Phoenix Gold SX18S4 User manual

Subwoofer Manual
Manuel de subwoofer
Features Caractéristiques
Models: SX18s4, SX110d2, SX110d4, SX112d2, SX112d4
• OnePiecePolypropyleneDustcap
• HighTemperature2.5InchOFCVoiceCoils
 (12and10inchmodels)
• HighTemperature2.0InchOFCVoiceCoil
 (8inchmodel)
• LongThrowRubberSurround
• OptimizedforSealedorVentedEnclosures
• RigidPowderCoatedSteelFrame
• NickelPlated12GaugeSpeakerTerminals
• HighExcursionMotorDesign
• Pare-poussièremonopièce
• Bobinesacoustiquesencuivreexemptd’oxygène
àhautetempérature
• Enceinted’ambianceaveccontouren
caoutchoucdelongueportée
• Optimisépourlesboîtiersétanchesouporté
• Panierrigideenacier
• Bornesd’enceintenickeléesdecalibre12
• Modèledemoteuràgrandbattement

www.phoenixgold.com
SubwooferOwner’sManual
Enclosures
SEALED Enclosure recommendations
ENCLOSURE INFORMATION
Phoenix Gold subwoofers are overbuilt in virtually every way conceivable. It is important that the subwoofer’s enclosure is built to these same exacting
standards. The enclosure must be constructed of at least .75 inch MDF for 10 and 12 inch subwoofers or .625 MDF for 8 inch subwoofers. Screws or air staples
are excellent construction fasteners when used with a strong bonding “yellow” wood working glue that can ll joint gaps. Be sure that the enclosure’s panels are
airtight at all joining seams. Lining the walls with a polyester matting 1 to 3 inches thick is sufcient.
Your PG dealer has extensive knowledge, tools and the experience needed for the design and construction necessary for your subwoofer application. We also
recommend you consult with your dealer for specic technical assistance related to your installation. The charts provided should be used as a reference when
building an enclosure for your subwoofer. The charts contain several enclosure types. The Sound Quality enclosure provides deeper, tighter, and more musical
output to truly reproduce the original source material. The SPL enclosure ts the “basshead’s” need for maximum output while sacricing some sound quality.
The normal enclosure is a balance between SPL and SQ.
INFORMATIONS SUR L’ENCEINTE
Les caissons d’extrêmes graves sont fabriqués en fonction de normes rigoureuses an de fournir des années de plaisir acoustique. Il est important que
l’enceinte du caisson des extrêmes graves soit construite en fonction de ces mêmes normes rigoureuses. L’enceinte doit comprendre au moins un RP d’au
moins 3/4” de pouces. Les vis ou agrafeuses pneumatiques constituent d’excellentes pièces de xation lorsqu’elles sont utilisées avec une colle forte de
couleur «jaune » pour le travail du bois qui peut combler les écarts de jointures. Assurez-vous que les panneaux de l’enceinte soient étanches au niveau de
toutes les piqûres de liaison. Le revêtement des murs à l’aide d’une natte en polyester épaisse de 1 à 3 pouces suft.
Votre concessionnaire PG dispose de grandes connaissances, d’outils et d’expérience requise pour la conception et la constructions de votre application
de caisson d’extrêmes graves. Nous recommandons également de consulter votre concessionnaire an d’obtenir une assistance technique spécique se
rapportant à votre installation. Les tableaux fournis devraient être utilisés comme référence au moment de construire une enceinte pour votre caisson aux
extrêmes graves PG. Les tableaux présentent plusieurs types d’enceinte. L’enceinte de Qualité du son offre une sortie de musique qui est plus profonde, plus
serrée et davantage de sortie sonore an de reproduire véritablement le matériau source d’origine. L’enceinte SPL satisfait le besoin en «basshead» pour une
sortie maximale tout en sacriant un peu de la qualité du son.
SEALED
VOLUME(cu.ft.)
SX18s4 SX110d2
SX110d4
SX112d2
SX112d4
SPL 0.3 0.4 0.75
Normal 0.4 0.6 1.1
SQ 0.6 0.8 1.5
SPL = More overall output and compact enclosure size, but sacrices some low bass and smooth overall output
Normal = Recommended for most listeners. Excellent blend of low bass, accurate and strong overall output
SQ = Smooth and exceptional low bass output, but larger enclosure size and sacrices some overall output
Additional Notes:
- For vented enclosures a subsonic lter set at 30Hz to 40Hz is highly recommended.
- Sealed enclosure volumes INCLUDE THE DISPLACEMENT of the subwoofer.
- Vented enclosure volumes INCLUDE THE DISPLACEMENT of the subwoofer. But DO NOT include displacement of the vent.
- In many cases, a 4 inch round (3 or 2 inch for SX18s4) vent/port can be used instead of a rectangle/slot vent. This can reduce
the vent length and simply the enclosure construction. However, in some rare cases at high power a small amount of port noise
maybe audible. The provided slot/rectangle ports will provide maximum performance and the most predictable results. Contact
technical support for additional enclosure options.

