NOCTURN SDI720p
Camera
Quick Start Guide
For Part Number: 204-AS-0052, 204-AS-0053, 204-AS-4018, 204-AS-4019
May 2017
Document Number: NOCTURN-SDI720p-CAM-QSG-MAY17-B1
Version: B.01

2
| no. : NOCTURN-SDI720p-CAM-QSG
Rev B.01
Photonis Digital Imaging, LLC
6170 Research Road | Suite 208
Frisco, Texas 75033 United States of America
This document may not be reproduced, in whole or in part, without prior written consent of Photonis USA, Inc. The information furnished in this document is believed to be correct at the time of publication
but is not guaranteed and is subject to change without prior notice. No liability is assumed by Photonis for its use. No claims or warranties are made as to the application of Photonis products. Customers
should verify they have the correct documentation before use. Improper assembly or use in a manner not intended may void the warranty.

3
| no. : NOCTURN-SDI720p-CAM-QSG
Rev B.01
Photonis Digital Imaging, LLC
6170 Research Road | Suite 208
Frisco, Texas 75033 United States of America
Table of
Contents
1. Start here 5
2. What is in the box? 5
2.1. OEM Version 5
2.2. End user Version 5
3. Things needed to get started 5
4. Getting to know your camera 6
5. Prepare your camera 8
6. Status indicator 9
7. Maintenance 9
8. Storage 10
9. Need help? 10
9.1. Download the user manual 10
9.2. Camera software updates 11
9.3. Customer support 11

4
| no. : NOCTURN-SDI720p-CAM-QSG
Rev B.01
Photonis Digital Imaging, LLC
6170 Research Road | Suite 208
Frisco, Texas 75033 United States of America
Safety
Summary
WARNING and CAUTION statements have been strategically placed throughout the text prior to operating or
maintenance procedures, practices, or conditions considered essential to the protection of personnel
(WARNING) or equipment and property (CAUTION). NOTES emphasize necessary and important data. CAUTIONS
and NOTES appear in the text as applicable. Definitions for WARNINGS, CAUTIONS and NOTES are as follows:
A warning indicates an operation, condition, or statement, etc., which, if not strictly observed, could result in
injury to or death of personnel.
A caution indicates an operation, maintenance procedure, or condition, etc., which, if not strictly observed,
could result in damage to, or destruction of, equipment or loss of hardware performance or function.
NOTE
A note indicates an essential operating or maintenance procedure, condition or statement or explanatory text.
WARNING
CAUTION

5
| no. : NOCTURN-SDI720p-CAM-QSG
Rev B.01
Photonis Digital Imaging, LLC
6170 Research Road | Suite 208
Frisco, Texas 75033 United States of America
1. Start here
Congratulations on your new NOCTURN SDI720p camera from PHOTONIS. This document is intended to show
you how to connect the camera and start displaying video on an HD-SDI 720p compatible monitor. Interface
details and additional support information are described in separate documents. Please contact Photonis
technical support at [e-mail] if you require additional information.
2. What is in the box?
Before getting started verify the content of your NOCTURN SDI720p camera box.
2.1. OEM Version
One (1) NOCTURN SDI720p camera
One (1) ¼-20” tripod mount adapter
NOTE
The OEM version of the camera does not include a power supply. The user can still power the camera using the
USB power adapter with the micro-B USB connector located on the back camera. If powering using a USB
interface, it is recommended to connect to either a high power charging port or a USB charger capable of
delivering at least 1 A of continuous current.
2.2. End user Version
One (1) NOCTURN SDI720p camera
One (1) ¼-20” tripod mount adapter
One (1) SMA to BNC adapter
One (1) Power/GPIO breakout cable for the NOCTURN SDI720p camera
One (1) AC/DC power adapter for the NOCTURN SDI720p camera
One (1) set of international power adapter blades for the AC/DC power supply
One (1) USB flash drive with documentation and control software
One (1) c-mount lens (optional)
3. Things needed to get started
To get started you will also need the following:
One (1) support 110/220VAC power outlet
One (1) HD-SDI compatible monitor
NOTE
The NOCTURN SDI720p camera is configured at the factory for either 50/60Hz. Please make sure that the
monitor used to display the camera video is compatible with this refresh rate of your camera.

