PHXIN T60R User manual

T60R
User Manual
MOTORCYCLE
BLUETOOTH
INTERCOM

1
Volume-
Earphone port(charing)
Volume+ Mesh Intercom button
Power button
QUICK START GUIDE

2
First fix the screws on the base, insert the installed base into the left
side of the helmet, use the socket head cap screws Tighten the screws
with the knife, and install the main unit on the base.
If there are any problems with mounting tne bracket, you may use the
3M tape bracket.peel off the protective backing sheet of the 3M tape
and adhere the bracket onto the helmet.Pressfor15 seconds and
glue dry for 24 hours.
Tear off the rough surface of the left and right speaker Velcro on the
headset, and paste them on the left and right ears of the helmet, then
After attaching the speaker to the Velcro surface in the helmet, the
speaker with short headphone cable is installed in the left ear.
The long horn is mounted on the right ear.
Paste the microphone Velcro on the rough surface of the helmet, and
then paste the microphone on the on the Velcro.
INSTALLATION INSTRUCTIONS

3
Basic
Operation
TYPE OPERATION BUTTON COMMANDS
Power On
Power Off
Volume Up
Volume Down
Check the battery
Mobile
Voice Command
(Siri/S-Voice)
press for
one second
press for
one second
press for
8 second
quick press
twice
Moblle Phone pairing
press for
5 second
Answer the call
short press
once
End phone call
Reject phone call
short press
once
quick press
twice
quick press
twice
Answer third party call
Reject third party call quick press
twice
press for
one second
press for
one second

4
Pairing
With Phone
When the “T60R ”is power off ,hold down the
“center key” for 5 seconds.after “T60R”the paring
state,the red and blue lights flashing alternately .
turn on the bluetooth of the mobile phone ,search
for new devices,and select the connection when
“T60R”is found.
TYPE OPERATION BUTTON COMMANDS
Mesh interphone enabled
Mesh interphone closed
Volume Up
Volume Down
Reset the MESH Intercom press for
8 seconds
While Mesh intercom mode on ,“T60R”will autom
atically connect to nearby “T60R” users and allow
them to support up to 32 rider onlino at the same time
through open intercom free conversation.
When the headset Mesh is reset,it clears all network
ing informationand automatically returns to the default
channel 4.
MESH
Intercom
Moblle Phone Pairing press for
5 seconds
short press
once
short press
once
short press
once
short press
once

5
TYPE OPERATION BUTTON COMMANDS
Setting
Frequency
Range
Enter channel setting
surfing the channels
Save channel and exit
If another team is using channel 4(the default
channel)and the network intercom is being interfered
with,it can be changed to another channels 1 to 10
Bluetooth
Intercom
Intercom No1 and No 2
enter into pairing mode
quick press
twice
press for
2 second
press for
2 second
press for
2 second
Short press one of the
intercom is “power”key to search
short press
once
Bluetooth Intercom
hang up the
Bluetooth intercom
short press
once
FM Radio
FM Rideo on
FM Rideo off
press for
2 second
press for
2 second
Scan up
Scan down
quick press
twice
quick press
twice
press for
2 second

6
TYPE OPERATION BUTTON COMMANDS
Intercom No1 and No 2
enter into pairing mode
Short press one of the
intercom is “power”key to search
Bluetooth Intercom
hang up the
Bluetooth intercom
Universal
Bluetooth
Intercom
short press
once
press for
2 second
short press
once
short press
once
Music
Music play
Music pause
Last song
Next song
share the music
that is playing
short press
once
short press
once
quick press
twice
quick press
twice
quick press
twice
Restore
factory
setting
press for
5 seconds
power off, clear set
Technical
specifications
Bluetooth suppport:HSP,HFP,A2DP,AVRCP,AGHSP
Battery:lithium battery,800mA,3.7v
Dimensions:92mm*48mm*26mm
Certification:CE/FCC/TELEC/ROHS
Charging time:3hours
Working time:12-18hours

7
WARRANTY CARD
Purchase Date：
Dealer/retailer：
Iten No：
customer Name：
customer Tel：
customer E-mail：
QC
QUALIFIED CERTICI
Passed
06
Product Failure Description
(Please be sure to fill in your related information so that we can better
serve you intime)

8
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
