Phoenix International 100FX Series User manual

MODEL PART # DESCRIPTION (All 50-60 Cycles) TEMP
RANGE** INSULATION CHAMBER SIZE CAPACITY WEIGHT & DIMENSIONS
Type 100FX Series Model
100˚ to 350˚F
(38˚ to 177˚C)
+/-25˚F (14˚C)
Adjustable
thermostat
control with
indicator light
2"
berglass
18" x 16", 2.5 cu ft
(46 cm x 41 cm,
.007 cu m)
100 lb (45 kg)
with canisters or
50 lb (23 kg) with
one 5 gal (19 L)
pail, or 150 lb
bulk-loaded flux
200 lb
30" x 30" x 44"
4 1201902 120V AC* @ 1000 watts
Type 100FX Series Model
6 1201906 240V AC* @ 1000 watts
*Operation on Direct Current (DC) will damage oven and void warranty.
**Average stabilized temperature @ 70˚F ambient temperature.
OPERATING INSTRUCTIONS
Type 100FX
Flux Stabilization Ovens
www.phx-international.com
8711 West Port Avenue •Milwaukee, WI 53224 USA •Telephone: [phone] •Fax: [phone]
Phoenix International, Inc.
N5421000A

www.phx-international.com
8711 West Port Avenue •Milwaukee, WI 53224 USA •Telephone: [phone] •Fax: [phone]
Phoenix International, Inc.
INSTALLATION
This oven is crated and packaged for long-distance shipment.
Exercise care in removing the oven from the wooden crate.
Open the oven door and remove packing material, manuals and
loose parts.
WIRING
Check type and voltage on nameplate.
1. 100FX Model 4 (120V AC only) single phase
2. 100FX Model 6 (240V AC only) single phase
GROUNDING
The 120V ovens have a three blade plug cap with grounding plug
(NEMA 5-15P) attached to a 10 foot power supply cord. When
used with a grounded receptacle, these ovens meet all local
electrical code requirements.
The 240V ovens have a 10 foot power supply cord. When used
with a grounded receptacle, these ovens meet all local electrical
code requirements.
FLUX PLACEMENT
For ease in unloading, Type 100FX ovens can be loaded using
filled pails. If preferred, bulk flux can be directly loaded into the
oven. This oven will hold four (4) 25 lb capacity pails or 150 lb of
bulk flux.
GUIDE TO STORAGE
Flux should be stored according to electrode supplier
recommendations. In the absence of detailed storage information
from your flux manufacturer, the Guide To Electrode and Flux
Stabilization section in this manual may help indicate
approximate temperatures.
A laminated version of the Guide To Electrode and Flux
Stabilization is available by contacting Phoenix International, Inc.
TEMPERATURE SETTINGS
Temperature range is 100˚F (38˚C) to 350˚F (177˚C). e
thermostat dial is calibrated from 100˚ to 550˚F. Required oven
temperature setting is obtained by rotation of dial to line up
desired temperature with indicator light in the thermostat housing.
e indicator light only operates when the voltage is applied to the
heating elements. Momentary rotation past desired temperature
setting may be necessary to activate the indicator light to locate for
indexing purposes.
ermostat is accurate to +/-25˚F (14˚C) at the sensing bulb;
however, temperature may vary slightly at dierent areas in the
oven chamber since this is a convection type oven.
WARNING
Excess Heat: At maximum setting, the actual temperature in
portions of the oven near the heating elements may exceed the
upper range.
REPAIR: SPARE PARTS
Enclosed with these instructions are wiring diagrams and a
repair parts list for your oven. For critical welding operations
requiring continuous holding we suggest carrying all the parts
listed in the Suggested Spare Parts section in this manual.
AMP DRAW
120V = 8.3 amps
240V = 4 amps
OVEN DESCRIPTION

