Pioneer DVR-310-S User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2003
DVR-310-S
RRV2842
DVD RECORDER
DVR-310-S
DVR-210-S
THIS MANUAL IS APPLICABLETOTHE FOLLOWING MODEL(S) ANDTYPE(S).
Model Type Power Requirement Regional restriction
codes (Region No.) Remarks
DVR-310-S KUXU/CA AC120V 1
DVR-210-S KUXU/CA AC120V 1
÷When servicing this model, some service procedures may reset the settings that customer
set (*) to the factory default settings. Make sure to explain this to the customer.
(*) : Initial Setup (Clock Setting, Remote Control Set, Channel settings, Video Out settings,
Audio In settings, Audio Out settings, Language settings)
Refer to the chapter 12 of the Operating Instructions for more details.
For details, refer to "Important symbols for good services" .
T-ZZV SEPT. 2003 printed in Japan

DVR-310-S
2
1234
1234
C
D
F
A
B
E
SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 – Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement
parts must be of identical designation.
REMARQUE
(POUR MODÈLE CANADIEN SEULEMENT)
Les symboles de fusible (fusible de type rapide) et/ou (fusible de type lent) sur CCI indiquent que
les pièces de remplacement doivent avoir la même désignation.
ANY MEASUREMENTS NOT WITHIN THE
LIMITS OUTLINED ABOVE ARE INDICATIVE
OF A POTENTIAL SHOCK HAZARD AND
MUST BE CORRECTED BEFORE RETURN-
ING THE APPLIANCETO THE CUSTOMER.
2. PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in the appliance
have special safety related characteristics. These are
often not evident from visual inspection nor the
protection afforded by them necessarily can be obtained
by using replacement components rated for voltage,
wattage, etc. Replacement parts which have these
special safety characteristics are identified in this
Service Manual.
Electrical components having such features are
identified by marking with a on the schematics and
on the parts list in this Service Manual.
The use of a substitute replacement component which
does not have the same safety characteristics as the
PIONEER recommended replacement one, shown in the
parts list in this Service Manual, may create shock, fire,
or other hazards.
Product Safety is continuously under review and new
instructions are issued from time to time. For the latest
information, always consult the current PIONEER
Service Manual. A subscription to, or additional copies
of, PIONEER Service Manual may be obtained at a
nominal charge from PIONEER.
(FOR USA MODEL ONLY)
1. SAFETY PRECAUTIONS
The following check should be performed for the
continued protection of the customer and service
technician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground
(water pipe, conduit, etc.) by connecting a leakage
current tester such as Simpson Model 229-2 or
equivalent between the earth ground and all exposed
metal parts of the appliance (input/output terminals,
screwheads, metal overlays, control shaft, etc.). Plug
the AC line cord of the appliance directly into a 120V
AC 60 Hz outlet and turn the AC power switch on. Any
current measured must not exceed 0.5 mA.
Device
under
test
Leakage
current
tester
Earth
ground
Reading should
not be above
0.5 mA
Also test with
plug reversed
(Using AC adapter
plug as required)
Test all
exposed metal
surfaces
AC Leakage Test

DVR-310-S 3
5678
5678
C
D
F
A
B
E
WARNING!
DEVICE INCLUDES LASER DIODE WHICH
EMITS INVISIBLE INFRARED RADIATION
WHICH IS DANGEROUS TO EYES. THERE IS
A WARNING SIGN ACCORDING TO PICTURE
1 INSIDE THE DEVICE CLOSE TO THE LASER
DIODE.
LASER
Picture 1
Warning sign for
laser radiation
LASER DIODE CHARACTERISTICS
MAXIMUM OUTPUT POWER : 50 mw
WAVELENGTH : 658 nm
1. The ON/OFF(ON:low level,OFF:high level) status of the
CLAMP signals for detecting the loading state are detected
by the drive CPUs, and the design prevents laser diode
oscillation when the CLAMP signal turns OFF.
In normal operation, if no disc is clamped, the laser diode
oscillation is disabled.
However, the interlock does not always operate in the test
mode.
2. When the cover is opened, close viewing of the objective
lens with the naked eye will cause exposure to a Class 3A
laser beam.
Additional Laser Caution
IMPORTANT
THIS PIONEER APPARATUS CONTAINS
LASER OF CLASS 1.
SERVICING OPERATION OF THE APPARATUS
SHOULD BE DONE BY A SPECIALLY
INSTRUCTED PERSON.
LABEL CHECK
DRW2179
DRW2080
DRW2152
* Some models have different caution labels
like the figure below .

