Philips 32PW9523 - annexe 1 User manual

1
Contents
Installation
Your remote control ________________________________________2
Preparation _______________________________________________3
Installation_________________________________________________3
Search for and Store TV channels
Select the menu language and country ______________________4
Automatic installation ___________________________________4
Manual installation ______________________________________5
Give name_________________________________________________6
Reshuffle the programme list _________________________________6
Select favourite TV channels __________________________________6
Install TV setup_____________________________________________7
Operation
Use of the remote control __________________________________8-9
Use of the menus
Picture menu __________________________________________10
Sound menu___________________________________________10
Features menu ______________________________________11-12
Teletext _______________________________________________13-14
Connect peripheral equipment_________________________15-18
Tips ____________________________________________________19
Index ___________________________________________________19
Lexicon ________________________________________________20
EasyLink features are based on the "one touch operation" approach. This means that
a sequence of actions are executed at the same time in both the television and the
video cassette recorder, provided both are fitted with the EasyLink function
and connected with the eurocable supplied.
English
English
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 1

2
Your remote control
Teletext
p. 14 fsolution to riddles
dmix tv/txt picture - hold
henlarge
Usubpage selection / time display
p. 9 spersonal preferences
Preduce image noise
fistrobe
Sfreeze the picture
p. 3 Bselect your choice
p. 3 Èactivate your choice
p. 10 kpicture menu
p. 10 ksound menu
p. 11 kfeatures menu
p. 8 Bswitch to standby
p. 3 Installation
Uf
yÚ
p. 8 Vvolume key
Pprogramme selection
¬temporarily switch sound off
0previous programme
p. 8 apicture
Msound
p. 13 bteletext on/off
p. 8 qpicture format
p. 8 æprogramme guide on/off
bfor future use
Menu
;
yÚ
B
87 9
54 6
0
31 2
F
yÚ
◊
h
dU
f
i
j
X
u
PfiS
s
MENU
B
b
æ
a
q
b
M
¬
0
+-V
+- P
OK
p. 17 uselection of EXT1, EXT2,
EXT3 or FRONT
p. 9 Xbilingual choice + sound info
p. 9 jcontinuous subtitles
p. 9 iinfo on screen
p. 8 ‡programme list
p. 8 Fincredible surround
on/off
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 2

3
Preparation
&Place the TV on a solid surface.
For ventilation, leave at least 5 cm free all around the TV.
To prevent any unsafe situation, do not place any objects on top of the TV.
Remove, if present, the protection foil at both front sides of the TV.
éInsert the aerial plug tightly into the aerial socket xat the back of the
TV. You can improve the picture quality by using the suppressor-aerial cable
supplied.
“Insert the mains plug in the wall socket with a mains voltage of 220V - 240V.
‘Remote control: Remove the cover of the battery compartment.
Insert the 2 batteries supplied (type R03G-1,5V).
The batteries supplied do not contain the heavy metals mercury and cadmium.
Nevertheless in many countries exhausted batteries may not be disposed of with your
household waste. Please ensure you dispose of exhausted batteries according to local
regulations.
(Switch TV on : Press the power switch Aon the front of your TV.
A green indicator and the screen light up.
If the indicator is red, press the Pkey on the remote control.
The green lamp blinks every time you press a key on the remote control.
When you switch on your set for the first time, the menu LANGUAGE automatically
appears on the screen. Alternatively the explanation appears in the different
languages. Choose your own language and press the OK key on the remote control.
Go on to page 4.
RO3 / AAA
CABLE
Installation
Select the INSTALLATION menu :
&Open the door of the remote control.
éPress fand Uat the same time.
To use the menus
&Use the Bkeys to select a menu item.
éUse the OK key to activate.
“Use the red MENU key to return or to switch menu off.
MENU
jiX
u
hd
fiS s
yÚ
B
o
pœ
π
f U
MENU
o
pœ
π
OK
Select
Activate
MENU TITLE
Subject 1
Subject 2
Subject 3
JSubject 4
Subject 5
Subject 6
JSubject 4 L M
o
pœ
π
o
pœ
π
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 3

Store TV channels
Select the menu language and country
First, you have to select your language and your country.
&Select the Menu Language and press the OK key.
éSelect your language and press the OK key.
“Select Country and press the OK key.
‘Select the country where you are now located and press the OK key.
Select Other when none of the countries applies.
You can now search for and store the TV channels in two different ways: using
automatic installation or manual installation (tuning-in channel by
channel).
•Select your choice and press the OK key.
If the TV is connected to a video recorder with the EasyLink function, the TV
automatically transfers the language and country selections to the video recorder.
The message EasyLink : Downloading ...... appears on the screen.
Automatic installation
In the Automatic Installation menu select Start and press the OK key to
activate the searching. All TV channels are searched for and stored
automatically.
If a cable system which broadcasts ACI (Automatic Channel Installation) or a
TV channel transmitting a teletext page with the frequencies and programme
names of all the TV channels which can be received, is detected, the search is
stopped and a programme list appears.
The programme list is automatically filled with all the programme numbers and
names of the TV channels transmitted.
It is possible that the cable company or the TV channel displays a broadcast selection
menu. Layout and items are defined by the cable company or the TV channel.
Make your choice with the Bkeys and press the OK key.
If the TV is connected to a video recorder with the EasyLink function, the TV
automatically transfers the stored TV channels to the video recorder.
The message EasyLink : Downloading Presets ... appears on the screen. The
programme list of the video recorder is now equal to the one of the TV.
To exit from the menu
•Press the red MENU key.
Go on to page 6.
4
MENU TITLE
Menu language
Country
Automatic Installation
JINSTALLATION
MENU TITLE
United Kingdom
....
....
JCountry
MENU TITLE
English
....
....
JMenu language
Automatic Installation
Start
Stop
TV is searching
One moment please ...
JStop K
Automatic Installation
Start
Stop
1 BBC1
2 BBC2
3 CNN
....
....
JStart K
MENU
o
pœ
π
OK
Select
Activate
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 4

