Pioneer DVR-220-S User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2004
PULL-OPEN
STANDBY/ON
DISC
NAVIGATOR
DISC
HISTORY
OPEN/CLOSE REC REC MODE
VIDEO/R/RW
DVR-220-S
RRV2925
DVD RECORDER
DVR-220-S
DVR-225-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Region No.
Serial No.
Please confirm 3rd & 4th
alphabetical letters.
DVR-220-S KU/CA AC120V 1
DVR-220-S KUXU/CA AC120V 1 &&PG######$$
DVR-220-S KUXQ/CA AC120V 1 &&CP######$$
DVR-225-S KUXU/CA AC120V 1 &&PG######$$
÷When servicing this model, some service procedures may reset the settings that customer
set (*) to the factory default settings. Make sure to explain this to the customer.
(*) : Initial Setup (Clock Setting, Remote Control Set, Channel settings, Video Out settings,
Audio In settings, Audio Out settings, Language settings)
Refer to the chapter 12 of the Operating Instructions for more details.
For details, refer to "Important symbols for good services" .
T-ZZV APR. 2004 printed in Japan

DVR-220-S
2
1234
1234
C
D
F
A
B
E
SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 – Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement
parts must be of identical designation.
REMARQUE
(POUR MODÈLE CANADIEN SEULEMENT)
Les symboles de fusible (fusible de type rapide) et/ou (fusible de type lent) sur CCI indiquent que
les pièces de remplacement doivent avoir la même désignation.
ANY MEASUREMENTS NOT WITHIN THE
LIMITS OUTLINED ABOVE ARE INDICATIVE
OF A POTENTIAL SHOCK HAZARD AND
MUST BE CORRECTED BEFORE RETURN-
ING THE APPLIANCE TO THE CUSTOMER.
2. PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in the appliance
have special safety related characteristics. These are
often not evident from visual inspection nor the
protection afforded by them necessarily can be obtained
by using replacement components rated for voltage,
wattage, etc. Replacement parts which have these
special safety characteristics are identified in this
Service Manual.
Electrical components having such features are
identified by marking with a on the schematics and
on the parts list in this Service Manual.
The use of a substitute replacement component which
does not have the same safety characteristics as the
PIONEER recommended replacement one, shown in the
parts list in this Service Manual, may create shock, fire,
or other hazards.
Product Safety is continuously under review and new
instructions are issued from time to time. For the latest
information, always consult the current PIONEER
Service Manual. A subscription to, or additional copies
of, PIONEER Service Manual may be obtained at a
nominal charge from PIONEER.
(FOR USA MODEL ONLY)
1. SAFETY PRECAUTIONS
The following check should be performed for the
continued protection of the customer and service
technician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground
(water pipe, conduit, etc.) by connecting a leakage
current tester such as Simpson Model 229-2 or
equivalent between the earth ground and all exposed
metal parts of the appliance (input/output terminals,
screwheads, metal overlays, control shaft, etc.). Plug
the AC line cord of the appliance directly into a 120V
AC 60 Hz outlet and turn the AC power switch on. Any
current measured must not exceed 0.5 mA.
Device
under
test
Leakage
current
tester
Earth
ground
Reading should
not be above
0.5 mA
Also test with
plug reversed
(Using AC adapter
plug as required)
Test all
exposed metal
surfaces
AC Leakage Test

DVR-220-S 3
5678
5678
C
D
F
A
B
E
WARNING!
DEVICE INCLUDES LASER DIODE WHICH
EMITS INVISIBLE INFRARED RADIATION
WHICH IS DANGEROUS TO EYES. THERE IS
A WARNING SIGN ACCORDING TO PICTURE
1 INSIDE THE DEVICE CLOSE TO THE LASER
DIODE.
LASER
Picture 1
Warning sign for
laser radiation
LASER DIODE CHARACTERISTICS
MAXIMUM OUTPUT POWER : 50 mw
WAVELENGTH : 658 nm
IMPORTANT
THIS PIONEER APPARATUS CONTAINS
LASER OF CLASS 1.
SERVICING OPERATION OF THE APPARATUS
SHOULD BE DONE BY A SPECIALLY
INSTRUCTED PERSON.
LABEL CHECK
PULL-OPEN
STANDBY/ON
DVD
HDD
OPEN/CLOSE
REC
ONETOUCH COPY
Î
CLAMP signals for detecting the loading state are detected
by the drive CPUs, and the design prevents laser diode
oscillation when the CLAMP signal turns OFF.
In normal operation, if no disc is clamped, the laser diode
oscillation is disabled.
However, the interlock does not always operate in the test
mode.
2. When the cover is opened, close viewing of the objective
lens with the naked eye will cause exposure to a Class 3A
laser beam.
Additional Laser Caution
1. The ON/OFF(ON:low level,OFF:high level) status of the
DRW2194

