pigtronix Resotron User manual

RESOTRON
User’s Guide
All contents © Bond Audio LLC 2022

CONTENTS
03
Introduction
04
Explanation of Controls
05
Warranty
07
Contact Information

3
Resotron is an analog filter pedal that brings the sound of 70s keyboard
synthesizers to the world of envelope pedals for guitar, bass, and beyond. The
filter at the heart of the Resotron is based on the SSM2040 chip found in the
legendary Prophet 5 and Octave CAT synthesizers. This 24db/octave, state-
variable filter provides the full gamut of familiar envelope filter sounds with
Up and Down sweeping modes, as well as a Sensitivity control to dial in the
response of the effect based on how hard you play.
In addition to these vintage-correct filter tones, the Resotron incorporates an
analog pitch-tracking system to move the cutoff frequency of the filter up and
down. The pitch-following filter effect found in the Resotron moves around
based on the notes you play instead of how hard you play. The attack time and
rate of filter motion can be adjusted using the Glide knob to dial in how long it
takes for the cutoff to travel between pitches.
PROPHETIC SYNTH TONE.

4
EXPLANATION OF CONTROLS
Cutoff: Sets the cutoff frequency of the filter when you are not playing.
Sensitivity: Sets the dynamic response of the filter cutoff in ENV modes.
Peak: Sets the amount of Resonance “”Q”” of the filter.
Glide: Sets the attack time for the filter cutoff in Pitch mode.

5
Blend: Sets the amount of optical compression that is blended in before the filter.
Resotron requires a negative tip, 18VDC power supply.
Resotron does not take batteries.
Your new Pigtronix product is warranted to be free from defects in materials and workmanship for
1 year from the original date of purchase. Warranty applies only to the original retail purchaser of
a registered Pigtronix product, subject to the limitations contained in this warranty.
THIS WARRANTY IS EXTENDED TO THE ORIGINAL RETAIL PURCHASER OF PIGTRONIX PRODUCTS
BOUGHT ON OR AFTER JANUARY 1, 2020 ONLY AND MAY NOT BE TRANSFERRED OR ASSIGNED
TO SUBSEQUENT OWNERS. IN ORDER TO VALIDATE YOUR WARRANTY, AND AS A CONDITION
PRECEDENT TO WARRANTY COVERAGE HEREUNDER, YOU MUST REGISTER YOUR PRODUCT WITHIN
THIRTY (30) DAYS FOLLOWING THE ORIGINAL DATE OF PURCHASE. YOUR PROOF OF PURCHASE
OR SALES RECEIPT MUST ACCOMPANY ALL REQUESTS FOR WARRANTY COVERAGE— YOU MAY
SUBMIT YOUR RECEIPT ON THE REGISTRATION FORM. IF YOU DO NOT REGISTER THE PRODUCT
WITHIN 30 DAYS OF PURCHASE, YOUR PRODUCT WILL NOT BE SERVICED UNDER WARRANTY.
If your product is destroyed, lost or damaged beyond repair while in the possession of Pigtronix for
repair, Pigtronix will replace that product with one of the same or most similar style of a value not
in excess of the original purchase price of your pedal. Any insurance covering the pedal, including
but not limited to collector’s value insurance, must be carried by you at your expense.
This warranty covers the cost of both labor and materials on repairs deemed necessary by our
Customer Service Representative.
PIGTRONIX LIMITED WARRANTY
HPF / BPF / LPF: Selects the filter type.
ENV UP / PITCH / ENV DOWN: Selects the filter motion.
Oscillate: Switches the filter into self oscillation for a pitch tracking synth in PITCH mode.

6
THIS WARRANTY DOES NOT COVER:
• Any product that has been altered or modified in any way or upon which the serial number has
been tampered with or altered.
• Any product whose warranty has been altered or upon which false information has been given.
• Any product that has been damaged due to misuse, negligence, accident, or improper operation.
• The subjective issue of tonal characteristics.
• Shipping damages of any kind.
• Any product that has been subjected to extremes of humidity or temperature
• Normal wear and tear
• Any product that has been purchased from an unauthorized dealer, or upon which unauthorized
repair or service has been performed.
PIGTRONIX MAKES NO OTHER EXPRESS WARRANTY OF ANY KIND WHATSOEVER. ALL IMPLIED,
WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, EXCEEDING THE SPECIFIC PROVISIONS OF THIS WARRANTY ARE HEREBY DISCLAIMED
AND EXCLUDED FROM THIS WARRANTY. SOME STATES AND/OR COUNTRIES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF IMPLIED WARRANTIES SO THAT THE ABOVE MAY NOT APPLY TO
YOU. PIGTRONIX SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT CONSEQUENTIAL, INCIDENTAL
OR OTHER SIMILAR DAMAGES SUFFERED BY THE PURCHASER OR ANY THIRD PARTY, INCLUDING,
WITHOUT LIMITATION. DAMAGES FOR LOSS OF PROFITS OR BUSINESS OR DAMAGES RESULTING
FROM USE OR PERFORMANCE OF THE PRODUCT, WHETHER IN CONTRACT OR IN TORT, EVEN IF
PIGTRONIX OR ITS AUTHORIZED REPRESENTATIVE HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES, AND PIGTRONIX SHALL NOT BE LIABLE FOR ANY EXPENSES, CLAIMS, OR SUITS
ARISING OUT OF OR RELATING TO ANY OF THE FOREGOING.
Steps To File for Warranty Coverage:
1. Register your new guitar at http://pigtronix.com/warranty
2. Complete the warranty request form available at http://pigtronix.com/support and we will
handle it from there!

7
CONTACT INFORMATION
Address
Bond Audio LLC
141 W 28th St, Floor 4
New York, NY, 10001
Phone
631-331-7447
Email
[email protected]
Warranty Service Email
[email protected]
Warranty Contact Form
pigtronix.com/warranty
Website
pigtronix.com
YouTube
youtube.com/pigtronix
All contents © Bond Audio LLC 2022
Product manuals are offered digitally in an attempt to be mindful of our environment.
We ask that you consider the same before printing at home. Thank you!
