Pioneer DV-333 User manual

DV-333
Operating Instructions
DVD PLAYER

2
CONGRATULATIONS ON YOUR PURCHASE OF
THIS FINE PIONEER PRODUCT.
Pioneer is on the leading edge of DVD research for
consumer products and this unit incorporates the latest
technological developments.
We are sure you will be fully satisfied with the DVD
player.
Thank you for your support.
THE STANDBY/ON SWITCH IS SECONDARY
CONNECTED AND THEREFORE DOES NOT
SEPARATE THE UNIT FROM MAINS POWER IN THE
STANDBY POSITION.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
IMPORTANT NOTICE
[For U.S. model]
The serial number for this equipment is located on the
rear panel. Please write this serial number on your
enclosed warranty card and keep it in a secure area. This
is for your security.
CAUTION: This product satisfies FCC regulations when
shielded cables and connectors are used to connect
the unit to other equipment. To prevent
electromagnetic interference with electric appliances
such as radios and televisions, use shielded cables
and connectors for connections. [For Canadian model]
CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT
USE THIS (POLARIZED) PLUG WITH AN EXTENSION
CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE
BLADES CAN BE FULLY INSERTED TO PREVENT
BLADE EXPOSURE.
ATTENTION: POUR PREVENIR LES CHOCS
ELECTRIQUES NE PAS UTILISER CETTE FICHE
POLARISEE AVEC UN PROLONGATEUR, UNE PRISE
DE COURANT OU UNE AUTRE SORTIE DE COURANT,
SAUF SI LES LAMES PEUVENT ETRE INSEREES A
FOND SANS EN LAISSER AUCUNE PARTIE A
DECOUVERT.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try
to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and
receiver.
– Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV
technician for help.
[For Canadian model]
This Class B digital apparatus complies with Canadian
ICES-003.
CAUTION
• Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
• The use of optical instruments with this product
will increase eye hazard.
[Pour le modèle Canadien]
Cet appareil numérique de la Classe B est conforme à
la norme NMB-003 du Canada.
Information to User
Alteration or modifications carried out without
appropriate authorization may invalidate the user's
right to operate the equipment.
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual property
rights owned by Macrovision Corporation and other
rights owners. Use of this copyright protection
technology must be authorized by Macrovision
Corporation, and is intended for home and other
limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.

3
Please read through these operating instructions so you will know how to operate your model properly. After you
have finished reading the instructions, put them away in a safe place for future reference.
• This player is not suitable for commercial use.
Thelightningflashwitharrowheadsymbol,within
anequilateraltriangle,isintendedtoalerttheuser
tothepresenceofuninsulated"dangerousvoltage"
within the product's enclosure that may be of
sufficientmagnitudetoconstituteariskofelectric
shock to persons.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
IMPORTANT
CAUTION:
TO PREVENT THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
Theexclamationpointwithinanequilateraltriangle
is intended to alert the user to the presence of
importantoperatingandmaintenance(servicing)
instructions in the literature accompanying the
appliance.
READ INSTRUCTIONS — All the safety and
operating instructions should be read before
the product is operated.
RETAIN INSTRUCTIONS — The safety and
operating instructions should be retained for
future reference.
HEEDWARNINGS—Allwarningsontheproduct
and in the operating instructions should be
adhered to.
FOLLOW INSTRUCTIONS — All operating and
use instructions should be followed.
CLEANING — Unplugthisproductfromthewall
outletbeforecleaning.Theproduct should be
cleanedonlywithapolishingclothorasoftdry
cloth.Nevercleanwithfurniturewax,benzine,
insecticidesorothervolatileliquidssincethey
may corrode the cabinet.
ATTACHMENTS—Donotuseattachmentsnot
recommended by the product manufacturer
as they may cause hazards.
WATER AND MOISTURE — Do not use this
product near water — for example, near a
bathtub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming
pool; and the like.
ACCESSORIES — Do not place this product on
an unstable cart, stand, tripod, bracket, or
table. The product may fall, causing serious
injury to a child or adult, and serious damage
to the product. Use only with a cart, stand,
tripod,bracket,ortablerecommendedbythe
manufacturer, or sold with the product. Any
mounting of the product should follow the
manufacturer’sinstructions,andshouldusea
mounting accessory recommended by the
manufacturer.
CART — A product and cart combination should
be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the
product and cart combination to overturn.
VENTILATION — Slots and openings in the
cabinet are provided for ventilation and to
ensurereliableoperationoftheproductandto
protectitfromoverheating,andtheseopenings
mustnotbeblockedorcovered.Theopenings
shouldneverbeblockedbyplacingtheproduct
on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in
installation such as a bookcase or rack unless
proper ventilation is provided or the
manufacturer’s instructions have been
adhered to.
POWER SOURCES — This product should be
operated only from the type of power source
indicated on the marking label. If you are not
sure of the type of power supply to your
home, consult your product dealer or local
power company.
LOCATION–Theapplianceshouldbeinstalledin
a stable location.
NONUSE PERIODS – The power cord of the
applianceshouldbeunpluggedfromtheoutlet
when left unused for a long period of time.
GROUNDING OR POLARIZATION
• If this product is equipped with a polarized
alternatingcurrentlineplug (aplughavingone
blade wider than the other), it will fit into the
outletonlyoneway.Thisisasafetyfeature.If
you are unable to insert the plug fully into the
outlet,tryreversingtheplug.Iftheplugshould
stillfailtofit,contactyourelectriciantoreplace
your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
• If this product is equipped with a three-wire
grounding type plug, a plug having a third
(grounding) pin, it will only fit into a grounding
type power outlet. This is a safety feature. If
you are unable to insert the plug into the
outlet,contactyourelectriciantoreplaceyour
obsolete outlet. Do not defeat the safety
purpose of the grounding type plug.
POWER-CORD PROTECTION — Power-supply
cords should be routed so that they are not
likely to be walked on or pinched by items
placeduponor againstthem,payingparticular
attention to cords at plugs, convenience
receptacles, and the point where they exit
from the product.
OUTDOOR ANTENNA GROUNDING — If an
outsideantennaor cablesystemis connected
to the product, be sure the antenna or cable
system is grounded so as to provide some
protection against voltage surges and built-up
static charges. Article 810 of the National
Electrical Code, ANSI/NFPA 70, provides
informationwithregardtopropergroundingof
the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location of
antenna-discharge unit, connection to
grounding electrodes, and requirements for
the grounding electrode. See Figure A.
LIGHTNING — For added protection for this
product during a lightning storm, or when it is
leftunattendedandunusedforlongperiodsof
time, unplug it from the wall outlet and
disconnect the antenna or cable system. This
will prevent damage to the product due to
lightning and power-line surges.
POWER LINES — An outside antenna system
shouldnotbelocatedinthevicinityofoverhead
power lines or other electric light or power
circuits, or where it can fall into such power
lines or circuits. When installing an outside
antennasystem,extremecareshouldbetaken
to keep from touching such power lines or
circuits as contact with them might be fatal.
OVERLOADING — Donot overload wall outlets,
extension cords, or integral convenience
receptaclesasthiscanresultin a risk of fireor
electric shock.
OBJECT AND LIQUID ENTRY — Never push
objects of any kind into this product through
openingsastheymaytouchdangerousvoltage
points or short-out parts that could result in a
fire or electric shock. Never spill liquid of any
kind on the product.
SERVICING — Do not attempt to service this
product yourself as opening or removing
coversmayexposeyoutodangerousvoltage
orotherhazards.Referallservicingtoqualified
service personnel.
DAMAGE REQUIRING SERVICE— Unplug this
productfromthewalloutletandreferservicing
to qualified service personnel under the
following conditions:
• When the power-supply cord or plug is
damaged.
• Ifliquidhasbeenspilled,orobjectshavefallen
into the product.
• If the product has been exposed to rain or
water.
• If the product does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions as an improper
adjustment of other controls may result in
damageandwilloftenrequireextensivework
byaqualifiedtechniciantorestoretheproduct
to its normal operation.
• If the product has been dropped or damaged
in any way.
• Whentheproductexhibitsadistinctchangein
performance — this indicates a need for
service.
REPLACEMENT PARTS — When replacement
parts are required, be sure the service
technician has used replacement parts
specified by the manufacturer or have the
same characteristics as the original part.
Unauthorized substitutions may result in fire,
electric shock, or other hazards.
SAFETY CHECK — Upon completion of any
service or repairs to this product, ask the
servicetechniciantoperformsafetychecksto
determine that the product is in proper
operating condition.
WALLORCEILING MOUNTING—Theproduct
should not be mounted to a wall or ceiling.
HEAT — The product should be situated away
from heat sources such as radiators, heat
registers,stoves,orother products(including
amplifiers) that produce heat.
IMPORTANT SAFETY INSTRUCTIONS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND CLAMPS
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUND
CLAMP
Fig. A
NEC — NATIONAL ELECTRICAL CODE
ANTENNA
LEAD IN WIRE
ELECTRIC
SERVICE
EQUIPMENT

