Pioneer GM6400F - Bridgeable Amplifier User manual

Owner’s Manual
Mode d’emploi
Manual de instrucciones
BRIDGEABLE FOUR-CHANNEL POWER AMPLIFIER
AMPLIFICATEUR DE PUISSANCE PONTABLE A QUATRE CANAUX
AMPLIFICADOR DE POTENCIA DE CUATRO CANALES DE PUENTE
GM-6400F
English Français Español
CZR5556Acover.indd1 2008/08/0711:22:46

Before you start
Information to User 3
After-sales service for Pioneer products 3
Visit our website 3
Before connecting/installing the amplifier 4
Setting the Unit
What’s what 5
Setting gain properly 5
Connecting the units
Connection diagram 7
Before connecting the amplifier 7
About bridged mode 8
About suitable specification of speaker 8
Connecting the speakers 8
Connections when using the RCA input
jack 10
Connections when using the speaker input
wire 10
Connecting the power terminal 11
Connecting the speaker output
terminals 12
Installation
Before installing the amplifier 13
Example of installation on the floor mat or
chassis 13
Additional information
Specifications 14
Contents
En
2

Thank you for purchasing this PIONEER pro-
duct. It is designed to give you many years of
enjoyment.
PIONEER SUGGESTS USING A PROFES-
SIONAL INSTALLER DUE TO THE COMPLEX-
ITY OF THIS PRODUCT. Please read all
instructions and WARNINGS in this manual
before attempting operation. Should you have
any questions, contact your nearest Pioneer
authorized dealer or installation specialist.
Information to User
Alteration or modifications carried out without
appropriate authorization may invalidate the
user’s right to operate the equipment.
After-sales service for
Pioneer products
Please contact the dealer or distributor from
where you purchased this unit for after-sales
service (including warranty conditions) or any
other information. In case the necessary infor-
mation is not available, please contact the
companies listed below:
Please do not ship your unit to the companies
at the addresses listed below for repair without
advance contact.
U.S.A.
Pioneer Electronics (USA) Inc.
CUSTOMER SUPPORT DIVISION
P.O. Box 1760
Long Beach, CA 90801-1760
800-421-1404
CANADA
Pioneer Electronics of Canada, Inc.
CUSTOMER SATISFACTION DEPARTMENT
300 Allstate Parkway
Markham, Ontario L3R 0P2
1-877-283-5901
905-479-4411
For warranty information please see the Lim-
ited Warranty sheet included with this unit.
Visit our website
Visit us at the following site:
http://www.pioneerelectronics.com
1 Register your product. We will keep the details
of your purchase on file to help you refer to
this information in the event of an insurance
claim such as loss or theft.
2 Receive updates on the latest products and
technologies.
3 Download owner’s manuals, order product
catalogues, research new products, and
much more.
Before you start
En 3
English
Section
01

Before connecting/
installing the amplifier
WARNING
!Handling the cord on this product or cords as-
sociated with accessories sold with the pro-
duct may expose you to chemicals listed on
proposition 65 known to the State of California
and other governmental entities to cause can-
cer and birth defects or other reproductive
harm. Wash hands after handling.
!The use of a special red battery and ground
wire RD-223, available separately, is recom-
mended. Connect the battery wire directly to
the car battery positive terminal +and the
ground wire to the car body.
!This unit is for vehicles with a 12 V battery and
negative grounding. Before installing in re-
creational vehicles, trucks or buses, check the
battery voltage.
!Always use a fuse of the rating prescribed.
The use of an improper fuse could result in
overheating and smoke, damage to the pro-
duct and injury, including burns.
!Check the connections of the power supply
and speakers if the fuse of the separately sold
battery wire or the amplifier fuse blows. Deter-
mine and resolve the cause, then replace the
fuse with identical equivalent.
!Do not allow this unit to come into contact
with liquids. Electrical shock could result.
Also, damage to this unit, smoke, and over-
heating could result from contact with liquids.
The surfaces of the amplifier and any attached
speakers may also heat up and cause minor
burns.
!In the event of any abnormality, the power
supply to the amplifier is cut off to prevent
equipment malfunction. If this occurs, switch
the system power OFF and check the power
supply and speaker connections. If you are un-
able to determine the cause, please contact
your dealer.
!Always disconnect the negative *terminal of
the battery beforehand to avoid the risk of
electric shock or short circuit during installa-
tion.
CAUTION
!Always keep the volume low enough so that
you can hear sounds from outside the vehicle.
!Extended use of the car stereo while the en-
gine is at rest or idling may exhaust the bat-
tery.
Important (Serial number)
The serial number is located on the bottom of
this unit. For your own security and convenience,
be sure to record this number on the enclosed
warranty card.
Before you start
En
4
Section
01

