PIAGGIO APE 50 E4 User manual

Piaggio would like to thank you
for choosing one of its products. We have drawn up this booklet to show you all features of our product. Please read the booklet carefully before using
your vehicle. It includes information, suggestions and warnings regarding your vehicle. You will also be informed of features, details and devices that
will prove the excellence of your choice. We believe that if you follow our suggestions you will soon tune in with your vehicle and use it for a long time
at full satisfaction.
This booklet is an integral part of the vehicle, and upon sale, it should be transferred to the new owner.
APE 50 E4
Ed. 03_07/2018 - Cod. 1Q000649 (IT-ES) 1Q000650 (FR-EN) 1Q000651 (DE-PT) 1Q000652 (EL-NL) 1Q000653 (DA-PL)

INSTRUCTIONS
The instructions given in this booklet are intended to provide a clear, simple guide to using your scooter; details are also given of routine maintenance
procedures and regular checks that should be carried out on the vehicle at an Authorised PIAGGIO Dealer or Service Centre. The booklet also
containsinstructionsforsimplerepairs.Anyoperationsnotspecificallydescribedinthisbookletrequiretheuseofspecialtoolsand/orparticulartechnical
knowledge: to carry out these operations refer to any authorised PIAGGIO Dealer of Service Centre. Read this booklet carefully before using your
vehicle. Follow the instructions contained in this booklet for your personal safety and to ensure long-lasting use of your vehicle. Failure to observe these
instructions may cause personal injury or damage to the vehicle.
2

Personal safety
Failure to completely observe these instructions will result in serious risk of personal
injury.
Safeguarding the environment
Sections marked with this symbol indicate the correct use of the vehicle to prevent dam-
aging the environment.
Vehicle intactness
The incomplete or non-observance of these regulations leads to the risk of serious
damage to the vehicle and sometimes even the invalidity of the guarantee.
Thesignsindicatedonthispageareveryimportant,theyhighlightthepartsofthebooklet
thatshouldberead with particular care. Each signconsistsofa different graphic symbol,
making it quick and easy to locate the various topics.
3

4

INDEX
IDENTIFICATION......................................................................... 7
Manufacturer plate.................................................................... 8
Vehicle identification number.................................................... 9
Engine identifications numbers................................................. 10
Inside view................................................................................ 11
Outside view............................................................................. 12
SAFE RIDING.............................................................................. 15
Safety rules............................................................................... 16
Safe drive.................................................................................. 16
Engine exhaust gas.................................................................. 17
Maintenance.......................................................................... 18
Ventilation system................................................................. 19
Running-in period...................................................................... 19
VEHICLE USE.............................................................................. 21
Checks...................................................................................... 22
Refuelling.................................................................................. 22
Before starting the engine......................................................... 26
Engine start up.......................................................................... 27
Stopping the engine.................................................................. 29
Vehicle Start-up........................................................................ 30
Starting difficulties..................................................................... 31
Gear position............................................................................. 32
SEATS AND SAFETY BELTS..................................................... 35
Using the safety belts................................................................ 36
Fasting the safety belt........................................................... 37
Adjusting the safety belt........................................................ 38
To release the safety belt...................................................... 38
INSTRUMENT PANEL AND CONTROLS................................... 39
Dashboard................................................................................ 40
Controls..................................................................................... 41
Ignition switch........................................................................... 43
12V accessories socket............................................................ 44
GAUGES AND WARNING LIGHTS............................................ 45
Instrument unit and indicators................................................... 46
Indicator lights........................................................................... 47
Brake fluid level warning light................................................ 48
Turn signal indicator light...................................................... 48
Indicators.................................................................................. 48
Speedometer......................................................................... 49
Odometer.............................................................................. 49
Fuel level indicator................................................................ 49
MIRRORS AND WINDOW GLASSES......................................... 51
Adjusting the mirror............................................................... 52
Wipers and Brushes.................................................................. 52
ELECTRICAL SYSTEM............................................................... 55
EMERGENCY.............................................................................. 59
Wheel replacement................................................................... 60
Spare wheel removal............................................................. 60
Removing the wheel.............................................................. 60
MAINTENANCE........................................................................... 69
Checking the brake fluid level................................................... 70
Gear box oil level...................................................................... 71
Differential-gear oil level........................................................... 73
Window washer fluid level......................................................... 74
Body maintenance.................................................................... 74
Outside cleaning.................................................................... 74
Checking and replacing the air cleaner element....................... 75
Checking and replacing the pre-heating plugs.......................... 75
Checking the battery status...................................................... 77
Bulbs......................................................................................... 78
Replacing the lights............................................................... 80
Fuses........................................................................................ 83
Brake pedal............................................................................... 86
Headlights adjustment.............................................................. 86
Tyres......................................................................................... 87
Periods of inactivity................................................................... 88
5

