PIAGGIO NRG Power DD User manual

PIAGGIO WOULD LIKE TO THANK YOU
for choosing one of its products. We have prepared this manual to help you to get the very best from your vehicle. Please read it carefully before riding
the vehicle for the first time. It contains information, tips and precautions for using your vehicle. It also describes features, details and devices to assure
you that you have made the right choice. We believe that if you follow our suggestions, you will soon get to know your new scooter and it will serve you
well for a long time to come. This booklet forms an integral part of the vehicle; should the vehicle be sold, it must be transferred to the new owner.
NRG Power DD
Ed. 01_11/2012

The instructions given in this manual are intended to provide a clear, simple guide to using your vehicle; this booklet also details routine maintenance
procedures and regular checks that should be carried out on the vehicle at an authorised Dealer or Service Centre. The booklet also contains
instructions for simple repairs. Any operations not specifically described in this booklet require the use of special tools and/or particular technical
knowledge: to carry out these operations, refer to any authorised Dealer or Service Centres.
2

Personal safety
Failure to completely observe these instructions will result in serious risk of personal
injury.
Safeguarding the environment
Sections marked with this symbol indicate the correct use of the vehicle to prevent dam-
aging the environment.
Vehicle intactness
The incomplete or non-observance of these regulations leads to the risk of serious
damage to the vehicle and sometimes even the invalidity of the guarantee.
The signs that you see on this page are very important. They are used to highlight parts
of the booklet that should be read with particular care. The different symbols are used
to make each topic in the manual simple and quick to locate.
3

4

INDEX
VEHICLE...................................................................................... 7
Dashboard................................................................................ 8
Instruments............................................................................... 8
Digitallcddisplay........................................................................ 9
Settingthetotalandtripodometers........................................... 9
Settingthehour/minutesfunction............................................. 10
Keyswitch.................................................................................. 11
Lockingthesteeringwheel....................................................... 11
Releasingthesteeringwheel................................................... 12
Switchdirectionindicators.......................................................... 12
Hornbutton................................................................................ 13
Lightswitch................................................................................ 13
Start-upbutton........................................................................... 14
Openingthesaddle................................................................. 14
Keys.......................................................................................... 15
Identification.............................................................................. 15
Bagclip...................................................................................... 16
USE.............................................................................................. 17
Checks...................................................................................... 18
Refuelling.................................................................................. 18
Tyrepressure............................................................................. 20
Runningin.................................................................................. 21
Startinguptheengine.................................................................. 22
Difficultstartup........................................................................... 23
Stoppingtheengine.................................................................... 24
Catalyticsilencer........................................................................ 24
Automatictransmission.............................................................. 25
Safedriving................................................................................ 26
MAINTENANCE........................................................................... 29
Huboillevel................................................................................ 30
Tyres......................................................................................... 31
Sparkplugdismantlement.......................................................... 32
Removingtheairfilter.................................................................. 33
Secondaryairsystem................................................................. 34
Coolingfluidlevel........................................................................ 34
Checkingthebrakeoillevel.......................................................... 36
Battery....................................................................................... 37
Checkingtheelectrolytelevel................................................... 38
Long periods of inactivity.......................................................... 39
Fuses........................................................................................ 40
Frontlightgroup.......................................................................... 42
Headlightadjustment.............................................................. 43
Frontdirectionindicators............................................................. 43
Rearopticalunit.......................................................................... 44
Rear-viewmirrors....................................................................... 44
Idleadjustment........................................................................... 45
Frontandreardiscbrake.............................................................. 46
Puncture.................................................................................... 47
delveicolo.................................................................................. 47
Cleaningthevehicle.................................................................... 48
TECHNICALDATA....................................................................... 53
Toolkit....................................................................................... 57
SPAREPARTSANDACCESSORIES........................................... 59
Warnings................................................................................... 60
SCHEDULEDMAINTENANCE..................................................... 61
Scheduledservicingtable........................................................... 62
SelèniaMotoRider..................................................................... 65
5

6

NRG Power DD
Chap. 01
Vehicle
7

01_01
Dashboard (01_01)
A= Rear brake lever
B= Turn signal switch
C= Horn button
D= Headlight switch
E= Warning lights assembly
F= Analogue instrument panel
G= Digital dashboard
H= Starter button
L= Throttle
M= Front brake lever
01_02
Instruments (01_02)
A= High-beam indicator light;
B= Oil reserve mixer indicator light;
C= Direction indicator light;
D= Fuel reserve indicator light;
E= Lights indicator light;
F= Rev counter;
G= "Mode" key;
H= "Clock" key;
8
1 Vehicle