4
Features of This Player
Compatible with DVD, Video CD
and CD formats
DVD, Video CD and CD discs that display the logos
shown below can be played back on PIONEER DVD
players. For more information on discs compatible with
this player, refer to the table below.
The disc format logos shown above are found on disc
labels or on disc jackets.
• To prevent malfunction, do not use an 8 cm (3 in.)
adaptor (for CDs).
• Discs other than the ones indicated above cannot be
played on this unit.
• DVDs that have incompatible region numbers, DVD-
Audio, DVD-ROM, and CD-ROM cannot be played on
this unit. The region number of the player can be
found on the rear panel.
*Playing recordable CDs
• Note that this unit cannot record onto recordable discs.
• This unit can play music-use CD-R and CD-RW discs.
However, depending on the condition of the player and the
disc, you may find that not all discs will play successfully.
(For example, if the disc is scratched or dirty, or if the
player’s pickup lens is dirty.)
12 cm (5in.)/
single-sided
12 cm (5in.)/
double-sided
8 cm (3 in.)/
single-sided
8 cm (3 in.)/
double-sided
1 layer
2 layer
1 layer
2 layer
1 layer
2 layer
1 layer
2 layer
DVD VIDEO DVD VIDEO
Types of playable
discs and their marks Diameter/ Playable sides Playback time
Digital audio
Digital video
(MPEG 2)
133 min.
242 min.
266 min.
484 min.
VIDEO CD
CD
Digital audio
Digital video
(MPEG 2)
DVD VIDEO
VIDEO CD
CD
41 min.
75 min.
82 min.
150 min.
VIDEO CD single
CD single
Digital audio
Digital video
(MPEG 1)
Max. 74
minutes
Digital audio
Digital video
(MPEG 1)
Max. 20
minutes
Digital audio
Max. 74
minutes
12 cm (5 in.)/
single-sided
8 cm (3 in.)/
single-sided
12 cm (5 in.)/
single-sided
8 cm (3 in.)/
single-sided
Digital audio
Max. 20
minutes
We
Want You
LISTENING
For A Lifetime
Selectingfineaudioequipmentsuchastheunityou’vejust
purchased is only the start of your musical enjoyment. Now
it’s time to consider how you can maximize the fun and
excitement your equipment offers. This manufacturer and
theElectronicIndustriesAssociation’sConsumerElectronics
Group want you to get the most out of your equipment by
playingitatasafelevel.Onethatletsthesoundcomethrough
loud and clear without annoying blaring or distortion-and,
most importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort
level” adapts to higher volumes of sound. So what sounds
“normal” can actually be loud and harmful to your hearing.
Guard against this by setting your equipment at a safe level
BEFORE your hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowlyincreasethesounduntilyoucanhearitcomfortably
and clearly, and without distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
Takingaminutetodothisnowwillhelptopreventhearing
damage or loss in the future. After all, we want you listening
for a lifetime.
We Want You Listening For A
Lifetime
Used wisely, your new sound equipment will provide a
lifetime of fun and enjoyment. Since hearing damage from
loud noise is often undetectable until it is too late, this
manufacturer and the Electronic Industries Association’s
ConsumerElectronicsGrouprecommendyouavoidprolonged
exposure to excessive noise. This list of sound levels is
included for your protection.
Decibel
Level Example
30 Quiet library, soft whispers
40 Livingroom,refrigerator,bedroomawayfromtraffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Averagecitytraffic, garbage disposals, alarm clock
at two feet.
THE FOLLOWING NOISES CAN BE
DANGEROUS UNDER CONSTANT EXPOSURE
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rockband concert in front of speakers,thunderclap
140 Gunshot blast, jet plane
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
We
Want You
LISTENING
For A Lifetime
EST 1924
EIA
E
L
E
C
T
R
O
N
I
C
I
N
D
U
S
T
R
I
E
S
•
A
S
S
O
C
I
A
T
I
O
N
•
EST 1924
EIA
E
L
E
C
T
R
O
N
I
C
I
N
D
U
S
T
R
I
E
S
•
A
S
S
O
C
I
A
T
I
O
N
•
*
*