What’s what
Front side
Rear side
To adjust the switch, use a flathead screwdri-
ver if needed.
1Power indicator
The power indicator lights up to indicate
power ON.
2GAIN (gain) control
Adjusting gain controls CHANNEL A (chan-
nel A) and CHANNEL B (channel B) helps
align the car stereo output to the Pioneer
amplifier. Default setting is the NORMAL
position.
If output remains low, even when the car
stereo volume is turned up, turn controls to
lower level. If distortion occurs when the car
stereo volume is turned up, turn these con-
trols to higher level.
!If using only one input plug, set the gain
controls for speaker outputs A and B to
the same position.
!For use with an RCA equipped car stereo
(standard output of 500 mV), set to the
NORMAL position. For use with an RCA
equipped Pioneer car stereo, with max.
output of 4 V or more, adjust level to
match that of the car stereo output.
3LPF (low-pass filter)/HPF (high-pass fil-
ter) select switch
Switch the settings based on the connected
speaker.
!When the Subwoofer is connected:
Select LPF. This eliminates high range
frequency and outputs low range fre-
quency.
!When the full range speaker is con-
nected:
Select HPF or OFF.HPF eliminates low
range frequency and output high range
frequency. OFF outputs the entire fre-
quency range.
4INPUT SELECT (input select) switch
Select 2CH for two-channel input and 4CH
for four–channel input.
Setting gain properly
!Protective function included to prevent
malfunction of the unit and/or speakers
due to excessive output, improper use or
improper connection.
!When outputting high volume sound etc.,
this function cuts off the output for a few
seconds as a normal function, but output
is restored when the volume of the head
unit is turned down.
!A cut in sound output may indicate impro-
per setting of the gain control. To ensure
continuous sound output with the head
unit at a high volume, set amplifier gain
control to a level appropriate for the preout
maximum output level of the head unit, so
that volume can remain unchanged and to
control excess output.
Setting the Unit
En 5
English
Section
02

!Despite correct volume and gain settings,
the unit sound still cuts out periodically. In
such cases, please contact the nearest
authorized Pioneer Service Station.
Gain control of this unit
Preout level: 2 V
(Standard: 500mV)
Above illustration shows NORMAL gain set-
ting.
Relationship between amplifier gain
and head unit output power
If amplifier gain is raised improperly, this will
simply increase distortion, with little increase
in power.
Signal waveform when outputting at
high volume using amplifier gain
control
Signal waveform distorted with high output, if
you raise the gain of the amplifier the power
changes only slightly.
Setting the Unit
En
6
Section
02

Connection diagram
1Special red battery wire
RD-223 (sold separately)
After completing all other amplifier connec-
tions, finally connect the battery wire terminal
of the amplifier to the positive (+) battery
terminal.
2Ground wire (Black)
RD-223 (sold separately)
Connect to metal body or chassis.
3Car stereo with RCA output jacks (sold sepa-
rately)
4External output
If only one input plug is used, do not connect
anything to RCA input jack B.
5Connecting wire with RCA pin plugs (sold se-
parately)
6RCA output jack
7RCA input jack A
8RCA input jack B
9Amplifier with RCA input jacks (sold sepa-
rately)
aSpeaker output terminals
Please see the following section for speaker
connection instructions. Refer to Connections
when using the speaker input wire on page 10.
bFuse (25 A) × 2
cSystem remote control wire (sold separately)
Connect male terminal of this wire to the sys-
tem remote control terminal of the car stereo
(SYSTEM REMOTE CONTROL). The female
terminal can be connected to the auto-anten-
na relay control terminal. If the car stereo
lacks a system remote control terminal, con-
nect the male terminal to the power terminal
via the ignition switch.
dFuse (30 A) × 2
eGrommet
fRear side
gFront side
Note
INPUT SELECT (input select) switch must be set.
For details, see Setting the Unit on page 5.
Before connecting the
amplifier
WARNING
!Secure the wiring with cable clamps or adhe-
sive tape. To protect the wiring, wrap sections
in contact with metal parts in adhesive tape.
!Never cut the insulation of the power supply
to feed power to other equipment. Current ca-
pacity of the wire is limited.
CAUTION
!Never shorten any wires, the protection circuit
may malfunction.
Connecting the units
En 7
English
Section
03

!Never ground speaker wire directly or band to-
gether multiple speakers’negative (*) lead
wires.
!If the system remote control wire of the ampli-
fier is connected to the power terminal via the
ignition switch (12 V DC), the amplifier will re-
main on with the ignition whether the car
stereo is on or off, which may exhaust battery
if the engine is at rest or idling.
!Install and route the separately sold battery
wire as far as possible from the speaker wires.
Install and route the separately sold battery
wire, ground wire, speaker wires and the am-
plifier as far away as possible from the anten-
na, antenna cable and tuner.
About bridged mode
Speaker impedance is max. 4 W, please carefully
check. Improper connection to the amplifier may
result in malfunction or personal injury due to
burns from overheating.
For bridged mode for a two-channel amplifier,
with a 4 Wload, either wire two 8 Wspeakers in
parallel, Left +and Right *(Diagram A) or use a
single 4 Wspeaker. For other amplifiers, please
follow the speaker output connection diagram for
bridging shown on rear: two 8 Wspeakers in par-
allel for a 4 Wload or a single 4 Wspeaker per
channel.
For any further enquiries, contact your local
authorized Pioneer dealer or customer service.
About suitable
specification of speaker
Ensure speakers conform to the following
standards, otherwise there is a risk of fire,
smoke or damage. Speaker impedance is 2 W
to 8 W,or4Wto 8 Wfor two-channel and other
bridge connections.
Subwoofer
Speaker channel Power
Four-channel output Nominal input:
Min. 70 W
Two-channel output Nominal input:
Min. 200 W
Three-channel
Speaker output A
Nominal input:
Min. 70 W
Three-channel
Speaker output B
Nominal input:
Min. 200 W
Other than subwoofer
Speaker channel Power
Four-channel output Max. input:
Min. 120 W
Two-channel output Max. input:
Min. 300 W
Three-channel
Speaker output A
Max. input:
Min. 120 W
Three-channel
Speaker output B
Max. input:
Min. 300 W
Connecting the speakers
The speaker output mode can be four-channel,
three-channel (stereo + mono) or two-channel
(stereo, mono). Connect the speaker leads
based on the mode and the figures shown
below.
Connecting the units
En
8
Section
03