L= "Set" key;
M= Total/Trip odometer;
N= Speedometer;
O= Clock;
P= Coolant temperature indicator (for liquid-cooled vehicles);
S= Fuel level indicator;
01_03
Digitallcddisplay (01_03)
A: Fuel level gauge
B: Coolant temperature gauge (for liquid-cooled vehicles)
C: Digital clock
D: Speedometer
E: Odometer (km/miles)
F: Trip odometer (km/miles)
G: Total odometer (km/miles)
Settingthetotalandtripodometers
Pushing the "MODE" button for less than a second obtains, respectively, the functions
of:
1. TOTAL - The word "TOTAL" appears and Km/h or mph. The value corre-
sponds to the total distance travelled by the vehicle and it is not adjustable.
2. PARTIAL- The word "TRIP" appears and Km/h or mph. The value can be
changed by pressing and holding the "SET" button for longer than three sec-
onds.
9
1 Vehicle

N.B.
IT IS POSSIBLE TO CHANGE THE DISPLAY FROM KILOMETRES (km/h) TO
MILES (mph) BY PRESSING THE "MODE" AND "CLOCK" BUTTONS AT THE
SAME TIME AND HOLDING THEM FOR LONGER THAN THREE SECONDS AF-
TER PUTTING THE KEY SWITCH IN THE «ON» POSITION.
ON THE DISPLAY THE WORD "SET" WILL APPEAR FOR ONE SECOND
CAUTION
IT IS STRONGLY ADVISED NOT TO USE THE FUNCTIONS OF THE DIGITAL
DISPLAY PANEL WHILE THE VEHICLE IS MOVING.
Settingthehour/minutesfunction
To set the clock, hold down the «CLOCK» button for more than three seconds. The
numbers representing the hours will start blinking.
Set the hours using the «SET» button.
By pressing the «CLOCK» button again the numbers representing the minutes will
start blinking.
Set the minutes using the «SET» button.
Press the «CLOCK» button again to exit the setting mode.
Thesettingmodeisterminatedautomaticallyif,duringthesetting,nobuttonispressed
for a period longer than 8 seconds, and the last set time will be shown on the display.
N.B.
THE TIME SETTING IS IN «P.M.» MODE, WHICH MAY BE IDENTIFIED BY THE
NUMBER "0" FOLLOWING "11". IN «A.M.» MODE, THE NUMBER «12» IS DIS-
PLAYED.
10
1 Vehicle

CAUTION
THE «CLOCK» BUTTON IS ENABLED ONLY WHEN THE ENGINE IS OFF AND
THE KEY IS TURNED TO «ON».
01_04
Keyswitch (01_04)
LOCK = Ignition disabled, extractable key, steering lock engaged, seat cannot be
opened.
OFF = Ignition disabled, extractable key, steering lock disengaged, seat can be
opened.
ON = Ignition enabled, antitheft protection disconnected, non-extractable key, seat
can be opened.
To open the seat the key switch must be set to either the «OFF» or «ON» position.
Lockingthesteeringwheel
Turn the handlebar to the left (as far as it will go), turn the key to «LOCK» and remove
the key.
11
1 Vehicle

CAUTION
DO NOT TURN THE KEY TO «LOCK» OR «KEY OFF» WHILE RIDING.
Releasingthesteeringwheel
Reinsert the key and turn it to «OFF».
CAUTION
DO NOT TURN THE KEY TO «LOCK» OR «KEY OFF» WHILE RIDING.
01_05
Switchdirectionindicators (01_05)
To set the left turn indicators flashing, move lever «B» to the left; to set the right turn
indicators flashing, move it to the right. The lever automatically returns to the central
positionandtheindicatorsremainon.Toturntheindicatorsoff,pressthelevertowards
the switch.
12
1 Vehicle

01_06
Hornbutton (01_06)
Horn button «E»
01_07
Lightswitch (01_07)
0 = Low-beam and tail light
1 = High-beam and tail light
13
1 Vehicle

01_08
Start-upbutton (01_08)
To start the engine, press the starter button, «P», after pulling either one of the two
brake levers.
01_09
Openingthesaddle (01_09)
Push the key switch when it is in the «ON» or «OFF» position.
14
1 Vehicle