DVR-220-S
4
1234
1234
C
D
F
A
B
E
[ Important symbols for good services ]
In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely.
When you find the procedures bearing any of the symbols, be sure to fulfill them:
2. Adjustments
To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.
In accordance with the procedures or instructions described in this manual, adjustments should be performed.
3. Cleaning
For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,
proper cleaning should be performed to restore their performances.
5. Lubricants, glues, and replacement parts
Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying
glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the
prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed
ones should be used.
4. Shipping mode and shipping screws
To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or
the shipping screws should be installed before shipping out in accordance with this manual, if necessary.
1. Product safety
You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.

DVR-220-S 5
5678
5678
C
D
F
A
B
E
CONTENTS
SAFETY INFORMATION......................................................................................................................................2
1. SPECIFICATIONS.............................................................................................................................................6
2. EXPLODED VIEWS AND PARTS LIST.............................................................................................................8
2.1 PACKING ....................................................................................................................................................8
2.2 EXTERIOR ...............................................................................................................................................10
2.3 FRONT PANEL.........................................................................................................................................12
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ..........................................................................................14
3.1.1 OVERALL BLOCK DIAGRAM ...............................................................................................................14
3.1.2 TUNB and FRJB ASSYS BLOCK DIAGRAM ........................................................................................16
3.1.3 MAIN ASSY BLOCK DIAGRAM ............................................................................................................18
3.1.4 POWER BLOCK DIAGRAM ..................................................................................................................20
3.2 OVERALL WIRING DIAGRAM .................................................................................................................22
3.3 TUNB ASSY..............................................................................................................................................24
3.4 JCKB ASSY(1/2).......................................................................................................................................26
3.5 JCKB ASSY(2/2).......................................................................................................................................28
3.6 MAIN ASSY(1/4).......................................................................................................................................30
3.7 MAIN ASSY(2/4).......................................................................................................................................32
3.8 MAIN ASSY(3/4).......................................................................................................................................34
3.9 MAIN ASSY(4/4).......................................................................................................................................36
3.10 FLKY, KIRB and FRJB ASSYS...............................................................................................................38
3.11 POWER SUPPLY UNIT ..........................................................................................................................40
3.12 WAVE FORMS........................................................................................................................................41
4. PCB CONNECTION DIAGRAM ......................................................................................................................43
4.1 TUNB ASSY..............................................................................................................................................44
4.2 JCKB ASSY..............................................................................................................................................46
4.3 MAIN ASSY ..............................................................................................................................................50
4.4 FLKY, KIRB and FRJB ASSYS.................................................................................................................54
4.5 POWER SUPPLY UNIT ............................................................................................................................58
5. PCB PARTS LIST............................................................................................................................................60
6. ADJUSTMENT ................................................................................................................................................64
6.1 TUNB ASSY ADJUSTMENT ....................................................................................................................64
6.2 MAIN ASSY ADJUSTMENT.....................................................................................................................65
7. GENERAL INFORMATION .............................................................................................................................66
7.1 DIAGNOSIS..............................................................................................................................................66
7.1.1 CPRM ID NUMBER AND DATA SETTING ............................................................................................67
7.1.2 MODEL SETTING .................................................................................................................................69
7.1.3 DOWNLOAD..........................................................................................................................................70
7.1.4 SERVICE MODE ...................................................................................................................................72
7.1.5 ERROR RATE MEASUREMENT...........................................................................................................83
7.1.6 VIDEO ADJUSTMENT FOR SPECIFIC AREA......................................................................................85
7.1.8 SETUP SEQUENCE..............................................................................................................................90
7.1.9 DISASSEMBLY......................................................................................................................................91
7.2 IC ..............................................................................................................................................................95
7.3 OUTLINE OF THE PRODUCT ...............................................................................................................112
7.4 DISC/CONTENT FORMAT.....................................................................................................................115
7.5 CLEANING .............................................................................................................................................116
8. PANEL FACILITIES .......................................................................................................................................117

