Philips FJ3.0E User manual

Published by EL 0671 BG CD Customer Service Printed in the Netherlands Subject to modification EN 3122 785 15992
©
Copyright 2006 Philips Consumer Electronics B.V. Eindhoven, The Netherlands.
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, or otherwise without the prior permission of Philips.
Colour Television Chassis
FJ3.0E
LA
ME6
ME6
TOP B
TOP B
TOP A
TOP A
TOP A
TOP A
G_15990_000.eps
021106
STEP 2k6
STEP 2k6
Contents Page Contents Page
1. Technical Specifications, Connections, and Chassis
Overview 2
2. Safety Instructions, Warnings, and Notes 9
3. Directions for Use 11
4. Mechanical Instructions 12
5. Service Modes, Error Codes, and Fault Finding 28
6. Block Diagrams, Test Point Overviews, and
Waveforms
Wiring Diagram 32” STEP (ME6) 57
Wiring Diagram 32” TOP B 58
Wiring Diagram 37” TOP B 59
Wiring Diagram 42” TOP A 60
Wiring Diagram 42” TOP B 61
Wiring Diagram 42” STEP 2k6 62
Block Diagram Supply 32” LCD 63
Block Diagram Display/Platform Supply 37” LCD64
Block Diagram Platform Supply 42” 65
Block Diagram Display Supply 295V (Sanken) 66
Block Diagram Display Supply 24V (Sanken) 66
Block Diagram Video 67
Block Diagram Audio 68
Block Diagram Control & Clock Signals 69
Test Point Overview SSB (Bottom Side) 70-75
I2C IC’s Overview 76
Supply Lines Overview 77
7. Circuit Diagrams and PWB Layouts Drawing PWB
Power Supply 32”: Mains Filter & Standby (A1) 78 81-84
Power Supply 32”: Supply (A2) 79 81-84
Power Supply 32”: Connections (A3) 80 81-84
Display Supply 37”: Part 1 (A1) 85 90-95
Display Supply 37”: Part 2 (A2) 86 90-95
Platform Supply 37”: Aux Supply (A3) 87 90-95
Platform Supply 37”: Standby Supply (A4) 88 90-95
Platform Supply 37”: 25W Supply (A5) 89 90-95
Ambi Light (AL1) 96 99
Ambi Light (AL2) 97 99
Ambi Light (AL3) 98 99
Platform Supply 42”: Aux Supply (AP1) 100 108-114
Platform Supply 42”: Stby Supply (AP2) 101 108-114
Platform Supply 42”: Filter (AP3) 102 108-114
Platform Supply 42”: Audio Left/Right (AP4) 103 108-114
Platform Supply 42”: Audio Prot / Mute (AP5) 104 108-114
Platform Supply 42”: Audio Subwoofer (AP6) 105 108-114
Platform Supply 42”: Audio Centre (AP7) 106 108-114
Platform Supply 42”: SRP List 107 108-114
Small Signal Board (B1-B16) 115-178 178-189
External I/O Panel: Externals A (BE1) 190 192
External I/O Panel: Externals B (BE1) 191 192
Side I/O Panel (ME6) (D) 193 194
Side I/O Panel (32PF9731D/10) (D) 195 196
Side I/O Panel (TOP 37”& 42”) (D) 197 198
Control Panel (ME6 32”) (E) 201 201
Control Panel (TOP) (E) 202 202
Front IR / LED Panel (ME6) (J) 203 203
LED Panel (TOP) (J) 204 205
Standby & Audio Panel: Connections (SA1) 206 211-213
Standby & Audio Panel: Standby (SA2) 207 211-213
Standby & Audio Panel: Supply (SA3) 208 211-213
Standby & Audio Panel: Audio Left / Right (SA4) 209 211-213
Standby & Audio Panel: Prot. / Mute (SA5) 210 211-213
8. Alignments 215
9. Circuit Descriptions, Abbreviation List, and IC Data
Sheets 221
Abbreviation List 230
IC Data Sheets 233
10. Spare Parts List 247
11. Revision List 269