Brakes....................................................................................... 88
Brake adjustment.................................................................. 89
Troubleshooting / What to do if................................................. 89
TECHNICAL DATA...................................................................... 95
Vehicle...................................................................................... 96
Engine....................................................................................... 99
SCHEDULED MAINTENANCE - CHECKS................................. 103
Checks...................................................................................... 104
Scheduled maintenance service............................................... 104
Recommended products........................................................... 106
6

APE 50 E4
Chap. 01
Identification
7

01_01
Manufacturer plate (01_01, 01_02, 01_03, 01_04)
Located under the right side seat.
MANUFACTURER'S PLATE KEY:
1. Manufacturer of the vehicle.
2. Type-approval number.
3. Vehicle Identification Number V.I.N.
4. Noise level (dB) under prescribed engine (Rpm)
5. Type of engine.
6. Vehicle code.
7. Country of production.
01_02
COLOUR LABEL:
This colour label indicates:
1. Original paintwork manufacturer
2. Paintwork colour
3. Paintwork code
8
1 Identification

01_03
01_04
TYRE LABEL.
To know the front and rear tyre pressure, read the values specified on the tyre label,
situated inside the driving cabin.
01_05
Vehicle identification number (01_05, 01_06)
The identification registration numbers are made up of a prefix that identifies the ve-
hicle type and a progressive number punched on the chassis and engine. These
numbers must always be quoted in the spare parts requests.
It is advisable to check that the identification registration numbers on the vehicle and
on the engine correspond with those indicated in the vehicle registration documents.
9
1 Identification

01_06
Check that the prefix and number punched on the chassis correspond to that shown
on the vehicle documents.
The chassis identification number is located on the right side of the cross member
under the seat.
CAUTION
BE REMINDED THAT ALTERING IDENTIFICATION REGISTRATION NUMBERS
MAY LEAD TO SERIOUS PENAL SANCTIONS (IMPOUNDING OF THE VEHICLE.
ETC.)
VEHICLE IDENTIFICATION NUMBER
CHASSIS PREFIX ZAPC81 ÷ 00000000001
01_07
Engine identifications numbers (01_07)
We always recommend checking that the prefix and number stamped on the engine
correspond to those reported on the vehicle's identification documents.
The identification number is stamped on the engine's left side.
10
1 Identification

CAUTION
BE REMINDED THAT ALTERING IDENTIFICATION REGISTRATION NUMBERS
MAY LEAD TO SERIOUS PENAL SANCTIONS (IMPOUNDING OF THE VEHICLE.
ETC.)
ENGINE IDENTIFICATION NUMBER
ENGINE PREFIX C804M *01001*
ENGINE IDENTIFICATION NUMBER (VERSION WITH
SPEED LIMITED TO 25 KM/H)
ENGINE PREFIX C805M *01001*
Inside view (01_08)
11
1 Identification

01_08
Outside view (01_09, 01_10)
12
1 Identification

01_09
13
1 Identification

01_10
14
1 Identification

APE 50 E4
Chap. 02
Safe riding
15

02_01
Safety rules (02_01)
The catalytic converter is an emission control device, mounted in the exhaust system,
whose function is to reduce the polluting agents from the exhaust gases.
CAUTION
DURING OPERATION, THE CATALYTIC SILENCER DEVELOPS HIGH TEMPER-
ATURES; THEREFORE, DO NOT STOP OR PARK THE VEHICLE ON: GRASS,
DRY LEAVES OR OTHER INFLAMMABLE MATERIALS, TO AVOID THE RISK OF
FIRE.
02_02
Safe drive (02_02)
Follow these simple recommendations to use your vehicle every day, confidently and
safely. Your skills and your mechanical knowledge are the basis for safe driving. We
recommend practising driving your vehicle in traffic-free zones, in order to get well
familiar with it.
1. Always drive within the limits of your ability, strictly following the road regu-
lations of the country where you are driving.
2. Carefully adjust the position of the rear-view mirrors to easily check the road
behind you.
3. Ensure nothing hinders the travel of controls or pedals (mats, etc.)
4. Ensure that all headlamps and lights are working properly.
5. Tostartthevehicle,withidlingengine,engagethe1stgearandgentlyrelease
the clutch lever, accelerating at the same time.
6. Reduce speed and drive carefully when on rough roads.
7. Do not brake hard on a wet, unsurfaced or slippery roads.
8. Do not downshift with the engine at high speed to avoid damaging the engine
or the gear.
9. When going downhill, do not keep the gearbox in neutral or the engine off,
but decrease speed untwisting the throttle grip. Use the brakes to help slow-
ing down the vehicle, but do not keep them pressed for extended periods, to
16
2 Safe riding

