pigtronix Gatekeeper Micro User manual

GATEKEEPER
User’s Guide
All contents © Bond Audio LLC 2020

2
CONTENTS
03
Introduction
04
Explanation of Controls
05
Warranty
06
Contact Information

3
Gatekeeper is a lightning fast, studio-quality noise gate that locks out unwanted noise from any rig.
Featuring Threshold and Release knobs, Gatekeeper provides 100% attenuation with unprecedented
response time and utilizes ultra high-speed J-FET circuitry to completely eliminate hum, hiss, buzz
and any other intrusive non-musical sounds from your signal path. Its wide range Threshold control
combines with exceptional headroom to deliver smooth transient response previously available only
in rackmount, studio-oriented noise gate processors. The addition of the Release knob allows the
user to control how long it takes gate to slam closed.
HEAR THAT? NOTHING.

4
EXPLANATION OF CONTROLS
Threshold is the most important control on the Gatekeeper pedal. This knob controls how
much signal is needed in order to open the gate. The hotter the signal you put into the
Gatekeeper, the lower the Threshold knob should be set.
The best way to set the Threshold knob on the Gatekeeper is to start with the knob turned
all the way counter-clockwise and then slowly move it in the clockwise direction until the
gate remains closed when you are not playing, but opens up immediately when you play a
note. The Threshold knob should be set somewhere in the region where the noise in your
system is below the level needed to open the gate and the sound of your instrument is
above the level needed to open the gate. If the Threshold knob is set completely counter-
clockwise, the gate will not open and your sound will remain muted.

5
The Release knob controls how long it will take the gate to close once your signal drops
below the level determined by the Threshold knob. The Release control changes the overall
“feel” of the way the Gatekeeper responds to your playing style. For most applications,
the fully counter-clockwise setting of the Release control is most desirable. This position
provides the fastest overall performance, closing the gate instantly when you stop playing.
As you turn the Release knob clockwise, the time it takes the gate to close increases. This
setting gives players a looser feel that extends the window of opportunity to keep the gate
open between notes as well as a smoother, more gradual gating effect.
The Mute LED turns on when the signal has fallen below the threshold needed to keep the
gate open. When the Release knob is at maximum, the pedal will mute shortly aer this light
comes on. When the Release knob is at minimum, the pedal will mute immediately when
the light comes on.
The Gatekeeper Micro requires a negative tip, 9VDC power supply.
The Gatekeeper Micro does not take batteries. The current consumption is under 20mA.
Your Pigtronix effect pedal comes with a 1-year limited warranty on parts and workmanship. During
the warranty period we will repair or replace, at our option, defective parts or pedals free of charge,
and return them to the owner. Warranty service does not include damaged, modified, or misused
pedals and such pedals will be subject to a standard repair charge.
Register your product at: pigtronix.com/product-registration
Contact us for warranty service at: [email protected]
WARRANTY

6
CONTACT INFORMATION
Address
Bond Audio LLC
141 W 28th St, Floor 4
New York, NY, 10001
Phone
631-331-7447
Email
[email protected]
Warranty Service Email
[email protected]
Warranty Contact Form
pigtronix.com/warranty
Website
pigtronix.com
YouTube
youtube.com/pigtronix
All contents © Bond Audio LLC 2020
Product manuals are offered digitally in an attempt to be mindful of our environment.
We ask that you consider the same before printing at home. Thank you!
