Pidion HM50 User manual

www.mypidion.com
HM50
- Before using, please read and follow the user warnings.
- In the manual the component’s shape and color
can be different from the actual model.
-The information in the manual can vary depending
on the software version and your mobile carrier.
USER MANUAL

PIDION as the future mobile’s leading global brand, expresses with reliability,
representativeness, and image of advanced technology. It is a registered trademark from the
global brand of Bluebird Inc. and is copyright protected.
※ PLEASE READ THE WARNING SIGNS BEFORE USING THIS PRODUCT.
MODEL TYPE NOTICE TO USERS
Class B Device
(Household Information and
Communication Device)
This device has qualified the electromagnetic wave suitable registration and can be used as a
household device at a residential area as well as any other areas.
NOTICE TOUSERS
REGISTERED
∙ This user manual is copyright protected.
∙ This user manual has been created by the bluebird Inc. We have done our best not to create typos, editing errors, and leaving out any
information. Please understand if there are any inconveniences.
∙ This product’s program is legally protected. Illegal copying, transmitting, or erasing of the program is prohibited
∙ This product’s partial functions might have problems from the environment, user program, and other machines.
∙ This wireless equipment cannot service related to safety of human lives due to possible signal interference.

HM50
1
Notice Before Using the Device
-----
2
Precautions Before Using the Battery
-
4
About the Product
-------------
5
Checking components
------------
5
Getting to know your device’s each part
-
6
Getting to know the buttons
-------
7
Learning Basics
-------------
10
Insert/Remove the battery
-------
10
Insert/Remove the USIM card
-----
12
Insert/Remove the MicroSD card
----
14
Connecting the hand-strap
------
17
Charging with Cradle
----------
19
Turning On
----------------
20
Soft Reset
----------------
21
Hard Reset
----------------
22
Using the Stylus Pen
-----------
23
Adjusting the Display
----------
23
Connecting ActiveSync
-------
24
Installing on PC
-----------
24
Using ActiveSync
----------
26
Connecting ActiveSync
-------
29
Using the Barcode Reader
-----
30
Using the Barcodes
---------
30
Scanning with Barcodes
-------
30
Checking Barcodes
---------
31
Getting to know your Home Screen
-
32
Looking at the Home screen
-----
32
u
p photos as Home Screen Background
-
32
Adjusting Volume
----------
33
Checking Battery Level
--------
33
Inputting Text
------------
34
Selecting text input mode
------
34
Block recognizer
-----------
34
Letter recognizer
----------
35
Transcriber
-------------
36
Phone
---------------
37
Making a Call
------------
37
Receiving a Call
------------
38
Blocking a Call
-----------
38
Hanging Up
-------------
39
Contacts
--------------
40
Searching
--------------
40
Adding a Contact
---------
40
Menu
----------------
42
Camera
---------------
43
Taking Photos
------------
43
Viewing Photos
-----------
44
Settings
---------------
46
Device Specifications
--------
59
Q & A
---------------
60
Service Center
------------
61
Warranty Certificate ---------
63
Contents

2
HM50 Manual
∙ In case your device is wet, do not put your device in
heaters, microwaves, or etc to dry- there is a risk of
explosion or it can be the cause of malfunction. (Please
note there is a label in the device that changes color
when it gets wet. In this case your will not be able to
get your free repair service.)
∙Do not use your device on-board an airplane or in
hospitals.
∙Please backup your device’s inner data and information.
During the repair or upgrade, there is a slight possibility
of your data being erased. (Ring tones, text/voice
message, characters will be reset.)
Notice Before Using Device
∙This device is qualified of electromagnetic wave human
safety standards. For your own safety please use the
authenticated devices only from the head company. If
not the case, we cannot guarantee your safety.
∙Do not press the power button or the power adepter/
cord when the device is wet. There is a danger of
electrical shock.
∙Do not remodel, take apart, or repair the device. Please
refer to your customer service center. If not the case,
you will not be able to get your free repair service.
∙Please follow instructions when using the batter.
∙Do not use your device at an explosive danger zone.
This information is for your own safety. Please observe the following precautions

