PI Micos LS-270 User manual

User Manual
LS-270 Linear Stage 1
Order no.
6239-9-
DC-B-086
1
2Phase-072
2
305 mm (12")
2
508 mm (20")
3
815 mm (32")
4
1016 mm (40")
5
Without LS-010
0
LS-010, length measuring system (steel)
1
ILS-020, limit switch (Inductive)
4
LS-270 Linear Stage
Order no. 6239-9-
User Manual
Version: 00.003 Date: 30.06.2023

2 LS-270 Linear Stage
© 2016 PI miCos GmbH, Eschbach, Germany. The text, photographs and drawings in this manual are protected by copyright. With regard thereto, PI miCos GmbH retains all
rights. The use of any text, images and drawings is permitted only in part and only when indicating the source.
Subject to change without notice. This manual is superseded by any new release. The respective current revision is available for download on our website
(http://www.pimicos.com).
File name:MAN_LS-270_9_EN.DOCX Document ID:DOC-000378698

LS-270 Linear Stage 3
www.pimicos.com // [e-mail] // phone:[phone] // fax:[phone]
CONTENTS
1. ABOUT THIS DOCUMENT
1.1 Objective and Target Group of this User Manual
1.2 Symbols and Typographic Conventions
1.3 Other Applicable Documents
2. SAFETY
2.1 Intended Use
2.2 General Safety Instructions
2.2.1 Organizational Measures
2.2.2 Measures during Installation
2.2.3 Measures during Start-Up
2.2.4 Measures during Operation
2.2.5 Measures during Maintenance
3. UNPACKING
4. PRODUCT DESCRIPTION
4.1 Features and Application Area
4.2 Model Overview
4.3 Product View
4.4 Safety Instructions
4.5 Scope of Delivery
4.6 Optional Accessories
4.7 Technical Features
4.7.1 Load Capacity Data
4.7.2 Motors
4.7.3 Measuring System
4.7.4 Limit Switch
4.7.5 Connector
4.7.6 Technical Data
4.8 Ambient Conditions
5. INSTALLATION
5.1 General Notes on Installation
5.2 Mounting the Stage
5.3 Affixing the Load
5.4 Setting up an XY System
6. START-UP
6.1 General Notes on Start-Up
7. MAINTENANCE
8. TROUBLESHOOTING
9. CUSTOMER SERVICE
10. OLD EQUIPMENT DISPOSAL
11. EU DECLARATION OF CONFORMITY

4 LS-270 Linear Stage
1. ABOUT THIS DOCUMENT
All specifications in this user manual refer only to the standard products that
are included in the PI miCos catalog. Any special features that are different,
in particular special requests from customers, are supplied with the user
manual as additional documentation in the form of "Technical Notes".
1.1 Objective and Target Group of this User Manual
•This user manual contains all information required for the intended use
of the LS-270.
•Basic knowledge on servo systems, motion control concepts and
applicable safety measures is assumed.
•The latest version of the user manual and answers to any questions can
be obtained from our customer service department (see chapter 9)
1.2 Symbols and Typographic Conventions
The symbols and typographic conventions used in this manual have the
following meanings:
NOTICE
Dangerous situation!
If not avoided, the dangerous situation will result in
death, injuries or damage to the equipment
-> Actions to take to avoid the situation
NOTICE
Information for easier handling, tricks, tips, etc.
1.3 Other Applicable Documents
All products and programs from PI miCos mentioned in this documentation
are described in separate user manuals.
The latest versions of the user manuals can be obtained from our customer
service department (see chapter 9).
2. SAFETY
2.1 Intended Use
The LS-270 is a laboratory device as defined by DIN EN 61010. It is
intended for indoor use and use in an environment which is free of dirt, oil,
and lubricants.
In accordance with its design, the LS-270 is intended for positioning,
adjusting and shifting of loads at various velocities. The LS-270 can be
mounted horizontally or vertically.
The intended use of the LS-270 is only possible in conjunction with suitable
electronics. The following options are available:
1. Drive electronics and controller with suitable software
2. Combination device with suitable software
•The electronics are not included in the scope of delivery of the LS-270.
•The electronics must provide the required voltages. To ensure proper
performance of the servo-control system, the electronics must be able to
read out and process the signals from reference and limit switches, and
from the incremental position encoder.