5
Manual installation
Searching for and storing TV channels is done channel by channel.
You must go through every step of the Manual Installation menu.
Selection Mode is only present and lights up if the country you selected also
offers the channel option (C-channels for aerial channels, S-channels for cable
channels).
You can choose either channel or frequency mode.
&Select the TV system
•Select the country or part of the world from where you want to receive the
TV channel.
•If you are connected to a cable system, select your country.
éEnter the programme number with the digit keys.
“Search for a TV channel
The frequency or the channel number increases until a TV channel is found.
In case of poor reception, you can improve the reception by adjusting the
frequency with the Pkey.
Direct selection of a TV channel
If you know the frequency, or the C- or S-channel number, enter it directly
with the digit keys 0 to 9.
Ask for a list from your cable company or dealer, alternatively consult the
Table of frequencies on the inside backcover of this handbook.
‘ Store steps &till “
•Select Store and press the OK key.
After the new or extra TV channel has been stored, the TV automatically transfers that
(those) TV channel(s) to the video recorder provided with the EasyLink function.
The message : EasyLink : Downloading Presets ... appears on the screen. The
programme list of the video recorder is now equal to the one of the TV.
Repeat every step to store another TV channel.
To exit from the menu :
•Press the red MENU key.
Manual Installation
(Selection Mode)
System
Programme No.
Search
Store
JSystem K
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 5

6
According to your preference you can change the order of the stored TV
channels.
&Select Reshuffle in the INSTALLATION menu and press the OK key.
éSelect the programme number you want to change.
“Press the OK key.
‘Select the new number.
(Press the OK key.
Repeat the operation until all TV channels are allocated as you like.
§Press the red MENU key to return to the INSTALLATION menu.
Reshuffle the programme list
Select Favourite TV channels
It is possible to change the name stored in the memory or to assign a name
to a TV channel which has not yet been entered. A name with up to 5 letters
or numbers can be given to the programme numbers 0 to 99. For example
SUPER, BBC1,... Between 99 and 0 you can also name any peripherals that are
connected.
&Select Give Name in the INSTALLATION menu and press the OK key.
éSelect the programme number.
“Press the OK key.
‘Select the character with the EF keys.
(Select the following position with the CD keys.
§Select the following character.
èPress the OK key when finished.
!Press the red MENU key to return to the INSTALLATION menu.
A space, numbers or other special characters are located between Z and A.
Give name
After leaving the installation you can browse through the TV channels by
pressing the Pkey. Only those TV channels which are in the favourite list
will be displayed. The non-favourite TV channels can still be selected with the
digit keys.
&Select Favourite Programmes in the INSTALLATION menu and press the
OK key.
éSelect your favourite programme number.
“Select Yes or No.
‘Repeat for every TV channel you want to change into a favourite or a non-
favourite TV channel.
(Press the red MENU key to return to the INSTALLATION menu.
If the TV is connected to a video recorder with the EasyLink function, the TV
automatically transfers the reshuffled or modified TV channels to the video recorder.
The message EasyLink : Downloading Presets ... appears on the screen. The
programme list of the video recorder is equal again to the one of the TV.
INSTALLATION
Menu language
Country
Automatic Installation
Manual Installation
Give name
Reshuffle
Favourite Programmes
Connection diagrams
SETUP
JGive Name
Give Name
EXT1
EXT2
EXT3
FRONT
0
1 BBC1
2 BBC2
3 ....
4 ....
5 ....
J0
Reshuffle
EXT1
EXT2
EXT3
FRONT
0 BBC1
1 CNN
2 BBC2
3 ....
4 ....
5 ....
J1 CNN
Favourite Programmes
0 .... No
1 .... Yes
2 .... Yes
3 .... No
4 .... No
5 .... Yes
J2 .... Yes
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 6