HM50
3
∙Please refrain from using your device while driving. If
you are in an unavoidable situation, stop your vehicle or
use your hand free kit.
∙Do not use in places of high temperature and
high humidity. The following can be the causes of
malfunction: getting wet from the rain, spilling drinks,
and taking it in with you at the sauna (high temp.) In
these cases, you cannot receive your free repair service.
∙Do not place credit cards, phone cards, bankbook, and
tickets next to the device. The device’s magnetism can
damage the listed item’s information.
∙Please avoid impacts or vibrations. When not using the
device unplug the power cord and place it at a safe
place where it will not drop.
∙ Do not place your device at a dusty place. Keep your
power cord away from any heating devices. Unplug
the power cord when cleaning. If there are any dusts or
residue clean the power cords pins thoroughly.
∙When not using a battery for long periods, please
charge it and leave in at room temperature. Even a
charged battery’s voltage will decrease over time.
∙Do not paint your device. It can damage your screen or
your device’s exterior. Also, the paint can peel off and
trigger allergies. If there is a allergic reaction please
seek medical advice.

4
HM50 Manual
∙If the battery is taken apart by impact, applied
heat, submersion, or hole-drilling, there is a risk of a
dangerous explosion. Please keep away from children
and animals.
∙Leaving the battery in a hot car or enclosed space
where there is direct sunlight, can deform or break
down the battery.
∙Please take precaution in not letting necklaces, coins
and etc touch the battery’s terminal (metal part). Do not
give an impact on the battery by a sharp object or an
animal. There is a risk of explosion.
∙Please use only the designated battery for the device.
If the original battery is not used, the device’s life may
decrease and there is a risk of explosion.
(In this case you cannot receive the free repair service)
∙When charging the battery you must use the supplied
standard power adapter. If the original adapter is not
used the battery life may decrease and may explode.
(In this case you cannot receive the free repair service)
Precautions Before Using Battery
These are safety precautions in order to prevent a dangerous accident. Please use the battery correctly and carefully
observe the instructions.

HM50
5
The images in this User’s Manual may not reflect the color and shape of the actual product.
(Please contact the Customer Care Center if you wish to purchase any additional or optional products.)
[ USB cable ][ Main set ]
1. Checking components
SCAN
[ Stylus Pen ]
[ Handstrap ]
[ Desktop Cradle ] [Battery]
[ Adaptor ]
[ SpringWire ]
About the Product

6
HM50 Manual
2. Getting to know your device's each
Power/Programmable
LED
Phone Speaker
Screen
End Button
Microphone
Cradle I/O
Connector
Barcode Scan Button/
Volume Up
Volume Dowm
Barcode Scan Button
Send Button
Battery Holder
Battery Holder
PTT Button
Speaker
Barcode Scan
Stylus Pen
Battery
Camera
Flash
Handstrap Holder
Barcode Scan Window
Stylus Pen Holder

HM50
7
3. Buttons
Button Description
SCAN
Send Button
Used to start the phone program. If you press
this button once while using the phone
program, a call is made to the last party in the
call list.
SCAN
SCAN
Arrow Buttons
Used to move left/right/up/down.
SCAN
SCAN
Barcode Scan Button
Scan the barcode.
Button Description
SCAN
End Button
Ends the phone program. You can
finish a call by pressing this button
during the call.
You can also exit an application
program.
SCAN
Numeric / Alphabet / Symbol
Button
The default is Numeric. Used
to enter numbers, alphabets or
symbol.
SCAN
Backspace Button

8
HM50 Manual
Button Description
SCAN
SHIFT Button
Used to switch between Lowercase/Uppercase
English alphabet. (The default is Lowercase
English.) If you press this button once and then
an alphabet key, the uppercase of the key is
entered. Then, input mode is switched to the
lowercase. If you press this key twice, the input
mode is remained in the Uppercase like Caps
Lock until you release it. To release the Caps
Lock, you need to press the SHIFT key twice.
SCAN
Enter Button
You can change the row you are typing in.
It functions the same as the computer
enter button.
Button Description
SCAN
Power Button
Turns on the device
SCAN
Tab Button
SCAN
SPACE Button
SPACE Button
(movesone space forward)
SCAN
OK Button

HM50
9
Button Description
SCAN
Flash Button
Press this button to set the Function key.
If you press and hold this button for over 2
seconds, the LCD display light is switched
On/Off. The Display On or Off status is
maintained until you press the button again
SCAN
Fn Button
This button’s function is used as a
combination. It is used when the blue
printed button is used.
버 튼 설 명
SCAN
/
SCAN
Fn Button - NUMERIC
This button’s function is used as a
combination. It is used when the blue
printed button is used.
SCAN
Numeric / Alphabet / symbol button
The default is Numeric. Used to enter
numbers, alphabets or symbol.

