Pioneer PD-F907 User manual

BASIC OPERATIONS
BEFORE OPERATING VARIOUS
OPERATIONS
1
<PRB1268>
En
MODE HI-LITE CLEAR PROGRAM RANDOM REPEAT
UNLOAD BEST PREVIOUS DISC
OPEN/
CLOSE
D
FILE–TYPE
COMPACT DISC PLAYER
◊Û¿X/?≥
Î
SINGLE
LOADER
ACSESS
PLAY
STANDBY / ON
POWER
67 ¡¢
'
FILE –TYME CD MECHANISM
DISC MIN SEC
CUSTOM ALL
TRACK
I II III SINGLE
RANDOM REPEAT 1REMAIN PGM
PREVIOUS
DISC SCAN BEST
41
1-BIT DLC
DIRECT LINER CONVERSION
◊Û¿X/?≥ '
FILE-TYPE COMPACT DISC PLAYER
CONTENTS
BEFORE YOU USE THE PLAYER ....................................... 4
CAUTIONS REGARDING HANDLING................................. 5
CONNECTIONS .................................................................. 6
NAMES OF PARTS ............................................................. 7
HOW TO LOAD THE DISCS ............................................... 9
BASIC OPERATIONS
To listen in order from the first track............................. 10
To select the disc and track .......................................... 10
To select a play mode ................................................... 10
Playing a disc in the Single Loader slot ......................... 11
The hood can be opened or closed during playback ..... 11
VARIOUS OPERATIONS
To program and play only the discs you want to hear... 12
To start playback from a specific disc ........................... 13
To play a track you want to hear ................................... 13
To repeat playback ........................................................ 13
To playback tracks/discs at random .............................. 14
To program tracks/discs in a desired order ................... 15
To store your favorite tracks ......................................... 16
To find out which discs you’ve listened to recently ...... 16
To scan quickly through tracks on a disc....................... 17
To use the TIME button ................................................ 18
TROUBLESHOOTING ....................................................... 19
SPECIFICATIONS.............................................................. 20
POWER ON DEMO display mode allows you
to see variations of the display. To enter the
POWER ON DEMO display mode, press
STANDBY/ON and then 41within 1 sec-
ond after turning on the power.
POWER ON DEMO display
To cancel the POWER ON DEMO display
mode, press any button.
BASIC OPERATIONS
BEFORE OPERATING VARIOUS
OPERATIONS
783
1¡4¢
RANDOM
DISC
DISC
SET
0
TRACK
SET
789
456
123
TIME
HI-LITE BEST
PREVIOUS POWER
MODE CLEARPGMREPEAT
D
Î
FILE-TYPE CD PLAYER
REMOTE CONTROL UNIT
CU-P0090
–+
Thank you for buying this Pioneer product.
Please read through these operating instructions so you
will know how to operate your model properly. After you
have finished reading the instructions, put them away in a
safe place for future reference.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
IMPORTANT NOTICE
The serial number for this equipment is located on the rear panel.
Please write this serial number on your enclosed warranty card
and keep it in a secure area. This is for your security.
Thisplayerisforconsumeruse. Iftheplayerisusedinabusiness
(forexample,usedfora longperiodatarestaurant),theplayerwill
not be covered under warranty.
CD Video, VIDEO CD, CD graphics, DVD and CD-ROM discs can
not be played with this player.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

2
<PRB1268>
En
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presenceofuninsulated"dangerousvoltage" within the
product'senclosurethatmaybeofsufficientmagnitude
to constitute a risk of electric shock to persons.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
IMPORTANT
CAUTION:
TOPREVENT THE RISKOF ELECTRICSHOCK, DONOT
REMOVECOVER(ORBACK). NOUSER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operatingandmaintenance(servicing)instructionsinthe
literature accompanying the appliance.
READ INSTRUCTIONS — All the safety and operating
instructions should be read before the product is
operated.
RETAIN INSTRUCTIONS — The safety and operating
instructionsshouldberetainedforfuturereference.
HEED WARNINGS — All warnings on the product and
in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS — All operating and use
instructions should be followed.
CLEANING — Unplug this product from the wall outlet
beforecleaning.Theproductshouldbecleanedonly
withapolishingclothorasoftdrycloth.Neverclean
with furniture wax, benzine, insecticides or other
volatile liquids since they may corrode the cabinet.
ATTACHMENTS — Do not use attachments not
recommendedbytheproductmanufacturerasthey
may cause hazards.
WATER AND MOISTURE — Do not use this product
near water — for example, near a bathtub, wash
bowl,kitchensink,orlaundrytub;inawetbasement;
or near a swimming pool; and the like.
ACCESSORIES — Do not place this product on an
unstable cart, stand, tripod, bracket, or table. The
product may fall, causing serious injury to a child or
adult, and serious damage to the product. Use only
with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with
the product. Any mounting of the product should
follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the
manufacturer.
CART — A product and cart combination should be
movedwithcare.Quickstops,excessiveforce,and
uneven surfaces may cause the product and cart
combination to overturn.
GROUNDING OR POLARIZATION
÷Ifthisproductisequippedwithapolarizedalternating
currentlineplug(aplughavingonebladewiderthan
theother),itwillfitintotheoutletonlyoneway.This
isasafetyfeature.Ifyouareunabletoinserttheplug
fullyintotheoutlet,tryreversingtheplug.Iftheplug
should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
÷If this product is equipped with a three-wire
groundingtypeplug,aplughavingathird(grounding)
pin,itwillonlyfitintoagroundingtypepoweroutlet.
Thisisasafetyfeature.Ifyouareunabletoinsertthe
plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the
safety purpose of the grounding type plug.
POWER-CORD PROTECTION — Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
againstthem,paying particularattention to cordsat
plugs,conveniencereceptacles,andthepointwhere
they exit from the product.
OUTDOOR ANTENNA GROUNDING — If an outside
antennaorcablesystemisconnectedtotheproduct,
besuretheantennaorcablesystemisgroundedso
astoprovidesomeprotectionagainstvoltagesurges
andbuilt-upstaticcharges.Article810oftheNational
ElectricalCode,ANSI/NFPA70,providesinformation
with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit,
connection to grounding electrodes, and
requirementsforthegroundingelectrode.SeeFigure
A.
LIGHTNING — For added protection for this product
duringalightningstorm,orwhenitisleftunattended
and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the product
due to lightning and power-line surges.
POWER LINES — An outside antenna system should
notbelocatedinthevicinityofoverheadpowerlines
or other electric light or power circuits, or where it
can fall into such power lines or circuits. When
installingan outsideantenna system, extremecare
should be taken to keep from touching such power
linesorcircuitsascontact with themmightbe fatal.
OVERLOADING — Do not overload wall outlets,
extensioncords,orintegralconveniencereceptacles
as this can result in a risk of fire or electric shock.
OBJECTAND LIQUID ENTRY —Never pushobjects of
any kind into this product through openings as they
may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
SERVICING — Do not attempt to service this product
yourselfasopeningorremovingcoversmayexpose
you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
DAMAGEREQUIRINGSERVICE—Unplugthisproduct
from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
÷When the power-supply cord or plug is damaged.
÷If liquid has been spilled, or objects have fallen into
the product.
÷If the product has been exposed to rain or water.
÷Iftheproductdoesnotoperatenormallybyfollowing
theoperatinginstructions.Adjustonlythosecontrols
that are covered by the operating instructions as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to its
normal operation.
÷If the product has been dropped or damaged in any
way.
÷When the product exhibits a distinct change in
performance — this indicates a need for service.
REPLACEMENT PARTS — When replacement parts
arerequired,besuretheservicetechnicianhasused
replacement parts specified by the manufacturer or
have the same characteristics as the original part.
Unauthorizedsubstitutionsmayresultinfire,electric
shock, or other hazards.
SAFETY CHECK — Upon completion of any service or
repairs to this product, ask the service technician to
performsafetycheckstodeterminethattheproduct
is in proper operating condition.
WALL OR CEILINGMOUNTING — The product should
not be mounted to a wall or ceiling.
HEAT—Theproductshouldbesituatedaway from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce
heat.
IMPORTANT SAFETY INSTRUCTIONS
GROUND
CLAMP
GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
ANTENNA
LEAD-IN
WIRE
NEC — NATIONAL ELECTRICAL CODE
Fig. A
ELECTRIC
SERVICE
EQUIPMENT
POWER SERVICE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDINGCONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
VENTILATION — Slotsand openings inthe cabinet are
provided for ventilation and to ensure reliable
operation of the product and to protect it from
overheating, and these openings must not be
blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug,
or other similar surface. This product should not be
placedinabuilt-ininstallationsuchasabookcaseor
rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
POWERSOURCES — This productshould beoperated
onlyfrom the typeofpowersourceindicatedonthe
marking label. If you are not sure of the type of
power supply to your home, consult your product
dealer or local power company.
LOCATION – The appliance should be installed in a
stable location.
NONUSE PERIODS – The power cord of the appliance
should be unplugged from the outlet when left un-
used for a long period of time.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