Technical Specifications, Connections, and Chassis Overview
EN 2 FJ3.0E LA1.
1. Technical Specifications, Connections, and Chassis Overview
Index of this chapter:
1.1 Technical Specifications
1.2 Connections
1.3 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
1.1 Technical Specifications
1.1.1 Vision
Display type : LCD
Screen size : 32” (82 cm), 16:9
: 37” (94 cm), 16:9
: 42” (107 cm), 16:9
Resolution (HxV pixels) : 32”: 1366(*3)x768
: 37”: 1920(*3)x1080
: 42”: 1366(*3)x768
Light output (cd/m2) : 550
Viewing angle (HxV degrees) : 176
Tuning system : PLL
Colour systems : PAL B/G, D/K, I
: SECAM B/G, D/K, L/L’
Supported computer formats (60 Hz) : 640x480
: 800x600
: 1024x768
Supported video formats : 640x480i - 1fH
: 720x576i - 1fH
: 640x480p - 2fH
: 720x576p - 2fH
: 1920x1080i - 2fH
: 1280x720p - 3fH
AV (playback only) : NTSC, PAL, SECAM
Tuner bands : UHF, VHF, S, Hyper
1.1.2 Sound
Sound systems : AV stereo,
: 2CS B/G, D/K
: NIC. B/G, D/K, I, L/L’
Maximum power (WRMS) : 2 x 15
: 2 x 12 + 1 x 24
(42PF9831/69)
1.1.3 Multimedia
Supported digital media
(only in sets equipped with memory
card slot) : Compact Flash I & II
: Memory Stick
: Microdrive
:SDCard
: Multi Media Card
: Smart Media Card
Supported file formats : JPEG
:MP3
: Slideshow (.alb)
: DivX 3.11 and 5 (only
32PF9731D/10, 37”
and 42”)
: MPEG1, 2
: MPEG4 (only
32PF9731D/10, 37”
and 42”)
: XviD (only
32PF9731D/10, 37”
and 42”)
USB input : USB2.0
Multimedia connections : 7-in-1 Memory Card
Reader (only 37” and
some 42” sets)
Multimedia connections
(37PF9731D/10 and
42PF9731D/10) : Ethernet-UTP5
:UPnP
: WiFi (opt. ethernet-
bridge)
1.1.4 Miscellaneous
Power supply:
- Mains voltage (VAC) : 220 - 240
- Mains frequency (Hz) : 50 / 60
Ambient conditions:
- Temperature range (°C) : +5 to +40
- Maximum humidity : 90% R.H.
Power consumption (values are indicative)
- Normal operation (W) : 32”: 163
: 37”: 185
: 42”: 248
- Standby (W) : < 2
Dimensions (WxHxD cm)
- 32PF9531/10 and 32PF9631D/10 : 935x516x120
- 32PF9731D/10 : 869x625x114
- 37PF9731/69 and 37PF9731D/10 : 991x707x114
- 42PF9641D/10 : t.b.f.
- 42PF9731D/10 : 1095x764x114
- 42PF9831/69 : 1279x872x114
Weight (kg)
- 32PF9531/10 and 32PF9631D/10 : 18.7
- 32PF9731D/10 : 20.4
- 37PF9731/69 and 37PF9731D/10 : 26
- 42PF9641D/10 : 31
- 42PF9731D/10 : 35
- 42PF9831/69 : 38

Technical Specifications, Connections, and Chassis Overview EN 3FJ3.0E LA 1.
1.2 Connections
Figure 1-1 Connection overview 32PF9531/10
Figure 1-2 Connection overview 32PF9631D/10
Figure 1-3 Connection overview 32PF9731D/10
G_15990_086.eps
190706
G_15990_087.eps
190706
G_15990_181.eps
190706

Technical Specifications, Connections, and Chassis Overview
EN 4 FJ3.0E LA1.
Figure 1-4 Connection overview 37PF9731/69 & 42PF9831/69
Figure 1-5 Connection overview 37PF9731D/10 & 42PF9731D/10 & 42PF9831D/10
Figure 1-6 Connection overview 42PF9641D/10
Note: The following connector colour abbreviations are used
(acc. to DIN/IEC 757): Bk= Black, Bu= Blue, Gn= Green,
Gy= Grey, Rd= Red, Wh= White, Ye= Yellow.
1.2.1 Side Connections
Headphone (Output)
Bk - Headphone 32 - 600 ohm / 10 mW ot
Cinch: Video CVBS - In, Audio - In
Rd - Audio R 0.5 VRMS / 10 kohm jq
Wh - Audio L 0.5 VRMS / 10 kohm jq
Ye - Video CVBS 1 VPP / 75 ohm jq
S-Video (Hosiden): Video Y/C - In
1 - Ground Y Gnd H
2 - Ground C Gnd H
3 - Video Y 1 VPP / 75 ohm j
4 - Video C 0.3 VPPP / 75 ohm j
G_15990_088.eps
190706
G_15990_085.eps
190706
G_15952_001.eps
311006