7
Connection diagrams
See Connect Peripheral Equipment, p. 15.
Install TV Setup
&Use the Bkeys to select the menu item.
éUse the OK key to activate.
“Use the red MENU key to return or switch menu off.
CD-i / Photo CD
See Connect Peripheral Equipment, TV and a CD-i / Photo CD, p. 16.
Define Decoder/Descrambler programme numbers
If you have connected a decoder or a descrambler, see p. 15, you can define
one or more programme numbers as decoder programme numbers.
•Press the CD keys to select Off, EXT1 or EXT2, the euroconnector where
you connected your decoder.
•Select Off if you do not want the selected programme number being activated
as a decoder programme number.
Select EXT2 when the decoder is connected to your EasyLink video recorder.
When selecting the decoder, the message EasyLink: Downloading Presets....
appears on the screen.
Picture Tilt
•Select Picture Tilt with the EF keys.
•Keep the CD keys pressed to adjust the rotation of the picture.
Information Line
After the selection of a TV programme or after pressing the ikey on the
remote control, a TV channel which broadcasts teletext may transmit the name
of the TV channel or the programme name or another message which appears
briefly in the information line on the screen.
When selected Off, the information line will only appear after pressing the i
key, and not after the selection of a TV channel.
Auto Format
Selecting Auto Format Yes, the screen will automatically be filled as much as
possible with the picture in case of no PALplus transmission or when TV
programmes are not carrying special signals detecting the correct screen
format.
With the qkey on the remote control you can still select other picture
formats (see p. 8).
Installation
Select Installation and press the OK key to return immediately to the
INSTALLATION menu.
To exit from the menu
‘Keep the red MENU key pressed.
INSTALLATION
Menu Language
Country
Automatic Installation
Manual Installation
Give Name
Reshuffle
Favourite Programmes
Connection diagrams
SETUP
JSETUP
SETUP
CD-i/Photo CD
Decoder/Descrambler
Picture Tilt
Information Line
Auto Format Yes/No
INSTALLATION
JCD-i/Photo CD
DECODER/DESCRAMBLER
Programme
Decoder Status
JProgramme
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 7

8
Use of the remote control
B Standby
The TV set is switched off and the red indicator
lights up.
To switch the TV on again, press Por the
digit keys.
Your TV consumes energy in the standby mode.
Energy consumption contributes to air and water
pollution. We advise to switch off your TV overnight
instead of leaving it on standby. You save energy. VVolume
The volume is adjusted. If you want to store the
volume adjustment in the memory, see the
Features menu, Store PP, p. 11 to store the same
volume adjustment for all the stored TV channels.
PProgramme selection
To browse through the TV channels activated in
the Favourite Programme menu. See p. 6.
0 / 9 Digit keys
To select a TV channel.
For a two digit programme number, enter the
second digit within 2 seconds.
¬ Mute key
Temporarily interrupt the sound or restore it.
0 Previous programme
The previously selected TV channel is displayed.
The ◊ indication has a video recorder
function.
‡kProgramme list
To select the programme list.
Select the desired TV channel with the Eor
Fkeys and press OK.
FkIncredible Surround
In MONO sound mode, this feature, when
switched on, enables you to hear a spatial effect
of sound.
In STEREO sound mode, when Incredible
Surround On is selected, it seems as though
the loudspeakers are spread further apart from
one another.
qPicture format
Press this key repeatedly to select another picture
format: 4:3, Movie Expand 14:9, Movie Expand
16:9 with or without subtitling, Wide Screen,
Automatic (in case Auto Format Yes has been
selected in the SETUP menu) or Super Zoom,
When in Movie Expand 14:9 or 16:9 picture
format you can make subtitles visible with the E
or Fkeys.
When the broadcaster transmits PALplus signals,
the Movie Expand 16:9 picture format is selected
automatically.
Sometimes video recorders or TV programmes
carry special signals which will automatically
switch the TV to the correct screen format.
Selecting Auto format, the screen will be filled as
much as possible with the picture in case of no
PALplus transmission or when TV programmes
are not carrying special signals detecting the
correct screen format.
bFor future use
æProgramme Guide
TV channels which broadcast teletext also
transmit a page with the programme guide of the
day. For each TV channel you can store the
programme guide page which can be selected
directly with the ækey.
• Press bto switch on teletext and select the
proper programme guide page.
• Press æfor 2 seconds to store the selected
page.
• Press bagain to switch off teletext.
Every time you press the ækey, the programme
guide page of the selected TV channel will be
available. Press EF or the Pkey to run
through the previous or the following pages and
subpages. Press the bkey again to switch the
page off.
For every TV channel the programme guide page
should be stored separately.
a M Smart Controls keys
To select predefined picture and sound settings.
Smart Picture (akey)
Each time it is pressed, a different picture setting
is selected, corresponding with a specific
predefined setting of Contrast, Colour,
Sharpness and Dynamic contrast.
Smart Sound (Mkey)
Each time it is pressed a different sound setting
is selected, corresponding with a specific
predefined setting of Treble, Bass and Loudness.
Personal refers to the personal preference
setting of picture and sound which you have
stored with Store PP in the Features menu,
p. 11.
The smart picture and sound settings are set to
Manual until the personal adjustments are
stored.
123
456
789
0
MENU
jiX
u
hUdf
fi
s
yÚ
o
®
‡
Ò
†
b
OK
pœ
π
◊
‡
®
¬V
-+
P
-+
0
q
a
12
a
M
B
‡
F
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 8

