Pinnacle Technology LP1 User manual

L
LP P1 1 L LA AB BE EL L
P
PR RI IN NT TE ER R U US SE ER R M MA AN NU UA AL L
P
Pi in nn na ac cl le e T Te ec ch hn no ol lo og gy y C Co or rp p. .

CONTENTS
1 UNPACKING THE LP LABEL PRINTER....................................................................................................... 1
2 SUMMARIZATION.......................................................................................................................................... 2
2.1 Technical Specification.............................................................................................................................. 2
2.2 Advanced Features..................................................................................................................................... 2
2.3 Dimension.................................................................................................................................................. 3
2.4 Power Switch and Communication Interface ............................................................................................ 3
3 KEYBOARD LAYOUT.................................................................................................................................... 4
4 HOW TO INSTALL PAPER ............................................................................................................................. 5
5 PC SOFTWARE INSTALLATION................................................................................................................... 8
6 COMMUNICATION....................................................................................................................................... 10
6.1 Connect LP to PC .................................................................................................................................... 10
6.2 Communication Test................................................................................................................................ 10
7 HOW TO CREATE PLU DATA...................................................................................................................... 12
8 HOW TO CREATE HOTKEY........................................................................................................................ 14
9 HOW TO PRINT HOTKEY............................................................................................................................ 16
10 LABEL DESIGN............................................................................................................................................. 21
11 SYSTEM SET MODE..................................................................................................................................... 25
12 PRINT LABEL................................................................................................................................................ 29
13 COMMUNICATION PROTOCOL................................................................................................................. 30

1
1UNPACKING THE LP LABEL PRINTER
User manual
4P9D Cable
LP1 Printer
PC Disk

2
2SUMMARIZATION
2.1 Technical Specification
Power supply: AC100―240V~50/60Hz1A
working environment: 0℃~40℃，5％~85%R.H.
storage environment: -10℃~50℃，5％~85%R.H.
Printer: ThermalPrinter
Printerhead: 72mmwidth,203Dot/in
Printspeed: 50mm/s(lightprinting)
Paperwidth: 72mm
Weight: 3Kg
Keyboard: 40membranekeys
Communicationport: PS/2,Ethernet,RS232
NAND Flash capacity: standard 16Mbit (can change to larger capacity)
2.2 Advanced Features
zProvide the label graph edition software for any label design with the scope of 30*30mm～55*60 size.
zWith auto label backing re-winder, can continuously printing labels and spit out the next label
automatically.
zIntegrate an auto-packing system with platform scale (with communication function).
zSupport UNICODE and can work with back office s/w based on NT, UNIX, INTERNET.
zCan select any kinds of font and language in PC editor application, and download for printing.
zPrinting darkness can be adjusted according to label sensitivity, and with auto compensation of voltage and
temperature changes, makes the lifetime of thermal head 2-3 times longer than normal machine's.
zSupport 60*40mm paper roll with 1000pcs labels while other competitive printer in the market only can
load paper roll with max.
zCapable of printing label, background and PLU name in different language for different countries.
zWith 65*132 graphic LCD to display commodity name, price, weight, amount and other details
information.

3
2.3 Dimension
Unit: mm
2.4 Power Switch and Communication Interface
ON OFF
Use to download data from PC or connect to scale

4
3KEYBOARD LAYOUT
Shiftthekeyfunction
Pressthekeyandholditfor2secondstoentersystemsetmode.
Confirm key
. Press key [SHIFT][COPY] to copy the last label, and stops until you press key [C]
Decimal point
Combinewithnumericalkeyshiftdigitstobarcodenumber
Cleardata
Paperfeeding

5
4HOW TO INSTALL PAPER
1. Follow the arrowhead
direction and push the two side
buttons.
2. Open the upper cover and
open the printer head

6
¾Label paper installation
3. Roll paper like the picture shows , lock the paper
edge on the winder and shut up the flake
4. Close the printer head
5. Close the cover

7
¾Receipt paper installation
Load the receipt paper like the picture shows and
then shut up the flake
Close the printer head
Close the cover

8
5PC SOFTWARE INSTALLATION
Double click lbmn602b.exe:
Click it.
Click it.

9
Click it to finish
installation.
Click it.
Here shows the
destination location.

10
6COMMUNICATION
Before you download data or driver, you need to test the communication.
6.1 Connect LP to PC
LP 4P9Dcable PC
There are 2 methods to connect LP1X and PC:
zVia Ethernet port
zVia RS232 port
6.2 Communication Test
Before you use link 32, you need to test the communication:
1. Connect LS to PC: Via Ethernet port
2. Communication Test
a) Open attached PC software LB-MNB, and choose ‘Link32’.
b) Input scale information, we suggest you connect LP to PC via Ethernet port.
2. Input the LP’s
IP address here.
1. Input printer
name
3. Double click to
choose the printer

11
3. Choose the button and click it, then, start to test communication.
<Communicating>
<Result>
Communication is OK

12
7HOW TO CREATE PLU DATA
1. Click open “PLU manager” and edit PLU information.
2. Click button
Note: if you connect LP to PC via RS232, then you should choose ‘RS-232’, choose COM port and the baud
rate ‘9600’, and input the series number of the LP1X in ‘Scale S/N’.
Select ‘TCP/IP’.
Input the LP’s IP
address here.
If the LP isn’t connected
to scale, here you should
choose ‘PCS’. Or the
label cannot be
p
rinted.

13
3. Save the PLU data
zYou can also import PLU data from excel file

14
8HOW TO CREATE HOTKEY
You can create the hotkey by “PLU manager”.
1) Download a PLU file:
Click , select a PLU file, and click “open” to download it.
Click this icon
Select this file
Click ‘Open’

15
2) Click button
Click this button
Choose the default
TCP/IP item
Click ‘OK’

16
9HOW TO PRINT HOTKEY
1. Choose ‘Preferences’in PLU Manager:
Choose this
hotkey sheet type.

17
2. Click ‘File/Hotkey sheet input’to set the hotkey table in the following interface:
first page: Font --- set the characters’font on hotkey table.
Load Plu --- click this item, you can choose the PLU in the pop-up window:
Double click the blank
to choose the PLU.