DVR-220-S
6
1234
1234
C
D
F
A
B
E
1. SPECIFICATIONS
General
System. . . . . . . . . . . . . . . . . . . . . . .DVD-Video,DVD-R/RW,
Video-CD,CD,
CD-R/RW (WMA, MP3, JPEG. CD-DA)
Power requirements. . . . . . . . . . . . . . . . . . . . . .120 V, 60 Hz
Power Consumption
DVR-220 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 W
Power consumption in standby mode . . . . . . . . . . . . 0.42W
(Front Panel Display : off)
Weight 8 lb 13 oz / 4.0 kg
Dimensions . . . . . . . . . . . . .420 (W) x 59 (H) x 339 (D) mm
Operating temperature . . . . . . . . . . . . . . . . . +5°C to +35°C
Operating humidity. . . . . . . . . . . . . . . . . . . . . . . . 5%to 85%
(no condensation)
TV format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NTSC
Recording
Recording format. . . . . . . . . . . . . . . . DVD Video Recording
DVD-VIDEO
Recordable discs
DVD-RW (DVD Re-recordable disc)
DVD-R (DVD Recordable disc)
Video recording format
Sampling frequency . . . . . . . . . . . . . . . . . . . . . . . . 13.5MHz
Compression format . . . . . . . . . . . . . . . . . . . . . . . . . MPEG
Audio recording format
Sampling frequency . . . . . . . . . . . . . . . . . . . . . . . . . . 48kHz
Compression format. . . . . . . . . Dolby Digital or LinearPCM
(uncompressed)
Recording time
Fine (FINE). . . . . . . . . . . . . . . . . . . . . . . . . . .Approx. 1 hour
Standard Play (SP). . . . . . . . . . . . . . . . . . . Approx. 2 hours
Long Play (LP). . . . . . . . . . . . . . . . . . . . . . Approx. 4 hours
Extended Play (EP). . . . . . . . . . . . . . . . . . . Approx. 6 hours
Manual Mode (MN) . . . . . . . . . . . . . . . . . Approx. 1–6 hours
Tuner
Receivable channels
VHF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–13ch
UHF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14–69ch
CATV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C1–C125ch
Timer
Programs. . . . . . . . . . . . . . . . . . . . . . .1month/32 programs
Clock . . . . . . . . . . . . . .Quartz lock (12-hour digital display)
Power off memory. . . . Approx. 5 years (after manufacture)
Input/ Output
VHF/UHF antenna input/output terminal . . . . VHF/UHF set
75 (F-shape connector)
Video input . . . . . . . . . . . . . . . . . . Input 1, 3 (rear), 2 (front)
Input level . . . . . . . . . . . . . . . . . . . . . . . . . . . .1Vp-p (75 )
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA jack
Video output. . . . . . . . . . . . . . . . . . . . . . . . . . . . Output 1,2
Output level . . . . . . . . . . . . . . . . . . . . . . . . . . .1Vp-p (75 )
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA jack
S-Video input . . . . . . . . . . . . . . . . .Input 1, 3 (rear), 2 (front)
Y (luminance) - Input level. . . . . . . . . . . . . . . 1Vp-p (75 )
C (color) - Input level . . . . . . . . . . . . . . . .286 mVp-p (75 )
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4pin mini DIN
S-Video output. . . . . . . . . . . . . . . . . . . . . . . . . . . .Output 1,2
Y (luminance) - Output level. . . . . . . . . . . . . . 1Vp-p (75 )
C (color) - Output level . . . . . . . . . . . . . . 286 mVp-p (75 )
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4pin mini DIN
Component video output
Output level . . . . . . . . . . . . . . . . . . . . . . .Y: 1.0 Vp-p (75 )
PB, PR: 0.7 Vp-p (75 )
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .RCA jacks
Audio input. . . . . . . . . . . . . . . .Input 1, 3 (rear), 2 (front) L/R
Input level
During audio input . . . . . . . . . . . . . . . . . . . . . . . . . 2V rms
(Input impedance: more than 22 k )
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA jacks
Audio output . . . . . . . . . . . . . . . . . . . . . . . . .Output 1,2 L/R
During audio output . . . . . . . . . . . . . . . . . . . . . . . . .2V rms
(Output impedance: less than 1.5 k )
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA jacks
Control input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Mini jack
Supplied accessories
Remote control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Dry cell batteries (AA/R6P). . . . . . . . . . . . . . . . . . . . . . . . 2
Audio / Video cable (red/white/yellow) . . . . . . . . . . . . . . . .1
RF antenna cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Power cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Warranty card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Note: The specifications and design of this product are subject
to change without notice, due to improvement.
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω

