Phytec LCD-014 User manual

A product of a PHYTEC Technology Holding company
Display Adapter
LCD-014 / 017
Hardware Manual
Document No.: L-758e_1
Add-on Prod. No.: LCD-014
Add-on PCB. No.: 1337.1
Add-on Prod. No.: LCD-017
Add-on PCB. No.: 1344.0
First Edition

Display Adapter LCD-014-x / LCD-017-x
©PHYTEC Messtechnik GmbH 2011 L-758e_1
In this manual are descriptions for copyrighted products that are not explicitly
indicated as such. The absence of the trademark (™) and copyright (©) symbols
does not imply that a product is not protected. Additionally, registered patents and
trademarks are similarly not expressly indicated in this manual.
The information in this document has been carefully checked and is believed to be
entirely reliable. However, PHYTEC Messtechnik GmbH assumes no
responsibility for any inaccuracies. PHYTEC Messtechnik GmbH neither gives
any guarantee nor accepts any liability whatsoever for consequential damages
resulting from the use of this manual or its associated product. PHYTEC
Messtechnik GmbH reserves the right to alter the information contained herein
without prior notification and accepts no responsibility for any damages which
might result.
Additionally, PHYTEC Messtechnik GmbH offers no guarantee nor accepts any
liability for damages arising from the improper usage or improper installation of
the hardware or software. PHYTEC Messtechnik GmbH further reserves the right
to alter the layout and/or design of the hardware without prior notification and
accepts no liability for doing so.
©Copyright 2011 PHYTEC Messtechnik GmbH, D-55129 Mainz.
Rights - including those of translation, reprint, broadcast, photomechanical or
similar reproduction and storage or processing in computer systems, in whole or
in part - are reserved. No reproduction may occur without the express written
consent from PHYTEC Messtechnik GmbH.
EUROPE NORTH AMERICA
Address: PHYTEC Technologie Holding AG
Robert-Koch-Str. 39
D-55129 Mainz
GERMANY
PHYTEC America LLC
203 Parfitt Way SW, Suite G100
Bainbridge Island, WA 98110
USA
Ordering
Information:
[phone]
[email protected]
1 [phone]
[email protected]
Technical
Support:
[phone]
[email protected]
1 [phone]
[email protected]
Fax: [phone] [phone]
Web Site: http://www.phytec.de http://www.phytec.com
1st Edition June 2011

Contents
©PHYTEC Messtechnik GmbH 2011 L-758e_1 i
List of Figures...............................................................................................ii
List of Tables................................................................................................ii
Conventions, Abbreviations and Acronyms.............................................iii
Preface...........................................................................................................v
1Introduction.........................................................................................1
1.1 View of LCD-014-x ..................................................................... 4
1.2 View of LCD-017-x .................................................................... 5
1.3 Minimum Requirements to Operate the Display Adapters ..........6
1.3.1 PDI Power Supply Connector ......................................... 6
1.3.2 PDI Data Connector ........................................................ 6
2Connectors...........................................................................................7
2.1 Carrier Board Connectivity (X5, X3)........................................... 7
2.1.1 Display Data Connector (X5)..........................................7
2.1.2 Display Power Connector (X3)..................................... 10
2.2 Display Connectivity (X2) ......................................................... 11
2.3 Touch Screen Connectivity (X1, X16, X17, X18)..................... 12
2.4 Backlight Connectivity (X4, X10, X11) ....................................12
3Power..................................................................................................13
4Components.......................................................................................15
4.1 Backlight Converter ................................................................... 15
4.2 Ambient Light Photo Sensor ...................................................... 15
4.3 I2C-EEPROM ............................................................................ 15
4.4 phyWIRE-EEPROM ..................................................................16
5Technical Specifications ...................................................................17
6Component Placement Diagram......................................................21
7The Display Adapters on the phyBASE..........................................23
7.1 Controlling Touch with the phyBASE....................................... 24
7.2 Photo Sensor...............................................................................25
7.3 Power Connector ........................................................................ 25
8Mounting a Display Adapter on a Baseboard................................27
9Revision History................................................................................31