01_10
Keys (01_10)
The vehicle is supplied with two keys (one spare) which serve to start the engine and
unlock the saddle compartment. The keys are accompanied by a tag marked with the
identification code to be quoted when ordering duplicates.
WARNING
WE RECOMMEND KEEPING THE DUPLICATE KEY TOGETHER WITH ITS CODE
IN A SAFE PLACE AND NOT ON THE VEHICLE
01_11
01_12
Identification (01_11, 01_12)
The identification numbers consist of a prefix stamped on the chassis and on the en-
gine, followed by a number. They must be quoted when ordering spare parts. We
recommendthat youcheck thatthe prefixand chassisnumber stampedon thevehicle
correspond with those in the vehicle documents.
CAUTION
PLEASE REMIND THAT ALTERING IDENTIFICATION REGISTRATION NUM-
BERS CAN LEAD TO SERIOUS PENAL SANCTIONS (IMPOUNDING OF THE
VEHICLE, ETC.).
15
1 Vehicle

01_13
Bagclip (01_13)
To use the bag hook located on the knee-guard, it is necessary to pull it towards the
back of the vehicle.
16
1 Vehicle

NRG Power DD
Chap. 02
Use
17

Checks
Before riding the vehicle, check:
1. The fuel and oil tanks are full.
2. The rear hub oil level.
3. The tyres are inflated correctly.
4. The headlight, taillight and turn signals are working properly.
5. The front and rear brakes are in riding order.
6. The fluid level in the brake pump reservoir.
7. The coolant level in the expansion tank.
02_01
Refuelling (02_01, 02_02)
Fill up the fuel tank «A» with unleaded petrol with min number of octanes of 95. A low-
fuel warning light on the dashboard indicates the vehicle is now running on reserve.
Top-up the oil tank «B» with recommended oil. The min oil level is flagged by the
warning light located on the dashboard. The top-up should be carried out as soon as
the warning light goes on or, by all means, before covering 150 km. The vehicle is
fittedwith anelectronic system which performs a check onthe low-fueland oilwarning
lights. As the key is turned onto "ON" the low-oil warning light goes on for a few sec-
onds, indicating it is working correctly; a similar check is run by the digital display at
the same time. A failed check may indicate a fault within the dashboard. If this is the
case, please contact an Authorised Piaggio Service Station. In the event of running
out of oil, even if this has not damaged the engine, it will still be necessary to contact
an Authorised Piaggio Service Station to bleed the oil pump. If this is the case, fill
the fuel tank with at least 3 litres of petrol-oil mixture with 2% oil. Once this has been
exhausted, revert to standard, petrol fill-ups.
18
2 Use

02_02
CAUTION
SHUT OFF THE ENGINE BEFORE REFUELLING WITH PETROL. PETROL IS
HIGHLYFLAMMABLE. DO NOT LETPETROLSPILLFROMTHE TANK OR WHILE
REFUELLING
CAUTION
DO NOT BRING NAKED FLAMES OR CIGARETTES NEAR THE MOUTH OF THE
FUEL TANK: FIRE HAZARD. ALSO AVOID INHALING HARMFUL VAPOURS.
CAUTION
THE USE OF OILS AND SPARK PLUGS OTHER THAN THOSE RECOMMENDED
CAN SHORTEN THE LIFE OF THE ENGINE.
IF ONLY THE FIRST AND LAST SEGMENTS OF THE FUEL LEVEL GAUGE ARE
BLINKING,PLEASE CONTACTANAUTHRISEDPIAGGIO SERVICE STATIONSO
THAT AN INSPECTION OF THE INDICATOR MAY BE CARRIED OUT.
Recommended products
eni i-Ride PG 2t
Synthetic based lubricant for low smoke 2-stroke engines and additives.
API TC - JASO FC - ISO-L-EGD
Characteristic
Fuel tank
19
2 Use

Plastic, capacity ~ 6,5 l (approximate value) including ~ 1.5 l reserve
Oil mixer tank
In plastic, of capacity ~ 1.3 lt. (including reserve ~ 0.500 lt.)
Topping up mixer oil tank
with at least 0.5 ÷ 1 lit.
Tyrepressure
CAUTION
TYRE PRESSURE SHOULD BE CHECKED WHEN TYRES ARE COLD.INCOR-
RECT TYRE PRESSURE CAUSES ABNORMAL TYRE WEAR AND MAKES RID-
ING DANGEROUS.
TYRES MUST BE REPLACED WHEN THE TREAD REACHES THE WEAR LIMITS
SET FORTH BY LAW.
Characteristic
Front tyre pressure
1.2 bar
Rear tyre pressure
1.7 bar
Rear tyre pressure (with rider and luggage)
1.9 bar
20
2 Use
