AVIC-S1
User Manual
格式化: 縮排: 左 8 字元
刪除:
刪除:

Trademarks
The Bluetooth word mark and logo are owned by the Bluetooth SIG, Inc. All
other brand and product names are trademarks or registered trademarks of their
respective companies.
Note
The information in this document is subject to change without notice.

i
Table of Contents
Notice....................................................................................................iii
1Getting Started ...............................................................................1
1.1 Understanding Hardware Features.................................................. 1
Front Components ........................................................................... 1
Back Components............................................................................ 2
Right-Side Components................................................................... 3
Top Components ............................................................................. 3
Bottom Components ........................................................................ 4
1.2 Performing the Initial Startup............................................................ 5
1.3 Connecting to AC Power and Charging the Battery ......................... 6
1.4 Turning Your Device On and Off...................................................... 7
1.5 Main Menu....................................................................................... 7
1.6 Navigating on the Screen.................................................................8
1.7 Using a SD Card.............................................................................. 8
2Bluetooth HF Phone.......................................................................9
2.1 About Bluetooth HF Phone .............................................................. 9
2.2 Connecting a Bluetooth Mobile Phone.............................................9
2.3 Starting Bluetooth Mobile Phone.................................................... 10
2.4 Placing a Call................................................................................. 11
Keypad........................................................................................... 11
Contacts......................................................................................... 12
Call History .................................................................................... 13
Redial............................................................................................. 14
2.5 Operations During a Call................................................................ 14
2.6 Receiving a Call............................................................................. 15
2.7 Connecting to a Paired Phone....................................................... 16
2.8 Initiating Pair Mode ........................................................................ 16
2.9 Closing Bluetooth HF Phone.......................................................... 17
2.10 Ending the Bluetooth Connection................................................... 17

ii
3Troubleshooting and Maintenance.............................................18
3.1 Resetting Your System .................................................................. 18
3.2 Troubleshooting............................................................................. 19
Power Problems............................................................................. 19
Screen Problems ........................................................................... 19
Connection Problems..................................................................... 20
GPS Problems............................................................................... 20
3.3 Maintaining Your Device................................................................ 21

iii
Notice
zRead “Important Information for the User” (a separate manual) before using
this product.
zThis manual provides hardware and Bluetooth® information. For
information on the GPS navigation software, see the “Operation Manual.”

1
1 Getting Started
1.1 Understanding Hardware Features
Front Components
Ref Component Description
nBluetooth
Indicator Flashes in blue to indicate that Bluetooth is on. The
Bluetooth is always on when your device is turned on.
oPower
Indicator Glows bright amber to indicate that the battery is charging, and turns green when the battery is fully charged.
pMap Button Switches to the map screen.
刪除: radio
刪除: radio

2
In a list or in Phone Menu:
Scrolls through the list or menu buttons by rotating the
wheel. Select the highlighted item by pressing in the wheel.
qScroll Wheel
In other screens:
Adjusts the volume by rotating the wheel.
rMenu Button Opens the Main Menu.
sTouch Screen Displays the output of your device. Touch the screen with
your fingertip to select menu commands or enter
information.
Back Components
Ref Component Description
nON/OFF Switch The main power/battery cutoff switch.
oSpeaker For voice prompts, system operation tone, and hands free
dial voice.
pExternal GPS
Antenna This connector (under rubber dust cover) allows use of an external GPS antenna with magnetic mount (not available
through Pioneer), which may be positioned on top of the car
for better signal reception in areas with poor reception.
Contact Pioneer Support for recommendations on available
3rd party products.
刪除: optional

3
Right-Side Components
Ref Component Description
nSD Slot Accepts an SD (Secure Digital) card for future map and
software upgrades.
oReset Button Restarts your device (soft reset).
Top Components
Ref Component Description
nPower Button Turns the device on and off by pressing for at least 2
seconds.

4
Bottom Components
Ref Component Description
nMini-USB
Connector Connects to the AC adapter or USB cable.
oCar Kit
Connector Connects to the TMC Kit (European model only).
pMicrophone For Bluetooth hands-free calling.

5
1.2 Performing the Initial Startup
1. Slide the ON/OFF switch to the ON position.
2. Your device turns on and displays a warning screen. Tap OK after you have
read the entire warning, and if you agree.
3. The Main Menu appears.
4. Before using your device for the fist time, connect the AC adapter as
described in the next section to fully charge the device.

6
1.3 Connecting to AC Power and Charging the
Battery
When charging the battery for the very first time, you should charge it for at
least 8 hours.
1. Connect the AC adapter cable to the mini-USB connector on your device.
2. Connect one end of the power cable to the AC adapter and the other end to a
wall outlet.
The charge indicator glows amber when charging is in progress. Do not
disconnect your device from AC power until the battery is fully charged. The
charge indicator will turn green. This will take a couple of hours.
CAUTION: For optimal performance of the lithium battery, take note of the following:
zDo not charge the battery where the temperature is high (e.g. in direct sunlight).
zThere is no need to fully discharge the battery before charging. You can charge the
battery before it is discharged.
zIf you will not use the product for along period of time, be sure to fully chargethe
battery at least once every two weeks. Over discharge of the battery can affect the
charging performance.