Four-channel output
1Right
2Left
3Speaker out A
4Speaker out B
Three-channel output
1Right
2Left
3Speaker out A
4Speaker out B (Mono)
Two-channel output (Stereo)
1Speaker (Right)
2Speaker (Left)
Two-channel output (Mono)
1Speaker (Mono)
Connecting the units
En 9
English
Section
03

Connections when using
the RCA input jack
Connect the car stereo RCA output jack and
the RCA input jack of the amplifier.
Four-channel / Three-channel output
!Slide INPUT SELECT (input select) switch
to 4CH position.
1RCA input jack A
2RCA input jack B
3Connecting wires with RCA plugs (sold sepa-
rately)
4From car stereo (RCA output)
If only one input plug is used, e.g. when the
car stereo has only one output (RCA output),
connect the plug to RCA input jack A rather
than B.
Two-channel output (Stereo) / (Mono)
!Slide INPUT SELECT (input select) switch
to 2CH position.
1RCA input jack A
For two-channel output, connect the RCA
plugs to the RCA input jack A.
2Connecting wire with RCA pin plugs (sold se-
parately)
3From car stereo (RCA output)
Connections when using
the speaker input wire
Connect the car stereo speaker output wires
to the amplifier using the supplied speaker
input wire.
!Do not connect both the RCA input and the
speaker input at the same time.
1Car Stereo
2Speaker output
3White: CH A, Left +
4White/black: CH A, Left *
Connecting the units
En
10
Section
03

5Gray/black: CH A, Right *
6Gray: CH A, Right +
7Violet: CH B, Right +
8Violet/black: CH B, Right *
9Green/black: CH B, Left *
aGreen: CH B, Left +
bSpeaker input connector
To speaker input terminal of this unit.
Connecting the power
terminal
!The use of a special red battery and ground
wire RD-223, available separately, is recom-
mended. Connect the battery wire directly
to the car battery positive terminal (+) and
the ground wire to the car body.
WARNING
If the battery wire is not securely fixed to the term-
inal using the terminal screws, there is a risk of
overheating, malfunction and injury, including
minor burns.
1 Route battery wire from engine com-
partment to the vehicle interior.
After completing all other amplifier connec-
tions, finally connect the battery wire terminal
of the amplifier to the positive (+) battery
terminal.
1Positive (+) terminal
2Engine compartment
3Vehicle interior
4Fuse (30 A) × 2
5Insert the O-ring rubber grommet into the
vehicle body.
6Drill a 14 mm hole into the vehicle body.
2 Twist the battery wire, ground wire
and system remote control wire.
Twist
3 Attach lugs to wire ends. Lugs not sup-
plied.
Use pliers, etc., to crimp lugs to wires.
1Lug
2Battery wire
3Ground wire
4 Connect the wires to the terminal.
Fix the wires securely with the terminal
screws.
Connecting the units
En 11
English
Section
03

1System remote control terminal
2GND terminal
3Power terminal
4Terminal screws
5Battery wire
6Ground wire
7System remote control wire
Connecting the speaker
output terminals
1 Expose the end of the speaker wires
using nippers or a cutter by about 10 mm
(3/8 inch) and twist.
Twist
2 Attach lugs to speaker wire ends. Lugs
not supplied.
Use pliers, etc., to crimp lugs to wires.
1Lug
2Speaker wire
3 Connect the speaker wires to the
speaker output terminals.
Fix the speaker wires securely with the term-
inal screws.
1Terminal screws
2Speaker wires
3Speaker output terminals
Connecting the units
En
12
Section
03

Before installing the amplifier
WARNING
!To ensure proper installation, use the supplied
parts in the manner specified. If any parts
other than those supplied are used, they may
damage internal parts of the amplifier, or be-
come loose causing the amplifier to shut
down.
!Do not install in:
—Places where it could injure the driver or
passengers if the vehicle stops suddenly.
—Places where it may interfere with the dri-
ver, such as on the floor in front of the dri-
ver’s seat.
!Install tapping screws in such a way that the
screw tip does not touch any wire. This is im-
portant to prevent wires from being cut by vi-
bration of the car, which can result in fire.
!Make sure that wires are not caught in the
sliding mechanism of the seats, resulting in a
short-circuit.
!When drilling to install the amplifier, always
confirm no parts are behind the panel and
protect all cables and important equipment
(e.g. fuel/brake lines, wiring) from damage.
CAUTION
!To ensure proper heat dissipation of the ampli-
fier, ensure the following during installation:
—Allow adequate space above the amplifier
for proper ventilation.
—Do not cover the amplifier with a floor mat
or carpet.
!Avoid routing wires through hot areas, such
as near the heater outlet. Heat may damage
the insulation, resulting in a short-circuit
through the vehicle body.
!The optimal installation location differs de-
pending on the car model. Secure the ampli-
fier at a sufficiently rigid location.
!Firstly make temporary connections and
check to ensure the amplifier and system op-
erate properly.
!After installing the amplifier, confirm that the
spare tire, jack and tools can be easily re-
moved.
Example of installation on
the floor mat or chassis
1 Place the amplifier in the desired instal-
lation location.
Insert the supplied tapping screws (4 mm ×
18 mm) into the screw holes and push on the
screws with a screwdriver so they make an im-
print where the installation holes are to be lo-
cated.
2 Drill 2.5 mm (1/8 inch) diameter holes
at the imprints either on the carpet or di-
rectly on the chassis.
3 Install the amplifier with the use of
supplied tapping screws (4 mm × 18 mm).
1Tapping-screws (4 mm × 18 mm)
2Drill a 2.5 mm (1/8 inch) diameter hole
3Floor mat or chassis
Installation
En 13
English
Section
04