Type 100FX Flux Stabilization Ovens
WIRING DIAGRAMS
NOTE:
Jumper wires must be installed outside
of insulation.
Thermometer probe wire (not shown) must
be installed outside of insulation.
CAUTION:
All wiring should be done by licensed
electricians in accordance with state and
local codes, as well as the NEC (National
Electrical Code) Standards. Improper
installation or use may result in serious
injury. Always remove oven from power
source before troubleshooting or repairing.
CAUTION:
Disconnect power before opening or
servicing unit. Make sure oven is cooled
before opening or servicing unit.
Hot Surfaces! Use extreme care to avoid
possible burns or personal injury. Protective
gloves and personal protective equipment
are recommended.
ADDITIONAL PRODUCTS AVAILABLE
Type 300 Series
Stationary Electrode Oven
Safetube® Industrial
Storage Container
Type 5 Series
Portable Electrode Oven

www.phx-international.com
8711 West Port Avenue •Milwaukee, WI 53224 USA •Telephone: [phone] •Fax: [phone]
Phoenix International, Inc.
SUGGESTED SPARE PARTS
120 VOLT and 240 VOLT MODELS
For normal daily operation, the following spare parts and
quantities are recommended to have inventoried for every
10 units of DryRod ovens in use.
NOTE:
For users of large oven quantities, or users not in North America, we recommend keeping an inventory
of additional spare parts to support day to day operation.
SUGGESTED SPARE PART QUANTITY PER
10 OVENS PART #
Heating Element Kit (120V) 1 1257140
Heating Element Kit (240V) 1 1257148
Thermostat Kit (120V) 1 1257130
Thermostat Kit (240V) 1 1257131
Cord Kit 1 1257120
OVEN FAILS TO OPERATE: NO HEAT
1. If oven indicator light will not illuminate, check power supply.
2. Check plug at outer end of power cord and run continuity
check on complete power cord. If defective, replace cord
assembly.
3. Check indicator light for continuity. See Repair Parts drawing
for access details. If defective, replace indicator light.
4. Check thermostat. If indicator light illuminates, power is
being supplied through thermostat to heating elements. Turn
knob from low to high setting and return. A definite “snap”
should be heard at low temperature end and indicator light
should turn off and on with each “snap” cycle. If “snap” is
not heard and indicator light fails to operate, replace entire
thermostat.
5. If thermostat operates satisfactorily, check continuity of
heating elements at bottom center of oven. Failure of one
element will cause very slow heating.
OVEN OPERATES: OVERHEATS
1. Check thermostat operation as in Step 4 (Oven Fails to
Operate: No Heat) and Step 2 (Oven Operates: Temperature
Setting Off).
OVEN OPERATES: TEMPERATURE SETTING OFF
1. Check thermostat operation as in Step 4 (Oven Fails to
Operate: No Heat) and Step 2 (Oven Operates: Temperature
Setting Off).
2. If thermostat operates satisfactorily, recalibrate per thermostat
calibration adjusting sheet.
TROUBLESHOOTING
NOTE:
When replacing heating elements, always
replace all elements. Pairing of new element
with old elements may cause
rapid failure of the old element.

Type 100FX Flux Stabilization Ovens
To order spare or replacement parts please visit our website: www.phx-international.com.
When ordering, please confirm that you are ordering parts for the correct oven.
ORDERING INFORMATION
REPLACEMENT PARTS
# DESCRIPTION QTY OVEN
120V 240V
1Lid Assembly 1 1812600
2Pull Catch 2 7201400
3Lead Kit 1 1257124
Cord Kit
12571204Connection Cord 1
5Strain Relief (7W-2) 1
Heating Element Kit
6Heating Element 3 1257140 1257148
7Heating Element Clamp 3
Thermostat Kit
1257130 12571318Thermostat 1
9Thermostat Knob 1
Thermostat Conversion Kit
1255700 1255701
3High Temp Wire 7 ft
4Cord (Remove plug for 240V) 1
5Strain Relief (7W-2) 1
8Thermostat 1
9Thermostat Knob 1
10 Thermostat Housing 1
11 Thermostat Housing Mounting Bracket 1
12 High Temp Terminal Ring 11
13 Hole Plug 2
Thermostat Element Cover 1
Thermostat Element Gasket 1
8
1
13
9
12 11
4
5
10
3
2
7
6
3