9
MENU
hdf
fiS
s
yÚ
B
o
pœ
π
®
‡
OK
P
-+
◊
V
-+
0
¬
X
ui
U
j
MENU
jiX
u
hUdf
yÚ
B
o
pœ
π
123
456
789
0
®
‡
Ò
†
π
Fq
b
OK
P
-+
◊
V
-+
SMART CONTROLS
a
M12
a
‡
®
0
¬
fiS s
uSelect peripherals
Press this key repeatedly to select
EXT1, EXT2, EXT3 or FRONT, according to
where you connected your peripherals
(see p. 17).
XBilingual choice and
sound mode selection
Press this key
• to switch from Stereo to Mono sound, in
case of stereo transmission, or from Digital
Sound to Digital Sound available, in case of
digital transmission;
• to choose between language Y(Dual Y) or
language Z(Dual Z), in case of bilingual
transmission.
The setting is stored for each TV channel
separately.
U Time display
The time, downloaded from the TV channel
(with teletext) stored on programme number 1
or under the lowest favourite programme
number, is displayed on the screen.
This function is not available when continuous
subtitles have been switched on.
sPersonal Preferences
Restore picture and sound settings, stored in the
features menu (see p. 11).
PDyn. Noise Reduction
To reduce the image noise and improve picture
quality when receiving weak signals.
Press this key to select Minimum,
Medium (optimum picture quality for normal
strength signal), Maximum (for poor picture
quality) or Off.
DNR can be individually set for each TV channel.
j Continuous subtitles
TV channels with teletext often transmit certain
programmes with subtitling.
Switch on teletext and select the proper subtitle
page from the index.
Press jto store the subtitle page.
Switch off teletext.
Every time a programme of the selected TV
channel is subtitled, the subtitling will be available
for that TV channel.
Press jto switch the subtitles On of Off.
When switched on and only the subtitle symbol
appears, there are no subtitles available for that
programme.
iScreen information
Press for 5 seconds to activate/de-activate
extended or reduced display of TV channel and
programme information on the screen.
Press briefly to display information about the
selected TV channel and programme, the sound
reception, the selected DNR setting and picture
format and the remaining time set with the
sleeptimer.
fiStrobe
Press this key to reproduce the picture image by
image.
Press the fikey to have a faster speed.
Press fiagain to switch off the strobe function.
S Freeze
To activate/de-activate the frozen picture.
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 9

10
Use of the menus
&Press the red, green or yellow colour key to display/cancel the PICTURE,
SOUND or FEATURES menu .
éUse the Bkeys to select the menu item.
“Use the OK key to activate.
‘Press the same colour key to return or to switch menu off.
Picture menu
When you are watching a TV channel in the NTSC-system, or if a NTSC peripheral
is connected to one of the euroconnectors, the option Hue also appears and can be
adjusted.
Sharpness
You can adjust the Sharpness for each TV channel separately.
Tint
•Select the colour temperature: Normal, Warm or Cool.
Digital Scan (Line Flicker Reduction)
In certain circumstances while watching TV programmes it may be preferred
to switch off the digital scan line flicker reduction.
•Press the CD keys to select On or Off.
Dynamic Contrast
To make the contrast between darker and brighter picture parts more
noticeable, select the Med setting.
In certain circumstances it may be preferred to select Min or Off.
•Store the modified adjustments for Contrast, Brightness, Colour, Tint, Digital
Scan and Dynamic Contrast for all TV channels with Store PP in the
FEATURES menu.
Sound menu
Switch Loudness on or off
When Loudness On is selected, the low and high frequencies are amplified so
that the natural balance is restored when listening at a low volume.
The selected setting for Loudness is stored for all TV channels.
Headphone
See Connect Peripheral Equipment, p. 16 for the connection of the headphone.
•Select Dual to choose between the dubbed or original language when the TV
channel broadcasts in 2 languages.
•Store the modified adjustments for Volume, Balance, Treble and Bass for all TV
channels with Store PP in the FEATURES menu.
To exit from the menus
•Press the corresponding red, green or yellow colour key.
MENU
o
pœ
π
OK
Select adjustments
Activate
Picture menu
Sound menu
Features menu
Contrast
Brightness
Colour
Sharpness
Tint
Digital Scan
Dynamic Contrast
JContrast L M
SOUND
Volume
Balance
Treble
Bass
Loudness
Headphone
JVolume L M
HEADPHONE
Volume
Dual
JVolume L M
Store PP
Sleeptimer
Message
Child Lock
Animation demo
JFEATURES
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 10

11
Features menu
&Press the yellow colour key to display/cancel the FEATURES menu.
éUse the Bkeys to select the menu item.
“Use the OK key to activate.
Store PP
The adjustments of Contrast, Brightness, Colour, Tint, Digital Scan and
Dynamic Contrast made in the picture menu and the adjustments of Volume,
Balance, Treble, Bass and Loudness made in the sound menu can be stored in
memory for all the TV channels.
Sleeptimer
With the sleeptimer you can set a time period after which the TV should
switch itself off to standby.
The counter runs from Off up to 180 min. or from 180 min. down to Off.
One minute before the TV is set to go to standby, the remaining minute
appears on screen. You can always switch off your set earlier or change the set
time.
Child Lock
If the child lock is on, the TV can only be switched on with the remote control.
The - and + keys on top of the TV cannot be used to select a TV channel. In
this way you can prevent unauthorised use of your TV.
If the message Child Lock On appears, the child lock must be switched off
before you can use the - and + keys on the TV to select a TV channel.
Animation demo
Selecting this menu item starts a continuous loop of an animation introducing
your TV. This animation has no operational function.
Press the OK key to stop the animation.
MENU
o
pœ
π
OK
Select adjustments
Activate
Picture menu
Sound menu
Features menu
Store PP
Sleeptimer
Message
Child Lock
Animation demo
JFEATURES
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 11