DVR-220-S 7
5678
5678
C
D
F
A
B
E
Accessories
• Remote control ×1
(VXX2928) • RF antenna cable ×1
(VDE1025 : )
• Power cable ×1
(ADG7021 : DVR-220-S/KU/CA)
(ADG7075 : DVR-220-S/KUXU/CA and /KUXQ/CA types,
DVR-225-S/KUXU/CA)
• Audio / Video cable(L=1.5m) ×1
(red/white/yellow)
(XDE3049 : DVR-220-S/KU/CA)
(VDE1077 : DVR-220-S/KUXU/CA and /KUXQ/CA types,
DVR-225-S/KUXU/CA)
• Dry cell batteries ×2
(AA/R6P)
Red
White
Yellow
+
DVD RECORDER
STANDBY/ON
OPEN/CLOSE
AUDIO SUBTITLE ANGLE PLAYMODE
TOP MENU MENU
RETURN
DISC NAVIGATOR PLAY LIST
HOME
MENU
INPUT
SELECT
ABC DEF
GHI JKL MNO
PQRS TUV WXYZ
CLEAR
ENTER
CHANNEL
PAUSE STOP OK SKIP CM BACK
REV SCAN PL AY FWD SCAN
DISC
HISTORY NAVI MARK
CASE
SELECTION
CHP
MARK EASY
TIMER
INPUT
SELECT
DISPLAY
TV CONTROL
CHANNEL VOLUME
REC
PREV NEX T STEP/SL OW
ST OP REC REC MODE TIMER REC
CLEAR
VCR Plus+
0
•
E e

DVR-220-S
8
1234
1234
C
D
F
A
B
E
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
NOTES:
9
7
8
10
12
13
15
14
10
4
6
2
5
DVR-220-S
Only
11
3
1
Note :
When re-packaging DVR-220-S models,
be sure to pack it with the front side of the
unit properly oriented towards the front of
the packing case.
(It is for matching the sensormatic seal of the
front panel and the POS code of the packing
case.)

DVR-220-S 9
5678
5678
C
D
F
A
B
E
PACKING parts List
(2) CONTRAST TABLE
DVR-220-S/KU/CA, KUXU/CA, /KUXQ/CA and DVR-225-S/KUXU/CA are constructed the same except for the
following :
Mark No. Description Part No.
> 1Power Cable See Contrast table (2)
2Audio / Video Cable See Contrast table (2)
3 RF Antenna Cable VDE1025
4 Remote Control VXX2928
5 Battery Cover AZN7933
NSP 6 Dry Cell Battery (R6P, AA) See Contrast table (2)
7 Operating Instructions See Contrast table (2)
(English)
NSP 8 Leaflet See Contrast table (2)
NSP 9 Warranty Card ARY7045
10 Polyethylene Bag VHL1051
11 Mirror Sheet VHL1006
12 IM Holder See Contrast table (2)
13 Front Pad See Contrast table (2)
14 Rear Pad See Contrast table (2)
15 Packing Case See Contrast table (2)
Mark No. Description Part No.
Mark No. Symbol and Description DVR-220-S/
KU/CA
DVR-220-S/
KUXU/CA
DVR-220-S/
KUXQ/CA
DVR-225-S/
KUXU/CA
> 1Power Cable ADG7021 ADG7075 ADG7075 ADG7075
2Audio / Video Cable XDE3049 VDE1077 VDE1077 VDE1077
NSP 6 Dry Cell Battery (R6P, AA) VEM1031 VEM1030 VEM1030 VEM1030
7 Operating Instructions VRB1333 VRB1333 VRB1333 VRB1344
(English)
NSP 8 Leaflet VRY1147 VRY1147 VRY1147 Not used
12 IM Holder VHC1116 VHC1115 VHC1115 VHC1115
13 Front Pad VHA1368 VHA1364 VHA1364 VHA1364
14 Rear Pad VHA1369 VHA1365 VHA1365 VHA1365
15 Packing Case VHG2504 VHG2501 VHG2553 VHG2527

DVR-220-S
10
1234
1234
C
D
F
A
B
E
2.2 EXTERIOR
F
O
I
I
J
J
H
H
A
A
C
C
F
D
E
DE
B
O
CONTACT SIDE
NON-CONTACT
SIDE
B
C
F
H
A
B
42
42
45
50
50
50
50
50
50
22
50
50
50
50
34
3
17
12 13
14
19
36
48
48
46
28
8
2
1
48
49
49
50
26
37
11
50
50
49
49
50
21
20
39
Refer to
"2.3 FRONT PANEL SECTION".
38
40
33
18
50
50
50
24
4
25
16
50
50
50
10
9
37
30 23
27
42
42
42
7
6
35
50
45
29 50
50
41
50
31
32
47
47
Lithium Battery
(CR2032)