DVR-310-S
4
1234
1234
C
D
F
A
B
E
[ Important symbols for good services ]
In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely.
When you find the procedures bearing any of the symbols, be sure to fulfill them:
2. Adjustments
To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.
In accordance with the procedures or instructions described in this manual, adjustments should be performed.
3. Cleaning
For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,
proper cleaning should be performed to restore their performances.
5. Lubricants, glues, and replacement parts
Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying
glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the
prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed
ones should be used.
4. Shipping mode and shipping screws
To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or
the shipping screws should be installed before shipping out in accordance with this manual, if necessary.
1. Product safety
You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.

DVR-310-S 5
5678
5678
C
D
F
A
B
E
CONTENTS
SAFETY INFORMATION......................................................................................................................................2
1. SPECIFICATIONS.............................................................................................................................................6
2. EXPLODED VIEWS AND PARTS LIST.............................................................................................................8
2.1 PACKING....................................................................................................................................................8
2.2 EXTERIOR ...............................................................................................................................................10
2.3 FRONT PANEL.........................................................................................................................................12
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ..........................................................................................14
3.1.1 OVERALL BLOCK DIAGRAM ...............................................................................................................14
3.1.2 TUJB ASSY BLOCK DIAGRAM ............................................................................................................16
3.1.3 MAIN ASSY BLOCK DIAGRAM ............................................................................................................18
3.1.4 POWER BLOCK DIAGRAM ..................................................................................................................20
3.2 ATAB ASSY and OVERALL WIRING DIAGRAM......................................................................................22
3.3 TUMJ(1/2), FRJB and DVJB ASSYS........................................................................................................24
3.4 TUMJ ASSY(2/2) ......................................................................................................................................26
3.5 MAIN ASSY(1/5).......................................................................................................................................28
3.6 MAIN ASSY(2/5).......................................................................................................................................30
3.7 MAIN ASSY(3/5).......................................................................................................................................32
3.8 MAIN ASSY(4/5).......................................................................................................................................34
3.9 MAIN ASSY(5/5).......................................................................................................................................36
3.10 MHLP ASSY...........................................................................................................................................38
3.11 FLKY ASSY............................................................................................................................................40
3.12 POWER SUPPLY UNIT..........................................................................................................................42
3.13 WAVE FORMS........................................................................................................................................43
4. PCB CONNECTION DIAGRAM......................................................................................................................45
4.1 ATAB ASSY...............................................................................................................................................45
4.2 TUMJ, FRJB and DVJB ASSYS ...............................................................................................................46
4.3 MAIN and MHLP ASYS............................................................................................................................50
4.4 POWER SUPPLY UNIT............................................................................................................................54
4.5 FLKY ASSY..............................................................................................................................................56
5. PCB PARTS LIST............................................................................................................................................57
6. ADJUSTMENT ................................................................................................................................................61
6.1 TUMJ ASSY ADJUSTMENT.....................................................................................................................61
6.2 MAIN ASSY ADJUSTMENT.....................................................................................................................62
7. GENERAL INFORMATION .............................................................................................................................63
7.1 DIAGNOSIS..............................................................................................................................................63
7.1.1 CPRM ID NUMBER AND DATA SETTING............................................................................................63
7.1.2 SERVICE MODE ...................................................................................................................................65
7.1.3 DV DEBUG MODE ................................................................................................................................73
7.1.4 ERROR RATE MEASUREMENT...........................................................................................................76
7.1.5 VIDEO ADJUSTMENT FOR SPECIFIC AREA......................................................................................78
7.1.6 SETUP SEQUENCE..............................................................................................................................82
7.1.7 DISASSEMBLY......................................................................................................................................83
7.2 IC..............................................................................................................................................................86
7.3 OUTLINE OF THE PRODUCT ...............................................................................................................113
7.4 DISC/CONTENT FORMAT.....................................................................................................................116
7.5 CLEANING .............................................................................................................................................118
8. PANEL FACILITIES .......................................................................................................................................119