BASIC OPERATIONS
BEFORE OPERATING VARIOUS
OPERATIONS
3
<PRB1268>
En
[FOR U.S. MODEL]
CAUTION
÷Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation
exposure.
÷The use of optical instruments with this product will increase eye hazard.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Information to User
Alteration or modifications carried out without appropriate authorization may invalidate the user's right to operate the equipment.
[For Canadian model]
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT
USE THIS (POLARIZED) PLUG WITH AN EXTENSION CORD,
RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPO-
SURE.
ATTENTION: POUR PREVENIR LES CHOCS ELEC-
TRIQUES NE PAS UTILISER CETTE FICHE POLARISEE AVEC
UN PROLONGATEUR, UNE PRISE DE COURANT OU UNE
AUTRE SORTIE DE COURANT, SAUF SI LES LAMES PEU-
VENT ETRE INSEREES A FOND SANS EN LAISSER AU-
CUNE PARTIE A DECOUVERT.
[Pour le modèle Canadien]
[For Canadian model]
This Class B digital apparatus meets all requirements of the
Canadian Interference–Causing Equipment Regulations.
[Pour le modèle Canadien]
Cet appareil numérique de la Classe B respecte toutes les
exigences du Règlement sur le matériel brouilleur du Canada.
CAUTION [For U.S. Model]
ThisproductsatisfiesFCCregulationswhenshieldedcablesand
connectors are used to connect the unit to other equipment. To
prevent electromagnetic interference with electric appliances
such as radios and televisions, use shielded cables and connec-
tors for connections.
THESTANDBY/ONSWITCHISSECONDARY CONNECTED AND
THEREFORE DOES NOT SEPARATE THE UNIT FROM MAINS
POWER IN THE STANDBY POSITION.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

4
<PRB1268>
En
BEFORE YOU USE THE PLAYER
Remote control unit x 1 Output cable x 1
Up to 100 CDs can be registered by classifying
them into 3 categories (CUSTOM). [page 12]
For example, if you register you own discs in CUSTOM I, your
mother’sdiscsinCUSTOMII andyour father’s discs in CUSTOM
III or if you select three kinds of music genres or artists and
register them in the three CUSTOM banks, you can play all of the
discs classified under one of the three CUSTOM banks. Addition
of discs to already-registered discs is also possible. Each of the
three CUSTOM banks can register up to 100 discs.
Single Loader slot is provided. [page 11]
If you have a disc borrowed from a friend, you can play only that
discbyloadingitin this special slot (DiscNo.0),withoutreplacing
discs stored in the rack.
Immediatelyaccessand playyourfavorite tracks
from among the 100 discs loaded in the player.
[page 16]
The Best Selection Memory function lets you store and play
favorite tracks with the touch of a single button (up to 20 tracks).
Easy access to the disc(s) you've listened to
recently. [page 16]
The Previous Disc Scan function recalls the last disc you played
and then moves one by one through the previously played discs
(auto-memory of last 20 discs played).
CONFIRM SUPPLIED ACCESSORIES
Size AA/R6P dry cell
batteries x 2
Control cable x 1
783
1¡4¢
RANDOM
DISC
DISC
SET 0TRACK
SET
789
456
123TIME
HI-LITE BEST
PREVIOUS POWER
MODE CLEARPGMREPEAT
D
Î
FILE-TYPE CD PLAYER
REMOTE CONTROL UNIT
CU-P0090
–+
PUT BATTERIES INTO THE REMOTE
CONTROL UNIT
Open the lid of the battery compartment on the rear of the remote
control unit, and insert the batteries, taking care to align the ªand
·polarities correctly.
Notes!!
÷ In order to prevent battery leakage, remove the batteries when
not using the remote control unit for an extended period (one
month or more). If leakage occurs, carefully wipe away any
battery fluid inside the compartment, and replace the batteries
with new ones.
÷ Do not allow books or other objects to rest on top of the re-
mote control unit, since the buttons may be depressed, causing
faster exhaustion of the batteries.
Incorrect use of batteries may cause leakage or rupture.
Always be sure to follow these guidelines:
A. Always insert batteries into the battery compartment cor-
rectly matching the positive ªand negative · polarities,
as shown by the display inside the compartment.
B. Never mix new and used batteries.
C. Batteries of the same size may have different voltages,
depending on brand. Do not mix different brands of batter-
ies.
HERE’S WHAT YOU CAN DO!
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

