Piotronics PY-RS0012 User manual

Marine Radar with Open-Array or Radome Antenna Radiator.
PY-R1012/R1006
Features
Scope of Supply
Display unit
Antenna Radiator
Display Bracket Set
PY-RD1000
PY-R0006 or R0012
NIL
1
1
1
Display Screen Protector
Quick Manual
Standard Spare Parts Set NIL
NIL
NIL
1
1
1 sets
Descriptions Part No Quantity Descriptions Part No Quantity
PY-RS0012 (Open-Array)
PY-RS0006 (Radome)
PY-RD1000 (Display)
• Good quality and reliability in a compact, functional and affordable radar radiator.
• Durable brushless antenna motor.
• Target Tracking function (TT) up to 40 targets.
• AIS target and radar target overlay. (external AIS input is needed).
• Digital radar target technology.
• On-screen alphanumeric readout of all operational information.
• Standard features include: EBL(Electronic Bearing Line) , VRM(Variable Range Marker),
Guard Alarm, Display Off Center, and Echo Trail.
• Watchman feature periodically transmits the radar to check for radar targets which
maybe entering the alarm zone.
• Ship's position in latitude and longitude and range and bearing to waypoint and
ship's speed/heading/course can be shown in the bottom of the screen.
(Requires a navigation aid which can output such data in IEC 61162 format.)
• Zoom feature provided.

Display Unit
Antenna Radiator
Other Information
Dimension (mm)
Power Supply
Radio Frequency Transceiver
1. PY-RD1000 Display 10-inch LED backlight,
32-bit TFT Color LCD Display
2. Range scale(nm) 0.125, 0.25, 0.5, 0.75, 1, 1.5,2, 3, 4, 6, 8,
12, 16, 24, 36, 48**, 64**, 72**
(** for PY-R1012 only)
No. of Rings：0.625, 0.125, 0.125,
0.25, 0.25, 0.5, 0.5, 1, 1, 2, 2, 3, 4, 6, 12
3. Echo Trail Interval: 15s, 30s, 1min, 3min,
6min, 15min, 30min or continuous
4. Interface (NEMA 0183 format) --: any talker (menu selection)
input: APB, BWC, BWR, DBK, DBS, DBT,
DPT, GGA, GLC, GLL, GTD, HGD,HDW,
HDT, MDA, MTW, RMA, RMB, RMC,
TVG, VHW, XTE
5. AIS Display Acquisition: AIS vessels or ATON
Tracking: Auto
Display: Vessel Name, MMSI, call sign,
Range/Bearing, L/L, Speed/ Course,
ROT, CPA/TCPA (AIS data input
required)
6. Target Tracking Function Acquisition: 20 manual or 10 auto + 10
manual
Tracking: Auto
Display: Speed, Course, Range/
Bearing and CPA/TCPA
7. Waterproofing IPX5
1. TYPE: PY-RS0006: 55cm hybrid array
PY-RS0012: 120cm hybrid array
PY-RS0018: 180cm hybrid array***
(***available soon)
2. Length and a. PY-R1006: Radome 60cm
Rotation speed (PY-RS006)24RPM
b. PY-R1012: Open array 120cm
(PY-RS012) 24RPM
3. Wind load Relative wind 100 knots (51.5m/s)
4. Beam width PY-RS0006: Horizontal: 4˚ Vertical: 25˚
PY-RS0012: Horizontal: 1.9˚ Vertical: 22˚
5. Side lobe Within±20°off main lobe; less
than-18dB
Outside±20°off main lobe; less
than-23dB
1. Transmitting tube MSF1421B or MAF1421B
2. Frequency 9410MHz±30MHz (X-band)
3. Peak output power PY-R1006: 4kW nominal
PY-R1012: 6kW nominal
4. I.F: 60MHz
Bandwidth: Tx pulse length 25MHz (0.08uS/ 0.3uS)
Tx pulse length 3MHz (0.8uS)
5. Mixer and Local Oscillator Microware Integrated Circuit (MIC)
6. Noise Figure 10dB nominal
7. Pulse length & pulse repetition rate:
0.08uS/2100Hz(0.125, 0.25, 0.5, 0.75, 1, 1.5*nm)
0.3uS/1200Hz(1.5*, 2, 3nm)
0.8uS/600Hz(3*, 4, ,6, 8, 12, 16, 24, 36, 48**, 64**nm)
*Pulse length & PRR for 1.5 and 3nm range can be selected in menu
**for PY-R1012 only
1. Temperature -25℃to +70℃(Antenna unit)
-10℃to +50℃(Display unit)
2. Humidity Relative humidity 93% or less at +40℃
5 VDC to 40 VDC, 60W (30W in economy mode)
303.5
252.0
282.6
101.5
128.0
148.0