Specifications
Power source ............................. 14.4 V DC (10.8 V to 15.1 V
allowable)
Grounding system ................... Negative type
Current consumption ............ 35 A (at continuous power,
4W)
Average current drawn ......... 9 A (4 Wfor four channels)
15 A (4 Wfor two channels)
Fuse ................................................ 25 A × 2
Dimensions (W × H × D) ... 265 mm × 62 mm × 346
mm
(10-3/8 in. ×2-1/2 in. × 1 ft.
2 in.)
Weight .......................................... 3.8 kg (Leads for wiring not
included)
Maximum power output ....... 120 W × 4 (4 W)/300W×2
(4 W)
Continuous power output ... 60 W × 4 (at 14.4 V, 4 W,20
Hz to 20 kHz 0.2% THD)
150 W × 2 (at 14.4 V, 4 W,20
Hz to 20 kHz 0.8% THD)
75 W × 4 (at 14.4 V, 2 W,20
Hz to 20 kHz 0.8% THD)
Load impedance ...................... 4 W(2 Wto 8 Wallowable)
(Bridge connection: 4 Wto 8
Wallowable)
Frequency response ............... 10 Hz to 50 kHz (+0 dB, –1
dB)
Signal-to-noise ratio ............... 95 dB (IHF-A network)
Distortion ..................................... 0.03 % (10 W, 1 kHz)
Separation .................................. 70 dB (1 kHz)
Low pass filter:
Cut off frequency ........... 80 Hz
Cut off slope ..................... –12 dB/oct
High pass filter:
Cut off frequency ........... 80 Hz
Cut off slope ..................... –12 dB/oct
Gain control:
RCA ...................................... 200 mV to 6.5 V
Speaker .............................. 0.8 V to 26 V
Maximum input level / impedance:
RCA ...................................... 6.5 V / 22 kW
Speaker .............................. 26 V / 90 kW
CEA2006 Specifications
Power output ............................. 60 W RMS × 4 Channels (at
14.4 V, 4 Wand ≦1 % THD
+N)
150 W RMS × 2 Channels
(at 14.4 V, 4 WBRIDGE and
≦1 % THD+N)
75 W RMS × 4 Channels (at
14.4 V, 2 Wand ≦1 % THD
+N)
S/N ratio ....................................... 80 dBA (reference: 1 W into
4W)
Notes
!Specifications and the design are subject to
modifications without notice due to improve-
ments.
!The average current drawn is nearly the maxi-
mum current drawn by this unit when an
audio signal is input. Use this value when
working out total current drawn by multiple
power amplifiers.
Additional information
En
14
Appendix

PIONEER CORPORATION
4-1, MEGURO 1-CHOME, MEGURO-KU
TOKYO 153-8654, JAPAN
PIONEER ELECTRONICS (USA) INC.
P.O. Box 1540, Long Beach, California 90801-1540, U.S.A.
TEL: [phone]
PIONEER EUROPE NV
Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium
TEL: [phone]
PIONEER ELECTRONICS ASIACENTRE PTE. LTD.
253 Alexandra Road, #04-01, Singapore 159936
TEL: [phone]
PIONEER ELECTRONICS AUSTRALIA PTY. LTD.
178-184 Boundary Road, Braeside, Victoria 3195, Australia
TEL: [phone]
PIONEER ELECTRONICS OF CANADA, INC.
300 Allstate Parkway, Markham, Ontario L3R 0P2, Canada
TEL: [phone]
TEL: [phone]
PIONEER ELECTRONICS DE MEXICO, S.A. de C.V.
Blvd.Manuel Avila Camacho 138 10 piso
Col.Lomas de Chapultepec, Mexico, D.F. 11000
TEL: [phone]
先鋒股份有限公司
總公司:台北市中山北路二段44號13樓
電話: [phone]
先鋒電子（香港）有限公司
香港九龍尖沙咀海港城世界商業中心
9樓901-6室
電話: [phone]
Published by Pioneer Corporation.
Copyright ©2008 by Pioneer Corporation.
All rights reserved.
Publié par Pioneer Corporation. Copyright
©2008 par Pioneer Corporation. Tous
droits réservés.
Printed in Malaysia
Imprimé en Malaisie
<CZR5556-A>UC
<KNAZX> <08H00000>