5
Wide range of DVD viewing options
Multi-Angle (page 30)
You can view scenes from different camera angles when
watching movies or other media with multiple angle
playback available.
Multiple Languages (page 32)
You can select the language on when watching movies
or other media that have multiple language and/or audio
soundtracks recorded on them.
Multi-Language Subtitles (page 33)
You can select a subtitle language or turn subtitles off
when watching movies or other media with subtitles
available.
This mark indicates this may not be possible with certain discs.
Energy-saving design
This unit is designed to use less than 1 W of energy
when this player is in standby mode.
Audio : 1 English Dolby Digital
5.1CH Audio : 2 Spanish
HELLO
HOLA
Dolby Digital
5.1CH
HELLO! HOLA!
Subtitle :1 English Subtitle :2 Spanish
ANGLE : 3/4
ANGLE : 2/4
Compatible with a wide range of
DVD digital audio output formats
DVDs are recorded in one of four types of digital audio
formats (as of October 1998). The digital audio output
jacks of this player output Dolby Digital*, DTS**, MPEG,
and linear PCM digital bitstreams.
This player has a function that converts Dolby Digital and
MPEG audio formats into the linear PCM format. This
allows playback of DVDs recorded in Dolby Digital and
MPEG without the need for a decoder.
Easy setup and adjustment using
on-screen menus
Press SETUP on the remote control to open the Setup
screen and you’ll find setting up and adjusting the
system easy to do with on-screen menus conveniently
organized and arranged. Additionally, on-screen
information ( i)❖appears to clarify the functions and
explain the options available. Below are just a few
examples.
Select the type of TV screen
you are using and the
preferred screen format
you’d like to use when
watching DVDs in the Video
menu (page 28).
* Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby
Laboratories. Confidential unpublished works, © 1992-1997
Dolby Laboratories. All rights reserved.
** “DTS” and “DTS Digital” are trademarks of Digital Theater
Systems, Inc.
Audio1 Audio2 GeneralLanguageVideo
TV Screen
Picture Quality -
Move
Exit
16:9(Wide)
4:3(Pan&Scan)
4:3(Letter Box)
SETUP
Select your display preference
1
Answer a few questions and
have all the necessary audio,
video, and on-screen
language adjustments set
automatically by the player
using the Setup Navigator
(page 17).
Audio1 Audio2 GeneralLanguageVideo
Setup Navigator
Move
Exit
SETUP
Select
ENTER
Setup Navigator
Auto Start Off
Start
❖The on-screen information (
i
) only appears if you
choose [English] as the [OSD Language] (page 18,
31).
While using the Setup Navigator, no on-screen
information (
i
) is displayed.

6
How to Proceed in This
Manual
DVD is an incredible format that presents the highest
quality digital audio and video available today. The
amount of information that can be recorded onto a DVD
disc is remarkable, allowing it to offer numerous
functions and features available with no other format.
Because using the DVD player and DVDs may be
confusing at first, following the order below should help
you get through the important stages of getting set up
so you can start using your player as soon as possible.
Get familiar with the player.
Refer to the section “Before Using” on page 8 to
confirm that all the accessories were included with the
player. If you are new to DVD, it might be beneficial for
you to go through the “Names and Functions” section
starting on page 9 to get familiar with the parts and
buttons on the main unit and remote control as they will
be referred to throughout this manual.
There is also a list of terms that can be found on page 54
if you are having trouble understanding some of the
terminology associated with DVD.
Make the necessary connections.
No entertainment system seems to be set up exactly
the same way. The “Making Connections” section
starting on page 14 shows how video and audio
connections may be made to suit your home
entertainment system.
Set up the necessary player
menus.
Before you can begin to enjoy the benefits of the DVD
format, it is first necessary to set up the player to output
the video and audio information that corresponds to your
system. The section “Setting Up the Player” starting
on page 17 explains how to use the Setup Navigator, a
function that automatically sets up the player
corresponding to the answers given in a multiple-choice
on-screen procedure. The Setup screen menus,
described in the section starting on page 24, are also
used in a number of other functions. Learning the
procedure for operating these menus will make using
this player much easier and more enjoyable.
Play a disc.
When all the connections and setups have been made,
you are ready to play a DVD, Video CD, or CD with the
player. The section “Getting Started Using Your DVD
Player” starting on page 20 outlines the basic player
operations.
Enjoy the many features available.
Once you are comfortable using the basic player
functions, you are ready to take advantage of the various
options DVD and this player have to offer. The section
“Advanced Functions” starting on page 36 describes
how to use the features available on many DVDs.
Differences in Disc
Composition
DVD
DVDs are divided into units referred to as titles, and
titles are divided into chapters. A DVD which contains a
movie may have only one title with many or no chapter
divisions. Karaoke DVDs may have many titles, assigning
a title to each song on the disc. Menu screens do not
belong to any title.
DVD player functions generally apply to titles on a disc or
chapters within a selected title. The player functions
available may also vary from title to title, depending on
the disc. When discs have a unique title division, it
should be noted that search and program functions may
be affected.
Video CD/CD
Video CDs and CDs are divided into units referred to as
tracks (Video CD tracks may also be referred to as
scenes). One song generally corresponds to one track.
Some tracks are further divided into units referred to as
indexes. Video CDs with PBC (Playback Control) also
contain menus recorded on the disc which enable easy
access to the contents of the disc.
When played back on a DVD player, both Video CDs and
CDs are considered to be a single title, regardless of the
number of tracks.
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 2
DVD
Chapter 1
Video CD
Track 1 Track 2 Track 3 Track 4
CD
Track 2 Track 4Track 3Track 1 Track 5

