Phoenix RUSH RU791 CHR User manual

STYLISH
PREMIUM
CHROME
FINISH
PHOENIX
WARRANTY
CONTEMPORARY
DESIGN
MATCH WITH....
RUSH
SHOWER/BATH DIVERTER MIXER
PRODUCT CODE:
FINISH:
RU791 CHR
CHROME

TECHNICAL SPECIFICATIONS
CONSUMER INFORMATION
MERCHANT INFORMATION
PRODUCT:
RANGE:
SHOWER/BATH DIVERTER MIXER
RUSH
PRODUCT CODE: RU791 CHR
BARCODE NUMBER: 9320594 012 366
WM21009
REVISION DATE: DEC 2013
CONNECTION TYPE: N/A
MATERIAL: BRASS
AVAILABLE FINISHES: CHROME, MATTE BLACK
WELS RATING: N/A
FLOW RATE: N/A
TEMPERATURE RATING: MIN 1° - MAX 75°
PRESSURE RATING: MIN 150 KPA
- MAX 500 KPA
WARRANTY: 15 YEAR REPLACEMENT
CARTRIDGE
7 YEAR REPLACEMENT
PRODUCT OR PARTS
1YEAR REPLACEMENT PARTS
OR PRODUCT & LABOUR
CARTON SIZE: L 185MM x W 135MM
L 395MM x W 280MM
x H 75MM
x H 195MM
OUTER BOX SIZE:
OUTER BOX QUANTITY: 10 CARTONS
19 KG
CARTON WEIGHT:
OUTER BOX WEIGHT:
X.X KG
WATERMARK LICENCE:
68
53.70
48mm to mm
Adjustment
5.50
99
119
39
65
150
79
35
22

EXPLODED VIEW
PARTS LIST
1
5
10
7
11
6
13
8
9
4
3
2
12
1 . DIVERTER MIXER OUTLET
2 . WALL MIXER BODY
3 . CARTRIDGE 35MM
4 . SHOWER MIXER LOCKNUT
5 . DIVERTER ASSEMBLY
6 . SQUARE DIVERTER BUTTON
7 . BACK PLATE
8 . MIXER HANDLE
9 . GRUB SCREW M5x5
10. DIVERTER SHROUD
11. O-RING
12. O-RING
13. GRUB SCREW M4x5

RUSH SHOWER/BATH DIVERTER
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
SHOWER DIVERTER MIXER
www.phoenixtapware.com.au
Water Supply Requirements
To ensure optimum performance and customer satisfaction
please adhere to the following:
- Maximum hot water temperature 75°C.
- Recommended minimum working pressure 300kPa.
- Recommended maximum working pressure 500kPa.
If the water pressure exceeds or is likely to exceed 500kPa, an
approved pressure limiting valve must be fitted.
- Flush out all pipe work prior to installation.
- If the water temperature exceeds 75°C an approved
tempering valve must be fitted.
- Installation should comply with Australian standard AS3500.1
or relevant local authority requirements.
Failure to comply with the above may void all warranties. For
details on Phoenix’s warranty policy refer to
www.phoenixtapware.com.au
Maintenance and Care
Do not use cleaning agents containing a corrosive acid or
scouring agent. Do not use cream cleaners, as they are
abrasive. Surfaces should only be cleaned with a cloth and
clear water of mild liquid detergent. Use of unsuitable cleaning
agents may damage the surface.
IN0109 revC
Create a 35mm hole and
50mm hole in cement sheet
and tiles, as shown in diagram.
1
2
3
4
5
54mm
35mm
50mm
Diverter Shroud
Release Grub Screw and
remove Diverter Shroud and
Diverter Button from Diverter
Mixer Assembly.
Screw Diverter Mixer Assembly
in place.
Attach water supply and
connectors as shown.
TEST & CHECK FOR LEAKS
Hot Water
Inlet
Cold
Water
Inlet
Shower
Connection
Bath
Connection
Do not remove the protective
cover until final fit-off.
Diverter Button
Grub Screw
Remove the plastic
protective cover.
Gently Push on
Diverter Shroud and
Dress Plate.
Dress Plate
Diverter Shroud
Push on Diverter Button
and ensure that Square
Cut is facing Screw Hole
as shown
Screw on Diverter Button
over Spindle and ensure
that Screw Hole is facing
down.
Fasten Grub Screw to
secure Diverter Shroud.
On the
same side
Dress Button
Square Cut
Screw Hole
Grub Screw
Dress Shroud
Spindle
Push on Mixer Handle
Fasten Grub Screw to
secure Mixer Handle. Mixer Handle
Grub Screw
Stud
Cement sheet and Tiles
48mm to 67mm
Adjustment