Display Adapter LCD-014-x / LCD-017-x
ii ©PHYTEC Messtechnik GmbH 2011 L-758e_1
List of Figures
Figure 1: Modular Concept of the PHYTEC phyCARD Development
Kit family ................................................................................... 2
Figure 2: Component side of LDC-014-x ................................................. 4
Figure 3: Component side of LDC-017-x ................................................. 5
Figure 4: LCD-014 Physical Dimensions ............................................... 18
Figure 5: LCD-017 Physical Dimensions ............................................... 19
Figure 6: LCD-014 Component Placement, Bottom View ..................... 21
Figure 7: LCD-017 Component Placement, Bottom View ..................... 22
Figure 8: Preparing Baseboard and Display Adapter.............................. 27
Figure 9: Screwing .................................................................................. 28
Figure 10: Rubber Plugs and Wires .......................................................... 28
Figure 11: The result... .............................................................................. 29
List of Tables
Table 1: Abbreviations and Acronyms used in this Manual................... iv
Table 2: Display data connector signal description ................................. 9
Table 3: Display power connector signal description............................ 10
Table 4: Display connector signal description....................................... 11
Table 5: Possibilities how to controll backlight brightness ................... 15
Table 6: Adjusting output current .......................................................... 15
Table 7: Selection of the touch screen controller................................... 24

Conventions, Abbreviations and Acronyms
©PHYTEC Messtechnik GmbH 2011 L-758e_1 iii
Conventions, Abbreviations and Acronyms
This hardware manual describes the LCD-014-M / LCD-017-xxx
PHYTEC Display Adapter. The manual specifies the adapter boards
design and function. Precise specifications for the display mounted
can be found in the Data Sheet/User's Manual.
Conventions
The conventions used in this manual are as follows:
Signals that are preceded by a "n", "/", or “#”character (e.g.: nRD,
/RD, or #RD), or that have a dash on top of the signal name (e.g.:
RD) are designated as active low signals. That is, their active state
is when they are driven low, or are driving low.
A "0" indicates a logic zero or low-level signal, while a "1"
represents a logic one or high-level signal.
Tables which describe jumper settings show the default position in
bold, blue text.
Text in blue italic indicates a hyperlink within, or external to the
document. Click these links to quickly jump to the applicable
URL, part, chapter, table, or figure.
References made to the display connectors or the PHYTEC
Display-Interface (PDI) always refer to the combination of display
data connector (40 pin FCC connector, 0,5mm pitch) and display
power connector (AMP microMatch 8-188275-2) on the PHYTEC
Carrier Board.
Abbreviations and Acronyms
Many acronyms and abbreviations are used throughout this manual.
Use the table below to navigate unfamiliar terms used in this
document.
Abbreviation Definition
BSP Board Support Package (Software delivered with the
Development Kit including an operating system
(Windows, or Linux) preinstalled on the module and
Development Tools).

Display Adapter LCD-014-x / LCD-017-x
iv ©PHYTEC Messtechnik GmbH 2011 L-758e_1
Abbreviation Definition
CB Carrier Board; used in reference to the PHYTEC
Development Kit Carrier Board.
EMI Electromagnetic Interference.
GPI General purpose input.
GPIO General purpose input and output.
GPO General purpose output.
J Solder jumper; these types of jumpers require solder
equipment to remove and place.
JP Solderless jumper; these types of jumpers can be
removed and placed by hand with no special tools.
PCB Printed circuit board.
PEB PHYTEC Extension Board
PDI PHYTEC Display Interface
SBC Single Board Computer; used in reference to
PHYTEC modules, such as phyCOREs, phyCARDS,
etc.
SMT Surface mount technology.
Sx User button Sx (e.g. S1, S2, etc.) used in reference to
the available user buttons, or DIP-Switches
Sx_y Switch y of DIP-Switch Sx; used in reference to the
DIP-Switches on the display adapter or Carrier
Board.
Table 1: Abbreviations and Acronyms used in this Manual
Note:
The BSPs delivered with PHYTEC Development Kits usually include
drivers and/or software for also controlling the PHYTEC Extension
Boards. Therefore programming close to hardware at register level is
not necessary in most cases. For this reason, this manual contains no
information relevant for software development. Please refer to BSP
documentation, chip datasheets and Linux sources if such information
is needed.

Preface
©PHYTEC Messtechnik GmbH 2011 L-758e_1 v
Preface
As a member of PHYTEC's new Add-on product family the
LCD-014-M / LCD-017-xxx PHYTEC Display Adapter is one of a
series of boards that provide additional functions and interfaces to the
standard PHYTEC Carrier Boards.
Primarily designed for PHYTEC’s new phyCARD Rapid
Development Kit family, due to the flexibility of the concept we will
use the same LCD Adapters also in conjunction with further
phyCORE-baseboards.
PHYTEC supports the display adapters in two ways:
(1) as add-ons for Rapid Development Kits which serve as a
reference and evaluation platform
(2) as insert-ready, fully functional OEM display boards, which can
be embedded directly into the user’s peripheral hardware
design.
Implementation of an OEM-able subassembly as the "core" of a
specific function or interface allows you to focus on the development
of customer specific circuitry without having to worry about standard
functions and interface circuitry.
Production-ready Board Support Packages (BSPs) and Design
Services for our hardware will further reduce your development time
and risk and allow you to focus on your product expertise. Take
advantage of PHYTEC products to shorten time-to-market, reduce
development costs, and avoid substantial design issues and risks. With
this new innovative full system solution you will be able to bring your
new ideas to market in the most timely and cost-efficient manner.
For more information go to:
http://www.phytec.com/services/