LS-270 Linear Stage 5
www.pimicos.com // [e-mail] // phone:[phone] // fax:[phone]
2.2 General Safety Instructions
The LS-270 is built according to state-of-the-art technology and recognized
safety standards. Improper use of the LS-270 can result in personal injury
and/or damage to the LS-270.
Only use the LS-270 for its intended purpose, and only use it if it is in good
working order.
Read the user manual.
Immediately eliminate any faults and malfunctions that are likely to affect
safety.
The operator is responsible for the correct installation and operation of the
LS-270.
2.2.1 Organizational Measures
User Manual
•Always keep this user manual available when using the LS-270. If the
user manual is lost or damaged, contact our customer service
department (see chapter 10).
•Add all information from the manufacturer such as supplements or
technical notes to the user manual.
•Only use the device on the basis of the complete user manual. If your
user manual is incomplete and is therefore missing important
information, serious or fatal injury as well as damage to the equipment
can result.
•Only install and operate the LS-270 after you have read and understood
this user manual.
Personnel Qualification
The LS-270 may only be started up, operated, maintained and cleaned by
authorized and appropriately qualified personnel.
2.2.2 Measures during Installation
The LS-270 may be damaged by excessively long screws and wrongly
mounted parts.
•When mounting the LS-270, make sure that the mounting screws do not
interfere with the stage motion. The screw heads must not protrude from
the countersunk holes.
•Observe the depth of the mounting holes in the moving platform.
•Only use screws of the correct length for the respective mounting holes.
•Only mount the LS-270 and the loads on the mounting fixtures (holes)
intended for this purpose.
•The LS-270 heats up during operation. High temperatures can influence
your application.
•Install the LS-270 so that your application is not affected by the
dissipating heat.
•Cable extensions can affect the performance of the LS-270 and damage
the electronics.
•Only use genuine PI miCos parts to connect the LS-270 to the
electronics.
•Do not use cable extensions. If you need longer cables, use cable
extensions from PI miCos.
•Avoid short circuiting the lines for motor voltages since this can damage
the electronics.

6 LS-270 Linear Stage
2.2.3 Measures during Start-Up
•Do not put your LS-270 into operation until it is fully mounted and
connected.
Your system can be damaged by uncontrolled oscillation of the LS-270.
Noise generated during operation of the LS-270 is a typical sign of
oscillation.
•Immediately switch off the servo-control system of the affected stage
axes.
•Check the settings of the servo-control parameters.
Moving parts attached to devices with motorized stages can accelerate
rapidly and generate high forces which can cause injury or damage to
equipment.
Unintentional motion of the stage is possible when it is connected to the
controller for the first time. Defective software or incorrect operation of the
software can also result in unintentional motions.
•Do not place any objects in areas where they can be caught by moving
parts.
Collision of a part in motion at the end of the travel range and high
accelerations can cause damage to or wear on the mechanical system.
•Ensure that the automatic limit switch halt is supported by the controller,
or that it is activated in the controller.
•Do not disable the evaluation of the limit switch signals by the controller.
•Check the function of the limit switches at about 10% to 20% of the
maximum velocity.
•In the event of a malfunction of the limit switches, stop motion
immediately.
•Ensure that the end of the travel range is approached at low velocity.
Set the control signal so that the moving part does not stop abruptly or try to
continue motion at the end of the travel range.
•Determine the maximum velocity for your application.
2.2.4 Measures during Operation
•If noise occurs during operation of the LS-270, check the settings of the
servo-control parameters of your controller.
Highest dynamic force and holding force are achieved at a control signal
level of 100%; however, during continuous operation the motor/drive may
overheat.
•During continuous operation at room temperature, do not exceed a
maximum of 90% of the control signal level.
•For continuous operation at other temperatures, observe the maximum
permissible duty cycle in relation to the ambient temperature or contact
our customer service department for more information (see chapter 9).
2.2.5 Measures during Maintenance
The LS-270 is precision adjusted.
Do not loosen any sealed screws.
Dirt, oil, lubricants and condensation will render the motor/drive inoperable.
Keep the LS-270 free of lubricants.
Keep the LS-270 free of dirt and condensation.