www.phx-international.com
8711 West Port Avenue •Milwaukee, WI 53224 USA •Telephone: [phone] •Fax: [phone]
Phoenix International, Inc.
AWS (TYPE)
Air Conditioned Storage
Before Opening
(RH=Relative Humidity)
DryRod Oven Holding
Temp After Opening
After Exposure to Moisture,
Sucient Amount of Time to Aect Weld Quality
Recondition Step #1 Rebake Step #2
Cellulose
EXX10, EX11, EXX20
70˚–120˚F (21˚–49˚C)
50% Max RH 100˚–120˚F (38˚–49˚C) Not Recommended Not Recommended
Titania
EXX12, EX13, EXX14
70˚–120˚F (21˚–49˚C)
50% Max RH 100˚–120˚F (38˚–49˚C) 180˚–230˚F (82˚–110˚C) ½ Hour
250˚–300˚F (121˚–149˚C)
1 Hour
Iron Powder M.S.
EXX24, EX27
70˚–120˚F (21˚–49˚C)
50% Max RH 100˚–120˚F (38˚–49˚C) 180˚–230˚F (82˚–110˚C) ½ Hour
400˚–500˚F (204˚–260˚C)
½ Hour
Iron Powder Low Hydrogen
EXX18, EX28
Low Hydrogen
EXX15, EX16
Low Hydrogen High Tensile
EXXX15, EXX16, EXXX18
70˚–120˚F (21˚–49˚C)
50% Max RH 250˚–300˚F (121˚–149˚C) 180˚–220˚F (82˚–104˚C) 1½ Hour
650˚–750˚F (343˚–399˚C)
1 Hour
Stainless
EXXX-15, EXXX-16
40˚–120˚F (4.5˚–49˚C)
60% (+/-10) Max RH 250˚–300˚F (121˚–149˚C) 180˚–220˚F (82˚–104˚C) 1½ Hour
500˚–600˚F (260˚–316˚C)
1 Hour
Inconnel
Monel
Kickel
Hard-Surfacing
40˚–120˚F (4.5˚–49˚C)
60% (+/-10) Max RH 150˚–200˚F (66˚–93˚C) 180˚–230˚F (82˚–110˚C) ½ Hour Not Recommended
Brasses
Bronzes
40˚–120˚F (4.5˚–49˚C)
60% (+/-10) Max RH 150˚–200˚F (66˚–93˚C) Not Recommended Not Recommended
Granulated Flux
Agglomerated Flux
40˚–120˚F (4.5˚–49˚C)
60% (+/-10) Max RH 100˚–200˚F (38˚–93˚C) Contact Manufacturer for Specic Temperatures
Flux Cored Wire
EXXT-1, EXXT-2,
EXXT-5, EXXT-G
40˚–120˚F (4.5˚–49˚C)
60% (+/-10) Max RH 250˚–300˚F (121˚–149˚C) Contact Manufacturer for Specic Temperatures
NOTE: Proper redrying temperatures depend upon the electrode type and its condition. Contact your electrode manufacturer for specic instructions involving critical operations. Phoenix
International, Inc. does not accept liability for damage to electrodes and/or welded products resulting from the use of this table. Temperatures and times shown are recommended and are not
guaranteed to be correct.
Eliminate expensive rework and protect welding profits!
•Recondition/rebake procedures for electrode coatings exposed to moisture are included.
•Removeelectrodesfromcardboardcontainersbeforeplacinginovens.
•Electrodecoatingsshouldnotbeexposedtothere-bakingtemperaturewithoutfirstbeingreconditionedata
lower temperature. Failure to do so may result in breakdown of electrode coatings. After re-baking, lower
temperature to holding level until reissued.
GUIDE TO ELECTRODE & FLUX STABILIZATION
WARRANTY
Phoenix International, Inc. warrants its products against defects in
material and workmanship. The company will, at its discretion, repair
or replace any properly installed Phoenix International manufactured
product which fails under normal operating conditions within one year
from date of receipt. Contact the factory for return authorization before
returning the product to Phoenix International freight prepaid. If our
inspection confirms that the product is defective under terms of this
warranty, it will be repaired/replaced and returned freight prepaid.
This warranty applies only to products sold by Phoenix International,
Inc. and specifically excludes installation or de-installation labor,
transportation or equipment of another manufacturer used in
conjunction with Phoenix International products. No other warranty,
expressed or implied, exists beyond this warranty declaration.
Phoenix constantly strives to improve its products and therefore reserves
the right to change design, materials and specifications without notice.
The Guide to Electrode & Flux Stabilization
is also available as a laminated card.
Please visit www.phx-international.com or email [e-mail] to receive yours FREE!