PIONEER ELECTRONICS (USA) INC. PIONEER
ELECTRONIQUES DU CANADA, INC.
Main-d'ceuvre
1 an
< CRY1276-AlN >
Imp rime en Thailande
GARANTIE LIMITEE . . .
GARANTIE VALIDE SEULEMENT DANS LE PAYS OU LE PRODUIT A ETE ACHETE
GARANTIE
Pioneer Electronics (USA) Inc. (PUSA) et Pioneer Electronique du Canada, Inc. (POC) garantissent que les produits distribues par PUSA aux Etats-Unis et par POC au Canada qui, apres
avoir ete
instaMs et utilises conformement au manuel de I'utilisateur inclus avec I'unite, ne fonctionnent pas de fa<;:on appropriee dans des conditions d'utilisation normales en raison d'un
vice
de fabrication, seront repares ou remplaces par une unite de valeur comparable, au choix de PUSAou de POC, sans que vousdeviez payer pour les pieces ou les travaux de reparation.
Les unites ou pieces de rechange fournies en vertu de
la presente garantie peuvent etre neuves ou remises aneuf, au choix de PUSA ou de POCo
LA PRESENTE GARANTIE LIMITriE S'APPLIQUE AU PROPRIETAIRE INITIALAINSI QU'ATOUT PROPRIETAIRE SUBSEQUENT DU PRESENT PRODUIT PIONEER PENDANT LA PERIODE DE GARANTIE,
A CONDITION QUE LE PRODUIT AIT ETE ACHETE CHEZ UN DISTRIBUTEUR OU MARCHAND PIONEER AUTORISE AUX ETATS-UNIS OU AU CANADA. VOUS DEVREZ FOURNIR UN RELEVE DE CAISSE
OU UNE AUTRE PREUVE D'ACHAT VALIDE INDIQUANT LA DATE DE L'ACHAT INITIAL OU, SI VOUS LOUEZ LE PRODUIT, VOTRE CONTRAT DE LOCATION INDIQUANT L'ENDROIT ET LA DATE DE
LA PREMIERE LOCATION. SI JAMAIS UN SERVICE DE REPARATION EST REQUIS, LE PRODUIT DOlT ETRE EXPEDIE PENDANT LA PERIODE DE GARANTIE, EN PORT PREPAYE, A L'INTERIEUR DU
PAYS OU L'ACHAT A ETE EFFECTUE SEULEMENT, TEL QU'IL EST EXPLIQUE DANS LE PRESENT DOCUMENT. VOUS ETES RESPONSABLE DU DEMONTAGE ET DE L'INSTALLATION DU PRODUIT.
PUSA OU POC, LE CAS ECHEANT, PAIERA POUR VOUS RETOURNER LE PRODUIT REPARE OU REMPLACE, A L'INTERIEUR DU PAYS OU L'ACHAT A ETE EFFECTUE.
PERIODE DE GARANTIE DES PRODUITS Pieces
Prodults stereo pour I'auto 1an
La periode de garantie pour Ies clients qui louent Ie produit commence Ie jour ou Ie produit est utilise pour la premiere lois (a) pendant la periode de location ou (b) apres la vente au detail, selon ce qui sa produit en premier.
ELEMENTS NON COUVERTS PAR LA GARANTIE
UN PRODUIT ACHETE CHEZ UN DISTRIBUTEUR NON AUTORISE N'EST COUVERT PAR AUCUNE GARANTIE EXPRESSE OU IMPLICITE, YCOMPRIS QUELQUE GARANTIE
IMPLICITE DE QUALITE MARCHANDE OU D'ADAPTATION AUN USAGE PARTICULIER QUE CE SOIT. DE PLUS, CE PRODUIT EST STRICTEMENT VENDU "
TEL QUEL "ET
•AVEC TOUS SES DEFAUTS EVENTUELS ".
PIONEER N'EST PAS RESPONSABLE DE QUELQUE DOMMAGE CONSECUTIF ET(OU) INDIRECT QUE
CE SOIT.
PIONEER NE GARANTIT PAS LES PRODUITS ENUMERES CI-DESSUS LORSQU'ILS SONT UTILISES ADES FINS COMMERCIALES
OU PROFESSIONNELLES, OU AU SEIN
DE TOUTE APPLICATION INDUSTRIELLE OU COMMERCIALE QUE CE SOIT.
LA PRESENTE GARANTIE NE S'APPLIQUE PAS 51 LE PRODUIT AETE SOUMIS AUNE PUISSANCE NOMINALE EXCEDANT CELLE QUI AETE ETABLIE DANS LES
DOCUMENTS S'Y APPLIQUANT.
LA PRESENTE GARANTIE NE COUVRE PAS LES TELEVISEURS OU LES ECRANS ENDOMMAGES EN RAISON DE L'APPLICATION D'IMAGES STATIQUES ET 1M MOBILES
PENDANT DE LONGUES PERIODES (IMAGES REMANENTES).
LA PRESENTE GARANTIE NE COUVRE PAS LE COFFRAGE OU LES ELEMENTS ESTHETIQUES, LES ANTENNES INSTALLEES PAR L'UTILISATEUR, LES DOMMAGES AUX
DISQUES OU AUX RUBANS
OU DISQUES D'ENREGISTREMENT, LES DOMMAGES AU PRODUIT DECOULANT D'UNE RETOUCHE, D'UNE MODIFICATION NON AUTORISEE
PAR ECRIT PAR PIONEER, D'UN ACCIDENT, D'UN USAGE INAPPROPRIE
OU D'UN USAGE ABUSIF, LES DOMMAGES PRODUITS PAR LA FOUDRE OU LA SURTENSION,
LES DOMMAGES SUBSEQUENTS DECOULANT DE FUITES, LES DOMMAGES DECOULANT DE PILES DEFECTUEUSES OU DE L'UTILISATION DE PILES NON
CONFORMES ACELLES QUI
SO NT SPECIFIEES DANS LE MANUEL DE L'UTILISATEUR.
LA PRESENTE GARANTIE NE COUVRE PAS LE COOT DES PIECES OU DE LA MAIN-D'CEUVRE QUI SERAIENT AUTREMENT OFFERTES SANS FRAIS EN VERTU DE LA
PRESENTE GARANTIE, 51 ELLES SO NT OBTENUES AUPRES D'UNE SOURCE AUTRE QU'UNE SOCIETE DE SERVICE OU AUTRE AUTORISEE OU DESIGNEE PAR
PIONEER.
LA PRESENTE GARANTIE NE COUVRE PAS LES DEFECTUOSITES OU LES DOMMAGES CAUSES PAR L'UTILISATION D'UNE MAIN-D'CEUVRE OU DE PIECES
NON AUTORISEES, NI D'UN ENTRETIEN
INA DE QUAT.
LES NUMEROS
DE SERlE MODIFIES, OBLITERES OU ENLEVES ANNULENT LA PRESENTE GARANTIE DANS SA TOTALITE.
INVALIDITE DE TO UTE AUTRE GARANTIE
AUX ETATS-UNIS -PIONEER LIMITE SES OBLIGATIONS EN VERTU DE TOUTE GARANTlE IMPLICITE QUE CE SO IT, YCOMPRIS ENTRE AUTRES LES GARANTIES IMPLICITES
DE QUALITE MARCHANDE OU D'ADAPTATION A
UN USAGE PARTICULIER, AUNE PERIODE N'EXCEDANT PAS LA PERIODE DE GARANTIE. AUCUNE GARANTIE NE S'APPLIQUE
APRES LA PERIODE
DE GARANTIE. CERTAINS ETATS NE PERMETTENT PAS LA LIMITATION DE LA DUREE D'UNE GARANTIE IMPLICITE, ET CERTAINS NE PERMETTENT PAS
L'EXCLUSION OU
LA LIMITATION DES DOMMAGES CONSECUTIFS OU INDIRECTS. LES LIMITATIONS ET EXCLUSIONS ETABLIES CI-DESSUS PEUVENT DONC NE PAS
S'APPLIQUER AVOUS.
