Pipishell PITSC1 User manual

SAVE THESE INSTRUCTIONS
WARNING: Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
Service Cart V1.0
PITSC1
[email protected]

TECHNICAL DATA
TABLE OF CONTENTS
Technical Data.....................................................................................................................1
General Safety Rules..........................................................................................................2
Expanded View....................................................................................................................3
Part List................................................................................................................................3
Assembly..........................................................................................................................4-5
Warranty...............................................................................................................................5
Property
Model:
Loading Capacity:
Shelves(qty):
Product Dimension:
Tray Size:
Caster Size:
Net Weight:
Color:
Caster Material:
Cart Material:
Specification
PITSC1
500Ibs
2 rigid casters and 2 swivel casters
L41.3"x W16.7"x H34.6"(Handle Height)
L30.7"x W16.3"x H2.6"
5"x 1-1/4"
30.8Lbs
Grey
TPR Thermo-Plastic-Rubber material
PP
1

GENERAL SAFETY RULES
Safety is a combination of common sense, staying alert and knowing how your items works.
SAVE THESE SAFETY INSTRUCTIONS.
1.READ and become familiar with this entire instruction manual. LEARN the tool’s applications,
limitations, and possible hazards.
2.KEEP WORK AERA CLEAN. Cluttered areas invite injuries and accidents.
3.OBSERVE work area conditions. Keep work area well lit.
4.ALWAYS keep your work area clean, uncluttered, and well lit. DO NOT work on floor surfaces
that are slippery with sawdust or wax.
5.STORE IDLE EQUIPMENT. When not in use, store the service cart in a safe and clean location.
Always secure products and keep out of reach of children.
6.USE THE RIGHT PRODUCT FOR THE JOB. There are certain applications for which this item
was designed. Do not modify it and do not use it for a purpose for which it was not intended.
7.CHECK FOR DAMAGED PARTS. Before using any product, any part that appears damaged
should be carefully checked to determine that it will operate properly and perform its intended
function. Check for any broken or damaged parts and any other conditions that may affect its
operation. Replace or repair damaged or worn parts immediately.
8.WHEN SERVICING use only identical replacement parts and accessories. Using any other parts
will void the warranty.
9.DO NOT operate the tool if you are under the influence of drugs, alcohol, or medication that
may affect your ability to properly use the tool.
10.USE EYE PROTECTION. Always wear ANSI approved impact safety goggles.
11.DO NOT EXCEED THE PRODUCTS MAXIMUM LOAD CAPACITY. Always keep weight evenly
distributed.
12.ONLY USE ON A FLAT SURFACE capable of supporting the item with its maximum capacity
load. It is easy to lose control if attempting to pull a load on a sloping or uneven surface.
13.DO NOT ALLOW CHILDREN TO PLAY ON, stand upon or climb on this item. It is not intended
for carrying people or animals.
14.ALWAYS CHECK HARDWARE and assembled parts after assembling. All connections should be
tight.
15.Industrial or commercial application must follow OSHA requirements.
WARNING: To avoid mistakes and serious injury, do not use
your item until the following steps have been read and understood.
These safety instructions cannot address every possible scenario
you may encounter, so please use common sense and caution
when using the item.
!
2

EXPANDED VIEW
PARTS LIST
Part Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Part Description
HANDLE
SCREW
SCREW
PLATFORM
SCREW
BEAM
BASE PLATE
CARRIAGE BOLT
WASHER
NUT
BRACKET OF SWIVEL CASTER
NUT
CASTER
AXLE
BRACKET OF FIXED CASTER
Quantity
1
2
4
1
12
4
1
16
16
16
2
4
4
4
2
3

ASSEMBLY
Step 1
Locate the second base plate(7) and turn it
upside down. Set the second base plate(7)
onto the beams(6). See Figure A.
Step 2
Turn the cart upside down. Attach two casters(13) with the swivel caster brackets(11) using a
nut(12) and axle(14), if necessary. Thread a carriage bolt(8) through the base plate(7) and into
the casters(13). Attach one washer and one nut for each hole. See Figure B.
Step 4
Locate the two beams(6). Place one on the platform(4) corner nearest the handle(1), and place
one on the diagonal corner located on the outside of the platform(4). Make certain that the end
with the screw holes is facing upward. Using a rubber mallet(not provided), tap the beams(6)
down into the platform(4). Repeat step 4 for the other side. See Figure C.
Note: Position the beams so that the flange in each matches the space in the platform.
Inserts screws down through each beam and into the platform.
Step 3
Attach another two casters(13) to the
fixed caster brackets(15) using a
nut(12) and axle(14), if necessary.
Thread a carriage bolt(8) through the
base plate(7) and into the casters(13).
Attach one washer(9) and one nut(10)
for each hole. See Figure B.
4

ASSEMBLY
Before/After Each Use
WARRANTY
Step 5
Place the two swivel caster brackets on the
same side of the platform(4) as the handle(1).
Place the two fixed caster brackets on the
other side of the platform. See Figure C.
Step 6
Place one platform(4) upside down on the
work surface. Locate the handle(1). Attach
the handle with platform using screw(2&3).
Make certain that both trays are facing the
same way. See Figure D.
Step 7
Turn the cart upright. Make certain that all
hardware is tight. Make certain that the fixed
casters and swivel casters roll properly.
Inspect the unit before/after every use; do not use if parts are loose or damaged.
WARNING!
Thank you for choosing our product! We strive to provide the best quality and services for our
customers. Would you kindly share your experience on Amazon if you are satisfied? Should you
have any issues, please don't hesitate to contact us.
Telephone：[phone] Mon-Fri 10am - 6pm (PST) (USA) (CAN)
Email：[email protected] (US/CA/DE/UK/FR/IT/ES/JP/AU)
5