7
Table of contents
Before Using ........................................ 8
Checking Accessories .....................................8
Preparing the Remote Control.........................8
Names and Functions ......................... 9
Front Panel ......................................................9
Display Window.............................................10
Rear Panel .....................................................11
Remote Control .............................................12
Making Connections ......................... 14
Connecting Your DVD Player .........................14
Audio Connections ........................................15
Video Connections.........................................16
System Control Connections.........................16
Setting Up the Player ....................... 17
Using the Setup Navigator.............................17
Getting Started Using Your DVD
Player.................................................. 20
Playing DVDs, Video CDs and CDs................20
Chapter (Track) Skip Forward/Skip Back ........22
Forward and Reverse Scanning.....................22
Resuming playback from where
you stopped .............................................23
Stopping Playback and Switching
Power Off ................................................23
Adjusting Audio and Video Settings
............................................................ 24
Using the Setup Screen Menus ....................24
Changing to the Setup Screen “Expert” Menu
Mode........................................................25
Setting the Digital Audio Output To Be
Compatible with Your AV Component......26
Adjusting the Dynamic Range of the Audio
Soundtrack ...............................................27
Setting the TV Screen Size ............................28
Selecting Picture Quality Appropriate for
Program Content......................................29
Viewing from a Desired Camera Angle
(Multi-Angle).............................................30
Setting the Language Options......... 31
Setting the on-screen display
(OSD) language ........................................31
Setting Language and Subtitle Preferences in
the Setup Screen Menus .........................31
Changing the Audio Language
(Multi-Language Function) .......................32
Selecting a Subtitle Language
(Multi-Language Subtitles) .......................33
Advanced Functions ......................... 36
Setting the Parental Lock Level.....................36
Changing the Background Color
of the Screen ...........................................37
Still Frame/Slow Play/
Frame Advance Playback .........................38
Searching for a Title, Chapter, Track,
or Location on a Disc ...............................39
Repeat Play....................................................40
Random Play..................................................41
Playback in a Desired Order
(Program Play)..........................................42
Continuing Playback from a
Specified Location (Last Memory) ...........45
Memorizing Settings for Often
Viewed DVDs (Condition Memory) ..........46
Viewing Disc Information ..............................47
Resetting the Player to System Settings.......48
Additional Information ..................... 49
Disc Care .......................................................49
For Proper and Long Use of This Unit ...........50
Language Code List.......................................51
Troubleshooting .............................................52
Terms.............................................................54
Specifications ................................................55

8
Preparing the Remote Control
Inserting batteries into the remote
control
1While pushing the tab on the battery
compartment cover
toward the center of
the remote, pull out
in the direction
indicated by the
arrow.
2Insert batteries.
Make sure to match the
plus (+) and minus
(–) polarity guides on the
batteries with the marks
inside the battery
compartment.
3Close the cover.
Notes
• Do not mix old and new batteries.
• When replacing batteries, use all new batteries.
• When not using the remote control for a long period of time
(over 1 month), remove the batteries to avoid possible
damage from battery corrosion. If battery leakage occurs,
wipe the battery liquid from the battery component, then
insert new batteries.
Remote control operation
When operating the remote control, point it at the
remote sensor (Î) located on the player’s front panel.
The remote control can be used up to 23 feet (7 m) from
the player and within a 30° angle on each side of the
sensor.
Notes
• Exposing the remote sensor to direct sunlight or strong light
may cause faulty operation.
• If the CONTROL IN jack on the player’s rear panel is
connected to the CONTROL OUT jack of another component,
point the remote control at the other component to operate the
player. Operation will not be possible when pointed at this
player (page 16).
Before Using
Checking Accessories
Please confirm that the following were received with the
player.
Audio cord
Video cord
Power cord
Remote control unit
AA/R6P batteries
Operating instructions (this manual)
RANDOM PROGRAM
SEARCH MODE
09
8
7
+10
6
5
4
CLEAR
3
2
1
1
REV FWD
¡
PLAY
3
PAUSE
8
STOP
7
e
STEP/SLOW
E
NEXT ¢
PREV 4
RETURN
REPEAT
CONDITION
MEMORY
LAST
MEMORY
ANGLE
SUB TITLE
AUDIO
SETUP MENU
TOP MENU
DISPLAY
¶
5
∞
3
2
Î
¶
OPEN/
CLOSE
REPEAT
A-B
¶
¶ 5
5
5
5
E
N
T
E
R
¶
¶
3030
7m (23ft.)

9
Names and
Functions
1STANDBY/ON switch
Press to switch the player on or to put in standby
(pages 20, 23).
2Disc tray
When loading a disc, place discs in the disc tray with
the label side facing up (pages 20, 23).
30(open/close) button
Press to open and close the disc tray (pages 20, 23).
47(stop) button
Press to stop playback. Pressing once enables
playback to resume from a point shortly before the
location where it stopped. Pressing twice causes the
disc to return to the beginning of the disc if playback
starts again (page 23).
58 (pause) button
Press during playback to pause. Press again to
resume playback (page 38).
63(play) button
Press to start or resume playback (pages 20, 23).
7¡¢(forward) button
Press to advance to chapters/tracks. Press and hold
to perform fast-forward scanning (page 22).
841(reverse) button
Press to go back to previous chapters/tracks. Press
and hold to perform reverse playback scanning
(pages 22).
9Remote sensor
Point the remote control toward the remote sensor
to operate the player (page 8).
0Display window
Displays system information (page 10).
Front Panel
STANDBY/ON
DVDPLAYER
387¡ ¢4 10
ÎA
9
13456
7
8
0
2
BEFORE USING/NAMES AND FUNCTIONS

10
Display Window
1VCD indicator
VCD lights when a Video CD is loaded. CD lights
when an audio CD is loaded.
2DVD indicator
Lights when a DVD is loaded.
3indicator
Indicates Multi-Angle playback is in progress (page
30).
4TITLE indicator
Indicates a title number is being displayed.
5TRK indicator
Indicates a track number is being displayed.
6CHP indicator
Indicates a chapter number is being displayed.
7GUI indicator
Indicates an on-screen menu operation is being
performed (page 17).
8REMAIN indicator
Indicates that the remaining playback time of a title
or chapter/track is being displayed.
9CONDITION indicator
Indicates that Condition Memory settings are
memorized for the currently loaded DVD (page 46).
0TOTAL indicator
Indicates that the disc in the player is stopped and
DISPLAY has been pressed (page 48).
-indicator
Indicates that the Repeat function is on and that the
current title, chapter, or track is being repeated (page
40).
=DOLBY DIGITAL indicator
Indicates Dolby Digital audio playback.
~LAST MEMO indicator
Indicates the Last Memory location is recorded in
memory for the currently loaded DVD or Video CD
(page 45).
!Counter display
Displays the playback mode, type of disc, title and
chapter/track numbers, playback time, etc.
@83 indicator
3light when any disc is playing. When a disc is
paused, 8lights.
TITLE
DVD
VCD
CONDITION
TOTAL
REMAIN
LAST
MEMO
TRK CHP
DOLBY
DIGITAL
GUI
1235
6
78 90-=~
!@
4