BASIC OPERATIONS
BEFORE OPERATING VARIOUS
OPERATIONS
5
<PRB1268>
En
CAUTIONS REGARDING HANDLING
Location
Installtheplayerinawell-ventilatedlocationwhereitwillnotbe
exposed to high temperatures or humidity.
Do not install the player in a location which is exposed to direct
rays of the sun, or near stoves or radiators. Excessive heat can
adversely affect the cabinet and internal components. Installation
of the player in a damp or dusty environment may also result in a
malfunction or an accident. (Avoid installation near cookers etc.,
where the player may be exposed to oily smoke, steam or heat.)
Do not install the player on a tottered stand nor in an unstable or
inclined place.
Precautions regarding installation
÷Placing and using the compact disc player for long periods on
heat-generating sources such as amplifiers will affect perfor-
mance. Avoid placing the player on heat-generating sources.
÷Install this compact disc player as far as possible from tuners
and TV sets. A compact disc player installed in close proximity
to such equipment may cause noise or degradation of the pic-
ture.
÷Such noise may be particularly noticeable when an indoor an-
tenna is used. In such cases, make use of an outdoor antenna,
or turn off power to the compact disc player.
÷Please place this unit on a level surface.
Cleaning the player
To clean the PLAYER, wipe with a soft, dry cloth. For stubborn
dirt, wet a soft cloth with a mild detergent solution made by dilut-
ing one part detergent to 5 or 6 parts water, wring well, then wipe
off the dirt. Also use a dry cloth to wipe the surface dry. Do not
use volatile liquids such as benzene and thinner which are harmful
to the unit.
Storing discs
÷Discs are made of the same kinds of plastic used for conven-
tional analog audio records. Be careful not to allow discs to
warp; always store discs in their cases vertically, avoiding loca-
tions with high heat or humidity, or extremely low tempera-
tures. Avoid leaving discs in cars, since the seat of a car in
direct sunlight can become unbelievably hot.
÷Always read and abide by the precautionary notes listed on disc
labels.
CD lens cleaner
The player's pickup lens should not become dirty in normal use, but
if for some reason it should malfunction due to soiling, consult your
nearest PIONEER authorized service center. Lens cleaners for CD
players are commercially available, but special care should be exer-
cised in their use since some may cause damage to the lens.
Condensation
When this unit is brought into a warm room from previously cold
surroundings or when the room temperature rises sharply, con-
densation may form inside, and the unit may not be able to attain
its full performance. If this occurs, allow the unit to stand for about
an hour or raise the room temperature gradually.
Cleaning and handling compact discs
÷The presence of fingerprints or smudges on the surface of the
disc will not directly affect the recorded signals, but depending
on the degree of contamination, the brightness of the light
reflected from the signal surfaces may be reduced, causing
degradation of sound quality. Always keep your discs clean by
wiping them gently with a soft cloth from the inner edge to-
ward the outer periphery.
BEFORE OPERATING
÷If a disc becomes very dirty, dip a soft cloth in water, and after
wringing it out well, wipe the dirt away gently, and then remove
any water drops with another soft, dry cloth.
÷Do not use record cleaning sprays or anti-static agents on discs.
Also, never clean discs with benzene, thinner, or other volatile
solvents, since damage to the disc surface may result.
Record
cleaning
sprays Thinner Benzene
With this unit, use a Compact Disc carrying the mark shown
below. Do not use other disc, for this may result in malfunction
or damage.
÷When holding discs, do not touch their signal surfaces. Hold by
the edges, or by one edge and the center hole.
÷Do not affix gummed labels or tape to the label surfaces. Also,
do not scratch or damage the label.
÷Discs rotate at high speed inside the player. Do not use dam-
aged (cracked or warped) discs.
÷Do not play a CD with a special shape (having other shape than
a circular disc, such as a heart shaped disc). Otherwise mal-
function may occur.
'
Re-transporting
Whenre-transportingthisunitinthefuture,removealldiscsfromthe
rack. Turnoffthe STANDBY/ONswitch,waitfor"OFF"togooutfrom
the display, and unplug the power cord.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

6
<PRB1268>
En
R
L
R
L
CONNECTIONS
AMaking connections
1Connect the OUTPUT jacks of this unit to the input jacks (CD
or AUX) of the amplifier. Make sure that the white plugs are
connected to the left (L) jacks and the red plugs to the right (R)
jacks.
÷Be sure not to connect this unit to the amplifier’s PHONO
jacks, as sound will be distorted and normal playback will not
be possible.
2Connect the power cord to a household AC wall outlet.
÷Make sure plugs are inserted fully into the wall outlet.
Note!!
Do not connect the power cord to an AC outlet on your amplifier.
If you connect the power cord to a "SWITCHED" AC outlet on an
amplifier, you will not be able to use this unit's memory function.
Before making or changing the connections, switch off the power switch and disconnect the power cord from the AC outlet.
DIGITAL
INPUT
OPTICAL
CD
L White
R Red A-1
Output cable White
Red
OUT
IN
CONTROL
OUT
Stereo amplifier
C
Control cable
=
TotheCONTROL IN jackof
the Pioneer component
bearing the Î mark.
CD player
A-2
CD-DECK
SYNCHRO
CD-DECK SYNCHRO cable
D
Cassette deck
BOptical fiber cable
Control cable
C
Power cord
(Be sure to use the supplied CD-DECK SYN-
CHRO control cord with the cassette deck.)
C System remote control with a Pioneer stereo amplifier that
has the Îmark
When a Pioneer stereo amplifier bearing the Îmark is used,
connect the CONTROL IN jack on the rear panel of the CD player
to the CONTROL OUT jack of the amplifier. This will enable the
CD player to be controlled using the remote control unit supplied
with the stereo amplifier. If you do not plan to use this feature, it
is not necessary to connect the CONTROL IN/OUT jacks.
÷The remote control unit supplied with the amplifier can be used
to control Play, Stop, Pause, Track/Disc Search and Disc Change
operations.
÷For instructions regarding connections and operation, refer to
the operating instructions provided with your stereo amplifier.
Notes!!
÷ When a control cable is connected to the player’s CONTROL
IN jack, direct control of the player with the remote control unit
is not possible. Operate the player with the remote control unit
by aiming it at the amplifier.
÷ Be sure to connect both of the control cable's plugs securely to
the CONTROL IN and CONTROL OUT jacks. Do not connect
only one end of the cable.
÷ Be sure to turn off the power of the amplifier before connecting
the power cord and output cable.
÷ When only the digital output is connected, the remote sensor of
the amplifier does not function. To operate it, connect the output
cable to the stereo amplifier as well as connecting the digital
output.
DCD-Deck synchro function
If you have a Pioneer cassette deck provided with the CD-Deck
synchro function, connect the CD-DECK SYNCHRO jacks of the
CD player and cassette deck. With this function, synchro record-
ing can be carried out between the player and deck.
÷For details on connections and operation, refer to the operating
instructions supplied with the cassette deck.
÷The CD-DECK SYNCHRO cable is not supplied with the CD
player.
÷When CD-Deck synchro recording is carried out on several discs,
use the program playback function. (Refer to page 15 for details
of program playback.)
Note!!
In order to enable the CD-DECK SYNCHRO recording function, the
Output cable must be connected to the stereo amplifier.
BConnecting the OPTICAL FIBER CABLE
This unit can be connected to an amplifier equipped with an optical
digital jack.
1. Remove the protective dust cap from this unit’s DIGITAL OUT
OPTICAL jack.
2. UseanopticalfibercabletoconnecttheDIGITALOUT OPTICAL
jack of this unit to the optical input jack of the amplifier.
• Align the plug of the optical fiber cable with the optical digital jack
and fully insert the plug to make a secure connection.
Use a separately sold optical fiber cable for the optical digital jack
connections.
Precautions concerning use of optical fiber cables
• Fully insert the optical fiber cable plugs all the way into the jacks.
• Be careful not to fold or crimp the cable. When coiling an optical
fibercableforstorage,makesurethediameterofthecoilis15cm
(6 in.) or larger.
• Use an optical fiber cable with a length of 3 m ( 10 ft.) or less.
• Protect the optical fiber cable plugs from scratches and dust.
• Whentheunitisnotconnectedusinganopticalfibercable,besure
to keep the protective dust cap plugged into the optical digital
output jack at all times.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

BASIC OPERATIONS
BEFORE OPERATING VARIOUS
OPERATIONS
7
<PRB1268>
En
NAMES OF PARTS
FRONT PANEL
Lights when the BEST button is pressed.
Lights when the remaining time is displayed.
Lights during random play. Lights during repeat play.
Lights when the PROGRAM (PGM)
button is pressed.
Lights when a CD is being played.
Lights during pause mode.
Blinks when the PREVIOUS button is pressed.
Blinks during DISC SCAN.
Blinks during TRACK SCAN.
Lightsduringcustomprogramming
and play.
Lights when you choose the play mode.
DISPLAY
÷The numbers in parenthesis ( ) are reference pages.
BEFORE OPERATING
DISC MIN SEC
CUSTOM ALL
TRACK
I II III SINGLE RANDOM REPEAT 1REMAIN PGM
PREVIOUS
DISC SCAN
BEST
1-BIT DLC
DIRECT LINER CONVERSION
MODE HI-LITE CLEAR PROGRAM RANDOM REPEAT
UNLOAD BEST PREVIOUS DISC
OPEN/
CLOSE
D
FILE–TYPE
COMPACT DISC PLAYER
◊Û¿X/?≥
Î
ACSESS
SINGLE
LOADER
PLAY
STANDBY / ON
POWER
6741 ¡¢
'
FILE –TYME CD MECHANISM
DISC MIN SEC
CUSTOM ALL
TRACK
I II III SINGLE RANDOM REPEAT 1REMAIN PGM
PREVIOUS
DISC SCAN BEST
Remote sensor P. 8
Hood P. 9
MODE button
HI-LITE button CLEAR button
PROGRAM button
SINGLE LOADER
ACCESS button
SINGLE LOADER
PLAY button
POWER STANDBY/ON
switch
UNLOAD button
OPEN/CLOSE button
BEST button
Play/Pause button (6)
PREVIOUS button
Stop button (7)
RANDOM button
REPEAT button
DISC (–/+) buttons
Track/Manual search
buttons (41/¡¢)
P. 17 P. 12 P. 15
P. 10
P. 10
P. 12 P. 15
P. 14
P. 13
P. 13
P. 10
P. 10
P. 10
P. 16
P. 16
P. 9
P. 9
P. 9
P. 11
P. 11
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

