philosys gmate step User manual

User's Guide
Thank you for purchasing the Gmate™
System.
Please read this User's Guide carefully
before using to ensure correct use.
Please keep this User's Guide for your
future reference.

Gmate™ System is very easy to carry around and able to be used
for measuring the glucose level in whole blood and steps anytime.
It is also very simple, easy and foolproof. You don't have to worry
about coding your meter because the Gmate™ meter does it
automatically. The system should be used only for testing glucose
and only with fresh capillary whole blood samples. The system is
Gmate™ meter has only one button to
navigate all functions easily with simple
operation.
It is small size, stylish design, and ease of
use allows you to take it everywhere.
It can show all information variously.
It requires very small volume(0.5uL) and
display the result in 5 seconds.
It can measure glucose in whole blood at
AST(Alternate site testing).
It can measure glucose concentration when
the test strip inserted without changing the
code number or using the code chip.
1
2
3
4
5
6
Features
intended for self-testing by persons with use at home and in clinical
settings. It should not be used for the diagnosis of diabetes without
the guidance of a healthcare professional or for the testing of
newborn.

Table of Contents
About Gmate™ System 4
Before Starting 5
Name and Function of the Parts 7
Cautions 10
About the Pedometer 13
Obtaining Blood Drop 15
About Alternate Site Testing 18
Testing Your Blood Glucose 20
Control Solution Testing 24
Reviewing Results 27
Setting the Meter 30
Replacing the Battery 33
Error Messages 34
Troubleshooting 36
Performance Characteristics 37
Caring for System 39
Specifications 41

4
About GmateTM System
Gmate™ System includes:

5
Before Starting
Symbols
Caution, see instructions for use
Single use only
Expiration date
Serial number
Lot number
In Vitro Diagnostic medical device
Manufacturer
Authorised representative
Symbol for temperature limitation
Consult instructions for use
Biological risks
Contains sufficient for <n> tests
Direct current
Separate disposal from other household waste

6
Before Starting
Intended Use
Gmate™ system is intended for self-testing to monitor glucose
concentrations in fresh whole blood. Gmate™ system is for use
outside body(in vitro diagnostic use) in fingertips, forearm, upper
arm, hand, thigh and calf testing.
Test principle
The Gmate™ system is based on measurement of a small electrical
current produced by the reaction of glucose in the blood sample with
the reagents on the strip. This current is changes tothe amount of
glucose in the blood sample. The glucose concentration in the
sample is calculated based on the electrical current and displayed on
the meter.
Setting the time and date
See the 30 page(Setting the Meter) to ensure your desired settings
are saved.
Your Gmate™ meter comes with the time, date and year pre-set.
Before using your meter for the first time or if you change the meter
battery, you should check and set the time and date. If you does not
set your meter for the first time or after changing the battery, you can
hear beep 3 times when inserting a test strip.
There are two types of glucose units: mg/dL and mmol/L.
Your Gmate™ meter does not allow you to change the glucose unit
yourself in order to prevent misinterpretation of the test results. The
glucose unit has been preset before leaving our factory. If you have
received a Gmate™ meter with the glucose unit different from the
method you use to measure your glucose levels, do not perform any
tests, and contact your local Philosys distributor for assistance .

7
Names and Functions of the Parts
Front View
Gmate™ Test Strip
Display Screen
This is where you read your test results,
steps and other informations.
M-button
The 'M' button is used to recall the
stored results and adjust the
parameters in set-up mode. You can
turn the meter off by pressing and
holding the 'M' button for 2 seconds.
Test Strip Port
Insert the end of a Gmate™ test strip
here. The meter will turn on when you
insert the test strip.
Electrodes
The end of the test strip is inserted into
the test strip port of the meter with the
end facing up.
Sample Tip
The end of the test strip where the
blood sample is drawn into.

8
Names and Functions of the Parts
Side View
Back View
Strap Hole
It is for hand-strap or neck-strap.
Battery Cover
Slide cover off to
replace batteries.
SET Button
Used to enter the set-
up mode for changing
the date and time.

9
Names and Functions of the Parts
Display
Lancing Device
Displays the mode of meter.
Warns when the battery is low or must
be replaced.
Display test results, steps, measuring
status, error messages and other
informations.
Results are displayed along with the
units of measure.
Clear AST cap
Lancet ejectorSliding barrel
Adjustable capLancet holderRelease button
*Clear AST cap is an optional accessory.
Please contact your local distributor.

10
Cautions
Cautions for
System
The Gmate™ System is intended for use
outside the body(in vitro diagnostic use) only.
The Gmate™ System is used only for
measuring fresh capillary whole blood.
The Gmate™ meter should only be used with
Gmate™ Test Strip and Gmate™ Control
Solution.
Do not use the Gmate™ System for diagnosis
of diabetes without the guidance of healthcare
professional, for testing on newborns and with
arterial blood.
The Gmate™ System contains small parts
that may be dangerous if swallowed.
Check the package before starting the
measurement.
Be sure to read user's guide and the test strip
insert found in the test strip box carefully
before testing.
Do not make any decision of medical
relevance without first consulting your
physician and/or having received appropriate
training.

11
Cautions
Cautions for
Meter
Keep the meter out of reach of young
children. If a young child swallows battery,
battery cover, immediately consult with a
doctor.
Do not swing the meter by holding the
neckstrap. You may injure yourself or other
people.
Do not throw the battery into fire.
Do not disassemble or modify the meter.
Do not subject the meter to severe shock,
drop or step on meter.
The meter is not waterproof. Do not wash it
or touch it with wet hands.
Do not wipe the meter with thinner, or
abrasive cleaners.
Avoid the meter being exposed to high
temperature, high humidity, rain and/or dust
when using or storing the meter.
Do not test glucose instantly when the meter
move to a place where it is a sudden change
in temperature. Wait 20 minutes and start
testing.