11
Rear Panel
1COMPONENT VIDEO OUT jacks
If your TV or monitor has component video inputs,
you can produce a higher quality picture on your TV
or monitor by connecting to the component video
outputs on this unit. When using these jacks, be
sure to set VIDEO OUT SELECT to the right position
(page 16).
2DIGITAL OUT jack (coaxial)
Use to output the digital audio signal recorded on
discs. You can output the digital signal via either
coaxial output jack to an AV amplifier or receiver
(page 15).
3VIDEO OUT SELECT switch
Use to set which output is used to output the video
signals. Select either video/S-video or component
video signal output depending on the connections
you make (page 16).
4DIGITAL OUT jack (optical (OPT.))
Use to output the digital audio signal recorded on
discs. You can output the digital signal via either
optical output jack to an AV amplifier or receiver
(page 15).
5CONTROL IN jack
Use to connect this player to another component
bearing the Pioneer Îmark. This lets you control
this unit as though it were a component in a system.
Player operations are then performed by pointing the
remote control at the component that the player is
connect to (page 16).
6AC IN power cord connection terminal
Use to connect the power cord to the wall outlet
(page 14).
7S-VIDEO OUT jack
If your TV or monitor has an S-video input, clear
picture reproduction is possible by connecting the
player to your TV or monitor via the S-Video jack.
When using this output, be sure to set VIDEO OUT
SELECT to the left position (page 16).
8VIDEO OUT jack
Connect to the video input on a TV or monitor or AV
amplifier or receiver with video input capability.
When using this output, be sure to set VIDEO OUT
SELECT to the left position (pages 14, 16).
9AUDIO OUT jacks
Use to output two-channel audio (analog) to the
audio stereo inputs on a TV or stereo amplifier. If you
are connecting to a receiver that has both digital and
analog input jacks for DVD player connection, it may
be beneficial to make both connections (pages 14,
15).
COMPONENT VIDEO OUT DIGITAL OUT
AUDIO OUT VIDEO
OUT S-VIDEO
OUT
VIDEO
OUT
SELECT
DIGITAL
OUT
OPT CONTROL
IN
AC IN
Y PBPR
L
R
1234 56
7
89
NAMES AND FUNCTIONS

12
(Buttons indicated with * are used for menu operation.)
1LAST MEMORY button
You can resume DVD or Video CD playback from the
point you last watched even if the disc is removed
from the player. Press LAST MEMORY during
playback to set a Last Memory point. When you
want to resume playback of that disc, press LAST
MEMORY in the stop mode and playback starts
from the memorized point. Last Memory locations
can be stored for up to 5 DVDs and 1 Video CD (page
45).
2(standby/on) button
Press to switch the player on or to put in standby
(pages 20, 23).
3AUDIO button
Press repeatedly to select one of the audio
languages and/or audio formats programmed on a
DVD (page 32).
For Video CD and CD, each press changes the audio
output as follows.
4SUBTITLE button
Press repeatedly to select one of the subtitle
languages programmed on a DVD or to turn the
subtitles off (page 33).
5SETUP button*
Press when the player is in either play or stop mode
to open and close the Setup screen (page 17).
6MENU button*
Use to display or close the DVD menu screen (page
21).
7DISPLAY button
Press during playback to display statistical disc
information. Press repeatedly to display different
information (page 47).
8Cursor buttons (2/3/5/∞)*
Use to move through the options on menu screens
and to change settings.
9ENTER button*
Use to implement settings selected with the cursor
buttons or to set items highlighted in a menu.
0PREV 4 (previous)
During playback, press PREV 4to go back to a
previous chapter/track (page 22).
-STOP 7button
Press to stop playback. Pressing once enables
playback to resume from a point shortly before the
location where it was stopped. Pressing twice
causes the disc to return to the beginning of the disc
when playback starts again (page 23).
Remote Control
=Stereo =1/L (Left) =2/R (Right)
RANDOM PROGRAM
SEARCH MODE
09
8
7
+10
6
5
4
CLEAR
3
2
1
1 REV FWD
¡
PLAY 3
PAUSE 8
STOP 7
e STEP/SLOW E
NEXT
¢
PREV
4
RETURN
REPEAT
CONDITION
MEMORY
LAST
MEMORY
ANGLE
SUB TITLE
AUDIO
SETUP MENU
TOP MENU
DISPLAY
¶
5
∞
3
2
Î
¶
OPEN/
CLOSE
REPEAT
A-B
¶
¶ 5
5
5
5
E
N
T
E
R
¶
¶
2
3
4
5
6
7
8
£
9
0
-
=
~
!
1
$
%
^
&
*
(
)
_
+
¡
™
#
@

13
_PLAY 3button
Press to start disc playback (pages 20, 23).
+PAUSE 8button
Press to pause playback of a disc. Press again to
resume playback (page 38).
¡1REV FWD ¡(fast reverse/forward)
buttons
During playback of DVD and Video CD, press
FWD ¡to perform fast forward scanning. Press
REV 1to perform fast reverse scanning of DVD
and Video CD. When a CD is loaded, audio scanning
is performed (page 22).
™CLEAR button
Works in conjunction with a number of player
functions. Use to cancel repeat and random
playback, and to edit programs.
£SEARCH MODE button
Press to perform a title, chapter/track or elapsed
time search (page 39).
=e STEP/SLOW Ebuttons
Press STEP/SLOW Eduring playback to view
slow playback. In pause mode, press STEP/SLOW
Eto advance DVDs and Video CDs frame by frame
and STEP/SLOW eto back up a few frames at a
time (page 38).
~Number buttons (1-9, 0, +10)*
Use to perform direct title and chapter/track
searches, and to input numerical values.
!RANDOM button
Press to play chapters/tracks in random order (page
41).
@PROGRAM button
You can program titles, chapters, or tracks to play
back in a desired order. Programs can be a
maximum of 24 steps. Additionally, DVD programs
for up to 24 discs can be stored in the player’s
memory for future use (page 42-44).
#CONDITION MEMORY button
You can store in memory the settings for up to 15
DVDs. Press CONDITION MEMORY during DVD
playback to memorize the settings (page 46).
$OPEN/CLOSE button
Press to open or close the disc tray (pages 20, 23).
%ANGLE button
Some DVDs are recorded with various camera angle
playback options. Press ANGLE repeatedly to
display different camera angles (page 30).
^REPEAT button
Press once to repeat playback of current chapter/
track. Press twice to repeat playback of current title
(page 40).
&REPEAT A-B button
Press at the beginning and end of the section you
want to repeat or to mark a location you want to
return to (page 40).
*TOP MENU button*
Press to call up the top menu programmed on the
DVD. Depending on the DVD, the top menu may be
identical to the DVD menu (page 21).
(RETURN button*
Use to go one menu back (current settings are
maintained). Use RETURN when you do not want to
change the option setting in a menu.
)NEXT ¢
During playback, press NEXT ¢to advance to the
next chapter/track (page 22).
NAMES AND FUNCTIONS