12
Message
With this function you can enter a personal message on 2 lines which will be
displayed automatically when the set is switched on from standby.
For example: I'll be late this evening. Don't wait for dinner.
Change
•Select with the EF keys the letter or number you want to enter.
•Select with the Dkey the next position.
•Press the OK key when you have entered the complete message.
Clear
•Press the OK key to remove a previous message.
Type
•Press the CD keys to select the way the message will be displayed : Wipe,
Slide, Fall or Fade.
The Fade display is a randomly selection of the three other display types.
Run
•Press the CD keys to select the display frequency : Continuous, Once or
No.
Display message
•Switch the TV to standby.
The message appears on the screen when the TV is switched on again.
If you selected Once, the message will disappear from the screen after
30 seconds.
If you selected Continuous, the message will appear on the screen until the
display frequency is switched off in the Message menu.
The message does NOT appear when Continuous Subtitles have been switched
On. See p. 9.
FEATURES
Store PP
Sleeptimer
Message
Child Lock
Animation demo
JMessage
MESSAGE
Message ...........................
...................................
Change
Clear
Type
Run
JChange
Should your remote control be lost or broken you can still change some of
the basic picture and sound settings with the keys in front of the TV.
•Press the MENU key repeatedly to select Volume, Brightness, Colour,
Contrast, Treble or Bass.
•Press the - or + key to regulate the selected adjustment.
When the menu adjustment is not displayed, the - and + keys enable you
to select the TV channels.
The selected adjustment automatically switches off when after 10 sec. no action has
been executed.
The keys in front of the TV
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 12

13
About the Easy Text system
The Easy Text system considerably reduces the waiting time (on condition the
teletext broadcast of the particular TV channel is switched on for at least half a
minute) by :
•adirect selection of previous and following pages which are in transmission
and of the pages referred to in the options line
• a habit watcher list: frequently used pages are put in a list of preferred
pages, so that they are immediately available afterwards
• the precapturing of the page numbers referred to in the displayed page
• the precapturing of all the subpages.
Switch Teletext on and off
•Press bto switch on or off the teletext.
The main index page appears on the screen together with two information lines
at the top and one option line at the bottom of the screen.
Select a Teletext page
With the digit keys
•Enter the desired page number with the digit keys.
The page counter seeks the page or the page appears immediately when the
page number has been stored in the memory.
A message appears when you have entered a non existent or an incorrect page
number. Page numbers beginning with 0 or 9 do not exist. Choose another number.
With the option line
•Select with the colour keys, corresponding to the coloured options at the
bottom of the screen, the desired subject.
Quickly run through the teletext pages
•Press EF or the Pkey to run through the previous or the following
pages.
Select the previously selected txt page
•Press the 0key.
Teletext
Most TV channels broadcast information via teletext. Each channel which
broadcasts teletext transmits a page with information on how to use its
teletext system. Look for the teletext page with the main index (usually p. 100).
Depending on the TV channel, teletext is transmitted in different systems.
The colours used in the options line correspond with the colour keys of your
remote control.
MENU
jX
u
hUdf
fiS
s
yÚ
B
123
456
789
0
®
‡
Ò
†
π
F
◊
V
-+
SMART CONTROLS
a
M
‡
®
¬
ii
o
pœ
π
q
P
-+
OK
OK
bb
0
P
-+
0
b
æ
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 13

14
MENU
X
u
fiS
s
yÚ
B
123
456
789
0
®
‡
Ò
†
π
F
◊
V
-+
SMART CONTROLS
a
M
‡
®
0
¬
o
pœ
π
q
P
-+
OK
b
æ
f
d
b
i
h
U
j
hUdf
b
i
Select the index teletext page
•Press the white colour key to display the main index (usually p.100).
Only for T.O.P teletext broadcasts :
T.O.P orders the pages in categories and adds other possibilities of enhancing
ease of use.
•Press i. A T.O.P. overview of the teletext subjects available appears.
Not all TV channels broadcast T.O.P. teletext. When the teletext system
is not T.O.P. teletext, a message appears at the top of the screen.
•Select with the Bkeys the desired subject and press the OK key.
Select subpages
When a selected teletext page consists of different subpages, one of the
subpages appears on the screen.
The coloured number in the first information line refers to the displayed
subpage.
The other subpages can be selected in 2 ways :
1. With the CD keys.
The other subpage numbers appear in white as soon as the transmission has
found them. They are stored in the memory so that they are available while the
teletext page is on screen.
•Select with the CD keys the previous or the following subpage.
2. With the Ukey.
Enter the subpage number yourself.
•Press U. Enter the desired subpage with the digit keys : e.g. 3 for the third
page of seven subpages.
The TV searches for the selected subpage.
Automatically rotating subpages:
•Press Uagain to cancel the entered digit for the subpage.
Now the subpages rotate automatically.
•Press Uagain to select the subpages with the CD keys again.
Special teletext functions
Mix / Interrupt
•Press dto overlay the teletext page on the TV programme.
•Press dagain to de-activate the screen overlay.
The display bindicates that you are still in the teletext mode.
You can select a page number. When the page has been found, the page
number appears on the screen.
•Press dagain to display the teletext page.
Enlarge
•Press hrepeatedly to display the upper part, the lower part and then to
return to the normal page size. When the upper part is displayed, you can
scroll the text line per line by using the EF keys.
Reveal
•Press fto reveal/conceal the hidden informations, such as solutions to
riddles and puzzles.
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 14

