Phoenix Gold SXT12D4 User manual

Subwoofer Manual
Manuel de subwoofer
Features Caractéristiques
Models: SXt10d2, SXt10d4, SXt12d2, SXt12d4
• OnePiecePolypropyleneDustcap
• HighTemperature2.0InchOFCVoiceCoils
•DieCastAluminumHeatsinkSpiderSpacer
• OptimizedforSealedorVentedEnclosures
• RigidPowderCoatedSteelFrame
• NickelPlated12GaugeSpeakerTerminals
• HighExcursionMotorDesign
• Pare-poussièremonopièce
•Aluminiummoulédissipateurthermiquespiderspacer
• Bobinesacoustiquesencuivreexemptd’oxygèneà
 hautetempérature
• Panierrigideenacier
• Bornesd’enceintenickeléesdecalibre12
• Modèledemoteuràgrandbattement

www.phoenixgold.com
SubwooferOwner’sManual
Enclosures
SEALED Enclosure recommendations
ENCLOSURE INFORMATION
Phoenix Gold subwoofers are overbuilt in virtually every way conceivable. It is important that the subwoofer’s enclosure is built to these same exacting
standards. The enclosure must be constructed of at least .75 inch MDF for 10 and 12 inch subwoofers or .625 MDF for 8 inch subwoofers. Screws or air staples
are excellent construction fasteners when used with a strong bonding “yellow” wood working glue that can ll joint gaps. Be sure that the enclosure’s panels are
airtight at all joining seams. Lining the walls with a polyester matting 1 to 3 inches thick is sufcient.
Your PG dealer has extensive knowledge, tools and the experience needed for the design and construction necessary for your subwoofer application. We also
recommend you consult with your dealer for specic technical assistance related to your installation. The charts provided should be used as a reference when
building an enclosure for your subwoofer.
INFORMATIONS SUR L’ENCEINTE
Les caissons d’extrêmes graves sont fabriqués en fonction de normes rigoureuses an de fournir des années de plaisir acoustique. Il est important que
l’enceinte du caisson des extrêmes graves soit construite en fonction de ces mêmes normes rigoureuses. L’enceinte doit comprendre au moins un RP d’au
moins 3/4” de pouces. Les vis ou agrafeuses pneumatiques constituent d’excellentes pièces de xation lorsqu’elles sont utilisées avec une colle forte de
couleur «jaune » pour le travail du bois qui peut combler les écarts de jointures. Assurez-vous que les panneaux de l’enceinte soient étanches au niveau de
toutes les piqûres de liaison. Le revêtement des murs à l’aide d’une natte en polyester épaisse de 1 à 3 pouces suft.
Votre concessionnaire PG dispose de grandes connaissances, d’outils et d’expérience requise pour la conception et la constructions de votre application
de caisson d’extrêmes graves. Nous recommandons également de consulter votre concessionnaire an d’obtenir une assistance technique spécique se
rapportant à votre installation. Les tableaux fournis devraient être utilisés comme référence au moment de construire une enceinte pour votre caisson aux
extrêmes graves PG. Les tableaux présentent plusieurs types d’enceinte. L’enceinte de Qualité du son offre une sortie de musique qui est plus profonde, plus
serrée et davantage de sortie sonore an de reproduire véritablement le matériau source d’origine. L’enceinte SPL satisfait le besoin en «basshead» pour une
sortie maximale tout en sacriant un peu de la qualité du son.
SEALED
VOLUME(cu.ft.)
SXt10d2
SXt10d4
SXt12d2
SXt12d4
SPL 0.4 0.75
Normal 0.6 1.1
SQ 0.8 1.5
SPL = More overall output and compact enclosure size, but sacrices some low bass and smooth overall output
Normal = Recommended for most listeners. Excellent blend of low bass, accurate and strong overall output
SQ = Smooth and exceptional low bass output, but larger enclosure size and sacrices some overall output
Additional Notes:
- For vented enclosures a subsonic lter set at 30Hz to 40Hz is highly recommended.
- Sealed enclosure volumes INCLUDE THE DISPLACEMENT of the subwoofer.
- Vented enclosure volumes INCLUDE THE DISPLACEMENT of the subwoofer. But DO NOT include displacement of the vent.
- In many cases, a 3 inch round vent/port can be used instead of a rectangle/slot vent. This can reduce the vent length and
simply the enclosure construction. However, in some rare cases at high power a small amount of port noise maybe audible. The
provided slot/rectangle ports will provide maximum performance and the most predictable results. Contact technical support for
additional enclosure options.