14
Making
Connections
Connection Guide
The illustration on this page shows the basic setup using
the audio and video cords included with this player. Use
this illustration as a guide to setting up your home
system.
An explanation of each type of audio and video
connection available can be found on pages 15 to 16 . To
determine the best audio and video connection setup for
your system, refer to the manuals supplied with the
components you are making connections to.
In addition to making physical connections to your TV or
monitor, it is also necessary to assign the TV screen size.
You can use the [Setup Navigator] in the Setup screen
General menu to set whether you are using a wide
screen or standard size TV or monitor (page 18).
Additionally, you can use the [TV Screen] setting in the
Setup screen Video menu (page 28).
Notes
• When making connections to this unit or when changing
connections, check that the unit is off by pressing
STANDBY/ON and unplug the power cord from the
power outlet.
• The analog video output on this player uses copy protect
circuitry to prevent the video playback on DVDs from being
copied. If you connect the player to a TV via a VCR, or
record and play back the contents of a disc with a VCR, the
playback picture may not be normal.
Connecting Your DVD Player
Unlike any other audiovisual media format, DVD offers a
wide array of audio and video output options which
allows playback to be enjoyed in any number of system
configurations from a standard TV with stereo audio
input to a home theater system with a TV or monitor and
full surround sound capabilities.
Audio cord
(Included) Video cord (Included)
TV or monitor
Make video connections from the VIDEO
OUT jacks on the player to the VIDEO IN jack
on the TV or monitor using the video cord
included with the player. Set the VIDEO OUT
SELECT to the left position.
Make audio connections from the AUDIO
OUT jacks on the player to the AUDIO IN
jacks on the TV or monitor using the stereo
audio cord included with the player. Be sure
to match the color of the plugs with the
color of the jacks (red and white).
Finally, connect to a
power outlet (120 V).
RL
AUDIO IN
S-VIDEO INVIDEO IN
COMPONENT VIDEO OUT DIGITAL OUT
AUDIO OUT VIDEO
OUT S-VIDEO
OUT
VIDEO
OUT
SELECT
DIGITAL
OUT
OPT CONTROL
IN
AC IN
YPBPR
L
R

15
MAKING CONNECTIONS
Audio Connections
This player features two digital (optical and coaxial) and
also analog audio output formats.
Digital Audio Connections:
You can enjoy the digital audio recorded on DVD discs
from both optical digital and coaxial digital output jacks.
When making digital audio connections, do not
make connections from both the coaxial and optical
digital outputs to the same component.
When a DVD recorded in Dolby Digital, DTS, or MPEG is
loaded, noise will be output if you have made
connections via the digital audio jacks to a receiver or
amplifier that cannot decode a Dolby Digital, DTS, or
MPEG digital bitstream. In this case, be sure to set up
the Setup Navigator audio settings to best reflect the
type of system you are using (page 19). Additionally, the
digital audio settings can be adjusted manually in the
Setup screen Audio 1 menu (page 26-27).
DIGITAL OUT (Optical)
The digital signal is transmitted as light pulses through a
fiber-optic cable.
• Use to connect to an AV amplifier or receiver with
built-in Dolby Digital, DTS, or MPEG decoder.
• Use a fiber-optic cable (not supplied) to connect the
DIGITAL OUT OPT (digital optical output) on the
player to the digital optical input on an AV amplifier or
receiver.
DIGITAL OUT (Coaxial)
The digital signal is transmitted electronically through a
coaxial cable.
• Use to connect to an AV amplifier or receiver with
built-in Dolby Digital, DTS, or MPEG decoder.
• Use a coaxial cable (not supplied) to connect the
DIGITAL OUT (coaxial digital output) on the player to
the coaxial digital input on an AV amplifier or receiver.
AV amplifier or receiver with
built-in Dolby Digital, DTS, or
MPEG decoder
COMPONENT VIDEO OUT DIGITAL OUT
AUDIO OUT VIDEO
OUT S-VIDEO
OUT
VIDEO
OUT
SELECT
DIGITAL
OUT
OPT CONTROL
IN
AC IN
Y PBPR
L
R
DIGITAL IN
DIGITAL OUT
DIGITAL IN
Analog Audio Connection:
AUDIO OUT
• Make analog audio connections to a stereo amplifier
or receiver.
• Analog audio connections can also be made to a TV or
monitor with stereo input jacks.
• Use the supplied audio cord to connect the AUDIO
OUT on the player to the audio input on the stereo
amplifier or receiver.
• When making analog audio connections, be sure to
match the color of the plugs with the color of the
jacks (red and white).
COMPONENT VIDEO OUT DIGITAL OUT
AUDIO OUT VIDEO
OUT S-VIDEO
OUT
VIDEO
OUT
SELECT
DIGITAL
OUT
OPT CONTROL
IN
AC IN
Y PBPR
L
R
AUDIO IN
AUDIO OUT
L
R
LR
Stereo amplifier or receiver
AV amplifier or receiver with
built-in Dolby Digital, DTS, or
MPEG decoder
COMPONENT VIDEO OUT DIGITAL OUT
AUDIO OUT VIDEO
OUT S-VIDEO
OUT
VIDEO
OUT
SELECT
DIGITAL
OUT
OPT CONTROL
IN
AC IN
Y PBPR
L
R
DIGITAL IN
DIGITAL
OUT
OPT