15
There is a wide range of audio and video equipment that can be connected
to your TV. The following connection diagrams show you how to connect it.
See also the menu item Connection diagrams in the INSTALLATION menu
where the different connection possibilities are shown. Each time a menu item
is selected a graphic is shown of the connection. Those graphics have no
operational function.
Video recorder
•Connect the aerial cables 1, 2and, to obtain a better picture quality,
eurocable 3as shown opposite.
If your video recorder is provided with the EasyLink function, the eurocable supplied
with it, should be connected to EXTERNAL 2 to benefit from the EasyLink functionality.
You have to do the following if you do not connect the eurocable 3.
Search for and store the test signal of the video recorder
•Unplug the aerial cable 1from the aerial socket xof your video recorder.
•Switch on your TV and put the video recorder on the test signal. (See the
handbook for your video recorder.)
•Search for the test signal of your video recorder in the same way as you
searched for and stored the TV signals. See Installation, Searching for and
storing TV channels, Manual Installation, p. 5.
•Store the test signal either under programme number 0 or between 90 and 99.
•Replace the aerial cable in the aerial socket xof your video recorder after
you have stored the test signal.
Decoder and video recorder
•Connect a eurocable 4to your decoder and to the special euroconnector of
your video recorder. See also the video recorder handbook.
See Define Decoder/Descrambler prog. numbers, p. 7.
You can also connect your decoder directly to EXTERNAL 1 or 2with a
eurocable .
Video recorder and other peripherals
(except CD-i/Photo CD)
•Connect the aerial cables 1, 2and 3as shown opposite. Better picture
quality can be obtained if you also connect eurocable 5to EXTERNAL 2 and a
eurocable 4to EXTERNAL 1 or 3.
•Look for the test signal of your peripheral in the same way as you do for a
video recorder.
When a video recorder is connected to EXTERNAL 1 you can only record a
programme from your TV.
Only when a video recorder is connected to EXTERNAL 2 it is possible to
record a programme from your TV as well as from other connected
equipment. See Record with your video recorder, p. 18.
Connect Peripheral Equipment
CABLE
2
EXTERNAL
1
2
3
4
CABLE
1
2
5
23
4
1
EXTERNAL
Amplifier
CD-i/Photo CD
Decoder/Descrambler
VCR1
VCR2
Antenna
JCONNECTION DIAGRAMS
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 15

16
Camera and camcorder
•Connect your camera or camcorder at the front side of your TV.
•Connect the equipment to VIDEO 2and AUDIO L 1for mono equipment.
•Press the Xkey under the door of the remote control repeatedly to select
the sound coming from one or both loudspeakers of your TV.
•For stereo equipment, also connect AUDIO R 1.
S-VHS quality with a S-VHS camcorder is obtained by connecting the S-VHS
cables with the S-VIDEO input 3 and AUDIO inputs 1.
Other equipments
Connect the eurocable 1to EXTERNAL 1 as shown opposite.
Only for CD-i and Photo CD :
•Press fand Uat the same time.
•Select CD-i/Photo CD Present in the Setup menu of the INSTALLATION
menu.
This offers you optimum picture quality for your CD-i or Photo CD.
•Keep the red MENU key pressed to switch off all menus.
Audio equipment / Amplifier
•Connect the audio cables to the audio input of your audio equipment and to
AUDIO L and Rat the back of your TV.
You can listen to your TV sound via your audio equipment.
Headphone
•Insert the plug into the headphone socket Lat the front side of the TV.
•Press ¬on the remote control to switch off the internal loudspeakers of the
TV.
The headphone impedance must be between 8 and 4000 Ohm. The headphone
socket has a 3.5 mm jack.
In the SOUND menu select Headphone to adjust the headphone volume and
to select dubbed or original language (when the TV channel broadcasts in two
languages) for your headphone sound. See p. 10.
If you want to connect more equipment to your TV, consult your dealer.
AUDIO
n
1
1
EXTERNAL
S-VIDEO
VIDEO
AUDIO
L
R
21 3
INSTALLATION
Menu language
Country
Automatic Installation
Manual Installation
Give name
Reshuffle
Favourite programmes
Connection diagrams
SETUP
JSETUP
SETUP
CD-i/Photo CD
Decoder/Descrambler
Picture Tilt
Information Line
Auto Format Yes/No
INSTALLATION
JCD-i/Photo CD
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 16

