPP / 75 k
20 -Video CVBS/Y 1 VPP / 75 j
21 -Shield Gnd H
10 - TV ANTENNA - In
Signal input from an antenna, cable or satellite.
21
20
1
2
10000_001_090121.eps
090121