DVR-310-S
6
1234
1234
C
D
F
A
B
E
1. SPECIFICATIONS
General
System..........................DVD-Video, DVD-R/RW, Video-CD,
CD, CD-R/RW (WMA, MP3, JPEG. CD-DA)
Power requirements..........................................120 V, 60 Hz
Power consumption.......................................................26 W
Power consumption in standby mode............0.44 W (FL off)
Weight ........................................................9 lb 8 oz / 4.3 kg
Dimensions...........................420 (W) x 69 (H) x 341 (D) mm
Operating temperature....................................+5°C to +35°C
Operating humidity..................5% to 85% (no condensation)
TV format.....................................................................NTSC
Recording
Recording format ...............................DVD Video Recording
DVD-VIDEO
Recordable discs
DVD-RW (DVD Re-recordable disc)
DVD-R (DVD Recordable disc)
Video recording format
Sampling frequency.................................................13.5MHz
Compression format....................................................MPEG
Audio recording format
Sampling frequency ....................................................48kHz
Compression format..................Dolby Digital or Linear PCM
(uncompressed)
Recording time
Fine (FINE).....................................................Approx. 1 hour
Standard Play (SP).......................................Approx. 2 hours
Long Play (LP)..............................................Approx. 4 hours
Extended Play (EP)......................................Approx. 6 hours
Manual Mode (MN)...................................Approx. 1–6 hours
Tuner
Receivable channels
VHF............................................................................2–13ch
UHF..........................................................................14–69ch
CATV...................................................................C1–C125ch
Timer
Programs..............................................1 month/32
programs
Clock..............................Quartz lock (12-hour digital display)
Power off memory.........Approx. 5 years (after manufacture)
Input/Output
VHF/UHF antenna input/output terminal..........VHF/UHF set
75 Ω(F-shape connector)
Video input......................................Input 1, 3 (rear), 2 (front)
Input level.........................................................1 Vp-p (75 Ω)
Jacks.......................................................................RCA jack
Video output..........................................................Output 1,2
Output level......................................................1 Vp-p (75 Ω)
Jacks.......................................................................RCA jack
S-Video input..................................Input 1, 3 (rear), 2 (front)
Y (luminance) - Input level................................1 Vp-p (75 Ω)
C (color) - Input level.................................286 mVp-p (75 Ω)
Jacks...............................................................4 pin mini DIN
S-Video output.......................................................Output 1,2
Y (luminance) - Output level.............................1 Vp-p (75 Ω)
C (color) - Output level..............................286 mVp-p (75 Ω)
Jacks...............................................................4 pin mini DIN
Component video output
Output level...............................................Y: 1.0 Vp-p (75 Ω)
PB, PR: 0.7 Vp-p (75 Ω)
Jacks.....................................................................RCA jacks
Audio input...............................Input 1, 3 (rear), 2 (front) L/R
Input level
During audio input.......................................................2V rms
(Input impedance: more than 22 kΩ)
Jacks.....................................................................RCA jacks
Audio output....................................................Output 1,2 L/R
During audio output....................................................2V rms
(Output impedance: less than 1.5 kΩ)
Jacks.....................................................................RCA jacks
Control input.............................................................Mini jack
DV input/output...............................................................4 pin
(i.LINK/IEEE 1394 standard)
Supplied accessories
Remote control.....................................................................1
Dry cell batteries (AA/R6P)..................................................2
Audio / Video cable (red/white/yellow).................................1
RF antenna cable.................................................................1
Power cable.........................................................................1
Operating Instructions..........................................................1
Warranty card.......................................................................1
Note: The specifications and design of this product are
subject to change without notice, due to improvement.

DVR-310-S 7
5678
5678
C
D
F
A
B
E
Accessories
• Remote control ×1
(VXX2882) • RF antenna cable ×1
(VDE1025)
• Power cable ×1
(ADG7021)
• Audio / Video cable(L=1.5m) ×1
(red/white/yellow)
(VDE1077)
• Dry cell batteries ×2
(AA/R6P) Red
White
Yellow

DVR-310-S
8
1234
1234
C
D
F
A
B
E
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
NOTES:
16
14
12
15
5
4
13 11
7
8
11
6
2
10
9
3
1