16
Video Connections
This player features S-video, composite, and component
video output possibilities.
Check the manual supplied with your TV or monitor to
determine the best possible connection for your system.
In addition to making physical connections to your TV or
monitor, it is also necessary to assign the TV screen size.
You can use the [Setup Navigator] in the Setup screen
General to set whether you are using a wide screen or
standard size TV or monitor (page 18). Additionally, you
can use the [TV Screen] setting in the Setup screen
Video menu (page 28).
S-VIDEO OUT
• Make S-video connections to a TV or monitor with S-
video input to produce a high quality video image.
• Use an S-video cable (not supplied) to connect the
output on the player to S-video input on the TV or
monitor.
• When making S-video connections, make sure to set
the VIDEO OUT SELECT switch on the rear panel of
the player to the left to assign S-video output.
VIDEO OUT
• Make composite video connections to a standard TV
or monitor with a video input jack.
• Use the supplied video cable to connect the VIDEO
OUT jacks on the player to the video input on the TV
or monitor.
• Be sure to match the color of the plug with the color
of the jack (yellow).
• When making video connections, make sure to set the
VIDEO OUT SELECT switch on the rear panel of the
player to the left to assign composite video output.
System Control Connections
Using a commercially available cord with a mini plug
(3.5 mm dia. with no resistance) to connect this player’s
CONTROL IN jack to the CONTROL OUT jack of
another PIONEER component bearing the Îmark, you
can control the player as though it were a component in
a system (system control).
• If you connect for system control, you cannot operate
the player directly. Point the remote control unit at the
component (AV amplifier, etc.) connected to the
CONTROL OUT jack to operate.
• When controlling as a system, be sure to make a
connection to the amplifier using an audio or video
cord, even when using only digital components.
• For details, refer to the operation manuals of the
connected components.
Pioneer component with Îmark.
COMPONENT VIDEO OUT DIGITALOUT
AUDIO OUT VIDEO
OUT S-VIDEO
OUT
VIDEO
OUT
SELECT
DIGITAL
OUT
OPT CONTROL
IN
AC IN
Y P B
P R
L
R
CONTROL
OUT
CONTROL
IN
TV or monitor
COMPONENT VIDEO OUT DIGITALOUT
AUDIO OUT VIDEO
OUT S-VIDEO
OUT
VIDEO
OUT
SELECT
DIGITAL
OUT
OPT CONTROL
IN
AC IN
Y PBPR
L
R
S-VIDEO IN
S-VIDEO
OUT
VIDEO
OUT
SELECT
TV or
monitor
COMPONENT VIDEO OUT DIGITALOUT
AUDIO OUT VIDEO
OUT S-VIDEO
OUT
VIDEO
OUT
SELECT
DIGITAL
OUT
OPT CONTROL
IN
AC IN
Y PBPR
L
R
VIDEO IN
VIDEO
OUT
SELECT
VIDEO
OUT
COMPONENT VIDEO OUT
• Make component video connections to a TV or
monitor with component inputs to produce a higher
quality video image.
• Use a component video cable or 3 video cords (not
supplied) to connect the COMPONENT VIDEO OUT
jacks on the player to the component jacks on the
monitor.
• When making component video connections, make
sure to set the VIDEO OUT SELECT switch on the
rear panel of the player to the right to assign
component video output.
TV or monitor
COMPONENT VIDEO OUT DIGITALOUT
AUDIO OUT VIDEO
OUT S-VIDEO
OUT
VIDEO
OUT
SELECT
DIGITAL
OUT
OPT CONTROL
IN
AC IN
Y P B
P R
L
R
Y
P
B
P R
COMPONENT
VIDEO IN
COMPONENT VIDEO OUT
YP
B
P R
VIDEO
OUT
SELECT

17
MAKING CONNECTIONS / SETTING UP THE PLAYER
Setting Up the
Player
Using the Setup Navigator
The Setup Navigator has been designed to simplify the
process of getting the DVD player ready to perform.
Designed as a series of on-screen multiple-choice
questions, the Setup Navigator automatically sets the
audio, video, and language settings according to how the
questions are answered. Once this procedure is
complete, it will be possible to begin using the DVD
player to enjoy DVDs.
The procedure on this page describes the operations
necessary to function within the Setup Navigator
screens. A detailed description of the contents of each
question that appears on the screen can be found on
the following pages.
When setting up for the first time
Some DVDs start playing automatically when loaded in
the player. Because the Setup Navigator cannot be used
if a disc is playing, it is recommended to set up the
player using the Setup Navigator before loading a DVD
for the first time. If a DVD has been loaded, be sure to
press STOP 7before proceeding.
1Press STANDBY/ON on the front panel
(on the remote control).
2Press SETUP.
When SETUP is pressed for the first time, the
following screen appears. Though the Setup
Navigator may be used more than once, this screen
only appears the first time SETUP is pressed.
3Use the cursor buttons (5/∞) to make a
selection.
• If you are going to use the Setup Navigator, it is
not necessary to change the setting on the first
screen. Please proceed to the next step.
•If you do not want to set up the player using
the Setup Navigator, use the cursor button
(∞) to select [Auto Start Off] at this time.
The Setup Navigator function may still be used at
a later time in manual Setup screen menu
operation (page 24).
4Press ENTER.
The selection is entered and the next Setup
Navigator screen appears.
Use steps 3and 4as a basis for entering selections on
the all of the Setup Navigator screens described on the
following pages.
To change the answer to a prior question
Use the cursor button (2) to return to previous screens.
Please note, however, that you cannot go forward using
the cursor button (3), so it will be necessary to answer
all the questions that occur after the screen that was
returned to.
To exit the Setup Navigator
Press SETUP while on any of the screens to exit the
Setup Navigator. Please note that if the Setup Navigator
is exited before all the questions are answered, no
settings are changed.
To return to the Setup screen
Press RETURN.The Setup Navigator is exited and the
Setup screen General menu screen appears. Please
note that no settings are changed if RETURN is pressed
before the Setup Navigator is finished.
STANDBY/ON
DVDPLAYER
387¡ ¢4 10
ÎA
RANDOM PROGRAM
SEARCH MODE
09
8
7
+10
6
5
4
CLEAR
3
2
1
1 REV FWD
¡
PLAY 3
PAUSE 8
STOP 7
e STEP/SLOW E
NEXT
¢
PREV
4
RETURN
REPEAT
CONDITION
MEMORY
LAST
MEMORY
ANGLE
SUB TITLE
AUDIO
SETUP MENU
TOP MENU
DISPLAY
¶
5
∞
3
2
Î
¶
OPEN/
CLOSE
REPEAT
A-B
¶
¶ 5
5
5
5
E
N
T
E
R
¶
¶
1
2
34
Audio1 Audio2 GeneralLanguageVideo
Setup Navigator
Move
Exit
SETUP
Select
ENTER
Setup Navigator
Auto Start Off
Start
1