LS-270 Linear Stage 7
www.pimicos.com // [e-mail] // phone:[phone] // fax:[phone]
3. UNPACKING
1. Unpack the LS-270 with care.
2. Compare the contents with the items listed in the contract and the
packing list.
3. Inspect the contents for signs of damage. If there is any sign of damage
or missing parts, contact PI miCos immediately.
4. Keep all packaging materials in case the product needs to be returned.
WARNING
Risk of suffocation for children. Keep the packaging foil
away from children.
Dispose of packaging materials according to
environmental regulations.
NOTICE
All specifications in this user manual refer only to the
standard products that are included in the PI miCos
catalog. Any special features that are different, in particular
special requests from customers, are supplied with the
user manual as additional documentation in the form of
"Technical Notes".
4. PRODUCT DESCRIPTION
4.1 Features and Application Area
Our products are designed specifically for use in the laboratory.
4.2 Model Overview
Order no.
6239-9-
DC-B-086
1
2Phase-072
2
305 mm (12")
2
508 mm (20")
3
815 mm (32")
4
1016 mm (40")
5
Without LS-010
0
LS-010, length measuring system (steel)
1
ILS-020, limit switch (Inductive)
4

8 LS-270 Linear Stage
4.3 Product View
4.4 Safety Instructions
WARNING
After removing the transport lock (if present), watch out
for moving parts.
NOTICE
Protect the product against mechanical damage
(knocking, shock, ...).
Never start up an axis if you suspect it to be damaged
or broken.
Do not disconnect or connect connectors when voltage
is present.
WARNING
Risk of catching by rotating parts such as couplers and
ball screws
WARNING
Risk of squeezing or crushing by moving sliders at the
places illustrated.
WARNING
It is recommended that all persons entrusted with
working with this product and who therefore come into
contact with areas marked by the ESD warning symbol,
are given training and a comprehensive explanation of
the ESD warning symbol with respect to the ESD
precautions.
4.5 Scope of Delivery
1. Stage according to order.
•Mounting accessories (screws & pins) in fast-sealing bag.

LS-270 Linear Stage 9
www.pimicos.com // [e-mail] // phone:[phone] // fax:[phone]
4.6 Optional Accessories
For optional accessories, please ask our customer service department
(chapter 9) for information on possible use of adapter plates or additional Z-
brackets.
4.7 Technical Features
4.7.1 Load Capacity Data
F A C T S
Load characteristics
Fx(N)
Fy(N)
Fz(N)
Mx(Nm)
My(Nm)
Mz(Nm)
kax(µrad/Nm)
kay(µrad/Nm)
DC-B-086
200
1200
1500
600
250
250
1.6
3.2
2Phase-072
260
1200
1500
600
250
250
1.6
3.2
4.7.2 Motors
DC-B-086 with Encoder
Motor type
DC-brush RS-230C
Nominal voltage
V
22.9
Max. continuous current
A
5.57
Electrical resistance

0.65
Electrical inductance
mH
0.42
Torque constant
mNm/A
57
Velocity constant
rpm/V
166
n/M slope curve
rpm/mNm
No load velocity
rpm
Max. continuous velocity at
nominal torque
rpm
3000
Inertia
kgm2
26.0E-6
Continuous torque
mNm
300
Rotary encoder
RE-015 RS422 2-channel + index
Encoder increments (quad
counts)
n
20000
RE-015
Rotary optical encoder RS-422 quadrature
Encoder type
RMHF rotary optical encoder
Quadrature counts per
revolution
n
20000
Signal output
RS-422
Channels
2 + index
Supply voltage
VDC
4.5..5.5
Current consumption,
Typical (Vcc = 5 V DC)
mA
35
Frequency range
KHz
1000
Code disc inertia
kgm2
1E-7
Operating temperature
°C
-40..85

