Philips 21PT2110C/79 User manual

Colour television
Operating Instructions
14PT2110
21PT2110
14PT2110
21PT2110

2
Introduction
Selecting the Main Menu...................................................................................10
AutomaticTuning of Channels ...........................................................................11
ManualTuningofChannels ................................................................................11
FineTuning of Channels ....................................................................................13
Channel Swap .................................................................................................14
Channel Skip ....................................................................................................15
Favorite Channel Setting ...................................................................................16
Selecting the Colour System .............................................................................17
Adjusting theTV Picture ...................................................................................18
Smart Picture Control
......................................................................................... 19
TimerFunction..................................................................................................20
Game Function .................................................................................................22
CalendarFunction .............................................................................................24
NotebookFunction............................................................................................25
TV Installation
Basic Installation/Function
General
Specification....................................................................................................28
Recycling Directive _ To minimise harm to the environment, the batteries
supplied with theTV set do not contain mercury or nickel cadmium. If possible,
when disposing of batteries, use recycling means available to you.YourTV set uses
materials which are reusable or which can be recycled.To minimise the amount of
waste in the environment, specialist companies recover used sets for dismantling and
collection of reusable materials (contact your dealer).
Safety Information/UsefulTips...........................................................................3
Before Calling Service......................................................................................4
Hooking UpYourTV (Basic Connection).............................................................5
Use/Care of Remote Control ..............................................................................5
Connecting the Audio/Video Sockets (Playback) ................................................6
Functions of Remote Control .............................................................................7
Functions ofTV Controls...................................................................................9
