Passive Video Balun
User Manual
Model Number: BALUN-100-2-1A
Introduction:
Application Diagram:
Specification:
Wire Dedication Chart:
Video Signal Chart:
Power Signal Chart:
A video balun allows you to send BNC video signal over a CAT5e cable. Depending on the balun, you are also able to send power
through the CAT5e cable and convert the output to 12V before sending power to your camera. Making the set up easy, organized
and efficient. This type of solution is great for small offices and homes at a great price due to cutting out expensive and heavy
coaxial and power cables. All the CAT5e cables meet in the server room which is plugged into an included rack mount video balun
which converts the signals back out to a BNC for you to connect to your output source, which in most common cases, a Stand-
Alone DVR, a Linux-Based DVR, or a monitor. The power is sent from your server room to each camera. Eliminated the need for a
power source at every camera end. 12V signals drop at about 300 ft. Supplying too much power to your camera will cause the
camera to burn and not supplying enough, your camera will not power up. We stand behind our video baluns completely, we
manufacture our own baluns and be reassured that we use only high quality materials ensuring our customers a satisfied, easy and
safe setup. PI Manufacture carries several other video balun setups, in which some includes converters for longer distance setups.
Model Number
Device Category
Video Input/Output
Connector Type
Cable Required
Wire Dedication
Maximum Distance
Video Balun Distance
Passive up to 1000 feet
up to 4000 feet
Video Balun
Passive
Passive Active
up to 4000 feet Passive
up to 6000 feet Active
Active
Active
Frequency Response
Attenuation
Impedance
Coaxial
UTP CAT5e
Telephone Cable
* Specification may change without prior notice.
Power Adapter Power CableCAT5e Cable
@ 250 mA
DC 18V
AC 24V
AC/DC 48V
UTP 1 Pair
100 feet
300 feet
600 feet
UTP 2 Pair
300 feet
600 feet
1000 feet
UTP 3 Pair
650 feet
1000 feet
1500 feet
22 AWG
1000 feet
1300 feet
2000 feet
18 AWG
1500 feet
1800 feet
2500 feet
AC Adapter Requirement
Input Power
Output Power
Dimensions (W x H x D)
Weight
Dimension & Weight
Output
NVA-P-100-PW NVA-P-100-SP
EIA / TIA -568B
POWER
POWER
VIDEO
VIDEO
ORAGNE
-
2GREEN
-
6BLUE
-
4
-
BROWN
8
+
ORAGNE
1
+
GREEN
3
+
BLUE
5
+
BROWN
7
Passive Passive
RJ-45 RJ-45
CAT5e, CAT6 CAT5e, CAT6
3 Pair Power, 1 Pair Video 3 Pair Power, 1 Pair Video
300 ft 300ft
DC to 6.5MHz
RL = 75 to 100: 0.4dB
RL = 75 to 600: 0.4dB
Coaxial: 75 ohm | UTP / Telephone Cable: 100/600 ohm
balanced twisted pair, 24 AWG, 100 ohm
balanced twisted pair, 26-28 AWG, 600 ohm
For the most up to date specification and details, please visit us at www.pimfg.com.
Caution: This product is not waterproof and should only be used indoors.
N/A N/A
12V 12V
DC 12V @ 1 Amp DC 12V @ 1 Amp
N/A N/A
N/A N/A
BNC Male BNC Male
unbalanced, 75 ohm
