Introduction
Guideline Installation PikoLoad Page 6 / 32
Version 2
1Introduction
1 1 Global
The intention of this guideline is to help to install / start-up the PikoLoad unit.
Due to the different vehicle brands and models it is not possible to have a global
installation guideline. The connectors, if already factory fitted, can be found at different
locations in the vehicle.
Some tools and guidelines in this document should assist you to install the PikoLoad in the
right way.

Check of the vehicle connection
Guideline Installation PikoLoad Page 7 / 32
Version 2
2Check of the vehicle connection
Please check the existing connections of the vehicle.
Try to get the configuration of the vehicle.
2 1 Vehicle ordered with function remote download ?
If yes, the wiring harness to the C-CAN of the tachograph (green connector) should be
available in the vehicle and the tachograph is configured to support remote download.
If no, the risk is that the tachograph is not configured to support remote download. The
wiring harness to the C-CAN of the tachograph might be missing as well.
Remark:
The configuration of the tachograph to support remote download can only be
done by an authorized workshop (with a workshop card) using a workshop toll
For Continental (Siemens VDO) a CTC II is necessary
2 2 Vehicle ordered with function FMS-Standard ?
If yes, the wiring harness should be available in the vehicle and the MS gateway is
correctly configured.
If no, there might be no MS data available at PikoLoad.
Remark:
The function must be configured at the workshop of the manufacturer of the vehicle.
The configuration can only be done with the brand specific workshop tool. In most cases it
is not necessary to install additional hardware.
Depending on the brand there might be new parameters needed. In some cases it is
necessary to install a new wiring harness.
2 3 Look for the „green connector“
If you did not get any information where the connector for MS/remote download can be
found in the vehicle, try to search it near the tachograph in one of the compartments. In
most cases the connector can be found in the overhead compartment of the driver. The
connector is green and with a wiring harness of about 1m length. If you are not sure that

Check of the vehicle connection
Guideline Installation PikoLoad Page 8 / 32
Version 2
you found the correct connector, please check if the power supply (Pin 12 = clamp 30),
ground (Pin 1 = clamp 31) and the ignition (Pin 10 = clamp 15) are available.
Figure 1: „Green connector“ in overhead compartment

Installation of PikoLoad
Guideline Installation PikoLoad Page 9 / 32
Version 1
3Installation of PikoLoad
3.1.1 Make up of the MS wiring (no MS connector in the vehicle)
Make up the MS wiring in the vehicle (if no standard MS connector is available).
This step is not necessary if the vehicle has already a standard MS connector
(green colour).
1.Make up the wiring for the PikoLoad (exact description in the appendix).
Pin 1
Pin 6
Pin 9
Pin 10
Pin 12
FMS-Plug
(female)
Figure 2: Make up of FMS wiring
2.Connect the wiring to the vehicle:
Pin 1 Clamp 31 (ground)
Pin 6 CAN high (C-CAN Tacho Pin 5 + MS CAN high)
Pin 9 CAN low (C-CAN Tacho Pin 7 + MS CAN low)
Pin 10 Clamp 15 (24 V DC UBat - Ignition)
Pin 12 Clamp 30 (24 V DC)
3.1.2 Installation in the Vehicle
3.1.2.1 Standard MS connector existing or made
FMS-Plug
(female)
Pin 1
Pin 6
Pin 9
Pin 10
Pin 12
PikoLoad
Figure 3: PikoLoad wiring
Connect the wiring harness to PikoLoad

Installation of PikoLoad
Guideline Installation PikoLoad Page 10 / 32
Version 1
3.1.3 Connection to the Tachograph (change of Tacho only)
Please do this step only if your tachograph has been not factory fitted as
remote download (with green connector)
Connecting Tacho (Example is Continental)
Figure : Connection to Tachograph
1
5
4
8
Figure 5: C-CAN Tachograph Pin Assignment
Pin 1 Not used
Pin 2 GND
Pin 3 Not used
Pin 4 Not used
Pin 5 CAN high
Pin 6 Not used
Pin 7 CAN low
Pin 8 Not used
Connect the C-CAN connector (red) to the C-CAN of the tachograph.
Attention: The connectors are coded (fits only to C-CAN)!
Please do not use any other connection to the tachograph! You might disturb the
correct function of the tachograph. Please keep in mind that any work at
tachographs is only allowed by authorized workshops!