10
HM50 Manual
Learning Basics
Only use the supplied adapter to charge your battery.
1-1. Insert the battery
1. Insert/Remove the battery
1 Push your battery in the direction of the arrow. 2 Turn the battery pins inside to fix the battery.
OPEN
Designed & Manufactured by
OPEN
LOCK
LOCK
MicroSD
SIM
Designed & Manufactured by
OPEN
LOCK
LOCK
MicroSD
SIM
Designed & Manufactured by
OPEN
LOCK
LOCK
MicroSD
SIM
Designed & Manufactured by
OPEN
Designed & Manufactured by
OPEN
LOCK
LOCK
MicroSD
SIM
Designed & Manufactured by
OPEN
LOCK
LOCK
MicroSD
SIM
Designed & Manufactured by
OPEN
LOCK
LOCK
MicroSD
SIM
Designed & Manufactured by

HM50
11
1-2. Removing the battery
1 Switch off PDA.
Turn the battery pins outside to remove the battery.
2 Lift off the battery to the arrow direction.
OPEN
Designed & Manufactured by
OPEN
LOCK
LOCK
MicroSD
SIM
Designed & Manufactured by
OPEN
LOCK
LOCK
MicroSD
SIM
Designed & Manufactured by
OPEN
LOCK
LOCK
MicroSD
SIM
Designed & Manufactured by
OPEN
Designed & Manufactured by
OPEN
LOCK
LOCK
MicroSD
SIM
Designed & Manufactured by
OPEN
LOCK
LOCK
MicroSD
SIM
Designed & Manufactured by
OPEN
LOCK
LOCK
MicroSD
SIM
Designed & Manufactured by

12
HM50 Manual
1 Slide in the USIM-Ⅰ card in the arrow direction.
The devices supports 2 USIM slots.
2 Push the top of the USIM card to slide it out in the arrow
direction.
2-1. Insert the USIM-Ⅰcard 2-2. Removing the USIM-Ⅰcard
2. Insert/Remove the USIM card
OPEN
LOCK
LOCK
MicroSD
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
LOCK
MicroSD
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
OPEN
LOCK
LOCK
MicroSD
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
LOCK
MicroSD
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
USIM-ⅠCard Slot

HM50
13
2
Place the USIM-II card on the holder then push down the
holder.
1 Push the USIM-II card holder to ‘OPEN’ direction then lift
up.
2-3. Insert the USIM-Ⅱcard
OPEN
LOCK
LOCK
MicroSD
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
LOCK
MicroSD
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
USIM-ⅡCard Slot

14
HM50 Manual
1 Open the storage card holder by lifting up the flap.
3-1. Insert the MicroSD Card
3. Insert/Remove the MicroSD Card
OPEN
LOCK
LOCK
MicroSD
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
LOCK
MicroSD
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
Push the top of the USIM-II card and slide it out from the holder.
2-3. Removing the USIM-Ⅱcard

HM50
15
3
Lock the storage card holder by pushing it down into place.
OPEN
LOCK
LOCK
MicroSD
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
LOCK
MicroSD
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
LOCK
MicroSD
OPEN
LOCK
SIM
2 Insert the microSD card into the storage card holder with its
gold contacts facing out.

16
HM50 Manual
∙ The SD card can break if you frequently slide in/out
or put or excessively put too much force.
∙ If the card is removed while being used or being
turned off, the data can be lost or malfunction.
∙ Please back up important data. We are not
responsible for the lost data.
∙ If the memory card does not slide out, do not
remove by force. After removing the card at the
repair center, exchange your device or get a refund.
3-3. Precautions using the MicroSD Card
With the USIM card and storage card compartment opened,
lift the storage card holder flap to open it.
3-2. Removing the MicroSD card

HM50
17
4. Connecting the hand-strap
1 Body in the groove at the bottom of the hand strap hand strap
is a push in the direction of the arrow.
2 Push your battery in the direction of the arrow.

18
HM50 Manual
3 Connect the hand-strap holder.