18
Setting the OSD Language
(On-Screen Display Language)
The [OSD Language] screen establishes the OSD
language, or on-screen display language, which refers to
the language that is used by the player in menus and
on-screen messages. Additionally, the language that is
established at this setting will also be used for the
default audio and subtitle language.
Settings: English*
français
Español * Factory setting
Note
In addition to setting the OSD language, the audio and
subtitle language are also set at this time. If you wish to
change the audio or subtitle language to a different language,
make changes in the Setup screen Language menu [Audio
Language] and [Subtitle Language] as needed (page 31,
33).
Audio1 Audio2 GeneralLanguageVideo
Setup Navigator
Move
Exit
SETUP
Select
ENTER
OSD Language
Español
français
English
Language
Audio1 Audio2 GeneralLanguageVideo
Setup Navigator
Move
Exit
SETUP
Select
ENTER
TVType
Standard (4:3)
Widescreen (16:9)
TV Connection
Setting the TV screen size
The [TV Type] screen establishes the size, or more
appropriately the width to height ration of your television
or monitor. The width-to-height ratio of conventional TVs
is 4:3, while the width-to-height ratio of wide screen and
high-definition TVs is 16:9. This width-to-height ratio is
called the aspect ratio.
Settings: Widescreen (16:9)*
Standard (4:3) * Factory setting
Note
There are two screen formats that can be used to display
wide-screen format DVDs: letter box and pan & scan. When
[Standard (4:3)] is selected in the Setup Navigator, the letter
box screen format is automatically selected. To switch the
preference to the pan & scan format, make changes in the
Setup screen Video menu [TV Screen] setting (page 28).

19
SETTING UP THE PLAYER
Audio1 Audio2 GeneralLanguageVideo
Setup Navigator
Move
Exit
SETUP
Select
ENTER
Exit Setup Navigator
Start Again
Delete Changes
Save Changes
Confirming the settings
The [Exit Setup Navigator] is the final screen in the
Setup Navigator.
Settings: Save Changes*
Select to have the player make all of the
necessary audio, video and language settings
automatically.
Delete Changes
Select to exit the Setup Navigator without
changing any of the system settings.
Start Again
Select to return to the [OSD Language]
screen of the Setup Navigator and do the
settings again. * Factory setting
To exit the Setup screen
When you have completed setting up the player using
the Setup Navigator or if you exit the Setup Navigator,
the Setup screen General menu appears. Press SETUP
to close the Setup screen.
To change other player settings in the Setup
screen menus
The procedure for changing the settings in the Setup
screen menus is described on page 24.
Setting digital audio connections
to an AV amplifier or decoder
The [Digital Jack] screen establishes whether digital
connections have been made to an AV amplifier,
receiver, or external decoder. As there are numerous
options available, please refer to the instructions
supplied with the component the player is connected to
determine what digital audio formats can be decoded. If
you have made no digital connections, select [Not
Connected].
Settings: Dolby Digital*
Dolby Digital/DTS
Dolby Digital/MPEG
Dolby D/DTS/MPEG
PCM
Not Connected * Factory setting
Setting compatibility with 96 kHz
output
The [96 kHz PCM Audio] screen establishes whether or
not the AV component the player is connected to is
capable of processing an audio signal with a sampling
rate of 96 kHz. This screen only appears if connections
have been made to an external AV component as
determined in previous screens.
Settings: No*
Select if the connected AV component
cannot process an audio signal with a
sampling rate of 96 kHz.
Yes
Select if the connected AV component can
process an audio signal with a sampling rate
of 96 kHz.
Don’t Know
Select if you are uncertain whether the
connected AV component can process an
audio signal with a sampling rate of 96 kHz.
* Factory setting
Audio1 Audio2 GeneralLanguageVideo
Setup Navigator
Move
Exit
SETUP
Select
ENTER
Digital Jack
Not Connected
Dolby D/DTS/MPEG
Dolby Digital/MPEG
Dolby Digital/DTS
PCM
Dolby Digital
Amp Connection
Audio1 Audio2 GeneralLanguageVideo
Setup Navigator
Move
Exit
SETUP
Select
ENTER
96 kHz PCM Audio
Don't Know
Yes
No
Amp Connection

20
1Press ( STANDBY/ON on the front
panel).
2Press OPEN/CLOSE (0on the front panel).
The disc tray comes out.
3Load a disc.
• Load a disc with the label side facing up, using
the disc tray guide to align the disc.
4Press PLAY 3(3on the front panel).
• The disc tray closes, and playback begins.
•Depending on the disc, a menu may be
displayed. If a menu is displayed, proceed to
step 5.
5Select the item you want to view.
•When a DVD is loaded:
Select the item with the cursor buttons (2/3/5/
∞) or the number buttons then press ENTER.
•When a Video CD is loaded:
Use the number buttons to select the item.
Notes
• Noise is output if you make digital audio connections to a
receiver or amplifier that does not have a built-in decoder.
Check that the digital audio output format selected in the
Audio 1 menu corresponds to the audio components you
have made connections to (page 26-27).
• The TV screen size is factory set to present the wide
screen format (16:9 aspect ratio). If you have a standard TV
screen (4:3 aspect ratio), this setting can be changed to
match your TV screen size in the Video menu (page 28).
Getting Started
Using Your DVD
Player
0
4¢
1¡
783
When an operation is prohibited
There are times when you are using the player and attempt to
perform an operation, but for some reason it cannot be
performed. When this occurs, one of the two following icons
appears on the screen.
The operation is prohibited by the player.
The operation is prohibited by the programming on
the disc.
Playing DVDs, Video CDs and
CDs– DVD/Video CD/CD
Before you can start to enjoy the digital audio and video
on DVDs, be sure that you have either performed the
Setup Navigator procedure described in the previous
section or made the necessary settings in the Setup
screen menus as outlined in the next section to set up
the player to correspond to your home system. Having
made these settings, you are now ready to start using
the player to enjoy DVDs, Video CDs, and CDs.
RANDOM PROGRAM
SEARCH MODE
09
8
7
+10
6
5
4
CLEAR
3
2
1
1 REV FWD
¡
PLAY 3
PAUSE 8
STOP 7
e STEP/SLOW E
NEXT
¢
PREV
4
RETURN
REPEAT
CONDITION
MEMORY
LAST
MEMORY
ANGLE
SUB TITLE
AUDIO
SETUP MENU
TOP MENU
DISPLAY
¶
5
∞
3
2
Î
¶
OPEN/
CLOSE
REPEAT
A-B
¶
¶ 5
5
5
5
E
N
T
E
R
¶
¶
STANDBY/ON
DVDPLAYER
387¡ ¢4 10
ÎA
1
5
4
2
5
1342