DVR-220-S 11
5678
5678
C
D
F
A
B
E
EXTERIOR parts List
(2) CONTRAST TABLE
DVR-220-S/KU/CA, KUXU/CA, KUXQ/CA and DVR-225-S/KUXU/CA are constructed the same except for the
following :
Mark No. Description Part No.
1 TUNB Assy VWV2010
2 JCKB Assy VWV2027
3 MAIN Assy VWV2007
4 FRJB Assy VWV2004
5•• • • •
> 6POWER SUPPLY Unit VWR1378
7 DRIVE Assy R7R (for Service) VXX2926
8 DC Fan Motor VXM1115
9 Connector Assy (2P) PF02PP-C07
10 Connector Assy (4P) PF04EE-S22
11 Connector Assy (13P) PF13PP-D47
12 Flexible Cable (8P) See Contrast table (2)
13 Flexible Cable (24P) See Contrast table (2)
14 Flexible Cable (32P) See Contrast table (2)
15 • • • • •
16 Flexible Cable (13P) See Contrast table (2)
17 Flexible Cable (40P) See Contrast table (2)
NSP 18 P. Plate Holder PNY-405
19 Rubber Foot VEB1349
20 Radiation Sheet VEB1360
NSP 21 PC Support VEC1749
22 Heatsink Cushion VEC2363
23 Gasket Sheet VEC2394
24 Spacer VEC2413
25 FFC Protector VEC2436
26 Gasket 20 x 8T VEC2437
27 Gasket Sheet 2 VEC2440
28 Rear Panel See Contrast table (2)
29 Bonnet Case S VXX2925
NSP 30 Bonnet Angle VNE2335
NSP 31 Writer Stay L VNE2336
NSP 32 Writer Stay R VNE2337
NSP 33 PCB Base VNE2339
NSP 34 Heatsink VNH1070
35 SYPS Cover VNK5426
NSP 36 Base Chassis Assy VXA2681
NSP 37 Binder (BK-1) ZCA-BK1
38 DVD RW Badge VAM1139
39 Tray Sheet B VEC2409
40 Tray Panel VNK5444
41 Bonnet Label VRW2104
NSP 42 Tape ZTA-156A-19
43 • • • • •
44 • • • • •
45 Screw BCZ40P060FNI
46 Screw PBZ30P080FTC
47 Screw AMZ30P060FTC
48 Screw BBZ30P040FTC
49 Screw BPZ30P080FTC
50 Screw BBZ30P060FTC
Mark No. Description Part No.
Mark No. Symbol and Description DVR-220-S/
KU/CA
DVR-220-S/
KUXU/CA
DVR-220-S/
KUXQ/CA
DVR-225-S/
KUXU/CA
12 Flexible Cable (8P) VDA2011 VDA1997 VDA1997 VDA1997
13 Flexible Cable (24P) VDA2012 VDA1998 VDA1998 VDA1998
14 Flexible Cable (32P) VDA2013 VDA1999 VDA1999 VDA1999
16 Flexible Cable (13P) VDA2015 VDA2001 VDA2001 VDA2001
17 Flexible Cable (40P) VDA2020 VDA2006 VDA2006 VDA2006
28 Rear Panel VNA2681 VNA2681 VNA2681 VNA2719

DVR-220-S
12
1234
1234
C
D
F
A
B
E
2.3 FRONT PANEL
CONTACT SIDE
NON-CONTACT
SIDE
D
E
3
2
4
18
6
8
16
5
10 1
21
21
12
9 (2/3)
9 (3/3) 9 (1/3)
13
11
7
21
21
14
19
21
21
17
(Note)
20
15
Note : When replacing the jack door, first fully open it.
If the jack door is not fully open during replacement,
it may unexpectedly fall out after being replaced.

DVR-220-S 13
5678
5678
C
D
F
A
B
E
FRONT PANEL parts List
(2) CONTRAST TABLE
DVR-220-S/KU/CA, KUXU/CA, KUXQ/CA and DVR-225-S/KUXU/CA are constructed the same except for the
following :
Mark No. Description Part No.
1 FLKY Assy VWG2489
2 KIRB Assy VWG2490
3 Flexible Cable (19P) See Contrast table (2)
4 Flexible Cable (7P) See Contrast table (2)
5Front Panel Assy See Contrast table (2)
6 Pioneer Name Plate VAM1146
7 Door Spring VBK1151
NSP 8 Mirror Sheet VHL1082
NSP 9 Main Key VNK5420
NSP 10 REC Ring VNK5425
NSP 11 Sub Panel VNK5442
NSP 12 Power Key VNK5539
NSP 13 IR Window VNK5446
NSP 14 Sensormatic Seal See Contrast table (2)
NSP 15 FL Lens See Contrast table (2)
NSP 16 Front Panel VNK5492
17 Jack Door VNK5494
18 Rubber Foot VEB1349
19 Drive Sheet VEC2345
20 Panel Sheet VEC2446
21 Screw BPZ30P080FTC
Mark No. Description Part No.
Mark No. Symbol and Description DVR-220-S/
KU/CA
DVR-220-S/
KUXU/CA
DVR-220-S/
KUXQ/CA
DVR-225-S/
KUXU/CA
3 Flexible Cable (19P) VDA2016 VDA2002 VDA2002 VDA2002
4 Flexible Cable (7P) VDA2019 VDA2005 VDA2005 VDA2005
5Front Panel Assy VXA2643 VXA2643 VXA2643 VXA2668
NSP 14 Sensormatic Seal VAN1004 VAN1004 VAN1004 Not used
NSP 15 FL Lens VNK5484 VNK5484 VNK5484 VNK5602