17
MENU
j
hdf
fiS
s
yÚ
B
o
pœ
π
®OK
◊
V
-+
¬
X
u
ui
U
To select connected equipment
If the TV is connected to a video recorder with the EasyLink function, in some cases
the TV will be switched on, even when the TV was in standby. (E.g. playback tape,...)
This is not possible when Child Lock On is selected.
Equipment connected with an aerial cable only :
•Select the programme number under which you have stored the test signal
with the digit keys.
Equipment connected to a euroconnector or to the front side of
the TV
•Press the ukey repeatedly to select EXT1, EXT2, EXT3 or FRONT, according
to where you connected your equipment at the back or the front side of your
TV.
Remark : Most equipment (decoder, video recorder) carries this switching itself.
Do you want to watch TV channels again ?
•Enter the programme number of the TV channel which you want to watch with
the digit keys.
Most of the video equipment from our range of products can be operated
with the remote control of the TV.
Video recorder keys
Press simultaneously on the VCR key and:
πkfor play,
®kfor record,
Òkfor rewind,
†kfor fast forward,
‡kfor stop,
Fkfor programming (on certain models),
◊for selecting 1- or 2- digit programme numbers from the
video recorder tuner,
Pfor fast programme selection from the video recorder tuner,
0to 9to select a programme number from your video recorder
tuner,
Bto switch the video recorder to standby
These keys function with video recorders which use the RC5 signalling standard.
If your video recorder has the EasyLink function the ‡Oand ®M keys for
record and stop can be operated in the TV mode.
123
456
789
0
MENU
jiX
u
hUdf
fi
s
yÚ
o
b
OK
pœ
π
SMART CONTROLS
¬V
-+
0
q
B
◊
b
æ
VCR
π
®
Ò
†
‡
F
‡
®
π
®
Ò
†
‡
F
‡
®
B
◊
P
-+
P
-
+
a
M
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 17

18
Record with your video recorder without EasyLink
To record S-VHS quality, connect a S-VHS peripheral directly to the video
recorder.
1. Record a TV programme
using only an aerial cable
•Select the programme number on your video recorder.
•Set your video recorder to record.
(See the handbook for your video recorder.)
Switching programme numbers on your TV does not disturb recording !
Record with a video recorder with EasyLink
If you have connected a S-VHS video recorder provided with the EasyLink function,
you can record S-VHS-quality from a S-VHS peripheral connected to the front side of
the TV. (E.g. from a S-VHS camcorder.)
In TV mode it is possible to start a direct recording of the programme which is being
displayed on the TV screen.
•Press at the same time the VCR key on the left side and the ®M key of the remote
control.
The video recorder switches on when it was in standby and a message of what is
being recorded appears at the bottom of the screen.
The video recorder starts recording the programme that appears on the screen.
•Press the ‡a key to stop the recording.
When recording a programme from a peripheral connected to EXTERNAL 1 or
FRONT, you can not select another TV programme on the screen.
To watch TV programmes again, press the programme number you want to select
twice . Then the recording is stopped and your video recorder switches to standby.
If you switch to standby during recording a programme from a peripheral connected
to EXTERNAL 1 or FRONT, the blinking red lamp on the front of your TV indicates
that you are still recording. The blinking stops after the recording is finished.
using a eurocable connected to the
euroconnector EXTERNAL 2
With a video recorder connected to EXTERNAL 2 it is
possible to record a programme from your TV as
well as from other connected equipment.
•Select the programme number or external
input on the TV.
•Select the right external on your video
recorder.
•Set your video recorder to record.
You record what you are watching on the
screen.
Do not switch programme numbers or do not
switch off your TV when you are recording !
using a eurocable connected to the
euroconnector EXTERNAL 1
With a video recorder connected to EXTERNAL 1 you
can only record a TV channel.
•Select the programme number on the TV.
•Set your video recorder to record.
Switching to a programme from a connected
peripheral equipment does not disturb
recording .
2. Record a programme on your video recorder connected to
EXTERNAL 2 from Audio/Video equipment connected to EXTERNAL 1,
EXTERNAL 3 or to the front side
•Switch on the equipment.
•Select the right external on your video recorder.
•Set your video recorder to record.
You record what you are watching on the screen.
Do not switch programme numbers or do not switch off your TV when you are
recording !
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 18