-
www.phoenixgold.com
VENTED - Normal SXt10d2
SXt10d4
SXt12d2
SXt12d4
Volume(cu.ft.) 1.5 2.0
VentOpening(in.) 2x8 2x10
VentLength(in.) 22.75 21.5
TuningFreq 38Hz 35Hz
VENTED - SPL SXt10d2
SXt10d4
SXt12d2
SXt12d4
Volume(cu.ft.) 1.25 1.75
VentOpening(in.) 2x8 2x10
VentLength(in.) 21 18
TuningFreq 44Hz 40Hz
SubwooferOwner’sManual
Vented Enclosure Recommendations
+
-
+
-
Allvoicecoilsarewiredinparallelfor2ohmload.
RX250.1makesmaximumpowerintoa2ohmload.
SXt12d4 or SXt10d4
SINGLE SUBWOOFER SYSTEM
Dual4ohmSubwoofer(wiredinparallel)
Dual4ohmSubwoofers(wiredinparallel)
SXt12d4 or SXt10d4
DUAL SUBWOOFER SYSTEM
Allvoicecoilsarewiredinparallelfor1ohmload.
SX600.1makesmaximumpowerinto1ohmload.
Touteslesbobinesmobilessontcâbléesenparallèlede2Ohms.
RX250.1fairepuissancemaximaleen2Ohms.
Touteslesbobinesmobilessontcâbléesenparallèlepour
1Ohm.SX600.1rendlapuissancemaximaledechargeen
1ohm.
RX250.1Terminal
SX600.1Terminal
SYSTEM EXAMPLES
+
-
+
-
+
-
+

PhoenixGold
ADivisionofAAMPofAmerica™
1319056thCourt
Clearwater,Florida33760
P:866-788-4237
[email protected]
www.phoenixgold.com
©2014AAMPofFlorida,Inc
DesignedandEngineeredintheUSA
LIMITED WARRANTY
Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) year from the original date of purchase. This
warranty is not transferable and applies only to the original purchaser from an authorized Phoenix Gold dealer in the United States of America only. Should
service be necessary under this warranty for any reason due to manufacturing defect or malfunction, Phoenix Gold will (at its discretion), repair or replace the
defective product with new or remanufactured product at no charge. Damage caused by the following is not covered under warranty: accident, misuse, abuse,
product modication or neglect, failure to follow installation instructions, unauthorized repair attempts, misrepresentations by the seller. This warranty does not
cover incidental or consequential damages and does not cover the cost of removing or reinstalling the unit(s). Cosmetic damage due to accident or normal wear
and tear is not covered under warranty.
INTERNATIONAL WARRANTIES:
Products purchased outside the United States of America are covered only by that country’s Authorized Phoenix Gold reseller and not by Phoenix Gold.
Consumers needing service or warranty information for these products must contact that country’s reseller for information.
Specifications
T/S Parameters: SXt10d2 SXt10d4 SXt12d2 SXt12d4
Re(Dcr) .85 1.65 .85 1.65
FS(Hz) 39.5 40.3 33.4 33.1
Sd(SqM) .033 .033 .051 .051
BLTM 6.7 7.8 6.3 7.8
Qms 2.79 3.05 2.13 2.61
Qes .577 .775 .735 .959
Qts .48 .62 .55 .7
Vas(liters) 22.63 23.59 56.20 54.99
Cms(uM/N) 132.85 138.45 140.40 137.36
Mms(gms) 122.40 112.59 161.33 168.22
SPL 90dB 90dB 90dB 90dB
Impedance Dual2 Dual4 Dual2 Dual4
Specications: SXt10d2
SXt10d4
SXt12d2
SXt12d4
RMSPowerHandling 300watts 300watts
Xmax(PeaktoPeak) 25mm 25mm
MountingDiameter** 9in-230mm 11in-280mm
MountingDepth 3.6in-92mm 4.25in-108mm
*Specications subject to change
**Install Tip: Remove the mounting gasket from the subwoofer and use it as a mounting hole template.