Display Adapter LCD-014-x / LCD-017-x
vi ©PHYTEC Messtechnik GmbH 2011 L-758e_1
Ordering Information
LCD-014 is available with the ordering number LCD-014-M and has a
5" VGA display.
The part numbering of the model LCD-017 has the following
structure:
LCD-017-xxxx
Display Size / Resolution
035V = 3.5" VGA
050V = 5" VGA
070W = 7" WVGA
104S = 10.4" SVGA
In order to receive product specific information on changes and
updates in the best way also in the future, we recommend to register at
http://www.phytec.de/de/support/registrierung.html
You can also get technical support and additional information
concerning your product.

Preface
©PHYTEC Messtechnik GmbH 2011 L-758e_1 vii
The support section of our web site provides product specific
information, such as errata sheets, application notes, FAQs, etc.
http://www.phytec.eu/europe/support/faq
Declaration of Electro Magnetic Conformity of the
PHYTEC Display Adapter LCD-014 / LCD-017
PHYTEC Single Board Computers and Add-on Boards (henceforth
products) are designed for installation in electrical appliances or as
dedicated Evaluation Boards (i.e.: for use as a test and prototype
platform for hardware/software development) in laboratory
environments.
Caution:
PHYTEC products lacking protective enclosures are subject to
damage by ESD and, hence, may only be unpacked, handled or
operated in environments in which sufficient precautionary measures
have been taken in respect to ESD-dangers. It is also necessary that
only appropriately trained personnel (such as electricians, technicians
and engineers) handle and/or operate these products. Moreover,
PHYTEC products should not be operated without protection circuitry
if connections to the product's pin header rows are longer than 3 m.
PHYTEC products fulfill the norms of the European Union’s
Directive for Electro Magnetic Conformity only in accordance to the
descriptions and rules of usage indicated in this hardware manual
(particularly in respect to the pin header row connectors, power
connector and serial interface to a host-PC).
Implementation of PHYTEC products into target devices, as well as
user modifications and extensions of PHYTEC products, is subject to
renewed establishment of conformity to, and certification of, Electro
Magnetic Directives. Users should ensure conformance following any
modifications to the products as well as implementation of the
products into target systems.

Display Adapter LCD-014-x / LCD-017-x
viii ©PHYTEC Messtechnik GmbH 2011 L-758e_1

Introduction
©PHYTEC Messtechnik GmbH 2011 L-758e_1 1
1Introduction
The display adapters LCD-014-x and LCD-017-x belong to a series of
add-on modules for PHYTEC’s Single Board Computers. These add-
on modules allow easy development of complex applications with off-
the-shelf components.
PHYTEC Display Adapters LCD-014-x and LCD-017-x are
compatible to the PHYTEC Display-Interface (PDI) which consists of
two universal connectors on the PHYTEC Carrier Board. The display
data connector (40 pin FCC connector, 0,5mm pitch) combines
various interface signals like LVDS, USB, I2C, etc. required to hook
up a display and a touch screen. The display power connector (AMP
microMatch 8-188275-2) provides all supply voltages needed to
supply the display and a backlight.
Because of featuring the PDI the PHYTEC Display Adapters
LCD-014-x and LCD-017-x are interchangeable and the same SBC /
Carrier Board combination might serve for different applications just
by changing the adapter board and the software.
Figure 1 depicts the usage of the PHYTEC Display Adapters together
with the modular concept of the phyCARD Development Kit.
The PHYTEC Display Adapters LCD-014-x and LCD-017-x are
insert-ready and provide connectivity to displays of different size and
resolution, as well as to corresponding touch panels.
Precise specifications for the display populating the display adapter
can be found in the applicable datasheet.
Software support for the display adapters is included within the latest
BSPs available for the different phyCARD SBCs.