8
<PRB1268>
En
REMOTE CONTROL UNIT
NAMES OF PARTS
Note!!
Iftheremotecontrolsensorwindowis in a positionwhereitreceives
strong light such as sunlight or fluorescent light, control may not be
possible.
When operating the remote control unit, point the unit's infrared
signaltransmitter at theremotecontrol receiver (RemoteSensor)on
the front panel of the player. The remote control unit can be used
withinarangeofabout7meters(23feet)fromtheremotesensor,and
within angles of up to about 30 degrees.
REMOTE CONTROL OPERATIONS
÷The numbers in parenthesis ( ) are reference pages.
D
7 m (23 ft)
30º
30º
783
1¡4¢
RANDOM
DISC
DISC
SET
0
TRACK
SET
789
456
123
TIME
HI-LITE BEST
PREVIOUS POWER
MODE CLEARPGMREPEAT
D
Î
FILE-TYPE CD PLAYER
REMOTE CONTROL UNIT
CU-P0090
–+
PREVIOUS button
BEST button
P. 16
HI-LITE button
P. 17
POWER STANDBY/ON
switch
P. 10
MODE button
P. 10 P. 12
REPEAT button
P. 13
DISC (–/+) buttons
P. 13
RANDOM button
P. 14
PLAY button (3)
P. 10
Track search buttons
(4/¢)
P. 10
P. 16
TIME button
P. 18
CLEAR button
P. 12 P. 15
TRACK SET button
P. 10 P. 15
PGM button
P. 15
Digit buttons
P. 12 P. 10 P. 15
DISC SET button
P. 12 P. 10 P. 15
STOP button (7)
P. 10
Pause button (8)
P. 10
Manual search buttons
(1/¡)
P. 10
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

BASIC OPERATIONS
BEFORE OPERATING VARIOUS
OPERATIONS
9
<PRB1268>
En
STANDBY / ON
POWER
UNLOAD
OPEN/
CLOSE
HOW TO LOAD THE DISCS(Be sure to read this before operation)
÷To load or remove a disc in or from the slot which is seen through
the hood, press OPEN/CLOSE. The hood is opened, “HOLD” is
displayed and the disc can be loaded in or ejected from the slot
seen through the hood. Even while “HOLD” is being displayed,
the rack can be rotated by pressing DISC (–/+).
÷Be sure to remove all discs from the rack, set the POWER
STANDBY/ON switch to off, and unplug the power cord before
moving the unit.
Loading discs into the rack
÷You can load up to 100 discs in the rack.
The numbers marked on the rack are used as the disc numbers.
These are marked in the clockwise order from 1to 100.÷If a disc is inserted with its label side facing to the right, it cannot
beplayedback.Besuretoloadalldiscswiththeirlabelsidesfacing
to the left.
WARNING:
Do not put your hand or any other object inside
the rack, otherwise injury or part damage may
result.
÷The following procedure describes how to load discs from
disc No. 1.
Press POWER STANDBY/
ON switch.
D
Press UNLOAD.
«
The hood will open.
1
2
Notes!!
÷÷
÷÷
÷ Do not attempt to open the hood with your hand.
÷ Becarefulnot to pinch yourfingerswhenopeningandclosing the
hood.
÷÷
÷÷
÷Do not put anything other than CDs inside the rack.
÷÷
÷÷
÷Do not use adapters for 8-cm (3-in.) CDs.
÷Load only one disc into each disc slot.
÷Inserting an 8-cm (3-in.) CDs in between two 12-cm (5-in.) CDs,
will make it difficult to remove the 8-cm (3-in.) CD.
Werecommendinserting12-cm(5-in.)CDsstartingfromDiscNo.
1 (i.e., 1, 2, 3...) and 8-cm (3-in.) CDs starting from Disc No. 100
(i.e., 100, 99, 98...).
÷Theunitwillnotoperateifthe hood isopenedduringplayback.Be
sure to close the hood before attempting any operations.
D
To remove the discs...
Press UNLOAD.
Select the disc No. to be removed by pressing DISC(–/+).
÷The rack rotates until the selected disc comes in the front of
the unit.
Remove from the rack.
Press OPEN/CLOSE.
÷The hood will close.
PressDISC(+)torotate
the rack.
÷The rack rotates in the di-
rection of 1,2,3.... Press-
ing DISC(–) rotates the
rack in the opposite direc-
tion.
Load other discs into the rack by repeating
steps 3 and 4 for each of them.
Press OPEN/CLOSE.
÷The hood will close.
4
5
6
Tip:
Difference between OPEN/CLOSE and UNLOAD
OPEN/CLOSE: The hood is simply opened or closed.
UNLOAD:The slot corresponding to the disc No. being displayed
rotates to the center position then the hood is opened.
1
2
3
4
When UNLOAD is pressed,
the hood opens to the disc
corresponding to the disc No.
displayed on the front of the
unit. Therefore, if you want to
load discs from No. 50, use
DISC (–/+) on the unit to dis-
play“50”,orenter “50” using
theremotecontrolunit,before
pressing UNLOAD.
Load the disc into the
rackwiththelabelside
(printedsurface)facing
to the left.
Sidetobeplayedfacesright
(label side faces left)
D
3
÷Ensure that the disc No.
shownonthedisplayis“1”.
÷If the displayed disc No. is
not “1”, press DISC(–/+)
to display “1”.
BEFORE OPERATING
DISC MIN SECTRACK
ALL
DISC
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