10 LS-270 Linear Stage
2Phase-072
Motor type
2 phase bipolar parallel PK-266M-E2.0B
Phase current
A
2
Step angle
°
0.9
Steps
n
400
Coil resistance

0.9
Coil inductance
mH
3.2
Holding torque
mNm
1170
Inertia
kgm2
30E-6
Weight
kg
0.7
4.7.3 Measuring System
LS-010
Linear optical encoder RS-422 quadrature
Encoder type
Linear incremental LIA-20
Quadrature counts per mm
n
20000
Resolution
nm
50
Grating period
µm
20
Grating material
Steel
Interpolator
n
Integrated 100 times
Signal output
RS-422 quadrature
Channels
2+1 index
Supply voltage
VDC
5 +/- 10%
Current consumption,
Typical (Vcc = 5 V DC)
mA
<200
Frequency range,
MHz
8
Counter capability
Operating temperature
°C
0..55
Linear expansion coefficient
Approx. 10.5 e-6
Absolute accuracy
µm
+/- 1
Index position
50 mm starting in the middle of travel
Connector
Sub-D (m)
4.7.4 Limit Switch
ILS-020
Inductive limit switches
Supply voltage Vs
V
10-30
Supply current
mA
<12 mA
Output configuration
Open emitter
Max. source current
mA
<200
Max. switching voltage
(resistive load)
VDC
30
Contact type
Normal closed
Output type
PNP
Operating temperature
°C
-25 to +75

LS-270 Linear Stage 11
www.pimicos.com // [e-mail] // phone:[phone] // fax:[phone]
4.7.5 Connector
DC brush motor, Sub-D (m), 25-pin, pin assignment with inductive limit switch
Sub-D (m),
25-pin
Function
1
M+
DC brush motor +
2
3
M-
DC brush motor -
4
5
nc
6
7
nc
8
9
EA+
Encoder channel A+
10
EB+
Encoder channel B+
11
EC+
Encoder channel I+
12
EGND
Supply encoder GND
13
E5V
Encoder supply voltage
14
LE2
Limit forward
15
LE1
Limit reverse
16
nc
17
nc
18
LVcc
Supply sensor limit
19
nc
20
LGND
GND supply sensor limit
21
nc
22
EA-
Encoder channel A-
23
EB-
Encoder channel B-
24
EC-
Encoder channel I-
25
nc
2SM motor, Sub-D (m), 25-pin
2SM motor, Sub-D (m), 25-pin, pin assignment with inductive limit switch
Sub-D (m),
25-pin
Function
1
MA+
Motor phase A+
2
3
MA-
Motor phase A-
4
5
MB+
Motor phase B+
6
7
MB-
Motor phase B-
8
9
nc
10
nc
11
nc
12
nc
13
nc
14
LE2
Limit forward
15
LE1
Limit reverse
16
nc
17
nc
18
LGND
GND supply sensor limit
19
nc
20
LVcc
Supply sensor limit
21
nc
22
nc
23
nc
24
nc
25
nc