DVR-310-S 9
5678
5678
C
D
F
A
B
E
(1)PACKING parts List
(2) CONTRASTTABLE
DVR-310-S/KUXU/CA and DVR-210-S/KUXU/CA are constructed the same except for the following :
Mark No. Description Part No.
> 1Power Cable ADG7021
2Audio/Video Cable VDE1077
3 RF Antenna Cable VDE1025
4 Remote Control VXX2882
5 Battery Cover AZA7424
NSP 6 Dry Cell Batteries (R6P,AA) VEM1010
7 Operating Instructions VRB1314
(English)
NSP 8 Information Card VRR1048
NSP 9 Card VRY1132
NSP 10 Warranty Card ARY7045
11 Polyethylene Bag VHL1051
12 Mirror Sheet VHL1006
13 Accessory Case VHC1112
14 Front Pad VHA1346
15 Rear Pad VHA1347
16 Packing Case See Contrast table(2)
Mark No. Description Part No.
Mark No. Symbol and Description DVR-310-S/
KUXU/CA DVR-210-S/ KUXU/CA
16 Packing Case VHG2411 VHG2454

DVR-310-S
10
1234
1234
C
D
F
A
B
E
2.2 EXTERIOR
K
C
N
M
E
G
A
F
N
E
FG
C
H
A
H I J
J
I
K
M
BB
E
H
D
B
G
A
C
52
1
16
49
49
36
49
49
49 38
49
49
18
31
31
48
48
22
22
15
11 10
8
6
37
52
33 49
55
49
7
31
31
49
41
49
49
49
49
49
13
12
49
4
49
49
49
49
49
49
49
49
42
44
43
45
43
49
349
35
49 49
949
53
54
56
23
26
21
27
28 29
39
20
25
30
40 5
19 17
14
34
24
49
49
49
51 50 50
50
32
2
49
50
25 21
47
46
46
CONTACT SIDE
NON-CONTACT
SIDE
Lithium Battery
Acetate Tape
(Taping for No.14 FFC)
Bond Lock process
(Use GYA1011 or GYL1005)
Paste the bond both to the aluminum
tape and the side chassis of the
DRIVE Assy.( part)
The paste point is only this aluminum tape.
Refer to "2.3 FRONT PANEL".
31

DVR-310-S 11
5678
5678
C
D
F
A
B
E
(1)EXTERIOR parts List
(2) CONTRASTTABLE
DVR-310-S/KUXU/CA and DVR-210-S/KUXU/CA are constructed the same except for the following :
Mark No. Description Part No.
1 ATAB ASSY VWV1968
2 TUMJ ASSY VWV1960
3 FRJB ASSY VWV1964
4 MAIN ASSY VWV1952
5 MHLP ASSY VWV1991
> 6POWER SUPPLY UNIT VWR1373
7 DRIVE ASSY R6 VXX2898
8 DC FAN Motor VXM1109
9DVJB ASSY VWV1966
10 Connector Assy PF08EE-D20
11 Connector Assy PF13PP-D20
12 Flexible Cable (32P) VDA1975
13 Flexible Cable (21P) VDA1976
14 Flexible Cable (40P) VDA1977
15 Flexible Cable (15P) VDA1978
16 Housing Assy (4P) VKP2313
17 Housing Assy (8P) VKP2314
18 Housing Assy (2P) VKP2315
19 Leg Assy AEC7113
NSP 20 PCB Holder PNW1706
NSP 21 P. Plate Holder PNY-405
22 Earth Plate VBK1148
23 Radiation Sheet VEB1360
24 Card Spacer VEC1708
NSP 25 Clamp VEC2362
26 Heatsink Cushion VEC2363
27 Gasket A VEC2382
28 Gasket B VEC2393
29 Gasket Sheet VEC2394
30 M Cushion A VEC2398
31 Aluminum tape VEF1056
32 Rear Panel See Contrast table(2)
33 Bonnet Case VXX2897
NSP 34 Base Chassis VNB1039
35 PCB Base VNE2278
NSP 36 Writer Stay R VNE2318
NSP 37 Writer Stay L VNE2319
NSP 38 HDD Stay VNE2320
NSP 39 Bonnet Angle VNE2321
NSP 40 Heatsink VNH1070
41 Cable Holder VNK5330
42 Pioneer Name Plate VAM1136
43 Tray Sheet A VEC2346
44 Tray Sheet B VEC2358
45 Tray Sheet C VEC2395
46 Tray Sheet D VEC2396
47 Tray Panel Assy See Contrast table(2)
48 Screw AMZ30P060FMC
49 Screw BBZ30P060FMC
50 Screw BPZ30P080FZK
51 Screw PPZ30P080FMC
52 Screw BCZ40P060FN
53 Flexible Cable (7P) VDA1979
NSP 54 DV Angle VNE2322
55 Bonnet Label VRW1985
56 Screw VBA108
Mark No. Description Part No.
Mark No. Symbol and Description DVR-310-S/
KUXU/CA DVR-210-S/ KUXU/CA
32 Rear Panel VNA2608 VNA2683
47 Tray Panel Assy VXA2602 VXA2628