<PRB1268>
En
10
TRACK
SET
7
DISC
SET
2
783
RANDOM
DISC
DISC
SET TRACK
SET
TIME
HI-LITE BEST
PREVIOUS POWER
MODE CLEARPGMREPEAT
D
Î
FILE-TYPE CD PLAYER
REMOTE CONTROL UNIT
CU-P0090
–+
1¡4¢
789
456
123
0
STANDBY / ON
POWER
BASIC OPERATIONS
• You can also use the remote control.
To listen in order from the first track
Side to be played faces right
(label side faces left)
Note!!
÷ Inserting more than one disc into the slot will damage the discs
and cause the unit to malfunction.
÷Ifyouchooseaplaymodebeforehand,thetracks/discsareplayed
back according to the respective play mode.
To skip to another track
Tap 41/¡¢ (or 4/¢on
the remote control unit).
To fast forward/reverse.
To select the disc and track
Use the digit buttons to se-
lectthedisc,thenpressDISC
SET.
Use the digit buttons to se-
lect the track, and press
TRACK SET.
To select a play mode
MODE
41/¡¢
3
6
7
2
1
D
To stop play Press 7.
To pause play
Press 6(or 8).
To start playback again, press 6.
Hold-down 41/¡¢ (or 1/
¡on the remote control unit).
1
2
3
Press 6(or 3).
Thetracks are playedinorder starting
fromthefirsttrackonthediscwiththe
lowest disc No.
Press MODE during play or
stop mode.
Pressafewtimestochoosethemode
you desire.
Playbackoccursaccordingtothecho-
sen mode.
÷When you select SINGLE during playback, only the current disc
will be played.
÷If you press MODE during program mode, the program contents
will be erased.
Notes!!
÷ WhenyouturnthepowerON,playbackstartsaccordingtothelast
selected play mode.
÷ If you did not select a play mode, playback starts in ALL.
÷ SINGLE is selected automatically when playing the disc loaded in
the Single Loader slot.
<Last disc memory>
When you press 7or turn the power OFF (STANDBY), the unit
memorizes the disc that was being played. The next time you press
6, playback will start from that same disc. (This feature is available
except in the PROGRAM play, BEST play, PREVIOUS scan, HI-LITE
scan and RANDOM play modes.)
2
ALL SINGLE
3
3
3
3ALL SINGLE
In stop mode:
During playback:
ALL: All discs are played back.
SINGLE: One disc is played back.
CUSTOM: Only discs stored in the CUSTOM file are played back
(see page 12 to create a custom file).
CUSTOM(III II I)
22
\
\
Load discs into the rack.
Press OPEN/CLOSE.
«
PressPOWERSTANDBY/ON.
To turn the power off...
Press POWER STANDBY/ONagain.
(I,II,III)
OPEN/
CLOSE
D
◊Û¿X/?≥
Î
'
FILE –TYME CD MECHANISM
741 ¡¢6
1-BIT DLC
DIRECT LINER CONVERSION
6
7
6
41 ¡¢
41 ¡¢
1
8 3
4/¢1/¡
TRACK SET
7
DISC SET
Digit buttons
MODE
3
MODE
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

BASIC OPERATIONS VARIOUS
OPERATIONS
BEFORE OPERATING
11
<PRB1268>
En
OPEN/
CLOSE
OPEN/
CLOSE
D
BASIC OPERATIONS
Playing a disc in the Single Loader slot
1
2
Press SINGLE LOADER AC-
CESS.
÷Thehood will openwith the single
loader slot located in the front of
the unit.
3
Press SINGLE LOADER
PLAY.
÷The play mode is set to SINGLE.
Tips:
÷ThediscloadedintheSingleLoaderslotcanalsobeselectedusing
DISC(–/+). It is located after disc No. 100 when DISC(+) is used
or disc No. 1 when DISC(–) isused.Onthedisplay, it is shown as
“P0”.
÷If a disc has been loaded in the Single Loader slot, pressing
SINGLE LOADER PLAY allows to play it anytime, even during
playback of a disc stored in the rack.
÷Toplay the discinthe Single Loaderslotusing the remotecontrol
unit, press “0” and DISC SET.
The hood can be opened or closed
during playback.
÷“HOLD” is displayed after the hood is opened.
÷In this case, the rack does not rotate.
÷When the playback of the current disc has completed, the unit
entersstopmode.Thenextdiscisplayedafterthehood hasbeen
closed.
1
2
3
OPEN/CLOSE
LoadingthediscintotheSin-
gle Loader slot with the la-
belside(printedsurface)fac-
ing to the left.
PressandholdOPEN/CLOSE
until “OPEN” is displayed.
To close the hood, press
OPEN/CLOSE again.
Note!!
If the hood is opened during play, UNLOAD, SINGLE LOADER
ACCESS and DISC (–/+) are defeated.
BASIC OPERATIONS
Side to be played faces right
(label side faces left)
D
◊Û¿X/?≥
Î
'
FILE –TYME CD MECHANISM
741 ¡¢6
OPEN/
CLOSE
1-BIT DLC
DIRECT LINER CONVERSION
ACSESS
PLAY
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

<PRB1268>
En
12
MODE 3
DISC
SET
3
MODE
783
1¡4¢
RANDOM
DISC
SET TRACK
SET
TIME
HI-LITE BEST
PREVIOUS POWER
MODE CLEARPGMREPEAT
D
Î
FILE-TYPE CD PLAYER
REMOTE CONTROL UNIT
CU-P0090
789
456
123
DISC
–+
0
VARIOUS OPERATIONS
This unit lets you program up to 100 of your favorite discs. For
example, you can store all the discs of your favorite artist, or some
other group of personal selections, and play only those discs.
You can even add other discs to the custom later on.
Operation example: Storing discs 3 and 12 in the CUSTOM II
file.
During stop mode, press
MODEsothattheCUSTOM
II indicator lights.
DISC MIN SEC
CUSTOM
TRACK
II
÷If you use DISC (–/+) to select a disc, it will be programmed
automatically after approximately 2 seconds.
To program and play only the discs
you want to hear (CUSTOM play)
÷The parenthesis ( ) show operations for the main unit.
Use the digit buttons to
select disc.
DISC MIN SEC
CUSTOM
TRACK
II
( )
÷If some disc number appears, press CLEAR.
DISC MIN SEC
CUSTOM
TRACK
II
Press DISC SET.
Repeat steps 2 and 3 to
store other discs.
DISC MIN SEC
CUSTOM
TRACK
II
()
Note!!
You cannot change the discs stored in the CUSTOM file. Likewise,
you cannot erase just one disc from the CUSTOM file.
÷Pressing DISC (–/+) during CUSTOM playback lets you choose
among other discs stored in the CUSTOM file.
÷If you use the digit buttons and DISC SET on the remote control
during CUSTOM playback to choose a disc not stored in the
CUSTOM file, “nodISC”willbedisplayedfor approximately
3 seconds.
÷When a disc appointed to the CUSTOM file is not loaded in the
rack,“nodISC” isdisplayedforapproximately3seconds,the
disc is erased from memory, and CUSTOM searches for the next
disc.
÷The discs stored in the CUSTOM file will not be erased when you
turn off the power.
÷Itemsstoredinmemoryaresavedforapproximately 2days,even
if the power cord is unplugged. However, this period may be
shortenedsomewhat,dependingontheamountofmemoryused.
(Memory Back-Up Function).
÷While the hood is open, DISC (–/+) cannot be used for CUSTOM
file entry.
4
3
2
1
Erasingallthe discsfromthe eachCUSTOM
file.
Press MODE to choose CUSTOM, then press the CLEAR
button.
\
Checking the numbers of the stored discs.
Press TIME repeatedly (3 times) during stop mode so that
the display changes as shown below.
Press DISC(–/+). Each time you press DISC(–/+), a disc
number stored in the CUSTOM file is displayed. When all
the disc numbers have been displayed, the disc number
changes to a blank.
(=)
\
To start playback
PressMODEtoselectCUS-
TOM and press 3.
Playback starts from the lowest
disc No.
DISC MIN SEC
CUSTOM
TRACK
II
÷The remote control is the most convenient way to perform these
operations.
DISC
6
MODE
6
DISC (–/+)
CLEARMODE
OPEN/
CLOSE
D
◊Û¿X/?≥
Î
'
FILE –TYME CD MECHANISM
741 ¡¢6
1-BIT DLC
DIRECT LINER CONVERSION
MODE
Digit buttons
DISC SET
CLEAR
DISC (–/+)
3
DISC
SET
1 2
DISC
)(
MODE
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