Technical Specifications, Connections, and Chassis Overview EN 5FJ3.0E LA 1.
USB2.0
Figure 1-7 USB (type A)
1-+5V k
2 - Data (-) jk
3 - Data (+) jk
4 - Ground Gnd H
1.2.2 Rear Connections
Common Interface
68p- See diagram B10A jk
RJ45: Ethernet (if present)
Figure 1-8 Ethernet connector
1 - TD+ Transmit signal k
2 - TD- Transmit signal k
3 - RD+ Receive signal j
4-n.c.
5-n.c.
6 - RD- Receive signal j
7-n.c.
8-n.c.
HDMI 1 & 2: Digital Video, Digital Audio - In
Figure 1-9 HDMI (type A) connector
1 - D2+ Data channel j
2 - Shield Gnd H
3 - D2- Data channel j
4 - D1+ Data channel j
5 - Shield Gnd H
6 - D1- Data channel j
7 - D0+ Data channel j
8 - Shield Gnd H
9 - D0- Data channel j
10 - CLK+ Data channel j
11 - Shield Gnd H
12 - CLK- Data channel j
13 - n.c.
14 - n.c.
15 - DDC_SCL DDC clock j
16 - DDC_SDA DDC data jk
17 - Ground Gnd H
18 - +5V j
19 - HPD Hot Plug Detect j
20 - Ground Gnd H
Cinch: Audio - In
Rd - Audio - R 0.5 VRMS / 10 kohm kq
Wh - Audio - L 0.5 VRMS / 10 kohm kq
VGA: Video RGB - In
Figure 1-10 VGA Connector
1 - Video Red 0.7 VPP / 75 ohm j
2 - Video Green 0.7 VPP / 75 ohm j
3 - Video Blue 0.7 VPP / 75 ohm j
4-n.c.
5 - Ground Gnd H
6 - Ground Red Gnd H
7 - Ground Green Gnd H
8 - Ground Blue Gnd H
9-+5V
DC +5 V j
10 - Ground Sync Gnd H
11 - n.c.
12 - DDC_SDA DDC data j
13 - H-sync 0 - 5 V j
14 - V-sync 0 - 5 V j
15 - DDC_SCL DDC clock j
Aerial - In
- IEC-type Coax, 75 ohm D
Digital Audio In: Cinch: S/PDIF - In
Bk - Coaxial 0.2 - 0.6VPP / 75 ohm jq
EXT2: Video RGB/YC - In, CVBS - In/Out, Audio - In/Out
1 - Audio R 0.5 VRMS / 1 kohm k
2 - Audio R 0.5 VRMS / 10 kohm j
3 - Audio L 0.5 VRMS / 1 kohm k
4 - Ground Audio Gnd H
5 - Ground Blue Gnd H
6 - Audio L 0.5 VRMS / 10 kohm j
7 - Video Blue/C-out 0.7 VPP / 75 ohm jk
8 - Function Select 0 - 2 V: INT
4.5 - 7 V: EXT 16:9
9.5 - 12 V: EXT 4:3 j
9 - Ground Green Gnd H
10 - Easylink P50 0 - 5 V / 4.7 kohm jk
11 - Video Green/Y 0.7 VPP / 75 ohm j
12 - n.c.
13 - Ground Red Gnd H
14 - Ground P50 Gnd H
15 - Video Red/C 0.7 VPP / 75 ohm j
16 - Status/FBL 0 - 0.4 V: INT
1 - 3 V: EXT / 75 ohm j
17 - Ground Video Gnd H
18 - Ground FBL Gnd H
19 - Video CVBS 1 VPP / 75 ohm k
20 - Video CVBS/Y 1 VPP / 75 ohm j
21 - Shield Gnd H
1234
E_06532_022.eps
300904
112345678
E_06532_025.eps
210905
19 1
18 2
E_06532_017.eps
250505
1
610
11
5
15
E_06532_002.eps
050404