WARRANTY INFORMATION
MANUFACTURER’S WARRANTY
“Our goods come with a guarantee that cannot be
excluded under the Australian Consumer Law
(“ACL”), You are entitled to a replacement or refund
for a major failure and for compensation for any
reasonable or foreseeable loss or damage. You are
also entitled to have repaired or replaced if the
goods fail to be of acceptable quality and a failure
does not amount to a major failure”.
In addition to the above obligations Phoenix oers
the following Manufacturer’s Warranty subject to
the following terms and conditions. Any provision in
the warranty which is inconsistent with the ACL or is
otherwise unenforceable shall be severed from this
warranty to the extent of the inconsistency and the
remainder of the provisions shall continue to apply.
WARRANTY PERIODS
Residential
Phoenix tapware and accessories is made to the
highest industry standards and quality. Refer to
table below for warranty periods.
Commercial
(Hotels, Aged Care Facilities, Hospitals, Schools,
Factories, Motels, etc.)
For all Service Enquiries contact below:
This Manufacturer’s Warranty is provided by Phoenix
Industries Pty Ltd.
Telephone: [phone]
Facsimile: + 61 3 9764 1898
Email: [email protected]om.au
Subject always to any overriding obligation pursuant
to the ACL, warranty shall be void for the following
reasons:
- Inability to provide proof of purchase or equivalent
documentation.
- Products not installed by a licensed plumber.
- Products not to relevant National Standards and
State Regulations.
- Products not installed in accordance with the
manufacturer’s installation instructions.
- Products exposed to environmental elements.
- Tapware exposed to water pressures and or
temperatures that exceed stated limitations.
MAXIMUM: Temperature- 75 degrees & Pressure-
550kPa
MINIMUM: Temperature- 1 degree & Pressure -
150kPa (300kPa for Shower/Bath Diverters)
Note: AS/NSZ 3500.1-2003 (Clause 3.3.4) species
550kPa maximum water supply pressure at any
outlet within a building for new installations.
- Showers may not be suitable for use within:
* Gravity-fed water systems.
* Some instantaneous hot water systems.
* Pressure supply less than 150kPa.
Note: The 550kPa maximum water supply pressure
does not apply to re service outlets.
- Isolation stop taps are not tted as stated on
manufacturer’s installation instructions.
- Fitting of other devices to the outlet of tapware, eg.
water lters.
- Fitting of Phoenix non-approved water ow
regulating devices.
- Fitting of other devices to outlet of tap, e.g., water
lters.
- Non-installation of ow regulated check valve for
hand showers.
- Products used for incorrect applications, non
potable water etc.
- Damage as a result of obstructions due to
inadequate ushing of system before use.
- Services repairs or with non-standard replacement
parts previously undertaken without Phoenix’s
written approval.
- Damage to nishes by adhesives, sealants etc.
- Failure to clean & replace outlet aerator inserts etc.
- Damage to nishes which arise from installation or
post installation use.
- Failure to observe manufacturers care and cleaning
instructions.
- The warranty work is limited to the pre-approved
scope of work. Additional work will require author
zation from Phoenix After Sales & Services
Departments.
- Evidence cannot be produced which conrms that
the relevant product was purchased from a
Phoenix Tapware authorized distributor.
WARRANTY CONDITIONS
Phoenix Warranty covers the repair or, at Phoenix’s
option, the replacement of any products which are
defective through faulty workmanship or materials.
The warranty period commences from date of
purchase or for new buildings date of handover to a
maximum period of 6 months. The warranty period
for replacement products is limited to the expiry
date of the original purchase. The warranty is limited
to the original purchaser and non-transferable. In
order to make a warranty claim, Proof of Purchase
(POP), handover documentation for new homes or
equivalent documentation must be supplied for
warranty claims to be considered. Claims must be
processed through Phoenix’s Customer Service and
each credit claim will be issued with a claim number
which is recorded on the Phoenix system.
Phoenix will not be liable for any claims for labour,
additional products or parts associated with alleged
faulty product for work not approved in advance by
Phoenix in writing.
* Note: These warranty periods apply to
products purchased after 10th April 2011.
Catagory
Mixers
Hand
Shower on
Rail
Tapware &
Standard
Showers
Accessories
Warranty
Period
Warranty
Details
15Years
3Years
7Years
7Years
-15 Years replacement cartridge
-7Years replacement product or parts
Note: Excludes damage to ceramic
disc cartridges from pieces of copper
tube, plastic tube, sand, dirt or thread
tape etc.
-1 Year replacement product or parts
& labour.
-3Years replacement product or parts
-1 Year replacement product or parts
and labour
-7Years replacement product or parts
-1Year replacement product or parts
and labour.
Note: Jumper valves and ceramic disc
spindles; 1Year parts only.
-7Years replacement product or parts
Catagory
All Products
Warranty
Period
Warranty
Details
1 Year -1Year replacement product or parts

WARRANTY INFORMATION
WARRANTY CONDITIONS CONT.
Should any warranty claim be made and attended to
by a Phoenix authorized Service Agent and that in the
opinion of the Service Agent or Phoenix the problem
was from faulty installation or use of the goods in
conjunction with products of another manufacturer
or from some other cause other than a manufacturing
defect to the goods for which Phoenix is responsible,
Phoenix has the right to charge a service fee for each
service sta attending the Owner’s premise where
goods have been installed.
Phoenix requires adequate access to products, ttings
and xtures to undertake warranty repairs. Phoenix
will not be responsible for any consequential damage
or costs where adequate access to product ttings
and xtures is not accessible.
TAPWARE AND ACCESSORIES
Care and cleaning Instructions
- Under no circumstances should you install
tapware using acetone silicones.
- Never use harsh detergents, citrus based
cleaners or abrasive cleaners, as these will
scratch the surface.
- Where your tapware remains dry in use, a soft
cloth can be used to remove surface dust.
Alternatively, a wipe over with warm soapy
water is all that is required to maintain the
nish in perfect condition for a lifetime of use.
- Use of wax based furniture cream should be
avoided as these can result in a build-up of
deposits, which could detract from the
appearance.
- Do not use undue pressure and wipe in one
direction only.
Note: Phoenix reserves the right to alter, or amend
this warranty oer in writing at any time. Phoenix
reserves the right to provide minor components (eg.
handles, aerators, buttons, dress rings, hinges, clips,
rod and washers) as‘Parts Only’ to the customer.