BASIC OPERATIONS VARIOUS
OPERATIONS
BEFORE OPERATING
13
<PRB1268>
En
DISC MIN SEC
REPEAT 1
ALL
TRACK
DISC MIN SEC
REPEAT
ALL
TRACK
DISC MIN SEC
REPEAT
II
TRACK
CUSTOM
DISC MIN SEC
REPEAT
SINGLE
TRACK
783
1¡
RANDOM
DISC
SET
0
TRACK
SET
789
456
123
TIME
HI-LITE BEST
PREVIOUS POWER
MODE CLEARPGMREPEAT
D
Î
FILE-TYPE CD PLAYER
REMOTE CONTROL UNIT
CU-P0090
DISC
–+
4¢
VARIOUS OPERATIONS
• You can also use the remote control.
To start playback from a specific disc
PressDISC(–/+)duringplay
or pause to choose a disc
number. During pause,
press 6(3or 8on the
remote control unit) after
choosing the disc.
÷Playbackstartsfromthefirsttrack
of the chosen disc.
To play a track you want to hear
Press 41/¡¢ dur-
ing play or pause to
choose the track number
you desire (or press 4/
¢ontheremotecontrol).
Duringpause,press6afterchoos-
ing the track.
41 / ¡¢
7
6
REPEAT
VARIOUS OPERATIONS
Press the REPEAT button
duringplayback.Eachtime
you press the button, the
repeat mode changes as
follows.
3(ALL/SINGLE/CUSTOM)
To repeat playback (REPEAT play)
3
One track repeat ALL repeat
OFF 2
(One track repeat)
Repeats the current or a selected
track in during other play operations
than HI-LITE scan and PREVIOUS
scan.
(ALL repeat)
Repeats in one of the following 3
ways according to the play mode .
ALL: Repeats all the tracks
on all the discs (1 - 100).
SINGLE: Repeats all the tracks
on the selected disc.
CUSTOM: All of the discs classi-
fied under one of the three CUS-
TOM banks are played repeatedly.
(OFF)
Cancels repeat play and returns the
unit to normal play mode.
One track
CUSTOM
ALL
÷To stop repeat playback, press 7.
÷When none of the ALL, SINGLE or CUSTOM play mode is
displayed(i.e.duringPROGRAMplay,BESTplay,PREVIOUSscan
or HI-LITE scan), the tracks which would be played with these
functions are played repeatedly.
41 ¡¢
OPEN/
CLOSE
D
◊Û¿X/?≥
Î
'
FILE –TYME CD MECHANISM
741 ¡¢6
1-BIT DLC
DIRECT LINER CONVERSION
DISC (–/+)
4 ¢
DISC (–/+)
3
7
REPEAT
SINGLE
REPEAT
DISC
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

<PRB1268>
En
14
To playback tracks/discs at random
(RANDOM play)
RANDOMselectstracksatrandomfromthedisc(s)inthecurrentplay
modeandplayseachtrackonce. Theselectedplaymodestopsafter
its contents are played back. (Refer to chart below)
Play mode selected
ALL
SINGLE
CUSTOM
Play contents
Plays up to 100 tracks at random
fromamong all the discs(1-100).
Plays all the tracks from a single
disc at random.
Plays up to 100 tracks at random
from the discs into one of three
groups in CUSTOM file.
Press RANDOM during ei-
ther play or stop mode.
÷TheRANDOMindicatorlightsup
and random play according to
the current play mode starts.
Tostoprandomplay,press
7.
VARIOUS OPERATIONS
7
• You can also use the remote control.
Notes!!
÷ Randomplaycannotbeactivatedduringtheprogrammode.(Ifyou
press RANDOM during program play, the program contents will
be erased and the unit will start to play tracks at random from all
the discs.)
÷ Inthe ALL orCUSTOM( I,IIorIII )mode, if lessthan100discs are
loaded, the same track may be played more than once.
÷ If you press REPEAT during random play, the contents of the
random mode are repeated. (RANDOM REPEAT)
÷ If you press DISC (–/+) during random play, random play is
canceled.
÷ If you press MODE during random play, random play is switched
to the ALL or SINGLE play.
OPEN/
CLOSE
D
◊Û¿X/?≥
Î
'
FILE –TYME CD MECHANISM
41 ¡¢6 7
1-BIT DLC
DIRECT LINER CONVERSION
RANDOM
783
1¡4¢
RANDOM
DISC
DISC
SET
0
TRACK
SET
789
456
123
TIME
HI-LITE BEST
PREVIOUS POWER
MODE CLEARPGMREPEAT
D
Î
FILE-TYPE CD PLAYER
REMOTE CONTROL UNIT
CU-P0090
–+
7RANDOM
7
RANDOM
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

BASIC OPERATIONS VARIOUS
OPERATIONS
BEFORE OPERATING
15
<PRB1268>
En
DISC MIN SECTRACK
PGM
TRACK
SET
3
DISC
SET
5
783
1¡4¢
RANDOM
DISC
DISC
SET TRACK
SET
TIME
HI-LITE BEST
PREVIOUS POWER
MODE CLEARPGMREPEAT
D
Î
FILE-TYPE CD PLAYER
REMOTE CONTROL UNIT
CU-P0090
–+
0
789
456
123
VARIOUS OPERATIONS
To program tracks/discs in a desired
order (PROGRAM play)
÷The remote control is the most convenient way to perform these
operations.
÷You can program up to 36 steps.
÷The parenthesis ( ) show operations for the main unit.
Press 3.
The program play starts from the
track that was programmed first.
Operation example: Programming disc 2, track 7 as step 1,
and disc 5, track 3 as step 2.
PressPGM(PROGRAM)dur-
ing stop mode.
Repeat steps 2 and 3 to pro-
gram additional discs and
tracks.
Once the track times have been
added,the PGM indicator stopsblink-
ing and the following display appears
(Total Time).
Use the digit buttons to se-
lectthedisc,thenpressDISC
SET.
(Use DISC (–/+) to select the disc
number, then press PROGRAM.)
DISC MIN SEC
PGM
TRACK
==
<Programming an entire disc as one step>
(Disc all program)
If you skip step of the operation example, disc 2 is programmed
as step 1.
<Programming a pause (remote control only) >
(Pause program)
Ifyou press8atstep ,you can programapause.Whenyou press
8, “PA” appears in the display instead of the disc number.
÷For example, when making a program for recording both sides of
a cassette tape, press 8to insert a pause after programming the
tracksforoneside.Afterturningthetapeover,press8toresume
recording.
Notes!!
÷ You cannot program a pause as the first step, or program two
pauses in a row.
÷ Whenyou programa pause, itcounts as 1step and reducesthe
total number of tracks you can program.
÷To erase a program...
Press7twiceduringplayback(oronceinstopmode). Youcanalso
erasetheprogrambypressingMODE,RANDOM,PREVIOUS,or
SINGLE LOADER PLAY in either play or stop mode (or by
pressing BEST in stop mode).
÷To cancel a program step
In stop mode, each time you press CLEAR, the last step in the
program is erased.
÷If a programmed disc is missing or inserted backwards
duringprogram play, “nodISC” appears in the display,
the step isautomaticallyerased,andplaybackproceedstothe
next step.
÷Program contents are stored in memory even when the power
is turned off (STANDBY).
Notes!!
÷ Ifstep is carried outbeforetheaccumulated timeisdisplayed,
the program play starts and the time is not displayed.
÷ WhenUNLOADispressedwhileaprogramhasbeenentered,the
discforthe1stprogramstepcomesonthecenterpositionandthe
hood opens.
÷ The display is not shown if the total time of the program is 100
minutes or more.
3
4
4
3
2
1
5
VARIOUS OPERATIONS
«
\
\
5
The following operations can only be performed
during stop mode
1
23
23
5
2
DISC
SET
PGM
7
TRACK
SET
«
Use the digit buttons to se-
lect the track, and press
TRACK SET.
(Use 41/¡¢ to select the
track number,then pressPROGRAM.)
)
)
41 ¡¢
PROGRAM
DISC MIN SECTRACK
PGM
DISC MIN SECTRACK
PGM
PROGRAM
1234
<Programming tracks during normal play>
(Direct program)
1. Press PGM (PROGRAM).
• Program mode is activated.
2. Press PGM (PROGRAM) during playback.
• The current track is programmed.
<Programmingduringnormalplayback (remotecontrolonly) >
(Preprogramming)
You can program during normal playback.
(\Operation example )
• The player changes to program play when the current track
finishes playing back.
• To change to program mode directly, press 3.
The following operations can only be performed
duringnormalplay,HI-LITEscanorPREVIOUSscan
÷Itemsstoredinmemoryaresavedforapproximately 2days,even
if the power cord is unplugged. However, this period may be
shortenedsomewhat,dependingontheamountofmemoryused.
(Memory Back-Up Function).
DISC MIN SECTRACK
PGM
)( 6
3
()
(
DISC
=
PROGRAM
(=
41 ¡¢
PROGRAM
(=
PROGRAM
DISC
)
The PGM indicator starts to blink.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