19
Care of the screen
Clean the TV with a slightly damp soft
cloth. Do not use abrasive solvent as it can
damage the TV screen.
Poor Picture
Have you selected the correct TV system?
Is your TV or house aerial located too
close to loudspeakers, non-earthed audio
equipment or neon lights, etc. ?
Mountains or high buildings can cause
double pictures or ghost images.
Sometimes you can improve the picture
quality by changing the direction of the
outside aerial.
Is the picture or teletext unrecognisable?
Check if you have entered the correct
frequency. See Installation, p. 5.
Are brightness and contrast out of
adjustment ? Press the skey.
Sometimes poor picture quality is possible
when having activated a S-VHS camera or
camcorder connected to the front side of
your TV and another peripheral is
connected to EXT1 or EXT2 at the same
time. In this case switch off one of the
other peripherals.
No picture
Is the aerial connected properly ? Are the
plugs tightly connected in the aerial socket?
Is the aerial cable in good condition and
does it have suitable plugs ? Are the
connection facilities to a possible second
TV in good condition ? If in doubt, consult
your dealer.
Remote control
If your TV no longer responds to the
remote control, the batteries may be
dead.
You can still use the MENU keys in front of
your TV.
Menu
Have you selected the wrong menu ? Press
the same key again to exit from the menu.
No solution
Switch your TV off and then on again.
Never attempt to repair a defective
TV yourself.
Check with your dealer or call a TV
technician.
End of life directives
Your new TV contains materials which can
be recycled and reused.
At the end of life specialised companies
can dismantle the discarded TV to
concentrate the reusable materials and to
minimise the amount of materials to be
disposed of.
Please ensure you dispose of your old TV
according to local regulations.
How to dispose of dead batteries ?
The batteries supplied do not contain the
heavy metals mercury and cadmium.
Nevertheless in many countries dead
batteries may not be disposed of with your
household waste. Please ensure you dispose
of dead batteries according to local
regulations.
Tips
aautomatic installation, 4
ACI, 4
bbilingual broadcast, 9
ccamcorder, 16
CD-i / Photo CD, 16
child lock, 11
clock, 9
country, 4
ddecoder/descrambler, 7
digital, 9
digital scan, 10
DNR, 9
dynamic contrast, 10
eeasy text, 13
eurocable, 15
ffavourite programmes, 6
freeze, 9
frequency, 5
ggive name, 6
hheadphone, 16
hue, 10
iIncredible Surround, 8
info on screen, 9
information line, 7
interrupt the sound, 8
llanguage, 4
loudness, 10
mmanual installation, 5
menu language, 4
message, 12
ppersonal preferences, 9
picture adjustments, 10
picture format, 8
programme guide, 8
programme list, 8
rrecording, 18
reshuffle, 6
ssearch for TV channels, 5
setup, 7
sleeptimer, 11
smart picture and sound, 8
sound adjustments, 10
sound mode, 9
stereo, 9
store PP, 11
store TV channels, 4
strobe, 9
subpages teletext, 14
subtitles, 9
S-VHS, 18
switch TV on, 3
tteletext, 13
vvideo recorder, 15
volume, 8
Index
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 19

20
Lexicon
100 Hz
100 Hertz provides a superior solution to
the problem of picture flicker which is
particularly noticeable with larger screen
sizes. In a conventional TV, the picture
area is scanned 50 times a second (50
Hertz) – a frequency which is still
detectable by the human eye in the form
of a flickering picture. In 100 Hertz sets,
the picture area is scanned at a rate of 100
times per second (100 Hertz). At this
frequency, the eye cannot detect flicker,
resulting in a clearer picture which is more
relaxing to the eye.
Automatic Channel Installation (ACI)
Automatically installs all TV channels in the
same order as offered by your cable
company, provided of course that the data
is transmitted. It also automatically
includes programme number and
programme name.
With ACI, channel installation is fully
automatic, simple and fast.
Child Lock
Feature to prevent children from viewing
unwanted channels.
Digital Scan
If you look at a television screen you will
see small imperfections in the picture
caused by line vibration. Digital Scan (an
internal process) removes interline flicker.
When combined with 100 Hz, you will see
a totally stable image.
DNR
Digital Noise Reduction.
By encoding signals digitally in 100 Hz sets
with Digital Scan it is possible to clean up
picture noise. This is especially beneficial in
poor signal areas and when viewing poor
quality video tapes.
Easy Link
Digital ‘intelligent’ ESI bus-system between
audio components in HiFi systems and
between TV and VCR. (Scart connection
required). Turns source selection and
control into a one-button operation.
Easy Text
Teletext memory that automatically
memorises Teletext pages and gives you
instant access to them.
Euroconnector
A 21-pins connector system enabling you
to simply connect various types of
audio/video and computer equipment.
Incredible Surround
Feature to enrich the sound performance
of your TV set or audio equipment. It
enhances the stereo effect by giving the
impression that the speakers are
positioned much wider apart than they
actually are.
Menu
On-screen display of functions and
facilities in a well-organised survey, which
you can select using your remote control.
NTSC
The broadcasting system used in the USA,
Japan and parts of South America and
Southeast-Asia.
Smart Picture and Sound Controls
Keys on the remote control to select
predefined picture and sound settings.
Sleeptimer
Function with which you can set a time
period after which the TV should switch
itself off to standby.
Picture Freeze
TV mode which allows you to “freeze” a
certain image in order to study a specific
detail at ease, e.g. to make notes of certain
programme information like phone
numbers.
Teletext
See also Easy Text
WST: World Standard Teletext.
FLOF: Full Level one Features. System
applied by the BBC, RVE.... that provides a
fast access to the teletext pages.
TOP: Table of (Teletext) Pages. German
system for an easy access to the teletext
pages.
Tint (or Hue in NTSC)
TV-function to modify the general colour
balance between cool and warm and to
adjust it according to your personal
preference.
3104 305 4775.5.gb 28-05-1999 10:49 Pagina 20