-
www.phoenixgold.com
VENTED - SQ SX18s4 SX110d2
SX110d4
SX112d2
SX112d4
Volume(cu.ft.) .8 2.0 2.5
VentOpening(in.) 1.5x4 2x10 2x12
VentLength(in.) 13.5 23 23
TuningFreq 40Hz 34Hz 32Hz
VENTED - Normal SX18s4 SX110d2
SX110d4
SX112d2
SX112d4
Volume(cu.ft.) .6 1.5 2.0
VentOpening(in.) 1.5x4 2x10 2x12
VentLength(in.) 14 25.5 25
TuningFreq 43Hz 38Hz 35Hz
VENTED - SPL SX18s4 SX110d2
SX110d4
SX112d2
SX112d4
Volume(cu.ft.) .5 1.25 1.75
VentOpening(in.) 1.5x4 2x10 2x12
VentLength(in.) 12 25.25 22
TuningFreq 48Hz 42Hz 40Hz
SubwooferOwner’sManual
Vented Enclosure Recommendations
+
-
+
-
Allvoicecoilsarewiredinparallelfor2ohmload.
SX400.1makesmaximumpowerintoa2ohmload.
SX112d4 or SX110d4
SINGLE SUBWOOFER SYSTEM
Dual4ohmSubwoofer(wiredinparallel)
Dual4ohmSubwoofers(wiredinparallel)
SX112d4 or SX110d4
DUAL SUBWOOFER SYSTEM
Allvoicecoilsarewiredinparallelfor1ohmload.
SX600.1makesmaximumpowerinto1ohmload.
Touteslesbobinesmobilessontcâbléesenparallèlede2Ohms.
SX400.1fairepuissancemaximaleen2Ohms.
Touteslesbobinesmobilessontcâbléesenparallèlepour
1Ohm.SX600.1rendlapuissancemaximaledechargeen
1ohm.
SX400.1Terminal
SX600.1Terminal
SYSTEM EXAMPLES
+
-
+
-
+
-
+

PhoenixGold
ADivisionofAAMPofAmerica™
1319056thCourt
Clearwater,Florida33760
P:866-788-4237
[email protected]
www.phoenixgold.com
©2013AAMPofFlorida,Inc
DesignedandEngineeredintheUSA
LIMITED WARRANTY
Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) year from the original date of purchase. This
warranty is not transferable and applies only to the original purchaser from an authorized Phoenix Gold dealer in the United States of America only. Should
service be necessary under this warranty for any reason due to manufacturing defect or malfunction, Phoenix Gold will (at its discretion), repair or replace the
defective product with new or remanufactured product at no charge. Damage caused by the following is not covered under warranty: accident, misuse, abuse,
product modication or neglect, failure to follow installation instructions, unauthorized repair attempts, misrepresentations by the seller. This warranty does not
cover incidental or consequential damages and does not cover the cost of removing or reinstalling the unit(s). Cosmetic damage due to accident or normal wear
and tear is not covered under warranty.
INTERNATIONAL WARRANTIES:
Products purchased outside the United States of America are covered only by that country’s Authorized Phoenix Gold reseller and not by Phoenix Gold.
Consumers needing service or warranty information for these products must contact that country’s reseller for information.
Specifications
T/S Parameters: SX18s4 SX110d2 SX110d4 SX112d2 SX112d4
Re(Dcr) 3.8 1.1 1.85 1.1 1.85
FS(Hz) 40.2 28.9 29.2 31.2 31.4
Sd(SqM) .021 .033 .033 .051 .051
BLTM 12.2 9.4 11.5 9.0 10.6
Qms 7.96 4.87 4.56 4.11 4.51
Qes .714 .445 .519 .629 .79
Qts .66 .41 .47 .55 .67
Vas(liters) 9.22 23.64 22.6 41.19 39.22
Cms(uM/N) 141.97 152.78 146.17 111.21 105.88
Mms(gms) 110.36 198.09 203.94 234.34 243.10
SPL 89dB 90dB 90dB 90dB 90dB
Impedance Single4 Dual2 Dual4 Dual2 Dual4
Specications: SX18s4 SX110d2
SX110d4
SX112d2
SX112d4
RMSPowerHandling 200watts 400watts 400watts
Xmax(PeaktoPeak) 30mm 35mm 35mm
MountingDiameter** 71/4in-185mm 91/4in-235mm 111/4in-285mm
MountingDepth 43/8in-110mm 57/8in-148mm 63/8in-160mm
*Specications subject to change
**Install Tip: Remove the rubber mounting gasket from the subwoofer and use it as a mouting hole template.