<PRB1268>
En
16
DISC MIN SEC
PREVIOUS
ALL
TRACK
SCAN
783
1¡4¢
RANDOM
DISC
DISC
SET
0
TRACK
SET
789
456
123
TIME
HI-LITE BEST
PREVIOUS POWER
MODE CLEARPGMREPEAT
D
Î
FILE-TYPE CD PLAYER
REMOTE CONTROL UNIT
CU-P0090
–+
VARIOUS OPERATIONS
÷You can also use the remote control for these operations.
÷÷
÷÷
÷These operations can not be performed on the CD inserted into the SINGLE LOADER SLOT.
<Tolistentothe memorized tracks>
Tousetheone-touchmemory,justpresstheBESTbuttonwhile
playing a track you like. You can store up to 20 tracks.
PressBESTwhileplayinga
track you like.
The BEST indicator blinks and the
disc and track number are stored in
memory.
Press BEST during stop
mode.
The BEST indicator lights and
playback starts from the most
recently memorized track.
To find out which discs you’ve listened
to recently (PREVIOUS scan)
÷This function scans the discs in reverse order, starting from
the last disc you played.
÷It can remember up to 20 discs. If the total number of discs
exceeds 20, the oldest disc will be erased to make room for
the new disc.
Example: If you played discs 1, 2, 9, 12 and 13 in order.
Press the PREVIOUS but-
ton.
÷Approximately 10 seconds from
one minute into the first track of
eachdiscisplayedback, starting
fromthelastdisc youplayed:13,
12, 9, 2, 1.
Press3(or 6) when you
reach the disc you want to
hear.
÷Previous disc scan is canceled
and normal play resumes.
÷To cancel the scanning, press 7.
÷Discs played during random, program, HI-LITE scan, Best and
Single Loader playback are not included in the PREVIOUS scan.
÷Ifthe first trackislessthan 1 minutelong,about10 seconds from
the beginning will be played. If the first track is less than 10
seconds long, the entire track will be played.
÷Itemsstoredinmemoryaresavedforapproximately 2days,even
if the power cord is unplugged. However, this period may be
shortenedsomewhat,dependingontheamountofmemoryused.
(Memory Back-Up Function).
÷If you press CLEAR during Best playback, the current track is
erased and the next track starts to play.
÷YoucannotmemorizeatracktwicebypressingBESTduringBest
playback.
÷IfyoupressBESTtomemorizeatrackwhen20tracks are already
memorized, the oldest track is erased from memory and the new
track is memorized.
÷The memorized contents are stored, even when the power is
turned off (STANDBY).
÷Itemsstoredinmemoryaresavedforapproximately 2days,even
if the power cord is unplugged. However, this period may be
shortenedsomewhat,dependingontheamountofmemoryused.
(Memory Back-Up Function).
To store your favorite tracks (BEST play)
6
7
OPEN/
CLOSE
D
◊Û¿X/?≥
Î
'
FILE –TYME CD MECHANISM
41 ¡¢76
1-BIT DLC
DIRECT LINER CONVERSION
PREVIOUS
BEST
73
PREVIOUS
BEST
BEST
PREVIOUS
3
BEST
Blink
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

BASIC OPERATIONS VARIOUS
OPERATIONS
BEFORE OPERATING
17
<PRB1268>
En
VARIOUS OPERATIONS
÷You can also use the remote control for these operations.
Toscanquicklythroughtracksonadisc
(HI-LITE scan)
This function plays a 10 second portion located 1 minute from the
start of each track on all the discs in the current play mode.
Press HI-LITE during either
play or stop mode.
÷The unit plays a 10 second por-
tion located 1 minute into the
first track of each CD, starting
from the first CD.
Press once
The ”DISC” and “SCAN” indicator blinks.
<Track scan> Press HI-LITE twice during
either play or stop mode.
÷The unit plays a 10 second por-
tion located 1 minute into each
track of each CD, starting from
the first CD.
Press twice
The “SCAN” indicator blinks.
<Program scan> Press HI-LITE during pro-
gram mode.
÷The unit plays a 10 second por-
tion located 1 minute into each
track in the program.
Press once
The “SCAN” indicator blinks.
<Best selection memory scan>
Press HI-LITE during best
selection memory play-
back.
÷The unit plays a 10 second por-
tion located 1 minute into each
track in the best selection mem-
ory.
Press once
The “SCAN” indicator blinks.
<To return to normal playback>
Press 3(or6) when you
reach the track you want
to hear.
HI-LITEscaniscanceledand
normal play resumes.
÷To cancel HI-LITE scan, press 7.
<Disc scan>
Notes!!
÷ You can use 4 / ¢ to skip to another track during track scan.
÷ IftheplayerisinALLREPEATmode,theHI-LITEscanwill repeat.
÷ If the track is less than 1 minute long, about 10 seconds from the
beginning of the track will be played. If the track is less than 10
seconds long, the entire track will be played.
VARIOUS OPERATIONS
OPEN/
CLOSE
D
◊Û¿X/?≥
Î
'
FILE –TYME CD MECHANISM
741 ¡¢
1-BIT DLC
DIRECT LINER CONVERSION
6
HI-LITE
6
783
1¡4¢
RANDOM
DISC
DISC
SET
0
TRACK
SET
789
456
123
TIME
HI-LITE BEST
PREVIOUS POWER
MODE CLEARPGMREPEAT
D
Î
FILE-TYPE CD PLAYER
REMOTE CONTROL UNIT
CU-P0090
–+
HI-LITE
3
3
HI-LITE
HI-LITE
HI-LITE
HI-LITE
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

<PRB1268>
En
18
783
1¡4¢
RANDOM
DISC
DISC
SET
0
TRACK
SET
789
456
123
TIME
HI-LITE BEST
PREVIOUS POWER
MODE CLEARPGMREPEAT
D
Î
FILE-TYPE CD PLAYER
REMOTE CONTROL UNIT
CU-P0090
–+
VARIOUS OPERATIONS
To use the TIME button
Press TIME during play-
back.
Each time you press TIME, the
display changes as follows.
=
«
Disc number, Track number and
Elapsed Time.
Remaining time (TRACK)
«
Remaining time (DISC)
«
Total elapsed time (TOTAL)
Notes!!
÷ Time remaining on the track may not be displayed for tracks
numbered greater than 24.
÷ Time remaining on the disc is not displayed during RANDOM,
PROGRAM or BEST play.
÷ During PROGRAM play ÷ During BEST play
=
«
Disc number, Track number
and Elapsed Time.
Remaining time (TRACK)
«
Total number of steps
memorized in BEST (TOTAL)
=
«
Disc number, Track number
and Elapsed Time.
«
Remaining time (TRACK)
Total program time and
number of steps (TOTAL)
÷You can use the remote control.
TIME
TIME
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