DVR-220-S
14
1234
1234
C
D
F
A
B
E
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
3.1 BLOCK DIAGRAM
3.1.1 OVERALL BLOCK DIAGRAM
SPDL
MOTOR
LD
DRIVE
Pickup
LOADING
MOTOR
STEPPIONG
MOTOR
TV FRONT-END
U301 VXF1022
ANT
INPUT3
VIDEO
Y/C
L
R
(15P)
CN1301
(19P)
CN301
(13P)
CN451
(19P)
CN401
(13P)
CN402
(15P)
CN705
FRJB
ASSY
JCKB ASSY(1/3)
JCKB ASSY
(2/3)
C
F
TUNB
ASSY
A
MAIN ASSY
DRIVE ASSY
M
6 8
10
6
12
4
8
VOUT
19
Y
C
UVL UVL
MPX
IN
L
OUT
LIN2
LIN4
LIN1
LIN3
L
V/Y
C
AOUT
16
RF IN
RF
OUT
V/Y
UVV
UVV
1V
3V
3Y
1Y
2Y
3C
1C
2C
2V
C
Video Selector
Video Driver
ATT WIDEBAND SPECTRAL
IC701
LA73033(1/2)
IC601
LC75342M
IC451 CXA2020M
13
5
11
14
12
19
27
17
15
13
79
77
75
7
5
3
LPF
1 Chip
Sysytem Codec
Audio MPX
Decoder
Audio Selector with Electirc ATT
721
JA1302
JA1301
VIN2
YIN2
CIN2
2
LIN2
INPUT1
INPUT3
VIDEO
Y/C
L
R
PICKUP
ASSY
Y
C
Y
C
JA601
VIDEO
Y/C
L
R
VIN1
LIN1
LIN3
VIN3
YIN1
YIN3
M
(40P)
[ATAPI]
DVD-VR DVD-Video
DVD-VR
DVD-Video
CD Digital
CD Digital
CN4401
1
CN201
(2P)
CN703 (2P)
CN101
(45P)
8
CIN1
CIN3
CN501
CN502
(12P)
33
39
A
B
C
D
S4
S3
S2
S1
5
4
3
2
1/3
B
2/3
B
PB DVD/CD
IC1001
M65673WG
IC201
UPD63630GM
IC501
BD7907FS
IC101
UPC3330GC
RF IC
IC301
M30700FKLGP
IC202
SDRAM
16Mbit
7-10
13-16
(40P)
(21P) (21P)
CN702
(1/2)
DSP
48
37
40
36
38
34
35
: Recording system signal route : Playback system signal route
LPF
IC1401 ATA SDRAM
256Mbit
CPU SDRAM
128Mbit
IC1102 IC1101
Flash
32Mbit
2
13 13
17 3
7 7
Writer
CPU
25
6CH
Driver
2
LPF
201
76 CN3001
(1/2)
CN403

DVR-220-S 15
5678
5678
C
D
F
A
B
E
DFLKY ASSY
EKIRB ASSY
L
Control
Data
IC1301
IC3201
PCM1742KE
IC1001 PT6315
V1001
IC3101
AK5381VT
IC3301
SM5950AM
Audio
A/D 2
SEL.L
VOUT
(19P)
CN201
(19P)
CN1001
YOUT
COUT
LOUT
(32P)
CN701(1/2)
9SEL.V/Y
7SEL.C
C IN
CVBS IN
(32P)
(21P) (21P)
CN2001
(2/2)
(32P)
CN701
(2/2)
CN702(2/2)
Audio
D/A Conv.
FL Driver
FL Key
SW
IC701
LA73033(2/2)
Sampling Rate
Converter
7
C
Y
Y/G
Cr/R
Cb/B
C OUT
Y OUT
Y(G) OUT
Cb OUT
Cr OUT
27
29
25
23
21
CN3001(2/2)
27
29
25
23
21
L OUT
17 17
SPDIF
1 1
3
21
IC3251-1/2
UPC4570G2
Cb
Cb
Cr
Cr
Y(G)
Y(G)
Y
C
V
Tuner U-com
JA651
OPTICAL
AC-3/PCM
DIGITAL
AUDIO
OUT
LINE
OUT 1
VIDEO
JA702
Y
C
Y
C
VIDEO
L
R
L
R
Y(G)
JA701
• R ch is same as L ch.
Cb
Cr
COMPONENT VIDEO OUT
LINE
OUT 2
(32P)
CN2001
9
5
7
Master Clock Freerun
48KHz 20Bit
JCKB ASSY(3/3)
3/3
B
ENC
SDRAM
128Mbit
IC1201
DEC
SDRAM
128Mbit
53
51
45
43
41
56
60
58
63
65
68
I C202
PEG034A
Tuner
U-com
I C204
BR24L32F-W
EEPROM
I C203
RS5C372A
Real
Time
Clock
5
9
10
12
1-3
F5 D2
AE24
AG25
AD21
AF23
AG24
T26
V27
• MPEG2 PS Encode
• AC-3/Linear PCM
Audio Encode
• 2ch ATA/ATAPI Interface
• MPEG2 PS Decode
• AC-3/MPEG1/Linear
PCM Audio Decode