DVR-310-S
12
1234
1234
C
D
F
A
B
E
2.3 FRONT PANEL
F
16
15 20
18
11
14 17
8
935
5
25
24 24
24
4
619
2
1
7
10
12
23
13
21
22
CONTACT SIDE
NON-CONTACT
SIDE
11
Daifree
GEM1036

DVR-310-S 13
5678
5678
C
D
F
A
B
E
(1)FRONT PANEL parts List
(2) CONTRASTTABLE
DVR-310-S/KUXU/CA and DVR-210-S/KUXU/CA are constructed the same except for the following :
Mark No. Description Part No.
1 FLKY ASSY VWG2443
2 Flexible Cable (19P) VDA1974
3 Rubber Sheet AEB7054
4 Door Spring VBK1144
5 Rubber Foot VEB1349
6Drive Sheet VEC2345
7 FL Lens See Contrast table(2)
8 Door Lens See Contrast table(2)
9Jack Sheet VEC2381
10 FL Filter (for DVR-310-S) See Contrast table(2)
10 Mirror Filter (for DVR-210-S) See Contrast table(2)
11 Jack Door VNK5309
12 JOG Dial L VNK5324
13 JOG Base VNK5317
14 Hologram Label VRW1962
15 Flont Panel Assy See Contrast table(2)
NSP 16 Front Panel See Contrast table(2)
17 Front Cover R See Contrast table(2)
18 Front Cover L See Contrast table(2)
19 Main Key S VNK5312
20 Power Key S VNK5313
21 Rec Key VNK5314
22 Stop Key S VNK5315
23 Function Cover VNK5318
24 Screw BPZ30P080FZK
25 DV Cover See Contrast table(2)
Mark No. Description Part No.
Mark No. Symbol and Description DVR-310-S/
KUXU/CA DVR-210-S/ KUXU/CA
7 FL Lens VEC2352 VEC2402
8 Door Lens VEC2374 VEC2375
10 FL Filter (for DVR-310-S) VEC2354 Not used
10 Mirror Filter (for DVR-210-S) Not used VEC2347
15 Front Panel Assy VXA2621 VXA2637
NSP 16 Front Panel VNK5363 VNK5428
17 Front Cover R VNK5360 VNK5430
18 Front Cover L VNK5358 VNK5431
25 DV Cover VNK5355 VNK5365

DVR-310-S
14
1234
1234
C
D
F
A
B
E
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
3.1 BLOCK DIAGRAM
3.1.1 OVERALL BLOCK DIAGRAM
SPDL
MOTOR
LD
DRIVE
Pickup
LOADING
MOTOR
STEPPIONG
MOTOR
TV FRONT-END
U3001 VXF1022
ANT
INPUT3
VIDEO
Y/C
L
R
(15P)
CN1301 (15P) CN3002
FRJB
ASSY
TUMJ ASSY(1/3)
TUMJ ASSY
(2/3)
D
C
MAIN ASSY
DRIVE ASSY
M
14 2
4
6
6
12
10
VOUT
19
Y
C
UVL
MPX
IN L
OUT
LIN2
LIN1
LIN3
L
V/Y
C
AOUT
16
RF IN
RF
OUT
V/Y
UVV
1V
3V
3Y
1Y
2Y
3C
1C
2C
2V
C
Y/Comp
Selector
ATT
IC3301
LA73030
IC2801
LC75342M
IC3105 CXA2064M
13
5
11
14
12
32
34
24
36
1
3
15
17
19
5
7
9
LPF
1 Chip
Sysytem Codec
Audio MPX
Decoder
Audio Selector with Electirc ATT
723
JA1302
JA1301
VIN2
YIN2
CIN2
10
LIN2
INPUT1
INPUT3
VIDEO
Y/C
L
R
PICKUP
ASSY
Y
C
Y
C
JA2832
VIDEO
Y/C
L
R
VIN1
LIN1
LIN3
VIN3
YIN1
YIN3
M
(40P)
[ATAPI]
DVD-VR DVD-Video
DVD-VR
DVD-Video
CD Digital
CD Digital
CN4401
1
CN201
(2P)
CN2009 (2P)
CN101
(45P)
8
CIN1
CIN3
CN501
CN502
(12P)
33
39
A
B
C
D
S4
S3
S2
S1
5
4
3
2
1/3
B
2/3
B
PB DVD/CD
IC1001
M65672WG
IC201
UPD63620
IC501
M63028FP
IC101
UPC3320GC
RF IC
IC301
M30700FJLGP
IC202
SDRAM
16Mbit
7-10
13-16
(40P)
CN401
(21P) (21P)
CN2008
(1/2)
DSP
48
37
40
36
38
34
35
LPF
WIDEBAND SPECTRAL
IC1401
IC1421 ATA SDRAM
256Mbit×2
CPU SDRAM
128Mbit
IC1102 IC1101
Flash
64Mbit
IC1103
SRAM
4Mbit
2
8 8
Writer
CPU
26
6CH
Driver
2
IC203
DS90LV027ATM
LVDS
Driver
26
28
LPF
201
76 CN3001
(1/2)