LA PRESENTE GARANTIE VOUS DONNE DES DROITS LEGAUX SPECIFIQUES. VOUS POUVEZ JOUIR D'AUTRES DROITS, QUI PEUVENT VARIER D'UN
ETAT AL'AUTRE.
AU
CANADA -SOUS RESERVE DE CE QUI EST EXPRESSEMENT STIPULE DANS LES PRESENTES, AUCUNE REPRESENTATION, GARANTIE, OBLIGATION OU CONDITION,
QU'ELLE SOIT IMPLICITE, OBLIGATOIRE OU AUTRE, NE S'APPLIQUE ACE PRODUIT.
SERVICE
Pour profiter du service en vertu de la garantie aux Etats-Unis et au Canada, vous devez presenter votre releve de caisse ou, si vous louez Ie produit, votre contrat de location
indiquant I'endroit et la date de la transaction par Ie premier proprietaire.
AUX ETATS-UNIS - Communiquez avec un des partenaires Pioneer suivants pour Ie service:
Votre marchand Pioneer autorise - Votre marchand Pioneer peut reparer ou remplacer votre unite, ou bien vous diriger vers une societe de service Pioneer autorisee. Votre re<;:u
de caisse devrait enumerer ses coordonnees (numeros de telephone et de telecopieur, courriel, etc.).
Volre societe de service autorisee .Celle-ci peut reparer la plupart des produits electroniques pour I'auto et vous aviser des options supplementaires qui pourraient s'appliquer.
Veuillez
acceder au site Web de Pioneer a www.pioneerelectronics.com.cliquer sur I'onglet" Service and Support" et choisir "Authorized Service Locator" pour trouver la societe
de service Pioneer la plus proche.
Pioneer Electronics Service -Ce service peut vous aviser des options de service optimales pour votre modele et votre emplacement geographique. Veuillez consulter les coordonnees
ci-dessous pour communiquer avec Pioneer par telephone, par courrier ou par Ie biais de son site Web.
AU CANADA -POC a designe un certain nombre de societes de service autorisees partout au Canada si jamais vous avez besoin de services de reparation pour votre produit.
Communiquez avec Pioneer Electronique du Canada (Ies coordonnees se trouvent ci-dessous) pour trouver une societe de service autorisee.
Expedition de votre unite aux fins de service -Si vous expediez I'unite, vous devez I'emballer soigneusement etl'envoyer a une societe de service autorisee ou a Pioneer,
en port prepaye et selon une methode de transport pouvant etre suivie et assuree. Emballez Ie produit au moyen de materiaux coussines adequats pour eviter les dommages
pendant Ie transport. Incluez votre nom, vqtre adresse et un numero de telephone ou nous pouvons vous joindre pendant les heures de bureau.
Pour toutes les plaintes et problemes aux Etats-Unis, communiquez avec Ie service de Soutien ala clientele au 1-800-421-1404. Au Canada, communiquez avec Ie groupe de
Satisfaction de la clientele au 1-877-283-5901.
Pour Ie raccordement ou Ie fonctionnement de votre unite, ou pour trouver une societe de service autorisee, appelez ou ecrivez a:
AUX ETATS-UNIS AU CANADA
PIONEER ELECTRONICS SERVICE, INC. GROUPE DE SATISFACTION DE LA CLiENTIOLE
P.O.
BOX 1760 PIONEER ELECTRONIQUES DU CANADA, INC.
LONG BEACH, CALIFORNIA 90801 300 ALLSTATE PARKWAY
1-800-421-1404 MARKHAM, ON L3R OP2
[phone]
http://www.pioneerelectronics.com1-877-283-5901
http://www.pioneerelectronics.ca
REGLEMENT DES CONFLITS
AUX ETATS-UNIS - 51 un contlit se produit entre vous et Pioneer apres la reponse it une demande Initiale falte au service de Soutien it la clientele, vous pouvez avoir
recours au Programme de resolution des plaintes de Pioneer pour resoudre Ie conflit. Ce programme vous est offert sans frals. Vous devez avolr recours au Programme
de resolution des plalntes avant de vous prevalolr de vos droits ou de chercher reparation en vertu du Titre I de la loi Magnuson-Moss Warranty-Federal Trade Commission
Improvement Act, 15 U.S.C. 2301 et S.S.
Pour avoir recours au Programme de resolution des plaintes, appelez au 1 800421-1404 et expllquez au representant du service ala clientele qui vous repondra Ie
probleme auquel vous faites face et les demarches que vous avez entreprises pour falre reparer Ie produit pendant la periode de garantie, puis donnez-Iui Ie nom du
dlstrlbuteur I marchand auto rise aupres duquel vous vous etes procure Ie produit Pioneer. Une fois que votre plainte a ete expllquee au representant, un numero de
resolution vous sera communique. Pioneer etudiera Ie confllt et, dans un delai de quarante (40) jours apres la reception de votre plainte, (1) repondra a votre plainte
par' ecrit pour vous aviser des demarches qu'elle entreprendra pour resoudre Ie conlllt, et indiquera combien de temps ces demarches prendront ; ou (2) repondra
a votre plalnte par ecrit pour vous indlquer les raisons pour lesquelles elle n'entreprendra aucune demarche. •
AU
CANADA - Communlquez avec Ie dlrecteur de la Satisfaction de la clientele au [phone] pour discuter de votre plainte et resoudre rapldement Ie probleme.
ENREGISTREZ LE LIEU ET LA DATE D'ACHAT POUR REFERENCE ULTERIEURE
NO.du modele :NO.deserie : _
Dated'achat: Achete de: _
PRENEZSOINDEGARDERCETTEINFORMAlmETVOTRER~UDACHATDANSUNENDROlTSOR