prevent brake overheating, which could reduce their efficiency. Shift down
gears to increase the engine braking effect.
10. For rapid «pick up», e.g. for overtaking, shift down a gear to get the required
torque.
11. When driving up demanding slopes, shift down to employ the maximum pow-
er.
12. Check that the load is evenly distributed on the vehicle, and do not exceed
the foreseen loads (see «Technical data» chapter) to prevent tilting while
turning on a corner.
ALWAYS DRIVE YOUR VEHICLE WITHIN THE LIMITS OF YOUR ABILITY. DRIV-
ING WHILE DRUNK OR UNDER THE EFFECT OF DRUGS OR CERTAIN MEDI-
CINES IS EXTREMELY DANGEROUS AND INFRINGES THE ROAD REGULA-
TIONS.
02_03
Engine exhaust gas (02_03)
To avoid accidents due to exhaust fumes, take the following precautions.
WARNING
•DO NOT INHALE THE EXHAUST FUMES. THEY CONTAIN CARBON
MONOXIDE, A POISONOUS, COLOURLESS AND ODOURLESS GAS.
INHALATION OF THIS GAS CAN CAUSE LOSS OF CONSCIOUSNESS
AND MAY EVEN BE FATAL.
•WHEN YOU SUSPECT THAT EXHAUST FUMES HAVE ENTERED THE
VEHICLESEARCH FOR THE CAUSE ANDELIMINATEIT IMMEDIATELY.
IFYOU HAVE TO DRIVE IN THESECONDITIONS,DO SO WITH THE SIDE
WINDOWS FULLY OPEN.
17
2 Safe riding

02_04
Maintenance (02_04)
Always keep the exhaust system, bodywork and air-conditioning system in good
working order. Ensure there are no loose connections or holes in the exhaust system.
It is advisable to have the exhaust system and the bodywork checked by an Author-
ised Piaggio Service Centre in the following cases:
•whenever there is a change in the sound of the exhaust.
•whenever the exhaust system is damaged or corroded.
•whenever it collides with an object.
CAUTION
•IT IS ALSO RECOMMENDED NOT TO LEAVE THE ENGINE RUNNING
WHEN THE VEHICLE IS STOPPED OR PARKED FOR LONG PERIODS
OF TIME, AS THERE IS A POSSIBILITY THAT EXHAUST FUMES MAY
ENTER THE VEHICLE DUE TO POOR MAINTENANCE OR TO A FAULT
IN THE EXHAUST SYSTEM.
•BEFORE STARTING UP THE ENGINE INSIDE A GARAGE OR SIMILAR
ENVIRONMENT, ALWAYS ENSURE THAT THE AREA IS NOT CLOSED
AND PERFORM ONLY PARKING MANOEUVRES.
•ENSURE THE EXHAUST PIPE IS COMPLETELY FREE FROM SNOW OR
OTHER DEBRIS IN ORDER TO PREVENT THE EXHAUST GASES FROM
ACCUMULATING UNDERNEATH THE BODY.
18
2 Safe riding

02_05
Ventilation system (02_05)
To allow the ventilation system to work properly, ensure the air intake grille, adjacent
to the headlight covers, is always clear of snow, leaves and any other obstructions.
02_06
Running-in period (02_06)
It is advisable to observe the following precautions during the first 1,000 km so as not
to compromise the vehicle performance.
•Avoid opening the throttle fully.
•Avoid travelling for any length of time at a constant speed, whether high or
low.
•Avoid abrupt braking mainly during the first 300 km, except in case of an
emergency.
It is recommended to not exceed the speeds listed below:
•1st 7 km/h;
•2nd 13 km/h;
•3rd 18 km/h;
•4th 28 km/h;
N.B.
4TH GEAR IS INHIBITED IN THE VERSION WITH SPEED LIMITED TO 25 km/h;
THEREFOREPOSITION "4" WILLNOT BE PRESENTON THE GEARINDICATOR.
19
2 Safe riding

20
2 Safe riding