DVR-310-S 15
5678
5678
C
D
F
A
B
E
FFLKY
ASSY
H
E
MHLP ASSY
L
Control
Data
IC1301
IC3201
PCM1742KE
IC1001 PT6315
V1001
IC3101
AK5381VT
IC3301
AD1895AYRS
IC5101
UPD72852AGB-8EU
IEEE1394
Physical IC
IC5202
UPD72893AGD-LML
IEEE1394
Link IC
Audio
A/D 2
SEL.L
VOUT
(19P)
CN2005
(19P)
CN1001
DVJB ASSY
YOUT
COUT
LOUT
(32P)
CN3001(1/2)
24 SEL.V/Y
26 SEL.C
C IN
V/Y IN
CN1302
(7P)
CN5102
(7P)
JA1303
(32P)
(30P) (30P)
(21P) (21P)
CN2001
(2/2) (32P)
CN3001
(2/2)
CN2008(2/2)
38 39 37 36
1,3 2 6 7
XTPA
TPA TPB
XTPB
XTPB TPB XTPA TPA
1,3 2 6 7
1 2 3 4
Audio
D/A Conv.
PLD
ALTERA
FL Driver
FL Key
SW
IC3501
LA73054
Sampling Rate
Converter
7
C
YY
Cr
Cb
C OUT
Y OUT
Y OUT
Cb OUT
Cr OUT
6
4
8
10
12
CN3001(2/2)
CN2
CN4702
6
4
8
10
12
L OUT
16 16
SPDIF
20 20
3
21
IC3251-1/2
UPC4570G2
Cb
Cb
Cr
Cr
Y
Y
Y
C
V
Tuner U-com
JA3081
OPTICAL
AC-3/PCM
DIGITAL
AUDIO
OUT
LINE
OUT 1
VIDEO
JA3551
Y
C
Y
C
VIDEO
L
R
L
R
Y
JA3582
: Recording system signal route
• R ch is same as L ch.
: Playback system signal route
Cb
Cr
COMPONENT VIDEO OUT
DV TERMINAL
LINE
OUT 2
(32P)
CN2001
(1/2)
24
28
26
48KHz 20Bit
TUJB ASSY(3/3)
3/3
B
ENC
SDRAM
128Mbit
IC1201
IC1
PDY081A
DEC
SDRAM
128Mbit
IC5204
DV SDRAM
16Mbit
14
16
11
8
6
23
25
21
28
31
33
I C2001
PD5942A8
Tuner
U-com
I C2251
BR24L32F-W
EEPROM
I C2271
RS5C372A
Real
Time
Clock
28
9
10
12
1-3
F5 D2
AE24
AG25
AD21
AF23
AG24
T26
V27
• MPEG2 PS Encode
• AC-3/Linear PCM
Audio Encode
• 2ch ATA/ATAPI Interface
• MPEG2 PS Decode
• AC-3/MPEG1/Linear
PCM Audio Decode
Master Clock Free Run

