PicnicTable WOCT001-01-280422 User manual

X4
50mm Bolt
100mm Bolt
80mm Bolt
Tabletop
x1
Table
Crossbar
x4
Seat
x4
Seat Leg
x8
Seat
Crossbar
x4
Undercarriage
Block
x1
Table Leg
x4
Contents:
Step 1:
Assemble the seat frames using 100mm, 80mm and 50mm bolts, bolting the seat legs
together with the table crossbar, and into the seat. Bolt the table leg to the table crossbar then
bolt into the seat undercarriage. Repeat x4.
Wood Octagonal Table
WOCT001-01-280422
Tools Required: 17mm Spanner
Step 2:
Move to final location and bolt the assembled seats into the undercarriage block as
shown below, using M10x100mm bolts.
Fixings QTY
M10x120 Bolt 4
M10x100 Bolt 8
M10x80mm Bolt 12
M10x50mm Bolt 12
M10 Nut 36
M10 Washer 72
Contact: Tel - 08081751903 Email - [email protected]
Web - picnictable.co.uk
THANK YOU FOR YOUR BUSINESS
Assembly Instructions

Maintenance:
Wood Octagonal Table
WOCT001-01-280422
15 years guarantee.
If damaged, repair and treatment is required.
Can be cleaned with soapy water.
Dependent on environment, more frequent treatment may be required.
Pressure treated tanalised timber (Class 4, BS EN 335-1 for direct contact with soil
and fresh water).
Step 3:
Move the tabletop into position and bolt through the legs using x4 M10x120 Bolts.