7
1.4 Turning Your Device On and Off
Press and hold the power button for at least 2 seconds to turn on and off your
device.
When you press the power button to turn off the unit, your device actually enters
into a suspend state and the system stops operating. Once you turn on the system
again, it resumes from the same guidance or menu screen you left off at.
1.5 Main Menu
The Main Menu is your starting place for various tasks. Tap a button to start a
task or open another menu. (For information on the GPS navigation software,
see the document supplied with the software. For information on the Phone
Menu, see the next chapter.)
You can access the Main Menu at any time by pressing the MENU button on
your device.
刪除: at .

8
1.6 Navigating on the Screen
To navigate and select objects on the screen, simply use your finger and touch
the screen. The following are possible via touch screen:
zTap
Touch the screen once with your finger to
open items or select options.
zDrag
Hold your finger on the screen and drag
up/down/left/right or across the screen.
zTap and hold
Tap and hold your finger until an action is
complete, or a result or menu is shown.
1.7 Using a SD Card
NOTE: Make sure that no foreign objects enter the slot.
Your device has a SD slot where you can insert an Secure Digital storage card
for future software and application upgrades sold by Pioneer. To use a SD card,
insert it into the slot, with the connector pointing to the slot and its label facing
the front of the device.
To remove a card, first make sure that no application is accessing the card, and
then slightly push the top edge of the card to release it and then pull it out of the
slot.
刪除: optional

9
2 Bluetooth HF Phone
2.1 About Bluetooth HF Phone
Your device can serve as a hands-free (HF) device for a Bluetooth mobile
phone. After establishing the Bluetooth connection, you can tap your device to
place and receive phone calls instead of picking up the mobile phone, and can
use the built-in speakers and microphone for your conversation.
2.2 Connecting a Bluetooth Mobile Phone
To connect with a Bluetooth mobile phone for the first time:
1. Initiate the Bluetooth searching process on your mobile phone. You should
see “Pioneer AVIC-S1” in the device list after searching is completed.
2. Select “Pioneer AVIC-S1” to create the connection. Use the 0000 default
passkey to connect.
3. Your AVIC-S1 can now serve as a hands-free device for your mobile
phone.
刪除: device

10
2.3 Starting Bluetooth Mobile Phone
1. Press and hold the MENU button on your device for at least 2 seconds.
- or -
Tap Settings on the Main Menu. Tap twice and then tap Phone
Menu.
2. The Bluetooth HF Phone main screen appears. The status bar at the bottom
shows the name of the mobile phone connected.

11
2.4 Placing a Call
After pairing with your mobile phone, you can place a call using any of the four
buttons ( Keypad, Contact, Call History, and
Redial) on the Bluetooth HF Phone main screen.
Keypad
By tapping the Keypad button on the Bluetooth HF Phone main
screen, you can enter the telephone number with the onscreen keypad. After
entering the telephone number, tap to place the call.
NOTE:
zTo delete the last digit entered, tap the Backspace button.
zThe other two buttons allow you to switch to Contacts and Call
History screens.
Backspace
Back
Contacts
Call History
Call

12
Contacts
You can exchange business cards between Bluetooth devices via OPP (Object
Push Profile). As long as you have sent such information to your device, the
information is available in Bluetooth HP Phone.
To call a contact, tap the Contact button on the Bluetooth HF Phone
main screen.
Tap the desired contact and the phone number list appears. Tap the phone
number to call and tap to call the selected phone number.
Index
Back
Call the selected
number.

13
Call History
NOTE: Bluetooth HF Phonecannot access the call history stored in a connected mobile
phone.
Tap the Call History button on the Bluetooth HF Phone main screen to
display the recent incoming, outgoing, or missed calls together with information
such as date, time, and duration of each call.
Tap the respective button ( Incoming, Outgoing, or
Missed) to view the last 20 calls of the selected type.
With an item selected, you can tap the button to dial the number
or the button to delete the item.
To clear all items in the current list, tap the button.
Outgoing Missed
Incoming
Call
Delete Delete All

14
Redial
Tap the Redial button on the Bluetooth HF Phone main screen to dial
the last number you called or received.
2.5 Operations During a Call
During a call, four functions are available:
zIf you need to input other numbers, such as an extension number, tap
to open the keypad and tap the digits. The keypad will close when you tap
the button again or when there has been no input for 5 seconds.
Switch to
mobile phone. Delete All
Cancel
Mute
End
Mute
