PI Manufacturing ANT-S300CPE User manual

PI MANUFACTURING
Powered by Innite Solutions
PI Manufacturing, www.pimfg.com
2.4GHz Wireless
Outdoor CPE with
ANT-S300CPE Installation Manual

Product FeaturesContents
PI Manufacturing, www.pimfg.com
Overview
Package Includes
Hardware / Connection
Web Interface
Typical Applications
Master Mode Conguration
Slave Mode Conguration
Installation Notes
Specications
1
1
7-8
9-10
9-10
2-5
6-10
11-12
13

PI Manufacturing, www.pimfg.com
The ANT-S300CPE is a 2.4GHz wireless outdoor CPE for long distance point-to-point
wireless transmission up to 1km or 3281 feet. Supporting speeds up to 150Mbps,
the wireless CPE uses an industrial Qualcomm chipset that delivers a more stable
and ecient wireless communication.
Built-in high gain 8dBi dual polarized directional antennas provide greater wireless
coverage.
The use of solid capacitors provides a longer life for the wireless CPE. Designed for
outdoor use, the enclosure also comes with 8KV lightning protection for protection
against voltage peaks from lightning strikes.
Overview
Package Includes
2 - 24V Power Adapter
with 2 x RJ45 Ports
2 - Fastening Rings

PI Manufacturing, www.pimfg.com
Hardware and Connection
Front
Bottom Left
Right
Top
Back

PI Manufacturing, www.pimfg.com
Cover
RJ45 Port RJ45 Port

PI Manufacturing, www.pimfg.com
For initial setup, plug a RJ45 Cat5e / 6 cable from one of the LAN ports on the CPE
to a computer or laptop. Plug another Cat5e / 6 cable from the other LAN port to
the PoE port on the supplied 24V 1A power adapter. Alternatively, you can also
plug the Cat5e / 6 cable from the LAN port on the power adapter to the computer
or laptop.
PoE LAN
Connect to computer
Can also connect
to computer through
LAN port on supplied
power adapter
Connect to PoE
port on supplied
power adapter

PI Manufacturing, www.pimfg.com
Go into the network adapter properties of your computer / laptop and change the
IP address to the following:
IP Address: 192.168.248.251
Subnet Mask: 255.255.255.0
Default Gateway: [Leave Empty]
Preferred DNS: [Leave Empty]
Go into your preferred web browser, and type the following into the web address.
The default username and password is “admin” (Once logged in, we recommend
that you change the password to a more secure one.
http://192.168.248.1
The last segment can be
changed to any number
up to 254, but cannot be
1 since this is already
assigned to the CPE

PI Manufacturing, www.pimfg.com
Web Interface
The web interface is divided ino the following sections:
- System Status
- Quick Start
- Network Trac
- Wireless
- LAN IP
- Administration
- System Log
For detailed options, view them on the web interface.

PI Manufacturing, www.pimfg.com
Product FeaturesTypical Applications
In a point-to-point setup, the master CPE is plugged
into the internet while the slave CPE is connected to a
computer, camera, or any other device. The maximum
transmission distance is up to 1km (3281 feet).
Master Slave
ANT-S300CPE
Internet

PI Manufacturing, www.pimfg.com
Point-to-point mode is mainly used for long distance wireless bridging of two
bridges and is also the most commonly used networking mode. The bridges in the
same box are bridged by default when shipped from the factory. The following
gure shows an example of the how to manually congure the bridge.
Master ModeSlave Mode
NVR
Switch

PI Manufacturing, www.pimfg.com
1. In the web interface, navigate to the [wireless] setting on the left hand menu.
Under bridge mode make sure Active Mode is toggled left to the blue color. The
default Paired ID Number is set to 0. Make sure to click the apply button after
making any changes for settings to take eect.
2. In the web interface, navigate to the [wireless] setting on the left hand menu.
Under bridge mode make sure Active Mode is toggled right to the gray color. The
default Paired ID Number is set to 0. Make sure to click the apply button after
making any changes for settings to take eect.
Product FeaturesMaster Mode Conguration
Product FeaturesSlave Mode Conguration

PI Manufacturing, www.pimfg.comPI Manufacturing, www.pimfg.com
- The Master and Slave’s pairing ID must be the same for the connection to work.
- The Master and Slave’s channel must be consistent.
- The Master and Slave’s wireless passwords must be the same.
- For testing the connection, ping each other’s bridge IP address.

Installation Notes
• When plugging in the Cat5e cable into the PoE port on the power adapter, keep
the lengths at or less than 40 meters for optimal operation. Please make sure bare
copper cables are used. Do not use CCA cables.
• When installing the CPE, ensure that it is installed securely to avoid deviations
caused by external factors, such as wind.
PI Manufacturing, www.pimfg.com
Install securely to avoid movement
Avoid CCA cables. Only use bare copper cables

Line of Sight
PI Manufacturing, www.pimfg.com
Make sure the master and slave are at least 2 meters apart or else interference may
occur.
2 meters
apart

PI Manufacturing, www.pimfg.com
Specications
Chipset
Memory
Storage
Speed
Transmission Power
Maximum Transmission Distance
Maximum Transmission Power
Wireless Standards
Receiver Sensitivity
Ports
Power
Power Consumption
Button
Qualcomm Industrial Chipset
DDR2 64MB
8MB Flash
150Mbps
Max 20dBm
1km (point-to-point)
20dBm
IEEE802.11n, IEEE802.11a
Up to -98dBm
2 - 10/100M adaptive LAN ports
PoE 24V 1A
<2W
Reset (Long Press 5-10 seconds to restore default
settings)
LED
- Wireless Signal
- LAN1 / 2
- Power
Antenna
Polarization
Gain
Web Management
Encryption
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Support Power
Dimensions
Weight
Built-in 2.4GHz directional dual polarized
Vertical: 35°, Horizontal: 65°
8dBi
Yes
WPA2-PSK (AES)
-20°C~55°C
-40°C~70°C
10%~90% RH non-condensation
5%~90% RH non-condensation
-40°C
200 x 110 x 61mm
2.35 lbs