12
Cautions
Cautions for
Test Strip
Store the test strip in a cool, dry place
between 2° and 32°C(36° and 90°F).
Keep away from direct sunlight and heat.
After removing test strip from the vial,
immediately close the vial cap tightly.
You may get the inaccurate result if vial cap
opened long period of time.
Don't drop the blood on the surface of test
strip directly.
Do not press the test strip against your finger.
This may affect inaccurate aspiration of
blood.
Do not use a test strip that appears damaged
or has been used. Test strips are for single
use only.
Store test strips in their original vial.
After you take a test strip out of the vial, be
sure to use it within three minutes.
Always use test strips within 3
months(90days) after first opening.
With clean, dry hands, you may touch the
test strip anywhere when removing it from the
vial or inserting it into the meter.
Do not bend, cut, or alter test strips.

13
About the Pedometer
Gmate™ STEP System is your walking partner, along with built-in
pedometer and can help you control your diabetes by counting your
steps and testing your blood glucose level.
We recommend that you place the meter in the upper front pocket of
your jacket, in a bag you hold tightly, or wear the meter with neck
strap around your neck.
Place the meter in your pocket
Do not place the meter in the back pocket of your pants.
Place the meter in the pocket you hold tightly.
Place the meter in your bag
Place the meter in your pocket or the partition of your bag.
Wear the meter with neck strap around your neck
Use the supplied neck strap and place the meter near your chest.
Important :
The meter can count steps only in the following cases:
When the meter is off with battery installed.
'M' button is pressed and released when the meter is off.

14
About the Pedometer
The meter may not be able to count the steps correctly in the
following cases.
When the memory is being displayed, the
blood glucose is being tested or the meter
is being set.
When the front of the meter is placed in the
angle of less than 60° or horizontal to the
ground.
When the meter is placed in the bag that
moves irregularly because it hits your foot,
your belt or the top of your pants.
When the unit hangs from your belt, the top
of your pants or a bag.
When you walk at an inconsistent pace.
When you use the meter in the place where
lots of up and down movements or
vibrations take place.
When you walk extremely slowly or fastly.

15
Obtaining Blood Drop
STEP 1
Wash your hands carefully with warm water
to increase the circulation of the blood into
the fingers. Dry hands thoroughly until the
finger to be pricked is completely dry.
STEP 2
Unscrew the cap of the lancing device by
turning it counter-clockwise while holding the
base firmly.

16
Obtaining Blood Drop
STEP 3
While holding the lancet carrier, insert a new
sterile lancet into the bottom of lancet carrier.
STEP 4
Twist the cap of the lancet off.
STEP 5
Put the cap of the lancing device back on
and turn it clockwise.
STEP 6
Hold the tip firmly in one hand then pull out
the sliding barrel with the other hand. This
will cock the lancing device.

17
Obtaining Blood Drop
STEP 7
Set the proper depth of penetration by
rotating the cap of lancing device. 1-2 for soft
or thin skin, 3 for average skin, 4-5 for thick
or calloused skin.
STEP 8
Place the lancing device in place. Hold the
lancing device firmly against the side of the
finger, with the cap resting on the finger.
(The harder it is pressed the deeper the
puncture). Press the release button to take a
sample.
Caution : To reduce the chance of infection :
Make sure to wash the puncture site with soap and water
before sampling.
Do not share a lancet or a lancing device with anyone.
Always use a new lancet - lancets are for single use only.
Keep your meter and lancing device clean.

18
About Alternate Site Testing
The Gmate™ Meter lets you obtain a blood sample from your Upper
arm, Forearm, Hand, Thigh or Calf. Obtaining a drop of blood from
these “alternate site testing” may be less painful than a fingertip
sample. Following figure shows the areas where you can test with
the Gmate™ System. Avoid moles, veins, bones and tendons.
Consult to your healthcare professional before using alternate site
testing.
Upper Arm
Forearm
Hand
Fingertips
Thigh
Calf

19
About Alternate Site Testing
Caution : Do not test on alternate sites :
when you think your blood glucose level is changing rapidly,
such as within two hours of exercise, a rapid-acting insulin
injection or insulin pump bolus or within two hours after a meal.
if you are testing for hypoglycemia (low blood glucose) or if you
suffer from hypoglycemia unawareness.
Obtaining a blood sample from alternate sites is different than getting
a sample from fingertips.
After inserting a new sterile lancet into the
bottom of lancet carrier, put the clear AST
cap to the lancing device.
Place the lancing device on the skin in the
chosen site, press and hold the lancing
device continuously for a few seconds, then
push the release button to take a sample.
watch through the clear cap until a sufficient
blood sample is taken. If there is not enough
blood, gently massage the area until a
sufficient sample has been collected.

20
Testing Your Blood Glucose
STEP 1
Hold the test strip with the electrode end
facing up. Insert the electrode end into the
test strip port on the meter. Insert a new test
strip into the meter until it stops. The meter
will turn on.
STEP 2
Time will be displayed for a moment. Then
Code number and strip symbol will be
displayed. A strip symbol with filling blood will
appear letting you know the meter is ready to
test.
STEP 3
Make sure the code number showed on the
screen is same as the code number printed in
the test strip vial. If the code number on the
screen is different from the code number
printed in the strip vial, try to insert new strip.