DVR-310-S
16
1234
1234
C
D
F
A
B
E
3.1.2 TUJB ASSY BLOCK DIAGRAM
U3001
V/U Tuner FrontEnd
VXF1022-
SCL
SDA AFT
AGC
<u-com>
TUON<u-com>
+32V
Reg. +6V
SW.
+5V
Ripple Filter
Audio
<IC3105>
IC3301
LA73030
Video
Selector
EVOLCLK
EVOLDATA
EVOLCE
LC75342M
IC2801
Audio Selector
with
Electric A.T.T
Audio Input Circuit
Output Circuit
Video Input Circuit
SDET2 <u-com>
SDET3 <u-com>
SDET1 <u-com>
LAMUTE
RAMUTE
<MAIN>
(Discrete)
R
L
Comp
C
Y
V
C
Y
Cb
Cr
Y
Muting
OUT2
OUT1
JA1301
JA1302
IN3
(Rear)
IN2
(Front)
IN1
(Rear)
JA2832
Y
V
V
C
Y
C
V
Y
C
S
S
S
L
R
L
R
L
R
JA3551
IC3501
LA73054
Video Driver
with LPF
<u-com>
SELV1
SELV2
SELV3
YVSEL
SWSTBY <u-com>
R
L
V/Y
C
SYNC
LPF
LPF
Sync-Sepa
LPF
LPF
LPF
C
V/Y
24
26
28
16
14
5
11
25
23
21
28
31
33
6
8
26
TUMJ ASSY (VWV1960)
B
FRJB ASSY (VWV1964)
C
CN1301
CN3002
8
8
610
6
10
2
14
12
4
JA3582
JA3081
Component
OUT
Optical
OUT
12 4
Decoder
CXA2064M
Spectral
IC3105
MPX Audio
STID <u-com>
SYNCAFT<u-com>
SYNCMAIN
SYNC<u-com>
Audio <U3001:U/V Tuner>
Q3344
Q3342
Q3362
Comparator
Q3301
Q3101
SUID
MUTE
S1
Wideband
ATT
15kHz LPF
525P

DVR-310-S 17
5678
5678
C
D
F
A
B
E
+6V
SW
FL Driver
PT6315
Front Keys
IR Detector
FAN
Driver FAN
EEPROM Battery
Ceramic
Resonator
EVOLCLK
EVOLDATA
EVOLCE
SPDIF
PCMOUT
PCMOUT
LAMUTE
525P
RAMUTE
FLKY
ASSY
(VWG2432)
FLPON
SELIR
BUP
BUP
JOGA, JOGB
KEY1, KEY2, KEY3
FLCLK, FLDATA, FLSTB
IC2001
CN1001
CN2005
Tuner/FL
Control U-com
PD5942A8
XINTRA
SCL
XIN, XOUT
XRESETIN
SDA
Other Devices
SCLEEP
SDAEEP
BR24L32F-W
IC2271
Real-Time
Clock
RS5C372A
U-com I/F
Y
24
23
22
21
20
19
18
30
29
28
27
26
25
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
C
Y/G
Cb/B
Cr/R
R
L
SYNCMAIN
SELC
CN2008
< from/to MAIN >
CN2009
< from DRIVE >
SELV/Y
SELR
SELL
20
21
3
5
4
8
2
F
SYNCAFT
<Q3362>
IC1001
Q1001
Q2640
IC2251 BT2272
X2001
Reset IC
PST3245
IC2521
IC1002
S1001-S1008
S1003
SR In
JOG
JA2201
FL Display
V1001
SYNC
<IC3301>
MUTE
<IC3105>
TUON
ASCK
SST to M
SSM to TSYS
HST to M
HSM to TSYS
XRESET
<Q3006,etc>
AGC
<U3001>
STID,SAPID
<IC3105>
<IC2801>
SELV1
SELV2
SELV3
SWSTBY
<IC3301>
SDET1
SDET2
SDET3
<JA1301,
JA2832>
< to/from MAIN >
CN3001

DVR-310-S
18
1234
1234
C
D
F
A
B
E
3.1.3 MAIN ASSY BLOCK DIAGRAM
To Writer
IC1401
ATA SDRAM
CN4401
ATA BUS
IC1102
FLASH
IC1103
IC1301
ENC
SDRAM
MT48LC4M32B2TG-6
K4S561632D-TC75
IC1201
DEC
SDRAM
W986416DH-6
VYW2116 CY62148VLL-70ZI
ARCLK0
DCLK0
ECLK0
IC3201
PCM1742KE
DAC
IC3101
A/D
AK5381VT
ADCCLKO
IC3403
AUDIO LR OUT
AUDIO LR IN
IC3251
CN2001CN3001
CN1901
SERIAL
MAIN ASSY
(VWV1952)
D
IC1001
M65672WG
1 Chip System Codec
• MPEG2 PS Encode
• AC-3/Linear PCM Audio Encode
• 2ch ATA/ATAPI Interface
• MPEG2 PS Decode
• AC-3/MPEG1/Linear PCM Audio Decode
Backup
SRAM
IC3001
Q2402,Q2403
Q2101-Q2105
IC2301,IC2331,Q2203
Q2222
VIDEO Y,C,Yp,Cb,Cr OUT
VIDEO Y,C IN
TO TUNER u-COM