PIONEER ELECTRONICS (USA) INC. PIONEER
ELECTRONICS OF CANADA, INC.
LIMITED WARRANTY
WARRANTY VALID ONLY IN COUNTRY OF PRODUCT PURCHASE
WARRANTY
Pioneer Electronics (USA) Inc. (PUSA), and Pioneer Electronics Of Canada, Inc. (POC), warrant that products distributed by PUSA in the U.S.A., and by POC in Canada that fail to
function properly under normal use due to amanufacturing defect when installed and operated
a=rding to the owner's manuai erclosed with the unit will be repaired or replaced with a
unit
of comparable value, at the option of PUSA or POC, without charge to you for parts or actual repair work. Replacement units and/or parts supplied under this warranty may be
new or rebuilt at the option
of PUSA or POCo
THISLIMITED WARRANTY APPLIES TO THE ORIGINAL OR ANY SUBSEQUENT OWNER OFTHIS PIONEER PRODUCT DURINGTHE WARRANTY PERIODPROVIDEDTHE
PRODUCT WAS PURCHASED FROM AN AUTHORIZED PIONEER DISTRIBUTORIDEALER INTHE U.S,A, OR CANADA. YOU WILL BE REQUIREDTO PROVIDEA SALES
RECEIPT OR OTHER VALID PROOF OF PURCHASE SHOWING THE DATE OF ORIGINAL PURCHASE OR, IFRENTED, YOUR RENTAL CONTRACT SHOWING THEPLACE
ANDDATE OF RRST RENTAL. INTHE EVENTSERVICEISREQUIRED,THE PRODUCTMUSTBEDELIVEREDWITHINTHEWARRANTYPERIOD, TRANSPORTATION PREPAID,
ONLY FROM WITHIN THE COUNTRY OF PURCHASE AS EXPLAINED IN THIS DOCUMENT, YOU WILL BE RESPONSIBLE FOR REMOVAL AND INSTALLATION OF THE
PRODUCT. PUSA OR POC, AS APPROPRIATE, WILL PAY TO RETURN THE REPAIRED OR REPLACEMENT PRODUCT TO YOU WITHIN THE COUNTRY OF PURCHASE.
PRODUCT WARRANTY PERIOD ~ Idb2r
Car Stereo Products ,........................... 1 Year 1 Year
The warranty period for retail customers who rent the product commences upon the date product is first put into use (a) duringthe rental period or (b) retail sale, whichever occurs first.
WHAT IS NOT COVERED
IFTHISPRODUCT WAS PURCHASEDFROMANUNAUTHORIZEDDISTRIBUTOR,THEREARE NO WARRANTIES, EXPRESS OR IMPLIED,INCLUDINGTHEIMPUEDWARRANTY
OFMERCHANTABILITY
AN[)THE IMPLIEDWARRANTY OFRTNESSFORAPARTICULAR PURPOSEANDTHISPRODUCTISSOLDSTRICTLY "AS IS" AND 'WITH ALL FAULTS".
PIONEER
SHALL NOTBELIABLEFOR ANYCONSEQUENTIALANDIORINCIDENTALDAMAGES.
PIONEERDOESNOT
WARRANT ANYPRODUCTLISTED ABOVE WHEN IT ISUSEDINATRADEOR BUSINESS OR IN ANYINDUSTRIALOR COMMERCIALAPPLICATION.
THISWARRANTYDOES NOTAPPLYIFTHE PRODUCT HASBEENSUBJECTED
TO POWER IN EXCESSOFITSPUBLISHED POWER RATING.
THIS
WARRANTY DOESNOTCOVER DISPLAYSCREENS DAMAGED BY STATIC, NON-MOVING,IMAGESAPPLIEDFOR LENGTHYPERIODS(BURN-IN).
THISWARRANTYDOESNOTCOVERTHECABINETORANYAPPEARANCEfTEM,USERATTACHEDANTENNA,ANYDAMAGETORECORDSORRECORDINGTAPESOR
DIscs, ANY
DAMAGETOTHEPRODUCTRESUL TING FROMALTERATIONS,MODIFICATIONSNOTAUTHORIZED INWRmNG BY PIONEER,ACCIDENT, MISUSE OR ABUSE,DAMAGEDUETO
UGHTNINGORTOPOWERSURGES,SUBSEQUENTDAMAGEFROMLEAKlNG,DAMAGEFROMINOPERAnvEBATTERIES,ORTHEUSEOFBATTERIESNOTCONFORMINGTOTHOSE
SPECIREDINTHEOWNER'S
MANUAL
THISWARRANTYDOESNOTCOVERTHECOSTOFPARTSOR LABOR WHICHWOULO BE OTHERWISEPROVIDEDWITHOUTCHARGEUNDERTHISWARRANTYOBTAINEDFROM
ANYSOURCEOTHERTHANAPIONEERAUTHORIZEDSERVlCECOMPANYOROTHERDESIGNATEDLOCATION.THISWARRANTYDOESNOTCOVERDEFECTSORDAMAGECAUSED
BYTHE USEOFUNAUTHORIZEDPARTSOR LABOROR FROMIMPROPERMAINTENANCE.
ALTERED,DEFACED,ORREMOVEDSERIALNUMBERSVOIDTHISENTIREWARRANTY
NOOTHER WARRANTIES
IN THE U.S.A. - PIONEER LIMITS ITS OBLIGATIONS UNDER ANY IMPLIED WARRANTIES INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESSFORA PARTICULAR PURPOSE, TO APERIOD NOTTO EXCEEDTHE WARRANTY PERIOD. NO WARRANTIES SHALL APPLY AFTER THE
WARRANTY PERIOD. SOME STATES DO NOTALLOW LIMITATIONSON HOWLONGAN IMPUEDWARRANTYLAS TSANDSOME STATES DO NOTALLOWTHE EXCLUSlONS
OR LIMITATIONSOF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SOTHEABOVE LIMITATIONSOR EXCLUSIONS MAY NOT APPL YTO YOU. THIS WARRANTY GIVES
YOU
SPECIRC LEGAl. RIGHTS AND YOU MAY HAVE OTHERRIGHTSWHICH MAY VARYFROM STATE TO STATE.
IN