Display Adapter LCD-014-x / LCD-017-x
2©PHYTEC Messtechnik GmbH 2011 L-758e_1
Figure 1: Modular Concept of the PHYTEC phyCARD Development Kit family
Carrier Board
optional
PEB Module PEB
Connecto
r
PHYTEC SBC (underneath
the opt. PEB Modules)
PHYTEC Display
Interface (PDI)
LCD-014-x / LCD-017-x

Introduction
©PHYTEC Messtechnik GmbH 2011 L-758e_1 3
The display adapters LCD-014-x and LCD-017-x offer the
following features:
•LCD-014-x suitable for 5" display PrimeView PD050VL1
•LCD-017-x available with different 3.5", 5", 7" and 10.4" Prime
View displays
•Compatible to the PHYTEC Display-Interface (PDI) with
improved interference safety achieved by using separate
connectors for data signals and power supply
•Integrated power supply for LED backlight
•Connectivity for 4-wire touch panels
•Different options for brightness control (fixed via DIP-Switch;
variable via PWM signal, or Trimming Potentiometer)
•Ambient light photo sensor
•I2C EEPROM for device recognition (only for x86-systems)
•1-Wire EEPROM for internal use only
•Can be mounted on top of an appropriate PHYTEC Carrier Board,
or aside with a film hinge

Display Adapter LCD-014-x / LCD-017-x
4©PHYTEC Messtechnik GmbH 2011 L-758e_1
1.1 View of LCD-014-x
Figure 2: Component side of LDC-014-x

Introduction
©PHYTEC Messtechnik GmbH 2011 L-758e_1 5
1.2 View of LCD-017-x
Figure 3: Component side of LDC-017-x

Display Adapter LCD-014-x / LCD-017-x
6©PHYTEC Messtechnik GmbH 2011 L-758e_1
1.3 Minimum Requirements to Operate the Display
Adapters
1.3.1 PDI Power Supply Connector
Operation of the display adapters only requires supply of two input
voltages (+3.3V with a 1A load and +5V with a 2A load) and the
corresponding GND connections.
These supply pins are located at the PDI power connector X3:
LCD_3V3: X3 2
LCD_5V: X3 4, 6, 8
Connect all power input pins to your power supply and all GND pins.
Corresponding GND: X3 1, 3, 5, 7, 9
There are also pins reserved for 12V backlight supply but currently
not used.
Caution:
On a custom board we recommend connecting all available +5V input
pins and at least the matching number of GND pins to the power
supply system.
Please refer to section 3for more information.
1.3.2 PDI Data Connector
In order to drive a display at least the LVDS signals, 3V3 logic supply
voltage, the /display_enable signal and GND are needed. If the display
has touch, then you also need to connect the pins for the touch.

Connectors
©PHYTEC Messtechnik GmbH 2011 L-758e_1 7
2Connectors
Please note that all connections are not to exceed their expressed
maximum voltage or current. Maximum signal input values are
indicated in this manual and the corresponding display data sheets. As
damage from improper connections varies according to use and
application, it is the user's responsibility to take appropriate safety
measures to ensure that the module connections are protected from
overloading through connected peripherals.
2.1 Carrier Board Connectivity (X5, X3)
The new concept of using display adapters such as the LCD-014-x and
LCD-017-x allows to attach a large number of different displays
varying in resolution, signal level, type of the backlight, pinout, etc. to
the baseboard using always the same connectors. The new PHYTEC
Display-Interface (PDI) has been designed in order not to limit the
range of displays connectable. It consists of two universal connectors
which provide the connectivity for the display adapter:
The display data connector combines all needed low-current interface
signals.
The display power connector provides all voltages needed to supply
the display and the LED backlight.
They also allow easy adaption to customer displays.
2.1.1 Display Data Connector (X5)
The display data connector at X5 (40 pin FCC connector 0,5mm pitch)
combines various interface signals like LVDS, USB, I2C, etc. required
to hook up a display, or a front panel, as well as the low-current
supply voltage for the logic on the adapter board. Table 2 shows the
pinout with signal names, descriptions, signal level voltages (column
SL) and signal directions (column I/O).