DVR-220-S
16
1234
1234
C
D
F
A
B
E
3.1.2 TUNB and FRJB ASSYS BLOCK DIAGRAM
U301
V/U Tuner FrontEnd
VXF 1022-
SCL
SDA AFT
AGC
<u-com>
Q306 TUON
TUON<u-com>
+32V
Reg. +6V
SW.
+5V
Ripple Filter
Audio
EVOLCLK
EVOLDATA
EVOLCE
LC75342M
IC601
Audio Selector
with
Electric A.T.T
Audio Input Circuit
Output Circuit
Video Input Circuit
SDET2 <u-com>
SDET3 <u-com>
SDET1 <u-com>
LAMUTE
RAMUTE
<MAIN>
(Discrete)
R
L
Comp
C
Y
V
C
Y
Cb
Cr
Y
Muting
OUT2
OUT1
JA1301
JA1302
IN3
(Rear)
IN2
(Front)
IN1
(Rear)
JA601
Y
V
V
C
Y
C
V
Y
C
S
S
S
L
R
L
R
L
R
JA702
IC701
LA73033
Video Selector
&
Video Driver
(2/2)
IC701
LA73033
Video Selector
&
Video Driver
(1/2)
<u-com>
SCL
SDA
YVSEL
SWSTBY <u-com>
R
L
V/Y
U/V
U/V
C
SYNC
Sync-Sepa
LPF
LPF
LPF
27
25
36
51
53
5
45
60
56
58
63
65
68
41
43
26
TUNB ASSY
(VWV2010)
A
JCKB ASSY (VWV2027)
B
FRJB ASSY (VWV2004)
F
CN1301
CN705
CN402
CN401
CN301
CN451
4
10
12 2
6
8
8
6
12
2
JA701
JA651
Component
OUT
Optical
OUT
410
13
5
4
18
17
2
1
3
9
7
5
1
4
7
15
16
1
3
18
19
17
5
7
9
13
10
Decoder
CXA2064M
Separation
IC451
MPX Audio
STID
<u-com>
<IC601>
<u-com>
SYNCAFT
<u-com>
SYNC
<u-com>
Q514
Q451
UV_L/R <from TUNB ASSY>
SUID STID
AGC
SCL
SDA
SCL
SDA AFT
AGC
AFT
SUID
UV_L
UV_R
MUTE
MUTE
Wideband
ATT
15kHz LPF

DVR-220-S 17
5678
5678
C
D
F
A
B
E
FL Driver
PT6315
Front Keys
IR Detector
FAN
Driver FAN
EEPROM Battery
Ceramic
Resonator
EVOLCLK
EVOLDATA
EVOLCE
SPDIF
PCMOUT
PCMOUT
LAMUTE
525P
RAMUTE
FLKY ASSY
(VWG2489)
KIRB
ASSY
(VWG2490)
SELIR
KEY1, KEY2, KEY3
FLCK, FLDATA, FLSTB
IC202
CN1001
CN201
Tuner/FL
Control U-com
PEG034A-K
XINTRA
SCL
XIN, XOUT
XRESETIN
SDA
Other Devices
SCLEEP
SDAEEP
BR24L32F-W
IC203
Real-Time
Clock
RS5C372A
U-com I/F
Y
9
10
11
12
13
14
15
3
4
5
6
7
8
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
C
Y/G
Cb/B
Cr/R
R
L
SELC
CN703
< from DRIVE >
SELV/Y
SELR
SELL
2
D
E
SYNCAFT
<Q514>
IC1001
Q104
IC204 BT201
X201
Reset IC
PST3265
IC201
IC1201
S1201-S1203
S1001-S1009
SR In
JA201
FL Display
V1001
SYNC
<IC701>
MUTE
<IC451>
TUON
ASCK
SST to M
SSM to TSIS
HST to M
HSM to TSYS
XRESET
<CN401 Pin15>
<CN401 Pin7>
<CN401 Pin19> AGC
STID,SAPID
<IC451>
<IC601>
SCL
SDA
SWSTBY
<IC701>
SDET1
SDET2
SDET3
<JA1301,
JA601>
< to/from MAIN >
CN701
CN702
< from/to MAIN >
1
13
16
17
18
22
24
23