CANADA -EXCEPT AS EXPRESSLY PROVIDEDHEREIN, THERE ARE NO REPRESENTATIONS,WARRANTIES, OBLIGATIONS OR CONDITIONS,IMPLIED, STATUTORY
OROTHERWISE, APPLICABLE TO THIS PRODUCT.
TO OBTAIN SERVICE
In the U.S.A. or Canada to receive warranty service you need to present your sales receipt or your rental contract showing place and date of original owner's transaction.
~ - Please contact one of the follOWing Pioneer partners to obtain service:
Your Authorized Pioneer Dealer - Your Pioneer Dealer may repair or replace your unit, or refer you to an Authorized Pioneer Service Company. Your sales receipt should
list
the contact information (phone number, fax, email, etc.) for your Dealer.
Your Authorized Pioneer Service Company - Can perform repairs for most Car Electronics products and can advise other options as applicable. Please access the
Pioneer website at www.pioneerelectronics.com and click on Service and Support and seiect Authorized Service Locator to find the nearest Pioneer servicer.
Pioneer Electronics Service - Can advise the optimal service option for your model and geographic location. Please reference the information listed below and phone,
email or access the Pioneer website to contact Pioneer.
CANADA -POC has a number of Authorized Service Companies should your product require service.Contact Pioneer of Canada as listed below to obtain alocal service location.
Shipping Your Unit for Service -Please package it carefully and send it, transportation prepaid by atraceable, insured method, to an Authorized Service Company or Pioneer.
Use
adequate padding material to prevent damage in transit. Include your name, address and telephone number where you can be reached during business hours.
On all complaints and concerns in the U.S.A. call Customer Support at 1-800-421-1404, or, in Canada, call Customer Satisfaction at 1-877-283-5901.
IN THE U.S.A. IN CANAPA
For hook-up and \lperation
of your unit or to locat~ an For additional information on this warranty, please call or write:
AuthOrized Service Company, please call
or write: CUSTOMERSATISFACTIONGROUP
PIONEERELECTRONICSSERVICE,INC. PIONEERELECTRONICS
OF CANADA INC
P.O. BOX 1760 300
ALLSTATE PARKWAY , .
LONG BEACH, CALIFORNIA 90801 MARKHAM ON L3R
OP2
1-800-421-1404 [phone]' 1-877-283-5901
http://www.pioneerelectronics.com http://www.pioneerelectronics.ca
DISPUTERESOLUTION
IN THE U.S.A. -Following our response to any initial request to Customer Support, should adispute arise between you and Pioneer, Pioneer makes available its Complaint
Resolution Program to resolve the dispute. The Complaint Resolution Program is available to you without charge. You are required to use the Complaint Resolution Program
before you exercise
any rights under, or seek any remedies, created by Title Iof the Magnuson-Moss Warranty-Federal Trade Commission Improvement Act, 15 U.S.C. 2301 et seq.
To use the Complaint Resolution Program call 1-800-421-1404 and explain to the customer service representative the problem you are experiencing, steps you have taken
to
have the product repaired during the warranty period and the name of the authorized Distributor/Dealer from whom the Pioneer product was purchased. After the complaint
has been explained to the representative, aresolution number will be issued. Within 40 days of receiving your complaint, Pioneer will investigate the dispute and will either:
(1) respond to your
complaint in writing informing you what action Pioneer will take, and in what time period, to resolve the dispute; or (2) respond to your complaint in writing
informing you why it will not take any action.
IN
CANADA -Call the Customer Satisfaction Manager at [phone] to discuss your complaint and to obtain a prompt resolution.
RECORDTHE PLACE AND DATE
OF PURCHASE FOR FUTURE REFERENCE
Model No. Serial No. .Purchase Date _
Purchased From KEEP THIS INFORMATION AND YOUR SALES RECEIPT
IN ASAFE PLACE <CRY1276-A/N >
Printed in Thailand
