Piega SUB MEDIUM User manual
THANK YOU!
And congratulations on choosing a PIEGA Sub
Medium. Use this guide for a quick and easy dive
into your personal sound adventure.
HOW TO GET STARTED
The PIEGA Sub Medium fits the Ace Wireless
speakers from PIEGA or a WiSA transmitter.
Simply follow the step-by-step instructions below
to start using your PIEGA subwoofer, or refer to
the comprehensive manual on our website if you
require further information.
1 UNPACK YOUR SUBWOOFER
Make sure that the following items are included in the
scope of delivery:
QUICK GUIDE
PIEGA SUB MEDIUM
PIEGA SUB MEDIUM
EXPECT MORE
ENGLISH
FÜR DEUTSCH BITTE WENDEN
QUICK
GUIDE
Power cable
Subwoofer
2 SET UP AND CONNECT TO POWER
Start by positioning your subwoofer and connecting it to the
power supply.
Option: WIRELESS-Mode
Select your preferred mode by flipping the «WIRELESS» switch:
Choose «ON» to enable all wireless functions and connect your
subwoofer wirelessly with your Ace speakers or any other WiSA
transmitter.
4 SET THE SUBWOOFER VOLUME
To set your subwoofer’s volume, simply adjust the «VOLUME»
knob until you get the desired result.
Tip: Subwoofers are often set too loud. Therefore, try different
volumes and, if in doubt, opt for the softer setting.
3 PAIR YOUR SUBWOOFER
Our PIEGA sub medium is an ideal addition to the Ace Wireless
loudspeaker series. To couple your subwoofer with a PIEGA Ace
Tx, press «PAIR» on your subwoofer. The «PAIR» indicator starts
to flash.
Then press «PAIR» on your Tx speaker until the «PAIR» indicator
equally starts to flash.
The connection is now being established automatically.
After approx. 20 seconds, the indicator stops blinking and
remains lit when the units are connected.
5 CONFIGURE YOUR SUBWOOFER
Besides easily establishing a wireless connection, using a
subwoofer will also simplify the loudspeaker management.
Provided that the «SOUND» switch on your Ace Tx is flipped
to «SUB», the frequency settings (adjusted by turning the
«FREQUENCY» knob) on your sub medium will be used
accordingly by your Ace speakers.
In this «SUB» setting, the lower frequencies are reproduced by
the subwoofer while the Ace speakers reproduce frequencies
higher than the selected «FREQUENCY».
Choose «OFF» to disable all wireless functions. Refer to the
online manual for further details.
Make sure the «WIRELESS» switch is flipped to «ON» during the
entire installation process.
ON 0° SAT
PAIR
OFF180° FULL
0100 50 160
ECIVRESTUPTUOTUPNI
AC 100-120/220-240V
~50/60HZ 240W
WIRELESS PHASE OUTPUT VOLUME FREQUENCY
ON 0° SAT
PAIR
OFF 180° FULL
0100
50 160
ECIVRESTUPTUOTUPNI
AC 100-120/220-240V
~50/60HZ 240W
WIRELESS PHASE OUTPUT VOLUME FREQUENCY
DO YOU NEED FURTHER INFORMATION TO
SUCCESSFULLY COMPLETE THE INSTALLATION?
A comprehensive manual on every model, including additional
instructions and FAQs, can be our website.
WARRANTY REGISTRATION
We don’t want you to miss out on our warranty period of 6 years
or 3 years on electronics, so don’t forget to register your product
on piega.ch/en/warranty-registration WE WISH YOU AN
UNFORGETTABLE
SOUND EXPERIENCE!
LEFT
MONO
RIGHT
PAIR
PAIR
SELECT
SOUND
NEUTRAL
WALL
SUB
WIRELESS
ON
OFF
ANALOG IN
AUDIO IN
AUDIO OUT
Ace
Rx
SERVICE
PAIR
LEFT
MONO
RIGHT
PAIR
WIFI
SELECT
WIFI
NETWORK
AUX/OPT
COAX
REMOTE
Ace
Tx
SOUND
NEUTRAL
WALL
SUB
WIRELESS
ON
OFF
HDMI eARC
SERVICE
ON 0° SAT
PAIR
OFF 180° FULL
0100 50 160
ECIVRESTUPTUOTUPNI
AC 100-120/220-240V
~50/60HZ 240W
WIRELESS PHASE OUTPUT VOLUME FREQUENCY
PAIR
LEFT
MONO
RIGHT
PAIR
WIFI
SELECT
WIFI
NETWORK
AUX/OPT
REMOTE
Ace
Tx
SOUND
NEUTRAL
WALL
OFF
HDMI eARC
SERVICE
RESET
ON 0° SAT
PAIR
OFF 180° FULL
0100 50 160
ECIVRESTUPTUOTUPNI
AC 100-120/220-240V
~50/60HZ 240W
WIRELESS PHASE OUTPUT VOLUME FREQUENCY
PAIR
LEFT
MONO
RIGHT
PAIR
WIFI
SELECT
WIFI
NETWORK
AUX/OPT
COAX
REMOTE
Ace
Tx
SOUND
NEUTRAL
WALL
SUB
WIRELESS
ON
OFF
HDMI eARC
SERVICE
RESET
LEFT
MONO
RIGHT
PAIR
PAIR
SELECT
SOUND
NEUTRAL
WALL
SUB
WIRELESS
ON
OFF
ANALOG IN
AUDIO IN
AUDIO OUT
Ace
Rx
SERVICE
RESET
ON 0° SAT
PAIR
OFF 180° FULL
0100 50 160
ECIVRESTUPTUOTUPNI
AC 100-120/220-240V
~50/60HZ 240W
WIRELESS PHASE OUTPUT VOLUME FREQUENCY
PAIR
LEFT
MONO
RIGHT
PAIR
WIFI
SELECT
WIFI
NETWORK
AUX/OPT
COAX
REMOTE
Ace
Tx
SOUND
NEUTRAL
WALL
SUB
WIRELESS
ON
OFF
HDMI eARC
SERVICE
RESET
LEFT
MONO
RIGHT
PAIR
PAIR
SELECT
SOUND
NEUTRAL
WALL
SUB
WIRELESS
ON
OFF
ANALOG IN
AUDIO IN
AUDIO OUT
Ace
Rx
SERVICE
RESET
ON 0° SAT
PAIR
OFF 180° FULL
0100 50 160
ECIVRESTUPTUOTUPNI
AC 100-120/220-240V
~50/60HZ 240W
WIRELESS PHASE OUTPUT VOLUME FREQUENCY
PAIR
LEFT
MONO
RIGHT
PAIR
WIFI
SELECT
WIFI
NETWORK
AUX/OPT
COAX
REMOTE
Ace
Tx
SOUND
NEUTRAL
WALL
SUB
WIRELESS
ON
OFF
HDMI eARC
SERVICE
RESET
LEFT
MONO
RIGHT
PAIR
PAIR
SELECT
SOUND
NEUTRAL
WALL
SUB
WIRELESS
ON
OFF
ANALOG IN
AUDIO IN
AUDIO OUT
Ace
Rx
SERVICE
RESET