12 LS-270 Linear Stage
ST-001
Linear encoder, Sub-D (m), 9-pin, RS-422 pin assignment
Sub-D (m),
9-pin
Function
1
EA+
Encoder channel A+
2
EB+
Encoder channel B+
3
EC+
Encoder channel I+
4
EGND
Supply encoder GND
5
E5V
Encoder supply
6
EA-
Encoder channel A-
7
EB-
Encoder channel B-
8
EC-
Encoder channel I-
9
nc
Housing
Shield
Shield of encoder, read head
4.7.6 Technical Data
TECHNICAL DATA
Travel range (mm)
305
508
815
1016
Pitch angle (µrad)
± 40
± 80
± 100
± 120
Straightness / Evenness (µm)
± 3
± 4
± 7
± 0
Yaw angle (µrad)
± 20
± 30
± 0
± 50
Weight (kg)
29
35
43
50
Motor
DC-B-086
2Phase-072
Pitch (mm)
5
5
LS-010
Max. velocity (mm/sec)
150
50
Typical resolution (µm)
0.5
0.4
0.05
Calculated resolution (µm)
12.5(FS)
0.05
Bidirectional repeatability (µm)
± 2.5
± 2.5
± 0.15
Unidirectional repeatability (µm)
0.5
0.4
0.15
Nominal current (A)
5.57
2
Max. operating voltage (V)
24
<100
Accuracy
on request
Velocity range (mm/sec)
0.001..150
Material
Aluminum, (black anodized)
Travel (mm)
305
508
815
1016
A
350
450
600
700
B
700
900
1200
1400
C
11
15
21
25

LS-270 Linear Stage 13
www.pimicos.com // [e-mail] // phone:[phone] // fax:[phone]
4.8 Ambient Conditions
For indoor use only.
•The LS-270 was calibrated at an ambient temperature of 20 °C (+/- 3
°C).
•The permissible operating temperature is between 5 °C and 40 °C.
•The permissible relative humidity is between 20% and 80%.
•Always keep the LS-270 free of dirt, dust and corrosive gases.
5. INSTALLATION
5.1 General Notes on Installation
Requirements
The axis must be screwed onto a surface with an evenness better than 5
µm.
It is necessary to make sure that no dust, dirt or other foreign bodies are
between the surface and the axis, otherwise the properties of the axis can
be impaired by mechanical tension.
To guarantee the prescribed specifications (see Internet www.pimicos.com),
the evenness of the mounting surface must be better than 5 µm.
(Reference surface of PI miCos measuring granite is 3 µm).

14 LS-270 Linear Stage
5.2 Mounting the Stage
Requirements
You have read and understood the general notes on installation (see
chapter 5.1).
Mounting material
screws, pins and auxiliary material or tools supplied (see chapter 4.5
"Scope of Delivery").
•DIN 912 screws and DIN 6325 dowel pins, m6 tolerance field
Tightening torques of the mounting screws to be used should not have
values higher than the following:
•M3 DIN 912 1.5 Nm
•M4 DIN 912 2.0 Nm
•M5 DIN 912 2.5 Nm
•M6 DIN 912 3.0 Nm
Mounting the LS-270
1. Displace the moving platform of the LS-270 to the center position by
hand until all of the countersunk holes in the base body required for
mounting are accessible (see following illustration).
2. Mount the stage with the screws supplied.
3. Make sure that the screw heads do not protrude from the countersunk
holes.
5.3 Affixing the Load
Requirements
You have read and understood the general notes on installation (see
chapter 5.1).
Mounting material
•DIN 912 screws and DIN 6325 dowel pins, m6 tolerance field
Tightening torques of the mounting screws to be used should not have
values higher than the following:
•M3 DIN 912 1.5 Nm
•M4 DIN 912 2.0 Nm
•M5 DIN 912 2.5 Nm
•M6 DIN 912 3.0 Nm
Mounting the Additional Part
Select the mounting position so that the existing fixing holes in the slider of
the LS-270 can be used for the additional part to be affixed.
Mount the additional part with the corresponding screws.