Display Adapter LCD-014-x / LCD-017-x
8©PHYTEC Messtechnik GmbH 2011 L-758e_1
Note:
Text in red indicates signals that are not used on the display adapters
LCD-014-x and LCD-017-x. They are included in the PDI
specification to provide more functions for a customer designed
display adapter or front panel (e.g. an integrated USB connector or
power switch). Please refer to the Carrier Board section within the
hardware manual of your phyCARD or phyCORE module to get
information how to use these signals.
Pin # Signal name I/O SL Description
1 SPI_SCLK I 3.3V SPI clock
2 SPI_MISO O 3.3V SPI Master data in; slave data out
3 SPI_MOSI I 3.3V SPI Master data out; slave data in
4 SPI_CS I 3.3V
SPI Chip select display
5 SPI_IRQ O 3.3V
SPI interrupt output
6 LCD_3V3_S +3V3 Logic Supply Voltage
7 I2C_SCL I 3.3V I2C Clock Signal
8 I2C_SDA I/O 3.3V I2C Data Signal
9 GND Ground
10 DISP_BRIGHT I 3.3V PWM brightness input (0%=dark,
100%=bright)1
11 LCD_3V3_S +3V3 Logic Supply Voltage
12 PWR_KEY O GND
Power on/off Button (close to GND)
13 DISP_ENA I 3.3V
Display enable signal
14 PHYWIRE I/O 3.3V Hardware Introspection Interface
15 GND Ground
16 USB D+ I/O USB USB data +
17 USB D- I/O USB USB data -
18 GND Ground
19 DISP_LVDS_0- I LVDS2LVDS data channel 0 negative input
20 DISP_LVDS_0+ I LVDS LVDS data channel 0 positive input
1: In order to control the brightness of the backlight with the DISP_BRIGHT signal DIP-Switch
S1 must be configured correctly (refer to section 2.3)
2: LVDS voltage level, differential signal with a voltage swing of typically 300 – 400 mV

Connectors
©PHYTEC Messtechnik GmbH 2011 L-758e_1 9
21 GND Ground
22 DISP_LVDS_1- I LVDS LVDS data channel 1 negative input
23 DISP_LVDS_1+ I LVDS LVDS data channel 1 positive input
24 GND Ground
25 DISP_LVDS_2- I LVDS LVDS data channel 2 negative input
26 DISP_LVDS_2+ I LVDS LVDS data channel 2 positive input
27 GND Ground
28 DISP_LVDS_3- ILVDS LVDS data channel 3 negative input
29 DISP_LVDS_3+ ILVDS LVDS data channel 3 positive input
30 GND Ground
31 DISP_LVDS_CLK- I LVDS LVDS clock channel negative input
32 DISP_LVDS_CLK+ I LVDS LVDS clock channel positive input
33 GND Ground
34 TS_X+ I/O
ANA
Touch Screen Right Side Contact /
Bottom right corner
35 TS_X- I/O
ANA
Touch Screen Left Side Contact /
Top left corner
36 TS_Y+ I/O
ANA
Touch Screen Top Side Contact / Top
right corner
37 TS_Y- I/O
ANA
Touch Screen Bottom Side Contact /
Bottom left corner
38 TS_WP I/O
ANA
depends
on
Touch
Controller
Touch Screen Wiper Contact (5-wire
only)
39 GND Ground
40 LS_ANA O
ANA 3.3V Photo sensor analog output (0V=dark, ≥2.0V=bright)
Table 2: Display data connector signal description
The supply voltage LCD_3V3_S is always present when the carrier
board is powered up. It is intended for supplying the photo sensor,
EEPROMs, etc. It should not be used to supply a display or backlight.
Only in case of connecting low-current displays, it might be possible
to renounce the Display Power Connector.
The PWM signal at pin 10 for controlling the brightness of a display's
backlight is generated by an LED dimmer.

Display Adapter LCD-014-x / LCD-017-x
10 ©PHYTEC Messtechnik GmbH 2011 L-758e_1
2.1.2 Display Power Connector (X3)
The display power connector X3 (AMP microMatch 8-188275-2)
provides all supply voltages needed to supply the display and a
backlight.
Table 3 shows the pinout with pin names, descriptions and voltages.
Pin # Pin Name Voltage Description
1 GND Ground
2 LCD_3V3 3.3 V 3,3V power supply display /
backlight
3 GND Ground
4 LCD_5V 5.0 V 5V power supply display /
backlight
5 GND Ground
6 LCD_5V 5.0 V 5V power supply display /
backlight
7 GND Ground
8 LCD_5V 5.0 V 5V power supply display /
backlight
9 GND Ground
10 DISP_BRIGHT 3.3 V PWM brightness Input
(see Table 2)
11 12V_Backlight 12.0 – 24.0 V Backlight power supply
12 12V_Backlight 12.0 – 24.0 V Backlight power supply
Table 3: Display power connector signal description
Caution:
On a custom board we recommend connecting all available +5V input
pins and at least the matching number of GND pins to the power
supply system.
Please refer to section 3for more information.