BASIC OPERATIONS VARIOUS
OPERATIONS
BEFORE OPERATING
19
<PRB1268>
En
TROUBLESHOOTING
Incorrect operations are often mistaken for trouble and malfunctions. If you think that there is something wrong with this component, check the
points below. Sometimes the trouble may lie in another component. Investigate the other components and electrical appliances being used.
If the trouble cannot be rectified even after exercising the checks listed below, ask your nearest PIONEER authorized service center or your dealer
to carry out repair work.
÷Outputcablesareconnectedincorrectlyorloosely.
÷Incorrect operation of stereo amplifier.
÷Pin plugs and/or amplifier terminals are dirty.
÷Player is in pause mode.
÷The disc is loaded with the label side rightward.
÷Disc is inserted in the wrong way.
÷Smudges, etc., on the disc.
÷Dead batteries.
÷Obstruction between player and remote control
unit.
÷Connect properly.
÷Check the settings of amplifier switches and
sound volume controls.
÷Clean away dirt.
÷Press 3or 8.
÷Reload the disc with the label side leftward.
÷Insert the disc correctly with the label side
leftward.
÷Cleanthesmudgesfrom thediscandthenplay
it again.
÷Replace batteries.
÷Relocate remote control unit or remove ob-
struction.
Abnormalfunctioningofthisunitmaybecausedbystaticelectricity,orotherexternalinterference.Torestorenormaloperation, unplugtheACpower
cord and then plug it in again.
No sound
When playback is started, it
stops immediately.
Pausesorstopsduringplayback.
Remote control will not func-
tion.
Symptom Cause Remedy
SELF-DIAGNOSTICS FUNCTION
The unit incorporates a self-diagnostic function.
When an abnormality is detected during operation of the unit, an error message (service no.) appears on the unit‘s display automatically. Treat the
error by following the instructions in ”Countermeasures”.
÷Reload the discs properly.
(Insert only one disc in a slot.)
÷Check if there is a foreign object attached onto
the disc.
÷Check if there is a foreign object in the rack.
÷Check if there is a foreign object in the rack.
÷Unplug the power cord then plug it in again.
÷Check if the hood is caught by anything.
÷Unplug the power cord then plug it in again.
Service No. Unit Status Countermeasures
The disc may not be loaded properly in the rack.
There is an operation error in the mechanical section.
There is an error related to the hood.
U1
U2
U3
If the same display appears again, there may be an error in the mechanical section. When requesting servicing, please also let us know the
service number displayed on the unit.
DISC MIN SECTRACK
Displayontheunit
Service No.
VARIOUS OPERATIONS
POWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out the plug by tugging the cord and never touch the power cord when your hands are wet as
this could cause a short circuit or an electric shock. Do not place the unit, a piece of furniture, etc., on the power cord, or pinch the cord. Never
make a knot in the cord or tie it with other cords. The power cords should be routed such that they are not likely to be stepped on. A damaged
power cord can cause a fire or give you an electrical shock. Check the power cord once in a while. When you find it damaged, ask your nearest
PIONEER authorized service center or your dealer for a replacement.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals

<PRB1268>
En
20
PIONEER ELECTRONICS [USA] INC. P.O. BOX 1540, Long Beach, California 90801-1540
PIONEER ELECTRONICS OF CANADA, INC. 300 Allstate Parkway, Markham, Ontario L3R 0P2, Canada
PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium TEL: [phone]
PIONEER ELECTRONICS AUSTRALIA PTY. LTD. 178-184 Boundary Road, Braeside, Victoria 3195, Australia, TEL: [03] 9586-6300
PIONEER ELECTRONICS DE MEXICO S.A. DE C.V. San Lorenzo Num 1009 3er Piso Desp. 302 Col. Del Valle, Mexico D.F. C.P.03100 TEL: [phone]
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153, Japan
SPECIFICATIONS
Printed in China <PRB1268-A><98A00ZF0Z00>
Selecting fine audio equipment such as the unit you’ve just purchased is
only the start of your musical enjoyment. Now it’s time to consider how you
canmaximizethefunand excitementyour equipment offers.Thismanufac-
turer and the Electronic Industries Association’s Consumer Electronics
Group want you to get the most out of your equipment by playing it at a safe
level. One that lets the sound come through loud and clear without annoying
blaringordistortion-and, most importantly,withoutaffecting your sensitive
hearing.
Soundcanbedeceiving.Overtime yourhearing“comfortlevel”adapts to
highervolumes ofsound. Sowhat sounds “normal”can actuallybe loudand
harmful to your hearing. Guard against this by setting your equipment at a
safe level BEFORE your hearing adapts.
To establish a safe level:
÷Start your volume control at a low setting.
÷Slowly increase the sound until you can hear it comfortably and
clearly, and without distortion.
Once you have established a comfortable sound level:
÷Set the dial and leave it there.
Takingaminutetodothisnowwillhelptopreventhearingdamageorloss
in the future. After all, we want you listening for a lifetime.
We Want You Listening For A Lifetime
Usedwisely,yournewsoundequipment willprovidealifetimeof funand
enjoyment.Sincehearingdamagefromloudnoiseisoftenundetectableuntil
it is too late, this manufacturer and the Electronic Industries Association’s
Consumer Electronics Group recommend you avoid prolonged exposure to
excessive noise. This list of sound levels is included for your protection.
Information courtesy of the Deafness Research Foundation.
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet plane
180 Rocket launching pad
THE FOLLOWING NOISES CAN BE DANGEROUS UNDER
CONSTANT EXPOSURE
30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock
at two feet.
Decibel
Level Example
3. Output terminal
Audio line output
Control input jack
Control output jack
CD-DECK SYNCHRO jack
Optical digital output jack
4. Accessories
÷Remote control unit .................................................................. 1
÷Size AA/R6P dry cell batteries................................................... 2
÷Output cable ............................................................................. 1
÷Control cable ............................................................................. 1
÷Operating instructions............................................................... 1
Note!!
Specifications and design subject to possible modification without
notice, due to improvements.
1. General
Type ...........................................Compact disc digital audio system
Power requirements .............................................. AC 120V, 60 Hz
Power consumption ................................................................. 12W
Operating temperature ...............................................+5°C - +35°C
(+41°F - +95°F)
Weight ( without package ) ................................. 6.5 kg (14 lb 5 oz.)
External dimensions.........................420(W) X 402(D) X 190(H) mm
16-9/16(W) X 15-13/16(D) X 7-1/2(H) in.
2. Audio section
Frequency response ................................................... 2 Hz - 20 kHz
S/N ratio .......................................................... 98 dB or more (EIAJ)
Dynamic range ................................................96 dB or more (EIAJ)
Channel separation ......................................... 96 dB or more (EIAJ)
Harmonic distortion.......................................0.003 % or less (EIAJ)
Level difference between channels................. 1.0 dB or less (EIAJ)
Output voltage ........................................................... 2 Vrms (EIAJ)
Wow and flutter ............................... less than ±0.001 % (W.PEAK)
( below measurable level ) (EIAJ)
Channels ............................................................2-channel ( stereo )
Published by Pioneer Electronic Corporation.
Copyright © 1998 Pioneer Electronic Corporation.
All rights reserved.
Downloaded from www.Manualslib.com manuals search engine
Downloaded From Disc-Player.com Pioneer Manuals