LS-270 Linear Stage 15
www.pimicos.com // [e-mail] // phone:[phone] // fax:[phone]
•Select the mounting position so that the existing fixing holes in the slider
of the LS-270 can be used for the additional part to be affixed.
•Mount the additional part with the corresponding screws.
5.4 Setting up an XY System
Requirements
You have read and understood the general notes on installation (see
chapter 5.1).
Tools and Accessories for Combining two LS-270
•Use the mounting material supplied (for example, pins, screws and
washers) with the LS-270 to carry out XY mounting.
•The mounting procedure is described in chapter 5.2.
•Special adapter plates are not required for the standard axes.
•To prevent too much negative influence on the travel behavior of the Y
axis, the shortest possible travel range should be selected. In extreme Y
axis positions, an adapter plate is used to allow sufficient space for
stiffening.
Two LS-270 can be stacked to form an XY system as follows:
1 - Loosen the 4 screws of the slider of the X axis
2 - Remove the slider plate
3 - Leave the pins in the X axis in order to position the Y axis.

16 LS-270 Linear Stage
4 - Place the Y axis onto the X axis with the help of the pins and use the 4
screws supplied (M6x35 DIN912 A2) to screw on according to a 250 mm
x 175 mm pattern
Use the mounting material supplied with the LS-270 (for example, pins,
screws and washers) for XY mounting.
Special adapter plates are not required for the standard axes.
To prevent too much negative influence on the travel behavior of the Y
axis, the shortest possible travel range should be selected. In extreme Y
axis positions, an adapter plate is used to allow sufficient space for
stiffening.
6. START-UP
6.1 General Notes on Start-Up
This stage must be started up with a suitable cable and the associated
controllers.
7. MAINTENANCE
Depending on the operating conditions and the period of use of the LS-270,
the following maintenance measures are required:
Maintenance Run
The maintenance run is performed to redistribute the existing lubricant on
the guidings of the stage.
•To evenly distribute the existing lubricant on the stage guidings, perform
a maintenance run across the entire travel range after 500 hours of
operation, or after 1 year at the latest.
•If the stage is to be operated continuously in an industrial environment
over a small travel (less than 20 percent of the entire travel range),
perform a maintenance run across the entire travel range every 5000
motion cycles.
Lubrication
Under laboratory conditions, the guidings of the stage need to be lubricated
in exceptional cases only. For continuous industrial use, the lubrication
intervals must be defined individually.
•Do not lubricate the guidings of the LS-270 without consulting our
customer service department (see chapter 9).
•To lubricate the guidings, follow the instructions specified in the
maintenance manual, which you can obtain from our customer service
department.

LS-270 Linear Stage 17
www.pimicos.com // [e-mail] // phone:[phone] // fax:[phone]
8. TROUBLESHOOTING
If the problem that occurred with your system is not listed in the table above
or cannot be solved as described, contact our customer service department
(see chapter 9).
9. CUSTOMER SERVICE
For inquiries and orders, contact your PI miCos sales engineer or send us
and email ([email protected]).
If you have questions concerning your system, have the following
information ready:
1. Product codes and serial numbers of all products in the system
2. Current firmware of the controller (if present)
3. Software version of the driver or the user software (if present)
4. User operating system (if present)
10. OLD EQUIPMENT DISPOSAL
In accordance with EU directive 2002/96/EC (WEEE), as of 13 August 2005,
electrical and electronic equipment may not be disposed of in the member
states of the EU via the municipal residual waste.
Dispose of your old equipment according to international, national, and local
rules and regulations.
In order to fulfil the responsibility as the product manufacturer, PI miCos
GmbH undertakes environmentally correct disposal of all old PI miCos
equipment made available on the market after 13 August 2005 without
charge.
Any old PI miCos equipment can be sent free of charge to the following
address:
PI miCos GmbH
Freiburger Strasse 30
79427 Eschbach, Germany
http://www.pimicos.com

18 LS-270 Linear Stage
11. EC Declaration of Conformity
An EC Declaration of Conformity has been issued for the LS-270 in
accordance with the following European directives:
2014/30/EU, EMC Directive
2011/65/EU, RoHS Directive
The applied standards certifying the conformity are listed below.
EMV: EN 61326-1:2013
Safety: EN 61010-1:2010
DIN EN ISO 12100:2010
RoHS: EN 50581:2012