6
| no. : NOCTURN-SDI720p-CAM-QSG
Rev B.01
Photonis Digital Imaging, LLC
6170 Research Road | Suite 208
Frisco, Texas 75033 United States of America
4. Getting to know your camera
C-MOUNT FOR
OBJECTIVE

7
| no. : NOCTURN-SDI720p-CAM-QSG
Rev B.01
Photonis Digital Imaging, LLC
6170 Research Road | Suite 208
Frisco, Texas 75033 United States of America
TRIPOD MOUNT
ADAPTER
BACK FOCAL LENGTH
ADJUSTMENT
STATUS LED
POWER
& GPIO
SDI VIDEO USB

8
| no. : NOCTURN-SDI720p-CAM-QSG
Rev B.01
Photonis Digital Imaging, LLC
6170 Research Road | Suite 208
Frisco, Texas 75033 United States of America
5. Prepare your camera
Description
Remove the c-mount dust cover from the
NOCTURN SDI720p camera
Install a c-mount lens on the NOCTURN SDI720p
camera
Screw an SMA to BNC adapter on the NOCTURN
SDI720p camera and connect the other end to
your monitor
Screw on the Power/GPIO breakout cable on the
NOCTURN SDI720p camera

9
| no. : NOCTURN-SDI720p-CAM-QSG
Rev B.01
Photonis Digital Imaging, LLC
6170 Research Road | Suite 208
Frisco, Texas 75033 United States of America
6. Status indicator
The NOCTURN SDI720p camera has a status indicator located on the back panel. When power is first applied to
the camera, the status light will turn red. Five (5) to (7) seconds after power has been applied, the status
indicator can have the following colors:
NO COLOR- camera did not boot
RED- camera did not complete boot cycle
BLINKING RED- power supply problem
GREEN- camera operating normally
ORANGE- file transfer in progress.
7. Maintenance
This section covers basic maintenance that should be performed periodically by the end user. Please note that
all servicing of the NOCTURN SDI720p camera should be referred to PHOTONIS Digital Imaging, LLC.
Recommended periodic inspection and cleaning –recommend camera be inspected and cleaned every time a
lens change is performed.
1. Visually inspect the external surfaces of the camera and connectors for damage, bent pins and ensure
they are clean and free of debris.
Connect the NOCTURN SDI720p AC/DC power
supply between the camera and AC power outlet
Status LED on the NOCTURN camera should turn
green
You should now be able to see the camera video
displayed on your monitor

10
| no. : NOCTURN-SDI720p-CAM-QSG
Rev B.01
Photonis Digital Imaging, LLC
6170 Research Road | Suite 208
Frisco, Texas 75033 United States of America
2. Clean the external body of the camera, including connectors, with a dry, lint free cloth and soft brush
if necessary to remove dirt, dust and debris. For caked on dirt, the cleaning cloth may be moistened
with a small amount of water or Methanol.
To avoid damage to the camera hardware, do not immerse the camera in any type of liquid, and do not pour
any liquid on, or in the camera.
3. Visually inspect the sensor for dust, debris, and residue (e.g., fingerprints, smears, etc.)
4. Clean the sensor and board with low pressure, dry, compressed air or nitrogen if necessary.
5. If there are fingerprints, smears, or other oily residue, the sensor glass may be cleaned with a lint free
cotton-tipped applicator moistened with a small amount of isopropyl alcohol. Allow the sensor to air
dry.
6. After the sensor is dry, visually verify no residue remains.
8. Storage
In preparation for storage, it is recommended that all cables and connectors be removed from the camera.
1. If operating, shut down and power off the core.
2. Disconnect all cables
3. Visually inspect the external surfaces of the core and connectors for damage, bent pins and ensure
they are clean and free of debris.
4. Clean the external body of the core, including connectors, with a dry, lint free cloth and soft brush if
necessary to remove dirt, dust and debris. For caked on dirt, the cleaning cloth may be moistened with
a small amount of water, Methanol or IPA.
To avoid damage to the camera hardware, do not immerse the camera in any type of liquid, and do not pour
any liquid on, or in the camera.
5. If necessary, clean the sensor and board with low pressure, dry, compressed air or nitrogen. If there
are fingerprints or other oily residue evident on the sensor glass, the sensor glass may be cleaned with
a lint free cotton-tipped applicator and Methanol.
6. If the sensor is cleaned allow the sensor to air dry.
7. Once the sensor is fully dry, install a protective blue lens saver dot.
8. Place the camera in a protective ESD bag and package.
9. For long term storage, a humidity and temperature controlled environment is recommended, however,
the ambient temperature in the storage area should not exceed the range of 50°C to +80°C.
9. Need help?
9.1. Download the user manual
To learn more about your NOCTURN kit, download the user manual at www.nocturncamera.com.
CAUTION
CAUTION

11
| no. : NOCTURN-SDI720p-CAM-QSG
Rev B.01
Photonis Digital Imaging, LLC
6170 Research Road | Suite 208
Frisco, Texas 75033 United States of America
9.2. Camera software updates
To get the latest features and best performance from your NOCTURN kit, you can request the latest camera
software from customer support at [e-mail].
9.3. Customer support
Need help or want some more info? Find answers to commonly asked questions by contacting customer support
at nocturn.supp[email protected].