DVR-310-S 19
5678
5678
C
D
F
A
B
E
HOST BUS
DV
IC1101
CPU SDRAM
IC5202
UPD72893AGD-LML UPD72852AGB-8EU
LINK/DV CODEC IC5101
Phy
CN5102
CN2
CN4702
IC5204
DV SDRAM
K4S281632E-TC75 K4S161622D
MCLK
VCLKI
SCLK
HCLK0
IC3301
SRC
SRC**O
SRC**I
IC4205
TC7WHU04FU
AD1895AYRS
Play Mster clock
IC4206
AMCLK2
IC3402
PLL IC
27M
24
VMCLKI
AMCLK1
33M
36M
33/36M
X4102
VSS1195
VCXO
Input Mster
clock
ADMCLKI
27M
IC4101
DVPLLCK(ADMCLKI)
DVVPWM
IC4009
DVVCLKO
SM8707KV
IC1
PDY081A
ALTERA
MHLP ASSY
(VWV1991)
E
Master Clock
Free Run

DVR-310-S
20
1234
1234
C
D
F
A
B
E
3.1.4 POWER BLOCK DIAGRAM
LIVE
FLDC (–)
AC IN
F1
4A/125V
NEUTRAL
1
2
3
5
4
7
9
11
13
3
5
4
7
9
11
13
FLDC (+)
FL–28V
EV+37V V+37E
EV+18V
EV+6V
SW+13
SW+12V
1
4
1
SW+5V
SW+12V
1
4SW+5V
DRIVE ASSY
R6 DC FAN
MOTOR
CN1 CN204
(4P)
CN203
(4P)
CN201
(13P)
SW+4V
V+13FAN
V+4SW
V+4SW
V+2_4SW
V+2_4SW
CN2001
(8P)
CN2006
(2P)
CN2003
(8P)
CN4001
(8P)
2
3
5
7
2 4 6 8
2 4 6 8
2
3
5
7
V+6SW
V+6SW
V+13SW
V+13SW
Q2640
Q2532Q2531
Q2621
SW+4V
SW+2.4V
SW+6V
CN202
(8P)
CN2
(30P)
16
17
18
19
16
17
18
19
CN4702
(30P)
POWER SUPPLY UNIT
G
FLKY ASSY
F
TUMJ ASSY
B
MAIN ASSY
DMHLP ASSY
E
CN2004
(13P)
V–28V
V+13SW
V+6SW
V+2_4SW
V+4SW
VEE 1
2
3
14
18
19
18
17
6
2
V+5VO
V+5VI
CN3001
(32P)
CN2001
(32P)
1
1
V+5VO
CN2008
(21P)
CN3001
(21P)
1
1
V+5VI
FLDC –
FLDC +
V+13SW (NC)
V+5E
V+5E
CN1001
(19P) CN2005 (19P)
V+18E V+6E V+13SW
IC2551
5V REG.
V+6E
V+5M
V+5E
IC2541
3.3V REG.
V1001
FL TUBE
IC1001
FL Driver
V+6E
V+6SW
V+6E
V+3_3E
V+5VO
V+13V
V+4V
V+4V
V+6V
V+1R2V
V+5VO
V+12A
V+5VI
V+5RP
IC2581
9V REG.
V+13SW
V+9
1
1
6
3
1 3
30
IC4001
12V REG.
5 8
V+5A IC4004
5V REG.
5 1
V+6V
V+5D IC4006
5V REG.
5 1
V+3D
IC4002
3.3V REG.
1 3
V+3D
V+2R5
IC5002
2.5V REG.
7 1
V+1R2V
V+PRA
V+3D
V+3D
IC4008
1.2V REG.
1 3
V+4V
V+3V
IC4007
3.3V REG.
5 4
V+3D
V+3D
V+3D
V+3D