DVR-220-S
18
1234
1234
C
D
F
A
B
E
3.1.3 MAIN ASSY BLOCK DIAGRAM
To Writer
To JCKB ASSY
To JCKB ASSY
IC1401
ATA SDRAM
CN4401
ATA BUS
IC1102
FLASH
IC1301
Q2101-Q2105
IC2301
ENC
SDRAM
MT48LC4M32B2TG-7
K4S561632E-TC75
IC1201
DEC
SDRAM
W986416DH-6
VYW2179
DCLK0
ECLK0
CD D.OUT
D.OUT
AGC,ACC
IC3201
PCM1742KE
DAC
IC3101
A/D
AK5381VT
ADCCLKO
IC3403
AUDIO LR OUT
AUDIO LR IN
VIDEO Y,C,Yp,Cb,Cr OUT
IC3251
VIDEO Y,C IN
CN2001CN3001
TO TUNER u-COM
CN1901
SERIAL
IC1001
M65673WG
1 Chip System Codec
• MPEG2 PS Encode
• AC-3/Linear PCM Audio Encode
• 2ch ATA/ATAPI Interface
• MPEG2 PS Decode
• AC-3/MPEG1/Linear PCM Audio Decode
MAIN ASSY
(VWV2007)
C
ARCLK0

DVR-220-S 19
5678
5678
C
D
F
A
B
E
HOST BUS
IC1101
CPU SDRAM
K4S281632E-TC75
HCLK0
IC3301
SRC
SRC**O
SRC**I
IC4205
TC7WHU04FU
SM5950AM
Play Mster clock
IC4206
AMCLK2
IC3402
PLL IC
27M
24M
VMCLKI
AMCLK1
33M
36M
33/36M
X4102
VSS1195
VCXO
Input Mster
clock
ADMCLKI
27M
SM8707KV

DVR-220-S
20
1234
1234
C
D
F
A
B
E
3.1.4 POWER BLOCK DIAGRAM
LIVE
FLDC (–)
AC IN
F1
NEUTRAL
1
2
3
5
4
7
9
11
13
3
5
4
7
9
11
13
FLDC (+)
FL–28V
EV+37V
V+37E
EV+6V
SW+13V
SW+6V
SW+12V
1
4
1
SW+5V DRIVE ASSY
R7R
DC FAN
MOTOR
CN101
CN203
(4P)
CN201
(13P)
SW+6V
V+13FAN
CN105
(2P)
2
4
6
7
8
V+6SW
V+13SW
Q104
Q102Q101
Q103
SW+2.5V
SW+4V
SW+4V
SW+4V
SW+6V
SW+2.5V
SW+4V
SW+4V
SW+4V
CN202
(8P)
2
4
6
7
8
CN4001
(8P)
POWER SUPPLY UNIT
G
FLKY ASSY
D
TUNB ASSY
A
JCKB ASSY
B
MAIN ASSY
C
CN104
(13P)
V–28V
VEE 1
2
3
14
18
19
18
17
6
V+5VO
V+5VI
V+13SW
CN701
(32P)
CN2001
(32P)
32
32
V+5VO
CN702
(24P)
CN3001
(24P)
21 23
21 23
V+5VI
V+13SW
CN301
(19P)
13 11
7 9
V+6E
V+37E
FLDC –
FLDC +
NC
V+5E
V+5E
CN1001
(19P) CN2005 (19P)
V+6E V+13SW V+6SW
IC101
5V REG.
V+6E
V+5M
V+5E
IC102
3.3V REG.
V1001
FL TUBE
IC1001
FL Driver
V+6E
V+6SW
V+6E
V+3_3E
V+5VO
V+13V
V+4V
V+4V
V+6V
V+2R5V
V+5VO
Q4000
V+12A
V+5VI
V+5RP
IC103
9V REG.
V+13SW
V+9
1
1
6
3
1 3
30
V+9
V+37E
V+6E
CN402
(13P)
CN401
(19P)
CN451
(13P)
3
11
V+9
V+9V+37EV+6E
V+5A IC4004
5V REG.
5 1
V+6V
V+5D IC4006
5V REG.
5 1
V+3D
IC4002
3.3V REG.
1 3
V+3D
V+2R5
IC5002
2.5V REG.
7 1
V+2R5V
V+PRA
IC4008
1.2V REG.
1 3
V+4V
V+3V
IC4007
3.3V REG.
5 4
2
